Search Results (40)

Pulse wave velocity (PWV) has been recognised as the gold standard for assessing arterial stiffness and a relevant indicator in diagnosing cardiovascular disease. Conventional approaches can be affected by factors such as the size of the probe, its positioning on the skin with the appropriate angle and magnitude of the incident force, or influenced by optical properties. Aiming at improving the assessment of PWV parameter, an important cardiovascular risk marker, the present study introduces a new arterial pulse wave measurement technique based on measurements of the impedance phase characteristics of giant magneto-impedance (GMI) sensors submitted to slight magnetic field variations caused by the displacement of a small magnetic marker placed on the patient’s skin, whose movement is coordinated by the local pressure wave. The proposed method eliminates the necessity of using probes with mechanical amplification, enhancing spatial resolution and usability in hard-to-reach anatomical regions through a contactless device unaffected by optical parameters. The obtained experimental results indicate the potential of the developed measurement system in measuring arterial pulse waveform and PWV. Full article

Co-based amorphous wires (Co-AWs) are functional materials renowned for their high impedance change rate in magnetic fields and a pronounced giant magnetoimpedance (GMI) effect. In this study, magnetron sputtering (MS) and dip-coating (DC) techniques were employed to fabricate carbon-based nanocoatings aimed at modulating the GMI properties of Co-AWs. The magnetic properties and GMI responses of the composite Co-AWs with carbon-based coatings were comparatively analyzed. The results demonstrate that both methods effectively enhanced the GMI properties of the coated Co-AWs. The DC method emerged as a rapid and efficient approach for forming the coated film, achieving a modest enhancement in GMI performance (10% enhancement). In contrast, the MS technique proved more effective in improving the GMI effect, yielding superior results. Co-AWs coated via Ms exhibited smoother surfaces and reduced coercivity. Notably, the GMI effect increased with the thickness of the sputtered carbon coatings, reaching a maximum GMI effect of 522% (a remarkable 357% enhancement) and a sensitivity of 33.8%/Oe at a coating thickness of 334 nm. The observed trend in the GMI effect with carbon layer thickness corresponded closely to variations in transverse permeability, as determined by vibrating sample magnetometry (VSM). Furthermore, the carbon coating induced changes in the initial quenching stress on the surface of the Co-AWs, leading to alterations in impedance and a significant reduction in the characteristic frequency of the Co-AWs. Our findings provide valuable insights into the modulation of GMI properties in Co-AWs, paving the way for their optimized application in advanced magnetic sensor technologies. Full article

Magnetic nanoparticles are extensively utilized as markers/signal labelling in various biomedical applications. Detecting and distinguishing magnetic signals from similarly sized moving magnetic nanoparticles in microfluidic systems is crucial yet challenging for biosensing. In this study, we have developed an original method to detect and differentiate magnetic signals from moving superparamagnetic (SPM) and ferrimagnetic (FM) nanoparticles of comparable sizes. Our approach utilizes a highly sensitive magnetic-coil-based sensor that harnesses the combined effects of giant magnetoimpedance (GMI) and an LC-resonance circuit, offering performance superior to that of conventional GMI sensors. Iron oxide nanoparticles, which have similar particle sizes but differing coercivities (zero for SPM and non-zero for FM) or similar zero coercivities but differing particle sizes, flow through the magnetic coil at controlled velocities. Their distinct effects are analyzed through changes in the complex impedance of the sensing system. Our findings provide a unique pathway for utilizing SPM and FM nanoparticles as innovative magnetic markers to identify specific biological entities, thereby expanding their potential applications. Full article

We provide new experimental studies of the temperature dependence of the giant magnetoimpedance (GMI) effect and hysteresis loops of Fe-rich and Co-rich amorphous microwires with rather different room temperature magnetic properties and GMI effect features. We observed a remarkable modification of hysteresis loops and magnetic field dependence of the GMI ratio upon heating in both of the studied samples. We observed a noticeable improvement in the GMI ratio and a change in hysteresis loops from rectangular to inclined upon heating in Fe-rich microwire. However, the opposite trend was observed in Co-rich microwire, in which, upon heating, the shape of the hysteresis loop changed from linear to rectangular. Generally, the evolution of the shape of the hysteresis loops during heating correlates with the modification of the dependencies of the GMI ratio ΔZ/Z on the magnetic field. For Co-rich microwire, the double-peak magnetic field dependence changed to single-peak, while for Fe-rich microwire, the opposite tendency was observed. The origin of the observed temperature dependences of the hysteresis loop and the GMI effect is discussed, considering internal stresses’ relaxation during heating, the temperature dependencies of the magnetostriction coefficient, and internal stresses, as well as the Hopkinson effect. Full article

Magnetic microwires with amorphous structures can present a unique combination of excellent magnetic softness and giant magnetoimpedance (GMI) effects together with reduced dimensions and good mechanical properties. Such unique properties make them suitable for various technological applications. The high GMI effect, observed in as-prepared Co-rich microwires, can be further optimized by postprocessing. However, unexpected magnetic hardening and a transformation of the linear hysteresis loop into a rectangular loop with a coercivity on the order of 90 A/m were observed in several Co-rich microwires upon conventional annealing. Several routes to improve magnetic softness and GMI effect in Fe- and Co-rich magnetic microwires are provided. We observed that stress annealing could remarkably improve the magnetic softness and GMI ratio of Co-rich microwires. Thus, almost unhysteretic loops with a coercivity of 2 A/m and a magnetic anisotropy field of about 70 A/m are achieved in Co-rich microwires stress annealed at appropriate conditions. The observed change in hysteresis loops and the GMI effect is explained by stress-annealing-induced anisotropy, which is affected by the stresses applied during annealing and by the annealing temperature. While as-prepared Fe-rich amorphous microwires present a low GMI effect, appropriate postprocessing (annealing and stress annealing) allows for a remarkable GMI ratio improvement (an order of magnitude). The evaluated dependence of the maximum GMI ratio on frequency allows the identification of the optimal frequency band for the studied samples. The origin of stress-annealing-induced anisotropy and related changes in hysteresis loops and the GMI effect are discussed in terms of the relaxation of internal stresses, “back-stresses”, as well as structural anisotropy. Full article

Studying the spatial response of a single-axis magnetometer could be the key parameter to optimize the ultimate performances of magnetic heads of detection. Indeed, the problem of non-orthogonality, misalignment, and 3D spatial response could be improved based on the knowledge of the 3D sensor spatial response. In that way, we have investigated the latter for our giant magneto-impedance (GMI) magnetometer, as a far-field pattern, by using a three-axis Helmholtz coil system. Firstly, we calibrate our device and secondly, we apply a specific 3D magnetic field to obtain this pattern. The latter helps to observe the directional or angular dependence of the sensor sensitivity versus the applied magnetic field, as we exemplified. The results confirm the excellent directivity of our off-diagonal GMI magnetometer. The evaluation of the associated error compared to an ideal vector magnetometer is also given and discussed. Full article

A sensitive non-contact sensing system based on the CoFeNiSiB amorphous ribbon giant magnetoimpedance (GMI) effect is proposed for current testing. The sensing system consists of a GMI probe, a sinusoidal current generator, a voltage follower, a preamplifier, a low-pass filter, and a peak detector. Four different GMI probes derived from amorphous ribbon meanders are designed and fabricated through MEMS processes. GMI probes were driven by a 10 MHz, 5 mA AC current. A permanent magnet was used to provide a bias magnetic field for the probe. The effect of the bias magnetic field on the output DC voltage was investigated. This non-contact current sensing system exhibits good sensitivity and linearity at a bias magnetic field H_bias = 15 Oe. The sensitivity can reach up to 24.2 mV/A in the ±1.5 A range. Full article

As-prepared Fe-rich microwires with perfectly rectangular hysteresis loops present magnetization reversal through fast domain wall propagation, while the giant magnetoimpedance (GMI) effect in Fe-rich microwires is rather low. However, the lower cost of Fe-rich microwires makes them attractive for magnetic sensors applications. We studied the effect of conventional (furnace) annealing and Joule heating on magnetic-propertied domain wall (DW) dynamics and the GMI effect in two Fe microwires with different geometries. We observed that magnetic softness, GMI effect and domain wall (DW) dynamics can be substantially improved by appropriate annealing. Observed experimental results are discussed considering the counterbalance between the internal stresses relaxation and induced magnetic anisotropy associated with the presence of an Oersted magnetic field during Joule heating. Full article

The giant magnetoimpedance effect of multilayered thin films under stress has great application prospects in magnetic sensing, but related studies are rarely reported. Therefore, the giant magnetoimpedance effects in multilayered thin film meanders under different stresses were thoroughly investigated. Firstly, multilayered FeNi/Cu/FeNi thin film meanders with the same thickness were manufactured on polyimide (PI) and polyester (PET) substrates by DC magnetron sputtering and MEMS technology. The characterization of meanders was analyzed by SEM, AFM, XRD, and VSM. The results show that multilayered thin film meanders on flexible substrates also have the advantages of good density, high crystallinity, and excellent soft magnetic properties. Then, we observed the giant magnetoimpedance effect under tensile and compressive stresses. The results show that the application of longitudinal compressive stress increases the transverse anisotropy and enhances the GMI effect of multilayered thin film meanders, while the application of longitudinal tensile stress yields the opposite result. The results provide novel solutions for the fabrication of more stable and flexible giant magnetoimpedance sensors, as well as for the development of stress sensors. Full article

It was observed recently that the giant magnetoimpedance (GMI) effect in Fe-rich glass-coated amorphous microwires with positive magnetostriction can be improved significantly by means of post-annealing. The increase in the GMI is attributed to the induced helical magnetic anisotropy in the surface layer of the microwire, which appears after the annealing. The application of external stresses to the microwire may result in changes in its magnetic structure and affect the GMI response. In this work, we study theoretically the influence of the tensile and torsional stresses on the off-diagonal magnetoimpedance in annealed amorphous microwires with positive magnetostriction. The static magnetization distribution is analyzed in terms of the core–shell magnetic structure. The surface impedance tensor is obtained taking into account the magnetoelastic anisotropy induced by the external stresses. It is shown that the off-diagonal magnetoimpedance response exhibits strong sensitivity to the magnitude of the applied stress. The obtained results may be useful for sensor applications of amorphous microwires. Full article

The giant magneto-impedance (GMI) effect of Co_83.2Fe_5.2Si_8.8B_2.8 ribbons at frequencies of <1 MHz was analyzed. To improve the GMI response, a Joule annealing treatment was conducted with a direct current, and the domain structure of the ribbon surface was investigated via magneto-optical Kerr effect microscopy. The annealed ribbons show larger impedance changes under external magnetic fields, and higher field sensitivity is obtained by certain current annealing treatments. The field sensitivity of 418 and 782%/(kA/m) at 0.2 MHz and 0.8 MHz are achieved after annealing at 0.8 A for 20 min. The annealing treatment under direct electric current induces stress relaxation, and domain rearrangement, and the crystallization process gradually increases with the increasing current density, which gives rise to anisotropic reformation. The release of stresses due to Joule heating below the crystallization temperature causes the homogenous distribution of stress induced by rapid solidification and influences the elastic anisotropy, causing the domain structures to become much more regular. The crystallization, along with the precipitation of hard magnetic phases, increases the crystal anisotropy and induces the intense magnetic coupling action. Consequently, the magnetic domains in the annealed ribbons are rearranged with reformed anisotropy by Joule annealing heat and by the transverse magnetic field induced by the current. The irregular domains, with complex anisotropy in the as-cast ribbons corresponding to the weak GMI response, are transformed into regular and strip-like domains, with transverse easy magnetization after annealing at 0.4 A. After annealing at 0.8 A, the domains are further transformed into fine axial fingerprint-like domains, which are much more sensitive to the change in the axial external magnetic field, allowing for the best GMI response. These results indicate that the Joule annealing treatment is an optional method to optimize the soft magnetic properties and the GMI effect of these Co-rich ribbons at low frequencies. Full article

A frequency downscaling technique for enhancing the accuracy of analog lock-in amplifier (LIA) architectures in giant magneto-impedance (GMI) sensor applications is presented in this paper. As a proof of concept, the proposed method is applied to two different LIA topologies using, respectively, analog and switching-based multiplication for phase-sensitive detection. Specifically, the operation frequency of both the input and the reference signals of the phase-sensitive detector (PSD) block of the LIA is reduced through a subsampling process using sample-and-hold (SH) circuits. A frequency downscaling from 200 kHz, which is the optimal operating frequency of the employed GMI sensor, to 1 kHz has been performed. In this way, the proposed technique exploits the inherent advantages of analog signal multiplication at low frequencies, while the principle of operation of the PSD remains unaltered. The circuits were assembled using discrete components, and the frequency downscaling proposal was experimentally validated by comparing the measurement accuracy with the equivalent conventional circuits. The experimental results revealed that the error in the signal magnitude measurements was reduced by a factor of 8 in the case of the analog multipliers and by a factor of 21 when a PSD based on switched multipliers was used. The error in-phase detection using a two-phase LIA was also reduced by more than 25%. Full article

Herein, we have presented the giant magneto-impedance (GMI) effect, microstructure and surface domain structure of the Co-Fe-based amorphous microwires after liquid medium—anhydrous ethanol Joule annealing (AJA). The AJA technique can effectively release the radial stress and induce large a circumferential magnetic field by changing the Joule heat transfer and the circumferential domain, to further tune the GMI performance of microwire. The linear response fields (0~3.5 Oe), the high sensitivity of 124.1%/Oe and the high GMI ratio make the microwire as promising materials for the miniaturized GMI sensors. The GMI ratios of [ΔZ/Z₀]_max(%) and [ΔZ/Z_max]_max(%) increase the near-linearly to 201.9% and 200.5%, respectively, for the 250 mA anhydrous ethanol Joule annealed wires. Moreover, a linear response to H_ex (ranging from 3.5 to 25 Oe, or more) is observed, which bears the potential in fabricating bi-sensors. Full article

In this paper, the giant magneto-impedance (GMI) model of a cylindrical alloy fiber was established by the Maxwell equation and Landau–Lifshitz equation to simulate the influence of physical parameters of cylindrical alloy fiber on GMI under different control parameters. MATLAB was employed to calculate the magneto-impedance of cylindrical fibers and draw its curves. We found that when the anisotropic equivalent field of the fiber changes from 10Oe to 50Oe, the peak position of the GMI ratio also moves from about 10Oe to 50Oe, and the peak value gradually increases from 100% to 300%. The GMI ratio increased rapidly with the decrease in the magnetization damping coefficient. Our findings could further guide the design of supersensitive micro GMI sensors by optimally regulating the magnetic damping coefficient, the angle between the external magnetic field and easy axis and the anisotropic equivalent field of cylindrical alloy fibers. Full article

A small DC magnetic field can induce an enormous response in the impedance of a soft magnetic conductor in various forms of wire, ribbon, and thin film. Also known as the giant magnetoimpedance (GMI) effect, this phenomenon forms the basis for the development of high-performance magnetic biosensors with magnetic field sensitivity down to the picoTesla regime at room temperature. Over the past decade, some state-of-the-art prototypes have become available for trial tests due to continuous efforts to improve the sensitivity of GMI biosensors for the ultrasensitive detection of biological entities and biomagnetic field detection of human activities through the use of magnetic nanoparticles as biomarkers. In this review, we highlight recent advances in the development of GMI biosensors and review medical devices for applications in biomedical diagnostics and healthcare monitoring, including real-time monitoring of respiratory motion in COVID-19 patients at various stages. We also discuss exciting research opportunities and existing challenges that will stimulate further study into ultrasensitive magnetic biosensors and healthcare monitors based on the GMI effect. Full article
