This study presents a comprehensive performance evaluation of hybrid global navigation satellite system (GNSS) configurations in urban canyon environments across South Korea, focusing on the integration of Global Positioning System (GPS) with the BeiDou, GLONASS, Galileo, Quasi Zenith Satellite System (QZSS), and Navigation with Indian Constellation (NavIC) constellations. Simulation scenarios representing pedestrian, vehicular, and unmanned aerial vehicle (UAV) movements are used to analyze the positioning accuracy and reliability of each hybrid system. The results indicate that GPS–BeiDou and GPS–QZSS combinations consistently provide superior accuracy and continuous satellite visibility, with GPS–BeiDou achieving centimeter-level precision in the UAV scenario. In contrast, GPS–GLONASS and GPS–NavIC systems exhibit higher error rates and less stable performance. These findings emphasize the critical role of satellite availability, receiver altitude, and signal compatibility in achieving robust positioning. Although the results are specific to South Korea, the proposed evaluation framework is broadly applicable and can help other countries assess hybrid GNSS performance to guide the design and optimization of their regional navigation satellite systems. Full article

In mountainous canyon regions, BeiDou Navigation Satellite System (BDS)/Global Navigation Satellite System (GNSS) receivers are susceptible to multireflection and tropospheric factors, which frequently reduce the accuracy in monitoring vertical deformation monitoring under short-baseline methods. This limitation hinders the application of BDS/GNSS in high-precision monitoring scenarios in those cases. To address this issue, this study proposes a three-dimensional (3D) deformation measurement method that integrates BDS/GNSS positioning with dihedral corner reflectors (CRs). By incorporating high-precision horizontal positioning results obtained from BDS/GNSS into the radar line-of-sight (LOS) correction process and utilizing ascending and descending Synthetic Aperture Radar (SAR) data for joint monitoring, the method achieves millimeter-level- accuracy in measuring vertical deformation at corner reflector sites. At the same time, it enhances the 3D positioning accuracy of BDS/GNSS to the 1 mm level under short-baseline configurations. Based on monitoring stations deployed at the Jinsha River dam site, the proposed deformation fusion monitoring method was validated using high-resolution SAR imagery from Germany’s TerraSAR-X (TSX) satellite. Simulated horizontal and vertical displacements were introduced at the stations. The results demonstrate that BDS/GNSS achieves better than 1 mm horizontal monitoring accuracy and a vertical accuracy of around 5 mm. Interferometric SAR (InSAR) CRs achieve approximately 2 mm in horizontal accuracy and 1 mm in vertical accuracy. The integrated method yields a 3D deformation monitoring accuracy better than 1 mm. This paper’s results show high potential for achieving high-precision deformation observations by fusing BDS/GNSS and dihedral CRs, offering promising prospects for deformation monitoring in reservoir canyon regions. Full article

The advancement of wearable technologies has resulted in significant interest in GNSS-integrated textile antenna development. Although existing literature surveys predominantly concentrate on flexible non-textile antenna systems operating within UHF and 5G frequency spectra, systematic investigations of textile-based antenna configurations in the 1–2 GHz GNSS band have been relatively scarce. Contemporary GNSS textile antenna architectures primarily target GPS frequency coverage, while the global proliferation of BeiDou Navigation Satellite System (BDS) infrastructure necessitates urgent development of BDS-compatible textile antenna solutions. This review methodically examines the structural configurations and radiation characteristics of 1–2 GHz textile antennas, bandwidth enhancement techniques, miniaturization methodologies, and gain optimization approaches, along with material selection criteria and manufacturing processes. Technical challenges persist in simultaneously achieving broadband operation, compact dimensions, and elevated gain performance. Primary manufacturing approaches encompassing laminated fabric assemblies, printed electronics, and embroidered conductive patterns are analyzed, while existing methodologies exhibit limited capacity for seamless garment integration. Despite remarkable progress in conductive material engineering, dielectric property modification studies demonstrate insufficient theoretical depth. Comprehensive mitigation strategies for multifaceted operational environments involving human proximity effects, mechanical deformation, and variable meteorological conditions remain notably underdeveloped. This comprehensive analysis aims to establish a foundational framework for next-generation BDS-oriented textile antenna development. Full article

In recent years, the rapid development of moving platforms, especially unmanned aerial vehicles (UAVs) and unmanned ground vehicles (UGVs), has promoted their widespread applications in various fields such as precision agriculture and formation flight. In these applications, for accurate real-time kinematic positioning between two moving platforms, receiver autonomous integrity monitoring (RAIM) is necessary to assure the reliability of the obtained relative positioning. However, the existing carrier phase-based RAIM (CRAIM) algorithms are mainly a direct extension of pseudorange-based RAIM (PRAIM), whose availability is also a major challenge in signal-harsh environments. Learning from the integrated system between Global Navigation Satellite System (GNSS) and INS and based on a multiple hypothesis solution separation (MHSS) algorithm, we have developed an improved CRAIM algorithm, which combines Beidou Navigation Satellite System (BDS) and INS to offer integrity information for real-time kinematic relative positioning between two moving platforms in challenging environments. To achieve more robust and efficient fault detection and exclusion (FDE) results, an algorithm of observation-domain outlier detection combined with MHSS (OOD-MHSS) is also proposed. In this algorithm, the kinematic relative positioning method with INS addition is performed first, then, based on double-difference (DD) phase observations with known integer ambiguities and the OOD-MHSS method, the integrity monitoring information can be provided for the kinematic relative positioning between two moving platforms. To assess the performance of the OOD-MHSS and the improved CRAIM algorithm, a series of kinematic experiments between different platforms was analyzed and discussed. The results show that the improved CRAIM algorithm can perform effective FDE and provide reliable integrity information, which offers centimeter-level relative position solutions with decimeter-level protection levels (PLs) (integrity budget: ${1\times 10}^{-5}$/h). Both observation outlier detection and INS improve the continuity and availability of kinematic relative positioning and the PLs in horizontal and vertical directions. The PL values have been improved by up to 24.3%, and availability has reached 96.67% in harsh urban areas. This is of great significance for applications requiring higher precision and integrity in kinematic relative positioning. Full article

The BeiDou-3 Navigation Satellite System (BDS-3) precise point positioning (PPP) service through the B2b signal (PPP-B2b) leverages precise correction data disseminated by satellites to eliminate or mitigate key error sources, including satellite orbit errors, clock biases, and ionospheric delays, thereby enabling high-precision timing and positioning. This paper investigates the disparities in time comparison and positioning capabilities associated with the PPP-B2b signals transmitted by the BDS-3 Geostationary Earth Orbit (GEO) satellites (C59 and C61). Three stations in the Asia–Pacific region were selected to establish two time comparison links. The study evaluated the time transfer accuracy of PPP-B2b signals by analyzing orbit and clock corrections from BDS-3 GEO satellites C59 and C61. Using multi-GNSS final products (GBM post-ephemeris) as a reference, the performance of PPP-B2b-based time comparison was assessed. The results indicate that while both satellites achieve comparable time transfer accuracy, C59 demonstrates superior stability and availability compared to C61. Additionally, five stations from the International GNSS Service (IGS) and the International GNSS Monitoring and Assessment System (iGMAS) were selected to assess the positioning accuracy of PPP-B2b corrections transmitted by BDS-3 GEO satellites C59 and C61. Using IGS/iGMAS weekly solution positioning results as a reference, the analysis demonstrates that PPP-B2b enables centimeter-level static positioning and decimeter-level simulated kinematic positioning. Furthermore, C59 achieves higher positioning accuracy than C61. Full article

Sea surface height (SSH) serves as a fundamental geophysical parameter in oceanographic research. In 2023, China successfully launched the world’s first spaceborne interferometric GNSS-R (iGNSS-R) altimeter, which features dual-frequency multi-beam scanning, interferometric processing, and compatibility with three major satellite navigation systems: the BeiDou Navigation Satellite System (BDS), the Global Positioning System (GPS), and the Galileo Satellite Navigation System (GAL). This launch marked the first in-orbit validation of the iGNSS-R altimetry technology. This study provides a detailed overview of the iGNSS-R payload design and analyzes its dual-frequency delay mapping (DM) measurements. We developed a refined DM waveform-matching algorithm that precisely extracts the propagation delays between reflected and direct GNSS signals, enabling the retrieval of global sea surface height (SSH) through the interferometric altimetry model. For validation, we employed an inter-satellite crossover approach using Jason-3 and Sentinel-6 radar altimetry as references, achieving an unprecedented SSH accuracy of 17.2 cm at a 40 km resolution. This represents a breakthrough improvement over previous GNSS-R altimetry efforts. The successful demonstration of iGNSS-R technology opens up new possibilities for cost-effective, wide-swath sea level monitoring. It showcases the potential of GNSS-R technology to complement existing ocean observation systems and enhance our understanding of global sea surface dynamics. Full article

Since 2022, DLR’s Mobile Rocket Base (MORABA) has observed jamming of GNSS signals on sounding rockets launched from Esrange in northern Sweden and Andøya Space Center (ASC) in northern Norway. The jamming primarily affected the GPS L1, Galileo E1 and BeiDou B1C and B1I signals on the L1 frequency band and was noticeable through a pronounced reduction in the carrier-to-noise ratio of the received GNSS signals. Jamming was observed in northern Sweden at an altitude above 22 km and in northern Norway at an altitude above 36 km. Geometric considerations made it possible to roughly localize the source of the jamming signals from the points of the flight path marking the start and end of interference. Full article

In this paper, we introduce a robust beamforming technique using array antennas. The proposed solution constitutes two stages; the first stage exploits the space-alternating generalized expectation-maximization (SAGE) algorithm to decompose the received GNSS signal into its constituent signals, i.e., direct and reflected signals. The SAGE algorithm estimates the angle of arrival (AoA) and the received covariance matrix for both the direct and reflected signals. The second stage, on the other hand, utilizes the Minimum Variance Distortionless Response (MVDR) algorithm to produce the weight vector that steers the main beam towards the satellite’s direction and the nulls towards the multipath effect. The MVDR uses the AoA of the direct path and the covariance matrix of the reflected path to minimize the multipath effect. The experimental results reveal that the proposed technique improves the received signal strength and the location estimation accuracy, as compared to a single-antenna system. Furthermore, the proposed technique outperforms the traditional MVDR technique in the tested environment. Finally, the 95% 3D position error of the proposed solution is 5.2 m, and the position dilution of precision (pdop) is 0.84. Full article

Precise Global Navigation Satellite System (GNSS) orbit prediction is critical for real-time positioning applications. Current orbit prediction accuracy for the BeiDou Navigation Satellite System-3 (BDS-3) exhibits a notable disparity compared to GPS and Galileo, with limited advancements from traditional dynamic modeling approaches. This study introduces a novel data-driven methodology, Sample Convolution and Interaction Network with Self-Attention (SCINet-SA), to augment dynamic methods and improve BDS-3 ultra-rapid orbit prediction. SCINet-SA leverages deep learning to model the temporal characteristics of orbit differences between BDS-3 ultra-rapid and final products. By training on historical orbit difference data, SCINet-SA predicts future discrepancies, facilitating the refinement of ultra-rapid orbit estimates. The incorporation of a self-attention mechanism within SCINet-SA enables the model to effectively capture long-range temporal dependencies, thereby enhancing long-term prediction capabilities and mitigating the latency associated with final product availability. Rigorous experimental evaluation demonstrates the superior performance of SCINet-SA in enhancing BDS-3 ultra-rapid orbit prediction accuracy relative to alternative deep learning models. Specifically, SCINet-SA achieved the highest average relative improvement (IMP) in 3D Root Mean Square (RMS) error across 1 d, 7 d, and 15 d prediction horizons, yielding improvements of 21.69%, 18.66%, and 15.42%, respectively. The observed IMP range spanned from 7.78% to 38.91% for 1 d, 4.34% to 35.96% for 7 d, and 1.68% to 31.13% for 15 d predictions, underscoring the efficacy of the proposed methodology in advancing BDS-3 orbit prediction accuracy. Full article

The pseudoranges of a Global Navigation Satellite System (GNSS) meta-signal can be reconstructed from the observations of its side-band components. More specifically, the Hatch–Melbourne–Wübbena (HMW) code-carrier combination is used to solve the ambiguity associated to the wide-lane carrier phase combination of the side-band components, obtaining a high-accuracy pseudorange. The HMW and the wide-lane combinations thus play a key role in constructing meta-signal measurements. The theory of GNSS meta-signals was recently extended to the case with a number of components equal to a power of two. This theory can be used to generalize HMW and wide-lane combinations to the quad-frequency case. This is carried out through a Hadamard matrix of order four, which defines a narrow-lane and three wide-lane combinations. This paper characterizes meta-signal-inspired quad-frequency HMW and wide-lane measurements combinations using Beidou Navigation Satellite System (BDS) observations. Two professional Septentrio PolarRx5S multi-frequency, multi-constellation receivers were set up in a zero-baseline configuration and used to collect observables from all the BDS open frequencies. These measurements are used to characterize different quad-frequency HMW and wide-lane carrier combinations. Some of the combinations analyzed have large equivalent wavelengths and have the potential to enable single-epoch ambiguity resolution in scenarios where short convergence times are required. Full article

In high-orbit space missions, the significant attenuation of Global Navigation Satellite System (GNSS) signals due to long transmission distances and complex environmental interferences has led to a drastic degradation in the accuracy of traditional positioning models, which has attracted great attention in recent years. Although multi-system GNSS fusion positioning can alleviate the problem of insufficient satellite visibility, the existing methods are difficult to effectively cope with the challenges of multi-source noise coupling and inter-system error differences unique to high orbit. In this paper, we propose an adaptive GNSS positioning optimization framework for a high-orbit environment, which improves the orbiting reliability under complex signal conditions through dynamic weight allocation and a multi-system cooperative strategy. Different from the traditional weighting model, this method innovatively constructs a two-layer optimization mechanism: (1) Based on BP neural network, it evaluates the noise characteristics of pseudo-range observations in real time and realizes the adaptive suppression of receiver thermal noise, ionospheric delay, etc.; (2) it introduces Helmert variance component estimation to optimize the weighting ratio of GPS, GLONASS, BeiDou, and Galileo and reduces the impact of signal heterogeneity on the positioning solution of the multi-system. Simulation results show that the new method reduces the root-mean-square error of positioning by 32.8% compared with the traditional algorithm to 97.72 m in typical high-orbit scenarios and significantly improves the accuracy loss caused by the defective satellite geometrical configurations under multi-system synergy. Full article

This article aims to examine the real-time precise point positioning (PPP) solution’s accuracy utilizing the low-cost dual-frequency multi-constellation U-blox ZED-F9P module and real-time GNSS orbit and clock products from five analysis centers, including Bundesamt für Kartographie und Geodäsie (BKG), Centre National d’Etudes Spatiales (CNES), International GNSS Service (IGS), Geo Forschungs Zentrum (GFZ), and GNSS research center of Wuhan University (WHU). Three-hour static quad-constellation GNSS measurements are collected from ZED-F9P modules and geodetic grade Trimble R4s receivers over a reference station in Aswan City, Egypt, for a period of three consecutive days. Since a multi-GNSS PPP processing model is applied in the majority of the previous studies, this study employs the single-constellation GNSS PPP solution to process the acquired datasets. Different single-constellation GNSS PPP scenarios are adopted, namely, GPS PPP, GLONASS PPP, Galileo PPP, and BeiDou PPP models. The obtained PPP solutions from the low-cost module are validated for the positioning and precipitable water vapor (PWV) domains. To provide a reference positioning solution, the post-processed dual-frequency geodetic-grade GNSS PPP solution is applied; additionally, as the station under investigation is not a part of the IGS reference station network, a new technique is proposed to estimate reference PWV values. The findings reveal that the GPS and Galileo 3D position’s accuracy is within the decimeter level, while it is within the meter level for both the GLONASS and BeiDou models. Additionally, millimeter-level PWV precision is obtained from the four PPP models. Full article

The increasing demand for clean and reliable water resources, coupled with the growing threat of water pollution, has made real-time water quality (WQ) monitoring and assessment a critical priority in many urban areas. Urban environments encounter substantial challenges in maintaining WQ, driven by factors such as rapid population growth, industrial expansion, and the impacts of climate change. Effective real-time WQ monitoring is essential for safeguarding public health, promoting environmental sustainability, and ensuring adherence to regulatory standards. The rapid advancement of Internet of Things (IoT) sensor technologies and smartphone applications presents an opportunity to develop integrated platforms for real-time WQ assessment. Advances in the IoT provide a transformative solution for WQ monitoring, revolutionizing the way we assess and manage our water resources. Moreover, recent developments in Location-Based Services (LBSs) and Global Navigation Satellite Systems (GNSSs) have significantly enhanced the accessibility and accuracy of location information. With the proliferation of GNSS services, such as GPS, GLONASS, Galileo, and BeiDou, users now have access to a diverse range of location data that are more precise and reliable than ever before. These advancements have made it easier to integrate location information into various applications, from urban planning and disaster management to environmental monitoring and transportation. The availability of multi-GNSS support allows for improved satellite coverage and reduces the potential for signal loss in urban environments or densely built environments. To harness this potential and to enable the seamless integration of the IoT and LBSs for sustainable WQ monitoring, a systematic literature review was conducted to determine past trends and future opportunities. This research aimed to review the limitations of traditional monitoring systems while fostering an understanding of the positioning capabilities of LBSs in environmental monitoring for sustainable urban development. The review highlights both the advancements and challenges in using the IoT and LBSs for real-time WQ monitoring, offering critical insights into the current state of the technology and its potential for future development. There is a pressing need for an integrated, real-time WQ monitoring system that is cost-effective and accessible. Such a system should leverage IoT sensor networks and LBSs to provide continuous monitoring, immediate feedback, and spatially dynamic insights, empowering stakeholders to address WQ issues collaboratively and efficiently. Full article

A system for monitoring and analyzing GNSS performance is being developed at DLR’s Galileo Competence Centre. Various parameters are monitored in order to characterize the performance of the four global satellite navigation systems. The focus of this contribution is on the extension of our system with monitoring and analysis capabilities for the Galileo HAS and specifically for the Internet Data Distribution component of the service. An initial analysis of the content of the HAS messages and the positioning performance of the service at example IGS station locations is discussed. Our analysis shows the continuous availability of the internet distribution component of the service and a horizontal positioning performance of the order of 20 cm or better for 95% of the epochs of the selected time periods and for the selected station locations. In addition to HAS, we also examined an additional set of performance parameters, which show similar performance levels between the Galileo, GPS and BeiDou systems. Full article

The BeiDou global navigation satellite system (BDS-3) and Galileo systems both broadcast satellite signals on five frequencies, which can form many observation combinations with dual-frequency ionospheric-free (DFIF) precise point positioning (PPP). This study analyzes the PPP static and kinematic performance of a total of eight different DFIF combinations, including BDS-3’s B1C/B2a, B1C/B3I, B1I/B2b, and B1I/B3I and Galileo’s E1/E5, E1/E6, E1/E5a, and E1/E5b combinations. A 10-day dataset from 60 Multi-GNSS Experiment (MGEX) stations was adopted. The root mean square error (RMSE) of the PPP was tested in the north, east, and up (NEU), horizontal (H), and three-dimensional (3D) components. The PPP accuracy of BDS-3 was comparable with that of Galileo. Both BDS-3 and Galileo signals allow for independent PPP processing both in static and kinematic modes. When the 3D error was used as the evaluation criterion, the order of the combinations in which the positioning accuracy gradually deteriorated was as follows: E1/E5, B1C/B3I, B1I/B2b, E1/E6, B1I/B3I, E1/E5b, E1/E5a, and B1C/B2a; The 3D RMSE values for the best combination, E1/E5, and the worst combination, B1C/B2a, were 1.06 cm and 1.43 cm, respectively; the positioning accuracies of all combinations remained at the level of 1 cm in static mode. In kinematic mode, the order of the combinations in which the PPP accuracy gradually deteriorated was as follows: E1/E5, E1/E5a, E1/E5b, B1I/B2b, B1I/B3I, B1C/B2a, B1C/B3I, and E1/E6. The 3D RMSE values for the best combination, E1/E5, and the worst combination, B1C/B2a, were 3.89 cm and 1.95 cm, respectively. The best results could be achieved with the E1/E5 combination, which outperforms the worst combination, E1/E6, by about 1 cm. Full article
