Search Results (21)

Accurate identification of concealed coal seam structures, such as folds or faults, is crucial for safe and effective production in the coal mining industry. In-seam seismic exploration serves as a promising technique for advanced detection of coal seam structures, but traditional numerical simulation methods easily produce errors when coping with irregular interfaces. This study uses the curvilinear grid finite-difference method (FDM) for modeling the 3D channel wave propagation. The body-fitted grids are utilized to conform to undulating interfaces, while the DRP/opt MacCormack difference scheme and the fourth-order Runge–Kutta algorithm are applied for the spatial and temporal derivative approximation, in that order. The forward and backward extrapolation for in-seam waves are implemented in the curvilinear coordinates. The roofs and floors of coal seams and special structures are imaged by reverse-time migration (RTM) using an excitation amplitude imaging condition. Numerical results show that compared with conventional methods, the curvilinear grid method effectively reduces spurious scattering caused by the staircase approximation, improves the modeling accuracy of channel waves, and enhances the continuity and interpretability of imaged coal-seam interfaces and structural boundaries. The proposed method has the potential to enhance the accuracy of channel wave exploration under complex geological conditions, supporting advanced hazard detection in coal mines. Full article

Applying deep neural networks (DNNs) to broadband seismic wave impedance inversion is challenging, especially in generalizing from synthetic to field data, which limits the exploitation of their nonlinear mapping capabilities. While many research studies are about advanced and enhanced architectures of DNNs, this article explores how variations in input data affect DNNs and consequently enhance their generalizability and inversion performance. This study introduces a novel data pre-processing strategy based on histogram equalization and an iterative testing strategy. By employing a U-Net architecture within a fully convolutional neural network (FCN) exclusively trained on synthetic and monochrome data, including post-stack profile, and 1D linear background impedance profiles, we successfully achieve broadband impedance inversion for both new synthetic data and marine seismic data by integrating imaging profiles with background impedance profiles. Notably, the proposed method is applied to reverse time migration (RTM) data from the Ceduna sub-basin, located in offshore southern Australia, significantly expanding the wavenumber bandwidth of the available data. This demonstrates its generalizability and improved inversion performance. Our findings offer new insights into the challenges of seismic data fusion and promote the utilization of deep neural networks for practical seismic inversion and outcomes improvement. Full article

Angle domain common image gathers (ADCIGs) play a crucial role in seismic exploration, offering prestack underground illumination information that aids in validating migration velocity and conducting prestack amplitude versus angle (AVA) analysis for reservoir characterization. This paper introduces an innovative approach for compensating amplitude errors caused by irregular seismic acquisition geometries in ADCIGs. By incorporating an angle domain illumination compensation factor, the proposed method effectively modifies these errors, preserving the amplitude of seismic reflectivity in the prestack angle domain. The effectiveness of the proposed approach is validated through comprehensive tests conducted on synthetic and field data examples. The results demonstrate the capability of the method to enhance the quality of ADCIGs derived from 3D reverse time migration (RTM), yielding accurate and reliable amplitude preservation. While the illumination compensation factor assumes a vertically linear velocity model, the method holds promise for extension to more complex media and diverse migration techniques. This suggests its applicability and adaptability beyond the specific assumptions considered in this study. In conclusion, this paper presents an innovative angle domain illumination compensation factor that significantly improves the quality of ADCIGs by addressing amplitude errors arising from irregular seismic acquisition geometries. The experimental validation using synthetic and field data confirms the effectiveness of the proposed method within the context of 3D RTM. Furthermore, the technique holds potential for broader application in more complex subsurface scenarios and various migration methodologies. Full article

Precise surveys are indispensable in coastal engineering projects. The extensive presence of sand in the coastal area leads to significant attenuation of seismic waves within unsaturated loose sediments. As a result, it becomes challenging for seismic waves to penetrate the weathered zone and reach the desired depth with significant amount of energy. In this study, the application of three-dimensional (3D) cross-well elastic reverse time migration (RTM) imaging based on multi-wave and multi-component techniques in coastal engineering exploration is explored. Accurate decomposition of vector compressional (P) and shear (S) waves is achieved through two wavefield decoupling algorithms without any amplitude and phase distortion. Additionally, compressional wave pressure components are obtained, which facilitates subsequent independent imaging. This study discusses and analyzes the imaging results of four imaging strategies under cross-correlation imaging conditions in RTM imaging. The analysis leads to the conclusion that scalarizing vector wavefields imaging yields superior imaging of P- and S-waves. Furthermore, the imaging results obtained through this approach are of great physical significance. In order to validate the efficacy of this method in 3D geological structure imaging in coastal areas, RTM imaging experiments were performed on two representative models. The results indicate that the proposed 3D elastic wave imaging method effectively generates accurate 3D cross-well imaging of P- and S-waves. This method utilizes the multi-wave and multi-component elastic wave RTM imaging technique to effectively leverage the Earth’s elastic medium without increasing costs. It provides valuable information about the distribution of subsurface rock layers, interfaces, and other structures in coastal engineering projects. Importantly, this can be achieved without resorting to extensive excavation or drilling operations. This method addresses the limitations of current cross-well imaging techniques, thereby providing abundant and accurate geological and geophysical information for the analysis and interpretation of 3D geological structures in coastal engineering projects. It has important theoretical and practical significance in real-world production, as well as for the study of geological structures in coastal engineering. Full article

The two-dimensional (2D) cross-hole seismic computed tomography (CT) imaging acquisition method has the potential to characterize the target zone optimally compared to surface seismic surveys. It has wide applications in oil and gas exploration, engineering geology, etc. Limited to 2D hole velocity profiling, this method cannot acquire three-dimensional (3D) information on lateral geological structures outside the profile. Additionally, the sensor data received by cross-hole seismic exploration constitute responses from geological bodies in 3D space and are potentially affected by objects outside the well profiles, distorting the imaging results and geological interpretation. This paper proposes a 3D cross-hole acoustic wave reverse-time migration imaging method to capture 3D cross-hole geological structures using sensor settings in multi-cross-hole seismic research. Based on the analysis of resulting 3D cross-hole images under varying sensor settings, optimizing the observation system can aid in the cost-efficient obtainment of the 3D underground structure distribution. To verify this method’s effectiveness on 3D cross-hole structure imaging, numerical simulations were conducted on four typical geological models regarding layers, local high-velocity zones, large dip angles, and faults. The results verify the model’s superiority in providing more reliable and accurate 3D geological information for cross-hole seismic exploration, presenting a theoretical basis for processing and interpreting cross-hole data. Full article

Although pressure pipelines serve as a secure and energy-efficient means of transporting oil, gas, and chemicals, they are susceptible to fatigue cracks over extended periods of cyclic loading due to the challenging operational conditions. Their quality and efficiency directly affect the safe operation of the project. Therefore, a thorough and precise characterization approach towards pressure pipelines can proactively mitigate safety risks and yield substantial economic and societal benefits. At present, the current mainstream 2D ultrasound imaging technology faces challenges in fully visualizing the internal defects and topography of pressure pipelines. Reverse time migration (RTM), widely employed in geophysical exploration, has the capability to visualize intricate geological structures. In this paper, we introduced the RTM into the realm of ultrasonic non-destructive testing, and proposed a 3D ultrasonic RTM imaging method for internal defects and sensor settings of pressure pipelines. To accurately simulate the extrapolation of wave field in 3D pressure pipelines, we set the absorbing boundary and double free boundary in cylindrical coordinates. Subsequently, using the 3D ultrasonic RTM approach, we attained higher-precision 3D imaging of internal defects in the pressure pipelines through suppressing imaging artifacts. By comparing and analyzing the imaging results of different sensor settings, the design of the observation system is optimized to provide a basis for the imaging and interpretation of actual data. Both simulations and actual field data demonstrate that our approach delivers top-notch 3D imaging of pipeline defects (with an imaging range accuracy up to 97.85%). This method takes into consideration the complexities of multiple scattering and mode conversions occurring at the base of the defects as well as the optimal sensor settings. Full article

As a fundamental part of ground penetrating radar (GPR) data processing, reverse time migration (RTM) can correctly position reflection waves and focusing diffraction waves on the proper spatial position. Least-squares reverse-time migration (LSRTM) is widely used in the seismic field for its ability to suppress artifacts and generate high-resolution images in comparison to conventional RTM. However, in the particular case of GPR detection methods, LSRTM is extremely susceptible to aliasing artifacts caused by under-sampling. In pursuit of enhanced precision in underground structure characterization, this paper presents the development of a new LSRTM based on modified total variation (MTV) regularization to improve imaging resolution. Initially, the objective function of LSRTM is derived by combining the Born approximation in 2-D transversal magnetic mode. Next, the adjoint equations and their gradients are solved using the Lagrange multiplier method. The objective function is then constrained by MTV regularization to ensure the precision and convergence of the LSRTM, which delivers a refined edge with reconstruction details. In the numerical experiments, in comparison to the conventional LSRTM method, the LSRTM-MTV algorithm demonstrated a 30.4% increase in computational speed and a 21.1% reduction in mean squared error (MSE). The outperformance of the proposed method is verified in detail through the image resolution and amplitude preservation in the test of synthetic data and laboratory data. Future research efforts will center on applying the proposed method to models featuring dispersive or anisotropic media that closely mimic real-world conditions and extending the application to various imaging techniques involving objective function minimization. Full article

Subsurface characterization is crucial for geothermal energy exploration and production. Yet hydrothermal reservoirs usually reside in highly fractured and faulted zones where accurate characterization is very challenging because of low signal-to-noise ratios of land seismic data and lack of coherent reflection signals. We perform an active-source seismic characterization for the Blue Mountain geothermal field in Nevada using active seismic data to reveal the elastic medium property complexity and fault distribution at this field. We first employ an unsupervised machine learning method to attenuate groundroll and near-surface guided-wave noise and enhance coherent reflection and scattering signals from noisy seismic data. We then build a smooth initial P-wave velocity model based on an existing magnetotellurics survey result, and use 3D first-arrival traveltime tomography to refine the initial velocity model. We then derive a set of elastic wave velocities and anisotropic parameters using elastic full-waveform inversion, and obtain PP and PS images using elastic reverse-time migration. We identify major faults by analyzing the variations of seismic velocities and anisotropy parameters, and reveal mid- to small-scale faults by applying a supervised machine learning method to the seismic migration images. Our characterization reveals complex velocity heterogeneities and anisotropies, as well as faults, with a high spatial resolution. These results can provide valuable information for optimal placement of future injection and production wells to increase geothermal energy production at the Blue Mountain geothermal power plant. Full article

Submarine pipelines are a safe and energy-efficient mode of gas transport. However, due to the complex manufacturing process and harsh operating environment, submarine pipelines are subject to fatigue cracks under long-term cyclic loading. A comprehensive and high-precision characterization strategy for submarine pipelines can effectively prevent potential safety hazards and have significant economic and social repercussions. As a matter of fact, pipeline defects cannot be reliably detected with current traditional 2D methods. On the other hand, in ultrasonic testing, cylindrical geometry increases the complexity of the 3D wave field in the submarine pipeline space and significantly influences the accuracy of the detection results. In this paper, we put forward a novel method for 3D ultrasonic image testing that is suitable for cylindrical coordinates. In order to accurately simulate the ultrasonic signal received from pipelines, we generalize the 3D staggered-grid finite-difference method from Cartesian coordinates to cylindrical ones and simulate the full wave field in the 3D pipeline space. Then, signal processing is performed on the ultrasound simulation records, and 3D reverse-time migration imaging of submarine pipeline defects can be effectively achieved using the reverse-time migration method and cross-correlation imaging conditions. The results obtained from simulations and real field data show that the proposed method provides high-quality 3D imaging of defects in pipelines, taking into account multiple scattering and mode conversion information at the bottom of the defects. Full article

Seismic imaging is now a well-established method in mineral exploration with many successful case studies. Seismic data are usually imaged in the time domain (post-stack or pre-stack time migration), but recently pre-stack depth imaging has shown clear advantages for irregular/sparse acquisitions and very complex targets. Here, we evaluate the effectiveness of both ray-based and wave-equation-based pre-stack depth imaging methodologies applied to crooked-line 2D seismic reflection profiles. Seismic data were acquired in the Kylylahti mining area in eastern Finland over severely folded, faulted and subvertical Kylylahti structure, and associated mineralization. We performed 3D ray-based imaging, i.e., industry-standard Kirchhoff migration and its improved version (coherency migration, CM), and wave-equation-based migration, i.e., reverse time migration (RTM) using a velocity model built from first-arrival traveltime tomography. Upon comparing the three different migrations against available geological data and models, it appeared that CM provided the least noisy and well-focused image, but failed to image the internal reflectivity of the Kylylahti formation. RTM was the only method that produced geologically plausible reflections inside the Kylylahti formation including a direct image of the previously known shallow massive sulfide mineralization. Full article

Carbon capture and storage (CCS) is a key technology that directly removes industry driven CO₂ to achieve carbon neutrality. In the process of CCS, it is necessary to monitor whether injected CO₂ is properly stored and not leaking. The behavior of CO₂ can be investigated using a 4D seismic survey that compares seismic data before and after injection. We proposed a two-step monitoring with diffraction-angle filtering (DAF) to effectively locate the CO₂ plume. Because DAF allows us to control wavenumber components, the gradient of full-waveform inversion (FWI), which is the first step, is composed of low-wavenumber components, and reverse time migration (RTM) for seismic imaging is carried out with high-wavelength components. To verify our method, we implemented FWI and RTM with and without DAF using the velocity model in the Volve oil field in the North Sea. Numerical examples show that the CO₂ plume is properly detected from the difference between baseline and post-injected survey and the extension of the reflective boundary is improved compared to the results of the conventional method. With our proposed method, local minima problem is mitigated in FWI, and the boundaries between layers can be clearly distinguished in RTM. Full article

Bubble clusters present in seawater can cause acoustic interference and acoustic signal distortion during marine exploration. However, this interference can also be used as an acoustic masking technique, which has significant implications for military purposes. Therefore, characterizing the distribution of bubble clusters in water would allow for the development of anti-detection technologies. In this study, a sea experiment was performed using a multi-sonar array system and a bubble-generating material developed by our research group to obtain acoustic signals from an artificial bubble cluster and characterize its distribution. The acquired acoustic data were preprocessed, and reverse-time migration (RTM) was applied to the dataset. For effective RTM, an envelope waveform was used to decrease computation time and memory requirements. The envelope RTM results could be used to effectively image the distribution characteristics of the artificial bubble clusters. Compared with acoustic Doppler current profiler data, the backscattering strength of the boundary of the imaged artificial bubble cluster was estimated to range between −30 and −20 dB. Therefore, the three-dimensional distribution characteristics of bubble clusters in the open sea can be effectively determined through envelope RTM. Furthermore, the data obtained from this study can be used as a reference for future studies. Full article

In this paper, the combined compact difference scheme (CCD) and the combined supercompact difference scheme (CSCD) are used in the numerical simulation of the shear-wave equation. According to the Taylor series expansion and shear-wave equation, the fourth-order discrete scheme of the displacement field is established; then, the CCD and CSCD schemes are used to calculate the spatial derivative of the displacement field. Additionally, the accuracy, dispersion, and stability of the CCD and CSCD are analyzed, and numerical simulation analyses are carried out using 1D uniform models. Lastly, based on the processing of artificial boundary reflection using PML boundary conditions, shear-wave reverse-time migrations are carried out using synthetic data. The results show that (1) CCD and CSCD have smaller truncation errors, higher simulation precision, and lower numerical dispersion than other normal difference schemes; (2) CCD and CSCD can use the coarse grid and larger time step to calculate, with less memory and high computational efficiency; (3) finally, the result of the shear-wave reverse-time migration of the 2D synthetic data model show that the reverse-time migration imaging is clear, and the proposed method for shear-wave reverse-time migration is practical and effective. Full article

Fault structures developed in coal seams, which are often associated with roof collapse, water inrush, gas outburst, and other accidents, are common geological hazards in coal exploration and development. The accurate detection of micro-structures such as small faults has always been a research focus to ensure safety in coalfields. Three-dimensional (3D) seismic research is one of the most efficient methods for obtaining the structural characteristics of coal areas and identify small faults in coal seams, but it is difficult for traditional seismic data imaging technologies to meet the high-precision demand of current coal exploration. Aiming at the characteristics of 3D seismic data in coalfields, we calculated the difference coefficients based on the optimized inversion algorithm and proposed a variable-density acoustic equation optimized with a temporal–spatial staggered-grid finite difference forward algorithm. On this basis, by combining normalized cross-correlation imaging conditions and GPU/CPU collaborative parallel processing technology, we developed an efficient and high-precision 3D reverse time migration method suitable for 3D seismic data in coalfields. Numerical tests verified the accuracy and efficiency of the proposed migration method for the imaging of coal-measure strata with small fault structures and could effectively identify 5 m small faults in the coal seam. The migration test of 3D seismic data in real coalfields showed that our 3D reverse time migration method has good practicability for high-precision imaging of 3D seismic data in coalfields and is an effective method for the precise imaging of small faults in coal measures. Full article

An ultrasonic reverse time migration imaging method, based on high-order singular value decomposition, is proposed in the study to solve the problems of low signal-to-noise ratio (SNR) and excessive artifacts in defect ultrasonic detection imaging results of materials with high noise levels. In this method, based on the 3D structural properties of the ultrasonic full-matrix capture data, higher-order singular value decomposition is directly performed with the 3D data. The method overcomes the difficulty in selecting the number of singular values in the original singular value decomposition noise-reduction algorithm and realizes the one-step noise reduction processing of all the signals. Subsequently, the reverse time migration imaging is performed in the frequency domain, and high-quality acoustic images are obtained. The effects of the number of array elements, the center frequency of the excitation signal, and the number of defects on the denoising effect of the algorithm are investigated. It was experimentally demonstrated that the method could suppress the interference of noise signals and significantly improve the imaging SNR compared with total focusing method and the reverse time migration. Full article
