The inspection of encapsulated MEMS devices typically relies on destructive methods which compromise the structural integrity of samples. In this work, we present the concept and preliminary experimental validation of a laser scanning setup to non-destructively inspect silicon-encapsulated microstructures by measuring small variations of transmitted light intensity in the near-infrared spectrum. This method does not require any particular sample preparation or damage, and it is based on the higher degree of transparency of silicon in the near-infrared and the transmission contrast resulting from the Fresnel reflections observed at the interfaces between the different materials of the MEMS device layers. We characterise the small feature resolving performance of the laser scanning setup using standard targets, and experimentally demonstrate the inspection of a MEMS latching device enclosed within silicon covers, comparing the contrast measurements with theoretical predictions. Full article

The aim of this research is to investigate the potential of Raman and FT-IR spectroscopy as well as mathematical linear and non-linear models as a tool for the discrimination of different seed varieties of paprika, tomato, and lettuce species. After visual inspection of spectra, pre-processing was applied in the following combinations: (1) smoothing + linear baseline correction + unit vector normalization; (2) smoothing + linear baseline correction + unit vector normalization + full multiplicative scatter correction; (3) smoothing + baseline correction + unit vector normalization + second-order derivative. Pre-processing was followed by Principal Component Analysis (PCA), and several classification methods were applied after that: the Support Vector Machines (SVM) algorithm, Partial Least Square Discriminant Analysis (PLS-DA), and Principal Component Analysis-Quadratic Discriminant Analysis (PCA-QDA). SVM showed the best classification power in both Raman (100.00, 99.37, and 92.71% for lettuce, paprika, and tomato varieties, respectively) and FT-IR spectroscopy (99.37, 92.50, and 97.50% for lettuce, paprika, and tomato varieties, respectively). Moreover, our novel approach of merging Raman and FT-IR spectra significantly contributed to the accuracy of some models, giving results of 100.00, 100.00, and 95.00% for lettuce, tomato, and paprika varieties, respectively. Our results indicate that Raman and FT-IR spectroscopy coupled with machine learning could be a promising tool for the rapid and rational evaluation and management of genetic resources in ex situ and in situ seed collections. Full article

Precision glass molding (PGM) is an efficient process used for manufacturing high-precision micro lenses with aspheric surfaces, which are key components in high-resolution systems, such as endoscopes. In PGM, production costs are significantly influenced by the lifetimes of elaborately manufactured molding tools. Protective coatings are applied to the molding tools to withstand severe cyclic thermochemical and thermomechanical loads in the PGM process and, in this way, extend the life of the molding tools. This research focuses on a new method which combines metallographic analysis and finite element method (FEM) simulation to study the interaction of three protective coatings—diamond-like carbon (DLC), PtIr and CrAlN—each in contact with the high Abbe number glass material S-FPM3 in a precision glass molding process. Molding tools are analyzed metallographically using light microscopy, white light interferometry, scanning electron microscopy (SEM), and energy dispersive X-ray spectroscopy (EDX). The results show that the DLC coating improved process durability more than the PtIr and CrAlN coatings, in which the phenomenon of coating delamination and glass adhesion can be observed. To identify potential explanations for the metrological results, FEM is applied to inspect the stress state and stress distribution in the molding tools during the molding process. Full article

Osteoarthritis (OA) is a degenerative disease, and there is currently no effective medicine to cure it. Early prevention and treatment can effectively reduce the pain of OA patients and save costs. Therefore, it is necessary to diagnose OA at an early stage. There are various diagnostic methods for OA, but the methods applied to early diagnosis are limited. Ordinary optical diagnosis is confined to the surface, while laboratory tests, such as rheumatoid factor inspection and physical arthritis checks, are too trivial or time-consuming. Evidently, there is an urgent need to develop a rapid nondestructive detection method for the early diagnosis of OA. Vibrational spectroscopy is a rapid and nondestructive technique that has attracted much attention. In this review, near-infrared (NIR), infrared, (IR) and Raman spectroscopy were introduced to show their potential in early OA diagnosis. The basic principles were discussed first, and then the research progress to date was discussed, as well as its limitations and the direction of development. Finally, all methods were compared, and vibrational spectroscopy was demonstrated that it could be used as a promising tool for early OA diagnosis. This review provides theoretical support for the application and development of vibrational spectroscopy technology in OA diagnosis, providing a new strategy for the nondestructive and rapid diagnosis of arthritis and promoting the development and clinical application of a component-based molecular spectrum detection technology. Full article

The new progressive smart technologies announced in the fourth industrial revolution in aviation—Aviation 4.0—represent new possibilities and big challenges in aircraft maintenance processes. The main benefit of these technologies is the possibility to monitor, transfer, store, and analyze huge datasets. Based on analysis outputs, there is a possibility to improve current preventive maintenance processes and implement predictive maintenance processes. These solutions lower the downtime, save manpower, and extend the components’ lifetime; thus, the maximum effectivity and safety is achieved. The article deals with the possible implementation of an unmanned aerial vehicle (UAV) with an infrared camera and Radio Frequency Identification (RFID) as two of the smart hangar technologies for airframe condition monitoring. The presented implementations of smart technologies follow up the specific results of a case study focused on trainer aircraft failure monitoring and its impact on maintenance strategy changes. The case study failure indexes show the critical parts of aircraft that are subjected to damage the most. The aim of the article was to justify the need for thorough monitoring of critical parts of the aircraft and then analyze and propose a more effective and the most suitable form of technical condition monitoring of aircraft critical parts. The article describes the whole process of visual inspection performed by an unmanned aerial vehicle (UAV) with an IR camera and its related processes; in addition, it covers the possible usage of RFID tags as a labeling tool supporting the visual inspection. The implementations criteria apply to the repair and overhaul small aircraft maintenance organization, and later, it can also increase operational efficiency. The final suggestions describe the possible usage of proposed solutions, their main benefits, and also the limitations of their implementations in maintenance of trainer aircraft. Full article

Inductive thermography is a non-destructive testing method, whereby the specimen is slightly heated with a short heating pulse (0.1–1 s) and the temperature change on the surface is recorded with an infrared (IR) camera. Eddy current is induced by means of high frequency (HF) magnetic field in the surface ‘skin’ of the specimen. Since surface cracks disturb the eddy current distribution and the heat diffusion, they become visible in the IR images. Head checks and squats are specific types of damage in railway rails related to rolling contact fatigue (RCF). Inductive thermography can be excellently used to detect head checks and squats on rails, and the method is also applicable for characterizing individual cracks as well as crack networks. Several rail pieces with head checks, with artificial electrical discharge-machining (EDM)-cuts and with a squat defect were inspected using inductive thermography. Aiming towards rail inspection of the track, 1 m long rail pieces were inspected in two different ways: first via a ‘stop-and-go’ technique, through which their subsequent images are merged together into a panorama image, and secondly via scanning during a continuous movement of the rail. The advantages and disadvantages of both methods are compared and analyzed. Special image processing tools were developed to automatically fully characterize the rail defects (average crack angle, distance between cracks and average crack length) in the recorded IR images. Additionally, finite element simulations were used to investigate the effect of the measurement setup and of the crack parameters, in order to optimize the experiments. Full article

Three-dimensional (3D) imaging and infrared (IR) thermography are powerful tools in many areas in engineering and sciences. Their joint use is of great interest in the buildings sector, allowing inspection and non-destructive testing of elements as well as an evaluation of the energy efficiency. When dealing with large and complex structures, as buildings (particularly historical) generally are, 3D thermography inspection is enhanced by Unmanned Aerial Vehicles (UAV—also known as drones). The aim of this paper is to propose a simple and cost-effective system for aerial 3D thermography of buildings. Special attention is thus payed to instrument and reconstruction software choice. After a very brief introduction to IR thermography for buildings and 3D thermography, the system is described. Some experimental results are given to validate the proposal. Full article

The aim of this study was to investigate the suitability of electrical impedance spectroscopy (EIS) as a nondestructive quality monitoring tool of aged beef, focusing on the development of accurate electrical indexes. The relationship between the electrical indexes derived from the impedance ratio (IR) or admittance was established. Quality parameters such as the drip loss, cooking loss, water-holding capacity, and shear force of beef loin wet-aged for 0 to 21 days were evaluated to develop the new electrical indexes. In addition, the predictive capability of EIS was trialed using different indexes and frequencies. This study revealed that the most appropriate choice is to use electrical parameters at a lower frequency to determine or predict the physical properties of aged beef. The IR was derived from the ratio between the electrical impedance measured parallel to and perpendicular to the muscle fibers in the low-frequency domain. Furthermore, the degradation of muscle fibers was observed by optical microscopy. The investigated electrical indexes had higher correlations with shear force (0.52 ≤ R² ≤ 0.58) compared to correlations with aging days (0.34 ≤ R² ≤ 0.39). The findings of the study could be used for meat quality inspection in slaughterhouses as well as during aging. Full article

Digital tools as 3D (three-dimensional) modelling and imaging techniques are having an increasing role in many applicative fields, thanks to some significative features, such as their powerful communicative capacity, versatility of the results and non-invasiveness. These properties are very important in cultural heritage, and modern methodologies provide an efficient means for analyzing deeply and virtually rendering artworks without contact or damage. In this paper, we present two laser scanner prototypes based on the Imaging Topological Radar (ITR) technology developed at the ENEA Research Center of Frascati (RM, Italy) to obtain 3D models and IR images of medium/large targets with the use of laser sources without the need for scaffolding and independently from illumination conditions. The RGB-ITR (Red Green Blue-ITR) scanner employs three wavelengths in the visible range for three-dimensional color digitalization up to 30 m, while the IR-ITR (Infrared-ITR) system allows for layering inspection using one IR source for analyses. The functionalities and operability of the two systems are presented by showing the results of several case studies and laboratory tests. Full article
