The electrical protection of power networks with fault contribution from inverter-based power sources imposes new application challenges that have to be dealt with by protection engineers. This paper describes the development of a study case model of an HVDC-MMC link for testing the protection behaviour of connected converter transformers. The paper summarises the implementation and validation of the converter control as well as enhancements to provide Fault Ride-Through capability and fast fault current injection as required by the German Technical Connection Rules for HVDC. The grid code standard requires positive- and negative-sequence reactive current injection in the case of grid faults. A Doubled Decoupled Synchronous Reference Frame Phase Locked Loop (DDSRF-PLL) for Vector Current Control (VCC) is implemented. Additionally, a Fault Detection and Fault Ride-Through Reference Generator with a Current Limitation strategy is introduced. Though these techniques are well described in the literature, the DDSRF is improved for current control stability. The relationship between the parameters of the PLL and the control, as well as the behaviour of the protection system, are demonstrated. Grid faults with large voltage dips pose a significant challenge to the stability of the control system. Nevertheless, it is shown that with the developed model, it is possible to make general statements about the protection behaviour in an inverter-based environment. Full article

Inverter-based resources (IBRs) exhibit different short-circuit characteristics compared to traditional synchronous generators (SGs). Hence, increased uptake of IBRs in the power system is expected to impact the performance of traditional protective relay schemes—set under the assumption of a SG-dominated power system. Protection engineers need to study these challenges and develop remedial solutions ensuring the effectiveness of system protection under higher levels of IBRs. To address this need, this paper studies the impact of IBRs on a variety of protective relay schemes including line distance protection, memory-polarized zero sequence directional protective relay element, negative sequence quantities-based protection, line current differential protection, phase comparison protection, rate-of-change-of-frequency, and power swing detection. For each protection function, potential misoperation scenarios are identified, and recommendations are provided to address the misoperation issue. The objective is to provide an improved understanding of the way IBRs may negatively impact the performance of traditional protection schemes as a first step towards developing future remedial solutions ensuring effective protection under high share of IBRs. Full article

Wind power is positioned as one of the fastest-growing energy sources today, while also being a mature technology with a strong capacity for creating employment and guaranteeing environmental sustainability. However, the stochastic nature of wind may affect the integration of power plants into power systems and the availability of generation capacity. In this sense, as in the case of conventional power plants, wind power installations should be able to help maintain power system stability and reliability. To help achieve this objective, a significant number of countries have developed so-called grid interconnection agreements. These are designed to define the technical and behavioral requirements that wind power installations, as well as other power plants, must comply with when seeking connection to the national network. These documents also detail the tasks that should be conducted to certify such installations, so these can be commercially exploited. These certification processes allow countries to assess wind turbine and wind power plant simulation models. These models can then be used to estimate and simulate wind power performance under a variety of scenarios. Within this framework, and with a particular focus on the new Spanish grid code, the present paper addresses the validation process of dynamic wind turbine models followed in three countries—Spain, Germany and South Africa. In these three countries, and as a novel option, it has been proposed that these models form part of the commissioning and certification processes of wind power plants. Full article

In renewable energy generation applications, phase locked loop (PLL) is one of the most popular grid synchronization technique. The main objective of PLL is to rapidly and precisely extract phase and frequency especially when the grid voltage is under non-ideal conditions. This motivates the recent development of moving average filters (MAFs) based PLL in a quasi-type-1 system (i.e., QT1-PLL). Despite its success in certain applications, the transient response is still unsatisfactory, mainly due to the fact that the time delay caused by MAFs is still large. This has significantly limited the utilization of QT1-PLL, according to common grid codes such as German and Spanish grid codes. This challenge has been tackled in this paper. The basic idea is to develop a new hybrid filtering stage, consisting of adaptive notch filters (ANFs) and MAFs, arranged at the inner loop of QT1-PLL. Such an idea can greatly improve the transient response of QT1-PLL, owing to the fact that ANFs are utilized to remove the fundamental frequency negative voltage sequence (FFNS) component while other dominant harmonics can be removed by MAFs with a small time delay. By applying the proposed technique, the settling time is reduced to less than one cycle of grid frequency without any degradation in filtering capability. Moreover, the proposed PLL can be easily expanded to handle dc offset rejection. The effectiveness is validated by comprehensive experiments. Full article
