Search Results (459)

Ba_0.6Sr_0.4TiO₃ (BST) thin films were deposited on ITO substrates via rf magnetron sputtering, followed by structural and morphological characterization using XRD and FE-SEM. Metal–insulator–metal (MIM) RRAM devices were fabricated by depositing Al top electrodes, and their electrical properties were examined through I–V measurements. The optimized BST films deposited at 40% oxygen concentration exhibited stable resistive switching, with an operating voltage of 3 V, an on/off ratio of 1, and a leakage current of 10⁻⁸ A. After rapid thermal annealing at 500 °C, the on/off ratio improved to 2 but leakage increased to 10⁻³ A. Incorporating an electron transport layer (ETL) effectively suppressed the leakage current to 10⁻⁵ A while maintaining the on/off ratio at 2. Moreover, a transition from bipolar to unipolar switching was observed at higher oxygen concentration (60%). These results highlight the role of ETLs in reducing leakage and stabilizing switching characteristics, providing guidance for the development of transparent, low-power, and high-reliability BST-based RRAM devices. This study aims to investigate the role of Ba_0.6Sr_0.4TiO₃ (BST) ferroelectric oxide as a functional switching layer in resistive random-access memory (RRAM) and to evaluate how interface engineering using an electron transport layer (ETL) can improve resistive switching stability, leakage suppression, and device reliability. Full article

High-quality AZO thin films were produced on a 4-inch Si substrate using large-area PLD equipment at a substrate temperature of 330 °C, with a ZnO: Al (98:2 wt.%) target. This study aims to enhance the electrical, optical, morphological and structural properties of large-area PLD-grown AZO thin films by tuning the deposition pressures. The samples were prepared under high-vacuum (HV) conditions, as well as in oxygen atmospheres of 0.005 mbar O₂, 0.01 mbar O₂, and 0.1 mbar O₂. Consequently, a bilayer AZO film was prepared in a combination of two deposition pressures (first layer prepared under HV, followed by the second layer prepared at 0.01 mbar O₂). Additionally, morphological and structural characterization revealed that high-quality columnar growth AZO thin films free of droplets, with a strong (002) orientation, were achieved on a 4-inch Si substrate. Moreover, Hall measurements in the Van der Pauw configuration were used to assess the electrical properties. A low electrical resistivity of 3.98 × 10⁻⁴ Ω cm, combined with a high carrier concentration (n) of 1.05 × 10²¹ cm⁻³ and a charge carrier mobility of 17.9 cm²/V s, was achieved at room temperature for the sample prepared under HV conditions. The optical characterization conducted through spectroscopic ellipsometry measurements showed that the large-area AZO sample exhibits an increased optical transparency in the visible (VIS) range with a near-zero extinction coefficient (k) and a wide bandgap of 3.75 eV, fulfilling the standards for materials classified as TCO. In addition, the increased thickness uniformity of the prepared AZO films over a large area represents a significant step in scaling the PLD technique for industrial applications. Full article

Mg-doped gallium oxide films were prepared on single crystal sapphire substrates through radio frequency magnetron sputtering technology, and then AlN films of different thicknesses were deposited on them as passivation layers. Finally, Pt interdigitated electrodes were prepared through mask plate and ion sputtering technology to make metal–insulator–semiconductor–insulator–metal (MISIM) photodetectors. The influence of the AlN passivation layer on the optical properties and photodetection performance of the device was investigated using UV-Vis (ultraviolet-visible absorption spectroscopy) spectrophotometer and a Keith 4200 semiconductor tester. The device’s performance was significantly enhanced. Among them, the MISIM-structured device achieves a responsivity of 2.17 A/W, an external quantum efficiency (EQE) of 1100%, a specific detectivity (D*) of 1.09 × 10¹² Jones, and a photo-to-dark current ratio (PDCR) of 2200. The results show that different thicknesses of AlN passivation layers have an effect on the detection performance of Mg-doped β-Ga₂O₃ films in the UV detection of the solar-blind UV region. The AlN’s thickness has little effect on the bandgap when it is 3 nm and 5 nm, and the bandgap increases at 10 nm. The transmittance of the film increases with the increase in AlN thickness and decreases when the AlN’s thickness increases to 10 nm. The photocurrent exhibits a non-monotonic dependence on AlN thickness at 10 V, and the dark current gradually decreases. The thickness of the AlN passivation layer also has a significant impact on the response characteristics of the detector, and the response characteristics of the device are best when the thickness of the AlN passivation layer is 5 nm. The responsiveness, detection rate, and external quantum efficiency of the device first increase and then decrease with the thickness of the AlN layer, and comprehensive performance is best when the thickness of the AlN passivation layer is 5 nm. The reason is that the AlN layer plays a passivating role on the surface of Ga₂O₃ films, reducing surface defects and inhibiting its capture of photogenerated carriers, while the appropriate thickness of the AlN layer increases the barrier height at the semiconductor interface, forming a built-in electric field and improving the response speed. Finally, the AlN layer inhibits the adsorption and desorption processes between the photogenerated electron–hole pair and O₂, thereby retaining more photogenerated non-equilibrium carriers, which also helps enhance photoelectric detection performance. Full article

Wearable and skin-mounted electronics demand encapsulation designs that simultaneously provide strong barrier performance, mechanical reliability, and transferability under ultrathin conditions. In this study, a residual stress-balanced transferable encapsulation platform was developed by integrating a urethane-based copolymer superstrate [p(IEM-co-HEMA)] with inorganic thin films. The polymer, deposited via initiated chemical vapor deposition (iCVD), offered over 90% optical transmittance, low RMS roughness (1–3 nm), and excellent solvent resistance, providing a stable base for inorganic barrier integration. An ALD Al₂O₃/ZnO nano-stratified barrier initially delivered effective moisture blocking, but tensile stress accumulation imposed a critical thickness of 30 nm, where the WVTR plateaued at ~2.5 × 10⁻⁴ g/m²/day. To overcome this limitation, a 40 nm e-beam SiO₂ capping layer was added, introducing compressive stress via atomic peening and stabilizing Al₂O₃ interfaces through Si–O–Al bonding. This stress-balanced design doubled the critical thickness to 60 nm and reduced the WVTR to 3.75 × 10⁻⁵ g/m²/day, representing an order-of-magnitude improvement. OLEDs fabricated on this ultrathin platform preserved J–V–L characteristics and efficiency (~4.5–5.0 cd/A) after water-assisted transfer and on-skin deformation, while maintaining LT80 lifetimes of 140–190 h at 400 cd/m² and stable emission for over 20 days in ambient storage. These results demonstrate that the stress-balanced encapsulation platform provides a practical route to meet the durability and reliability requirements of next-generation wearable optoelectronic devices. Full article

The 316L stainless steel, uncoated and coated with two types of EB-PVD thin-film deposits, was tested in liquid lead both under oxygen-saturated conditions (~10⁻³ wt.%) for exposure times of 1000 and 2000 h and under low-oxygen conditions (~10⁸ wt.%) for 1000 h. The first coating consisted of a ~1 µm NiCrAlY thin film. At the same time, the second was a NiCrAlY/Al₂O₃ multilayer with a total thickness of ~3 µm, on top of which an additional 100–200 nm metallic Cr layer was deposited. Uncoated specimens tested under oxygen-saturated conditions developed a duplex oxide layer on their surface. SEM-EDS analyses revealed that the inner layer was denser and contained Fe, Cr, and O, whereas the outer layer was more porous and composed mainly of Fe and O. Microscopic examinations indicated that the multilayer-coated specimens exposed to low-oxygen conditions exhibited no signs of material degradation. In contrast, both the uncoated samples and those coated only with a single NiCrAlY layer showed generalised corrosion over the entire surface after exposure to liquid lead at low oxygen concentrations. The austenitic microstructure was degraded to a depth of 100–200 µm. Vickers microhardness indentations performed on the structurally altered regions revealed two distinct corrosion zones with markedly different hardness values. Full article

In this study, we investigate the improvement of physical and electrical characteristics in 4H-silicon carbide (SiC) MOS capacitors using Aluminum Oxynitride (AlON) thin films fabricated via Plasma-Enhanced Atomic Layer Deposition (PEALD). AlON thin films are grown on SiC substrates using a high ratio of NH₃ and O₂ as nitrogen and oxygen sources through PEALD technology, with improved material properties and electrical performance. The AlON films exhibited excellent thickness uniformity, with a minimal error of only 0.14%, a high refractive index of 1.90, and a low surface roughness of 0.912 nm, demonstrating the precision of the PEALD process. Through XPS depth profiling and electrical characterization, it was found that the AlON/SiC interface showed a smooth transition from Al-N and Al-O at the surface to Al-O-Si at the interface, ensuring robust bonding. Electrical measurements indicated that the SiC/AlON MOS capacitors demonstrated Type I band alignment with a valence band offset of 1.68 eV and a conduction band offset of 1.16 eV. Additionally, the device demonstrated a low interface state density (D_it) of 7.6 × 10¹¹ cm⁻²·eV⁻¹ with a high breakdown field strength of 10.4 MV/cm. The results highlight AlON’s potential for enhancing the performance of high-voltage, high-power SiC devices. Full article

Binary oxide ceramics have emerged as key materials in solar energy research due to their versatility, chemical stability, and tunable electronic properties. This study presents a comparative analysis of seven prominent oxides (TiO₂, ZnO, Al₂O₃, SiO₂, CeO₂, Fe₂O₃, and WO₃), focusing on their functional roles in silicon, perovskite, dye-sensitized, and thin-film solar cells. A bibliometric analysis covering over 50,000 publications highlights TiO₂ and ZnO as the most widely studied materials, serving as electron transport layers, antireflective coatings, and buffer layers. Al₂O₃ and SiO₂ demonstrate highly specialized applications in surface passivation and interface engineering, while CeO₂ offers UV-blocking capability and Fe₂O₃ shows potential as an absorber material in photoelectrochemical systems. WO₃ is noted for its multifunctionality and suitability for scalable, high-rate processing. Together, these findings suggest that binary oxide ceramics are poised to transition from supporting roles to essential components of stable, efficient, and environmentally safer next-generation solar cells. Full article

This study examines the effects of laser pulse duration on the structural, morphological, optical, and gas-sensing characteristics of ${\mathrm{Al}}_2{\mathrm{O}}_3$/AgO thin films deposited on glass substrates using pulsed laser deposition (PLD). Pulse durations of 10, 8, and 6 nanoseconds were achieved through optical lens modifications to control both energy density and laser spot size. X-ray diffraction (XRD) and atomic force microscopy (AFM) analyses showed a distinct reduction in both crystallite and grain sizes with decreasing pulse width, along with significant improvements in surface morphology refinement and film compactness. Hall effect measurements revealed a transition from n-type to p-type conductivity with decreasing pulse width, demonstrating increased hole concentration and reduced carrier mobility attributed to grain boundary scattering. Furthermore, current-voltage (I-V) characteristics demonstrated improved photoconductivity under illumination, with the most pronounced enhancement observed in samples prepared using longer pulse durations. Gas sensing measurements for ${\mathrm{NO}}_2$ and ${\mathrm{H}}_2$S revealed enhanced sensitivity, improved response/recovery characteristics at 250 °C, with optimal performance achieved in films deposited using shorter pulse durations. This improvement is attributed to their larger surface area and higher density of active adsorption sites. Our results demonstrate a clear relationship between laser pulse parameters and the functional properties of ${\mathrm{Al}}_2{\mathrm{O}}_3$/AgO films, providing valuable insights for optimizing deposition processes to develop advanced gas sensors. Full article

In the era of artificial intelligence, neuromorphic devices that simulate brain functions have received increasingly widespread attention. In this paper, an artificial neural synapse device based on ZnAlSnO thin-film transistors was fabricated, and its electrical properties were tested: the current-switching ratio was 1.18 × 10⁷, the subthreshold oscillation was 1.48 V/decade, the mobility was 2.51 cm²V⁻¹s⁻¹, and the threshold voltage was −9.40 V. Stimulating artificial synaptic devices with optical signals has the advantages of fast response speed and good anti-interference ability. The basic biological synaptic characteristics of the devices were tested under 365 nm light stimulation, including excitatory postsynaptic current (EPSC), paired-pulse facilitation (PPF), short-term plasticity (STP), and long-term plasticity (LTP). This device shows good synaptic plasticity. In addition, by changing the gate voltage, the excitatory postsynaptic current of the device at different gate voltages was tested, two different logical operations of “AND” and “OR” were achieved, and the influence of different synaptic states on memory was simulated. This work verifies the application potential of the device in the integrated memory and computing architecture, which is of great significance for promoting the high-quality development of neuromorphic computing hardware. Full article

In this work, we investigated how the electrical resistivity of LaNiO₃ thin films deposited on SrLaAlO₄ (100), LaAlO₃ (100), and MgO (100) single-crystal substrates by the pulsed laser deposition (PLD) technique can be controlled by femtosecond laser irradiation. Thin films were characterized by X-ray diffraction (XRD), field emission scanning electron microscopy (SEM-EDS), and temperature-dependent electrical resistivity measurements. The XRD data indicated good crystallinity and preferential crystallographic orientation. The electronic transport parameters of irradiated samples showed a remarkable decrease in the electrical resistivity for all studied films, which ranged from 38% to 52% depending on the temperature region considered and the type of substrate used. The results indicate a new and innovative route to decrease the electrical resistivity values in a precise, controlled, and localized manner, which could not be performed directly by well-known growth processes, allowing for direct application in non-volatile-memory electrodes. Full article

In this study, tin oxide (SnO₂) resistive random-access memory (RRAM) thin films were fabricated using the thermal evaporation and radiofrequency and dc frequency sputtering techniques for metal–insulator–metal (MIM) structures. The fabrication process began with the deposition of a silicon dioxide (SiO₂) layer onto a silicon (Si) substrate, followed by the deposition of a titanium nitride (TiN) layer to serve as the bottom electrode. Subsequently, the tin oxide (SnO₂) layer was deposited as the resistive switching insulator. Two types of top electrodes were developed to investigate the influence of different oxygen concentrations on the bipolar switching, electrical characteristics, and performance of memory devices. An aluminum (Al) top electrode was deposited using thermal evaporation, while a platinum (Pt) top electrode was deposited via dc sputtering. As a result, two distinct metal–insulator–metal (MIM) memory RRAM device structures were formed, i.e., Al/SnO₂/TiN/SiO₂/Si and Pt/SnO₂/TiN/SiO₂/Si. In addition, the symmetry bipolar switching characteristics, electrical conduction mechanism, and oxygen concentration factor of the tin oxide-based memory devices using rapid thermal annealing and different top electrodes were determined and investigated by ohmic, space-charge-limit-current, Schottky, and Poole–Frenkel conduction equations in this study. Full article

Nanofiltration (NF) is considered a competitive purification method for acidic stream treatments. However, conventional thin-film composite NF membranes degrade under acid exposures, limiting their applications in industrial acid treatment. For example, wet-process phosphoric acid contains impurities of multivalent metal ions, but NF membrane technologies for impurity removal under harsh conditions are still immature. In this work, we develop a novel strategy of acid-resistant nanofiltration membranes based on interfacial polymerization (IP) of polyethyleneimine (PEI) and cyanuric chloride (CC) with the s-triazine ring. The IP process was optimized by orthogonal experiments to obtain positively charged PEI-CC membranes with a molecular weight cut-off (MWCO) of 337 Da. We further applied it to the approximate industrial phosphoric acid purification condition. In the tests using a mixed solution containing 20 wt% P₂O₅, 2 g/L Fe³⁺, 2 g/L Al³⁺, and 2 g/L Mg²⁺ at 0.7 MPa and 25 °C, the NF membrane achieved 56% rejection of Fe, Al, and Mg and over 97% permeation of phosphorus. In addition, the PEI-CC membrane exhibited excellent acid resistance in the 48 h dynamic acid permeation experiment. The simple fabrication procedure of PEI-CC membrane has excellent acid resistance and great potential for industrial applications. Full article

The Junggar Basin contains a large amount of coal resources and is an important coal production base in China. The coal seam in Zhundong coalfield has a large single-layer thickness and high content of inertinite, but large particle Fe-sulphide minerals are associated with coal seams in some mining areas. A series of economic and environmental problems caused by the combustion of large-grained Fe-sulphide minerals in coal have seriously affected the economic, clean and efficient utilization of coal. In this paper, the ultra-thick coal seam of the Xishanyao formation in the Yihua open-pit mine of the Zhundong coalfield is taken as the research object. Through the analysis of coal quality, X-ray fluorescence spectrometer test of major elements in coal, inductively coupled plasma mass spectrometry test of trace elements, SEM-Raman identification of Fe-sulphide minerals in coal and LA-MC-ICP-MS test of sulfur isotope of marcasite, the coal quality characteristics, main and trace element characteristics, macro and micro occurrence characteristics of Fe-sulphide minerals and sulfur isotope characteristics of marcasite in the ultra-thick coal seam of the Xishanyao formation are tested. On this basis, the occurrence state and genesis of large particle Fe-sulphide minerals in the ultra-thick coal seam of the Xishanyao formation are clarified. The main results and understandings are as follows: (1) the occurrence state of Fe-sulphide minerals in extremely thick coal seams is clarified. The Fe-sulphide minerals in the extremely thick coal seam are mainly marcasite, and concentrated in the YH-2, YH-3, YH-8, YH-9, YH-14, YH-15 and YH-16 horizons. Macroscopically, Fe-sulphide minerals mainly occur in three forms: thin film Fe-sulphide minerals, nodular Fe-sulphide minerals, and disseminated Fe-sulphide minerals. Microscopically, they mainly occur in four forms: flake, block, spearhead, and crack filling. (2) The difference in sulfur isotope of marcasite was discussed, and the formation period of marcasite was preliminarily divided. The overall variation range of the δ³⁴S value of marcasite is wide, and the extreme values are quite different. The polyflake marcasite was formed in the early stage of diagenesis and the δ³⁴S value was negative, while the fissure filling marcasite was formed in the late stage of diagenesis and the δ³⁴S value was positive. (3) The coal quality characteristics of the thick coal seam were analyzed. The organic components in the thick coal seam are mainly inertinite, and the inorganic components are mainly clay minerals and marcasite. (4) The difference between the element content in the thick coal seam of the Zhundong coalfield and the average element content of Chinese coal was compared. The major element oxides in the thick coal seam are mainly CaO and MgO, followed by SiO₂, Al₂O₃, Fe₂O₃ and Na₂O. Li, Ga, Ba, U and Th are enriched in trace elements. (5) The coal-accumulating environment characteristics of the extremely thick coal seam are revealed. The whole thick coal seam is formed in an acidic oxidation environment, and the horizon with Fe-sulphide minerals is in an acidic reduction environment. The acidic reduction environment is conducive to the formation of marcasite and is not conducive to the formation of pyrite. (6) There are many matrix vitrinite, inertinite content, clay content, and terrigenous debris in the extremely thick coal seam. The good supply of peat swamp, suitable reduction environment and pH value, as well as groundwater leaching and infiltration, together cause the occurrence of large-grained Fe-sulphide minerals in the extremely thick coal seam of the Xishanyao formation in the Zhundong coalfield. Full article

A super-polishing procedure was performed on the Al₂O₃ (0001) surface for epitaxial purposes. The roughness of the final polished surface was measured to be 0.16 nm using atomic force microscopy and X-ray reflectivity techniques. After heat treatment at 130 °C, results from low-energy electron diffraction and Auger energy spectroscopy indicated that the top surface was well ordered and clean, rendering it suitable for epitaxial growth. The successful growth of a GaN thin film on an Al₂O₃ (0001) substrate was confirmed by the hk-circle scan in XRD and the presence of a sharp peak in the rocking curve of the GaN (0002) Bragg peak. These findings indicate that the top surface of the substrate is conducive to epitaxial growth. Full article

Al/AgO seawater-activated batteries with high specific energy and high specific power are widely used at present. The AgO electrode determines the performance of the battery, with its active material utilization rate having a significant impact on the specific capacity, energy density and discharge capacity of the battery. Therefore, this study briefly introduces the structure and working principle of Al/AgO seawater-activated batteries. Starting from the AgO material itself, common preparation methods for such positive electrode materials—including sintered silver oxide electrodes, pressed silver oxide electrodes and thin-film silver oxide electrodes—are introduced, and the factors influencing their electrochemical performance are analyzed in depth. We elaborate on the relevant research progress regarding AgO electrodes in terms of improving battery performance, detailing the effects of the silver powder’s morphology, porosity, purity, ordered structure, surface treatment and doping modification methods on silver oxide electrodes. Finally, various methods for improving the electrochemical performance of silver oxide electrodes are detailed. Current challenges and possible future research directions are analyzed, and prospects for the future development of high-specific-energy batteries based on AgO electrode materials are discussed. Overall, this review highlights the characteristics of Al/AgO batteries, providing a theoretical basis for the development of high-performance Al/AgO batteries. Full article
