High-accuracy heading angle is significant for estimating autonomous vehicle attitude. By integrating GNSS (Global Navigation Satellite System) dual antennas, INS (Inertial Navigation System), and a barometer, a GNSS/INS/Barometer fusion method is proposed to improve vehicle heading angle accuracy. An adaptive Kalman filter (AKF) is designed to fuse the INS error and the GNSS measurement. A random sample consensus (RANSAC) method is proposed to improve the initial heading angle accuracy applied to the INS update. The GNSS heading angle obtained by a dual-antenna orientation algorithm is additionally augmented to the measurement variable. Furthermore, the kinematic constraint of zero velocity in the lateral and vertical directions of vehicle movement is used to enhance the accuracy of the measurement model. The heading errors in the open and occluded environment are 0.5418° (RMS) and 0.636° (RMS), which represent reductions of 37.62% and 47.37% compared to the extended Kalman filter (EKF) method, respectively. The experimental results demonstrate that the proposed method effectively improves the vehicle heading angle accuracy. Full article

Real-time and high-precision water level monitoring is crucial for the fields of hydrology, hydraulic engineering, and disaster prevention and control. The most prevalent method for measuring water level is through the use of water level gauges, which can be costly and have limited coverage. In recent years, Global Navigation Satellite System Reflectometry (GNSS-R) technology has emerged as a promising approach for water level monitoring due to its low cost and high coverage. However, a limitation of current GNSS-R technology is the extended time required to record signals, which hinders its potential for real-time application. This paper introduces a novel real-time water level monitoring method based on GNSS dual-antenna attitude measurement and develops a model to invert water level based on baseline vector. This method uses double-difference observations to eliminate errors caused by various factors, such as satellite and receiver clock, and ionospheric and tropospheric delay. To avoid the impact of detecting and correcting cycle slips during real-time operations, a single-epoch calculation method is introduced. In order to verify the stability and reliability of our method, field tests were carried out at Dongshahe Station in Beijing. We obtained water level data with a time resolution of 1 Hz through field experiments. Experimental data collected from 12 May to 8 June 2022 and from 4 July to 8 August 2022 showed good agreement with on-site water gauge measurements, with root mean square errors of 2.77 cm and 2.54 cm, respectively. Experimental results demonstrate that this method can achieve high-precision, high-temporal-resolution water level monitoring. Full article

We present a position and attitude estimation algorithm of moving platforms based on the tightly coupled sensor fusion of low-cost multi baseline GNSS, inertial, magnetic and barometric observations obtained by low-cost sensors and affordable dual-frequency GNSS receivers. The sensor fusion algorithm is realized by an Extended Kalman Filter and estimates the states including GNSS receiver inter-channel biases, integer ambiguities and non-GNSS receiver biases. Tightly coupled sensor fusion increases the reliability of the position and attitude solution in challenging environments such as urban canyons by utilizing the inertial observations in case of GNSS outage. Moreover, GNSS observations can be efficiently used to mitigate IMU sensor drifts. Standard GNSS cycle slips detection methods, such as the application of triple differences or linear combinations such as Melbourne–Wübbena combination and the phase ionospheric residual extended TurboEdit method. However, these techniques are not well suited for the localization in quickly changing environments such as urban canyons. We present a new method of tightly coupled sensor fusion supported by a prediction based cycle slip detection technique, applied to a GNSS setup using three antennas leading to multiple moving baselines on the platform. Thus, not only the GNSS signal properties but also the dynamics of the moving platform are considered in the cycle slip detection. The developed algorithm is tested in an open-sky validation measurement and two sets of measurement in an urban canyon area. The sensor fusion algorithm processes the data sets using the proposed prediction-based cycle slip method, the loss-of-lock indicator-based, and for comparison, the Melbourne–Wübbena and the TurboEdit cycle slip detection methods are also included. The obtained position and attitude estimation results are compared to the internal solution of raw data source GNSS receivers and to the observations of a high-accuracy GNSS/INS unit including a fiber optic gyro. The validation test confirms the proper cycle slip detection in an ideal environment. The more challenging urban canyon test results show the reliability and the accuracy of the proposed method. In the case of the second urban canyon test, the proposed method improved the integer ambiguity resolution success rate by 19% and these results show the lowest horizontal and vertical coordinate distortion in comparison of the linear combination and the loss-of-lock-based cycle slip methods. Full article

In view of the difficulties regarding that airborne navigation equipment relies on imports and the expensive domestic high-precision navigation equipment in the manufacturing field of Chinese navigable aircraft, a dual-antenna GNSS (global navigation satellite system)/MINS (micro-inertial navigation system) integrated navigation system was developed to implement high-precision and high-reliability airborne integrated navigation equipment. First, the state equation and measurement equation of the system were established based on the classical discrete Kalman filter principle. Second, according to the characteristics of the MEMS (micro-electric-mechanical system), the IMU (inertial measurement unit) is not sensitive to Earth rotation to realize self-alignment; the magnetometer, accelerometer and dual-antenna GNSS are utilized for reliable attitude initial alignment. Finally, flight status identification was implemented by the different satellite data, accelerometer and gyroscope parameters of the aircraft in different states. The test results shown that the RMS (root mean square) of the pitch angle and roll angle error of the testing system are less than 0.05° and the heading angle error RMS is less than 0.15° under the indoor static condition. A UAV flight test was carried out to test the navigation effect of the equipment upon aircraft take-off, climbing, turning, cruising and other states, and to verify the effectiveness of the system algorithm. Full article

In complex urban environments, a single Global Navigation Satellite System (GNSS) is often not ideal for navigation due to a lack of sufficient visible satellites. Additionally, the heading angle error of a GNSS/micro-electro-mechanical system–grade inertial measurement unit (MIMU) tightly coupled integration based on the single antenna is large, and the attitude angle, velocity, and position calculated therein all have large errors. Considering the above problems, this paper designs a tightly coupled integration of GNSS/MIMU based on two GNSS antennas and proposes a singular value decomposition (SVD)-based robust adaptive cubature Kalman filter (SVD-RACKF) according to the model characteristics of the integration. In this integration, the high-accuracy heading angle of the carrier is obtained through two antennas, and the existing attitude angle information is used as the observation to constrain the filtering estimation. The proposed SVD-RACKF uses SVD to stabilize the numerical accuracy of the recursive filtering. Furthermore, the three-stage equivalent weight function and the adaptive adjustment factor are constructed to suppress the influence of the gross error and the abnormal state on the parameter estimation, respectively. A set of real measured data was employed for testing and analysis. The results show that dual antennas and dual systems can improve the positioning performance of the integrated system to a certain extent, and the proposed SVD-RACKF can accurately detect the gross errors of the observations and effectively suppress them. Compared with the cubature Kalman filter, the proposed filtering algorithm is more robust, with higher accuracy and reliability of parameter estimation. Full article

Robust and centimeter-level Real-time Kinematic (RTK)-based Global Navigation Satellite System (GNSS) positioning is of paramount importance for emerging GNSS applications, such as drones and automobile systems. However, the performance of conventional single-rover RTK degrades greatly in urban environments due to signal blockage and strong multipath. The increasing use of multiple-antenna/rover configurations for attitude determination in the above precise positioning applications, just as well, allows more information involved to improve RTK positioning performance in urban areas. This paper proposes a dual-antenna constraint RTK algorithm, which combines GNSS measurements of both antennas by making use of the geometric constraint between them. By doing this, the reception diversity between two antennas can be taken advantage of to improve the availability and geometric distribution of GNSS satellites, and what is more, the redundant measurements from a second antenna help to weaken the multipath effect on the first antenna. Particularly, an Ambiguity Dilution of Precision (ADOP)-based analysis is carried out to explore the intrinsic model strength for ambiguity resolution (AR) with different kinds of constraints. Based on the results, a Dual-Antenna with baseline VEctor Constraint algorithm (RTK) is developed. The primary advantages of the reported method include: (1) Improved availability and success rate of RTK, even if neither of the two single-antenna receivers can successfully solve the AR problem; and (2) reduced computational burden by adopting the concept of measurement projection. Simulated and real data experiments are performed to demonstrate robustness and precision of the algorithm in GNSS-challenged environments. Full article

A high-precision navigation system is required for an unmanned vehicle, and the high-precision sensor is expensive. A low-cost, high-precision, dual-antenna Global Navigation Satellite System/Micro-electromechanical Systems-Inertial Navigation System (GNSS/MINS) combination method is proposed. The GNSS with dual antennas provides velocity, position, and attitude angle information as the measurement information is combined with the MINS. By increasing the heading angle, pitch angle, velocity, the accuracy of the integrated system is improved. The Extended Kalman Filtering (EKF) integrated algorithm simulation is designed to verify the feasibility and is realized based on the Field Programmable Gate Array and Advanced RISC Machine (ARM+FPGA) system. Static and dynamic tests were performed using the Synchronous Position, Attitude and Navigation (SPAN-CPT) as a reference system. The results show that the velocity, position, and attitude angle accuracy were improved. The yaw angle and pitch angle accuracy were 0.2° Root Mean Square (RMS) and 0.3° RMS, respectively. The method can be used as a navigation system for the unmanned vehicle. Full article
