This work presents a high-fidelity two-way coupled Fluid-Structure Interaction (FSI) simulation framework for wind turbine blades, developed using the Arbitrary Hybrid Turbulence Modelling (AHTM) implemented through Very Large Eddy Simulation (VLES) in the DAFoam solver. By integrating VLES with the Toolkit for the Analysis of Composite Structures (TACS) structural solver via the OpenMDAO/MPhys framework, this work aims to accurately model the complex aeroelastic characteristics of wind turbines, specifically focusing on the NREL Phase VI wind turbine. The numerical model accounts for the effects of transient, turbulent, and unsteady aerodynamic loading, incorporating the impact of structural deflections. A comparison of the calculated results with experimental data demonstrates strong agreement in key performance metrics, including blade tip displacements, power output, and pressure distribution. This alignment confirms that the proposed model is effective at predicting wind turbine performance. One of the significant advantages of this study is the integration of advanced turbulence modeling with shell element structural analysis, enhancing the design and performance predictions of modern wind turbines. Although computationally intensive, this approach marks a significant advancement in accurately simulating the aeroelastic response of turbines, paving the way for optimized and more efficient wind energy systems. Full article

Hydrogen-powered aircraft constitute a transformative innovation in aviation, motivated by the imperative for sustainable and environmentally friendly transportation solutions. This paper aims to concentrate on the design of hydrogen powertrains employing a system approach to propose representative design models for distribution and propulsion systems. Initially, the requirements for powertrain design are formalized, and a use-case-driven analysis is conducted to determine the functional and physical architectures. Subsequently, for each component pertinent to preliminary design, an analytical model is proposed for multidisciplinary analysis and optimization for powertrain sizing. A double-wall pipe model, incorporating foam and vacuum multi-layer insulation, was developed. The internal and outer pipes sizing were performed in accordance with standards for hydrogen piping design. Valves sizing is also considered in the present study, following current standards and using data available in the literature. Furthermore, models for booster pumps to compensate pressure drop and high-pressure pumps to elevate pressure at the combustion chamber entrance are proposed. Heat exchanger and evaporator models are also included and connected to a burning hydrogen engine in the sizing process. An optimal liner pipe diameter was identified, which minimizes distribution systems weight. We also expect a reduction in engine length and weight while maintaining equivalent thrust. Full article

Electric vertical takeoff and landing (eVTOL) aircraft attract attention due to their unique characteristics of reduced noise, moderate pollutant emission, and lowered operating cost. However, the benefits of electric vehicles, including eVTOL aircraft, are critically challenged by the energy density of batteries, which prohibit long-distance tasks and broader applications. Since the takeoff process of eVTOL aircraft demands excessive energy and couples multiple subsystems (such as aerodynamics and propulsion), multidisciplinary analysis and optimization (MDAO) become essential. Conventional MDAO, however, iteratively evaluates high-fidelity simulation models, making the whole process computationally intensive. Surrogates, in lieu of simulation models, empower efficient MDAO with the premise of sufficient accuracy, but naive surrogate modeling could result in an enormous training cost. Thus, this work develops a twin-generator generative adversarial network (twinGAN) model to intelligently parameterize takeoff power and wing angle profiles of an eVTOL aircraft. The twinGAN-enabled surrogate-based takeoff trajectory design framework was demonstrated on the Airbus $A^3$ Vahana aircraft. The twinGAN provisioned two-fold dimensionality reductions. First, twinGAN generated only realistic trajectory profiles of power and wing angle, which implicitly reduced the design space. Second, twinGAN with three variables represented the takeoff trajectory profiles originally parameterized using 40 B-spline control points, which explicitly reduced the design space while maintaining sufficient variability, as verified by fitting optimization. Moreover, surrogate modeling with respect to the three twinGAN variables, total takeoff time, mass, and power efficiency, reached around 99% accuracy for all the quantities of interest (such as vertical displacement). Surrogate-based, derivative-free optimizations obtained over 95% accuracy and reduced the required computational time by around 26 times compared with simulation-based, gradient-based optimization. Thus, the novelty of this work lies in the fact that the twinGAN model intelligently parameterized trajectory designs, which achieved implicit and explicit dimensionality reductions. Additionally, twinGAN-enabled surrogate modeling enabled the efficient takeoff trajectory design with high accuracy and computational cost reduction. Full article

During this research, aerodynamic shape optimization is conducted on the Ahmed body with the drag coefficient as the objective function and the ramp shape as the design variable, while aero-structural optimization is conducted on NACA 0012 to reduce the drag coefficient for the aerodynamic performance with the shape as the design variable while reducing structural mass with the thickness of the panels as the design variables. This is accomplished through a gradient-based optimization process and coupled finite element and computational fluid dynamics (CFD) solvers under fluid–structure interaction (FSI). In this study, DAFoam (Discrete Adjoint with OpenFOAM for High-fidelity Multidisciplinary Design Optimization) and TACS (Toolkit for the Analysis of Composite Structures) are integrated to optimize the aero-structural design of an airfoil concurrently under the FSI condition, with TACS and DAFoam as coupled structural and CFD solvers integrated with a gradient-based adjoint optimization solver. One-way coupling between the fluid and structural solvers for the aero-structural interaction is adopted by using Mphys, a package that standardizes high-fidelity multiphysics problems in OpenMDAO. At the end of the paper, we compare and discuss our findings in the context of existing research, specifically highlighting previous results on the aerodynamic and aero-structural optimization of wind turbine blades. Full article

This study presents an aerostructural optimization process for wind turbine blades aimed at enhancing the turbine’s performance. The optimization framework integrates DAFoam as the computational fluid dynamics (CFD) solver, TACS as the finite element method (FEM) solver, Mphys for fluid–structure coupling, and SNOPT as the optimizer within the OpenMDAO framework. The objective is to simultaneously increase the torque generated by the wind turbine while decreasing the mass of the blade, thereby improving its efficiency. The design variables in this optimization process are the blade shape and panel thickness. The aerodynamic objective function is torque, a key performance indicator for wind turbine efficiency. The structural objective function is the blade mass, as reducing mass is essential to minimize material and manufacturing costs. The optimization process utilizes the integrated capabilities of DAFoam, TACS, Mphys, and SNOPT to iteratively evaluate and modify the blade shape and panel thickness. The OpenMDAO framework facilitates seamless communication between the solvers and the optimizer, ensuring a well-coordinated, efficient optimization process. The results of the optimization show a 6.78% increase in torque, which indicates a significant improvement in the wind turbine’s energy production capacity. Additionally, a 4.22% decrease in blade mass demonstrates a successful reduction in material usage without compromising structural integrity. These findings highlight the potential of the proposed aerostructural optimization process to enhance the performance and cost-effectiveness of wind turbine blades, contributing to the advancement of sustainable energy solutions. This work represents the first attempt to implement DAFoam for wind turbine aerostructural design optimization. Full article

The aircraft environmental control system (ECS) is the second-highest fuel consumer system, behind the propulsion system. To reduce fuel consumption, one research direction intends to replace conventional aircraft with more electric aircraft. Thus, new electric architectures have to be designed for each system, such as for the ECS. In this paper, an electric ECS is modeled and then sized and optimized for different sizing scenarios with the aim of minimizing fuel consumption at the aircraft level. For the system and for each component, such as air inlets and heat exchangers, parametric models are developed to allow the prediction of relevant characteristics. These models, developed in order to be adapted to aircraft design issues, are of different types, such as scaling laws and surrogate models. They are then assembled to build a preliminary sizing procedure for the ECS by using a multidisciplinary design analysis and optimization (MDAO) formulation. Results show that the ECS design is highly dependent on the sizing scenario considered. An approach to size the ECS globally with respect to all the sizing scenarios leads to an ECS that accounts for around 200 N of drag, 190 kW of electric power, and 1500 kg of mass for the CeRAS aircraft. Full article

The market of solar-powered Unmanned Aerial Vehicles (UAVs) for defence purposes and drone services is expected to grow by a factor of more than 2 in the next decade. From an aircraft design perspective, the main challenge is the scalability of the proposed architectures, which is needed to increase the payload capabilities. Beside some successful examples of wing-tail UAVs, some newcomers are developing prototypes with tandem-wing architectures, hence enlarging the possible design. The present paper aims to introduce a further step in this direction, taking also the box-wing architecture into account to show how the presence of wing tip joiners can provide benefits from the aeroelastic point of view. UAVs with take-off mass within 25 kg are considered and the main tools adopted are presented. These are an in-house developed Multi-Disciplinary Analysis and Optimization (MDAO) code called SD2020 and the open source aeroelastic code ASWING, both presented together with an assessment of their accuracy by means of higher fidelity numerical results. SD2020 results are presented for the case of small box-wing solar UAVs optimized to achieve the longest endurance, focusing on the strategy implemented to achieve feasible solutions under an assigned set of constraints. Further results are presented for comparable box-wing and tandem-wing UAVs from both the aerodynamic and aeroelastic standpoints. Whereas the aerodynamic advantages introduced by the box-wing are marginal, significant advantages result from the aeroelastic analyses which indicate that, if the joiners are removed from the box-wing configuration, safety margin from flutter speed is halved and the bending-torsion divergence occurs at relatively low speed values. Full article

The use of unmanned aerial vehicles (UAVs) has seen a significant increase over time in several industries such as defense, healthcare, and agriculture to name a few. Their affordability has made it possible for industries to venture and invest in UAVs for both research and commercial purposes. In spite of their recent popularity; there remain a number of difficulties in the design representation of UAVs, including low image analysis, high cost, and time consumption. In addition, it is challenging to represent systems of systems that require multiple UAVs to work in cooperation, sharing resources, and complementing other assets on the ground or in the air. As a means of compensating for these difficulties; in this study; we use a model-based systems engineering (MBSE) approach, in which standardized diagrams are used to model and design different systems and subsystems of UAVs. SysML is widely used to support the design and analysis of many different kinds of systems and ensures consistency between the design of the system and its documentation through the use of an object-oriented model. In addition, SysML supports the modeling of both hardware and software, which will ease the representation of both the system’s architecture and flow of information. The following paper will follow the Magic Grid methodology to model a UAV system across the SysML four pillars and integration of SysML model with external script-based simulation tools, namely, MATLAB and OpenMDAO. These pillars are expressed within standard diagram views to describe the structural, behavior, requirements, and parametric aspect of the UAV. Finally, the paper will demonstrate how to utilize the simulation capability of the SysML model to verify a functional requirement. Full article

To reduce the environmental impact of aviation, aircraft manufacturers develop novel aircraft configurations and investigate advanced systems technologies. These new technologies are complex and characterized by electrical or hybrid-electric propulsion systems. Ensuring that these complex architectures are safe is paramount to enabling the certification and entry into service of new aircraft concepts. Emerging techniques in systems architecting, such as using model-based systems engineering (MBSE), help deal with such complexity. However, MBSE techniques are currently not integrated with the overall aircraft conceptual design, using automated multidisciplinary design analysis and optimization (MDAO) techniques. Current MDAO frameworks do not incorporate the various aspects of system safety assessment. The industry is increasingly interested in Model-Based Safety Assessment (MBSA) to improve the safety assessment process and give the safety engineer detailed insight into the failure characteristics of system components. This paper presents a comprehensive framework to introduce various aspects of safety assessment in conceptual design and MDAO, also considering downstream compatibility of the system architecting and safety assessment process. The presented methodology includes specific elements of the SAE ARP4761 safety assessment process and adapts them to the systems architecting process in conceptual design. The proposed framework also introduces a novel safety-based filtering approach for large system architecture design spaces. The framework’s effectiveness is illustrated with examples from applications in recent collaborative research projects with industry and academia. The work presented in this paper contributes to increasing maturity in conceptual design studies and enables more innovation by opening the design space while considering safety upfront. Full article

The MDAO framework has become an essential part of almost all fields, apart from mechanical, transportation, and aerospace industries, for efficient energy conversion or otherwise. It enables rapid iterative interaction among several engineering disciplines at various fidelities using automation tools for design improvement. An advanced framework from low to high fidelity is developed for ducted and unducted turbomachinery blade designs. The parametric blade geometry tool is a key feature which converts low-fidelity results into 3D blade shapes and can readily be used in high-fidelity multidisciplinary simulations as part of an optimization cycle. The geometry generator and physics solvers are connected to DAKOTA, an open-source optimizer with parallel computation capability. The entire cycle is automated and new design iterations are generated with input parameter variations controlled by DAKOTA. Single- and multi-objective genetic algorithm and gradient method-based optimization cases are demonstrated for various applications. B-splines are used to define smooth perturbation of parametric variables chordwise and spanwise of the blade. The ability to create parametric 3D blade shapes quickly from low-fidelity analyses with advanced control is demonstrated to be unique and enables a rapid 3D design cycle. Non-intuitive designs are feasible in this framework and designers can really benefit from parametric geometry manipulation. Optimization at each fidelity is realized through automation. As part of the multidisciplinary analysis, 3D structural analysis is also performed using the unidirectional fluid–structure interaction for a few cases with imported pressure loads from the 3D RANS solution. Examples of axial turbofans, compressor rotors, turbines, radial compressors, propellers, wind and hydrokinetic turbines are demonstrated to prove generality. Full article

Design modifications of the blade inner structure, targeted at reducing design-driving extreme loads due to storm conditions, are assessed in the present paper. Under survival wind speeds, the lack of sufficient aerodynamic damping in the edgewise direction is responsible for excessive stall-induced vibrations that usually drive wind turbine blade design loads. The modifications considered in the work are (i) a non-symmetric increase in the thickness of the uniaxial and tri-axial material on the suction and pressure side of the blade sections, (ii) a shift in the spar caps in opposite directions and (iii) the ply-angle re-orientation of the laminates on the spar caps. The first two design interventions aim at increasing the damping of the low-damped edgewise modes in the idling rotor, while the third aims at reducing the fatigue and ultimate loads in normal operation. The design parameters in the problem are determined on the basis of a multidisciplinary optimization (MDAO) process, which minimizes the levelized cost of energy (LCoE). The in-house integrated optimization tool employed in the present study combines: (i) a servo-aero-elastic analysis tool for calculating ultimate loads and power yield, (ii) a cross-sectional analysis tool for obtaining structural properties and stress distributions in the modified blades and (iii) a cost model of the overall wind turbine to evaluate the LCoE. Full article

Developing modern products involves numerous domains (controlling, production, engineering, etc.) and disciplines (mechanics, electronics, software, etc.). The products have become increasingly complex while their time to market has decreased. These challenges can be overcome by Model-Based Systems Engineering (MBSE), where all development data (requirements, architecture, etc.) is stored and linked in a system model. In an MBSE system model, product requirements at the system level can lead to numerous technical variants with conflicting objectives at the parameter level. To determine the best technical variants or tradeoffs, Multidisciplinary Analysis and Optimization (MDAO) is already being used today. Linking MBSE and MDAO allows for mutually beneficial synergies to be expected that have not yet been fully exploited. In this paper, a new approach to link MBSE and MDAO is proposed. The novelty compared to existing approaches is the reuse of existing MBSE system model data. Models developed during upstream design and test activities already linked to the MBSE system model were integrated into an MDAO problem. Benefits are reduced initial and reconfiguration efforts and the resolution of the MDAO black-box behavior. For the first time, the MDAO problem was modeled as a workflow using activity diagrams in the MBSE system model. For a given system architecture, this workflow finds the design variable values that allow for the best tradeoff of objectives. The structure and behavior of the workflow were formally described in the MBSE system model with SysML. The presented approach for linking MBSE and MDAO is demonstrated using an example of an electric coolant pump. Full article

In the context of reducing the environmental footprint of tomorrow’s aviation, Distributed Electric Propulsion (DEP) has become an increasingly interesting concept. With the strong coupling between disciplines that this technology brings forth, multiple benefits are expected for the overall aircraft design. These interests have been observed not only in the aerodynamic properties of the aircraft but also in the structural design. However, current statistical models used in conceptual design have shown limitations regarding the benefits and challenges coming from these new design trends. As for other methods, they are either not adapted for use in a conceptual design phase or do not cover CS-23 category aircraft. This paper details a semi-analytical methodology compliant with the performance-based certification criteria presented by the European Union Aviation Safety Agency (EASA) to predict the structural mass breakdown of a wing. This makes the method applicable to any aircraft regulated by EASA CS-23. Results have been validated with the conventional twin-engine aircraft Beechcraft 76, the innovative NASA X-57 Maxwell concept using DEP, and the commuter aircraft Beechcraft 1900. Full article

This paper proposes a feasibility study concerning a large turboprop aircraft to be used as a lower environmental impact solution to current regional jets operated on short/medium hauls. An overview of this market scenario highlights that this segment is evenly shared between regional turboprop and jet aircraft. Although regional jets ensure a large operative flexibility, they are usually not optimized for short missions with a negative effect on block fuel and environmental impact. Conversely, turboprops represent a greener solution but with reduced passenger capacity and speed. Those aspects highlight a slot for a new turboprop platform coupling higher seat capacity, cruise speed and design range with a reduced fuel consumption. This platform should operate on those ranges where neither jet aircraft nor existing turboprops are optimized. This work compares three different solutions: a high-wing layout with under-wing engines installation and both two- and three-lifting-surface configurations with low-wing and tail tips-mounted engines. For each concept, a multi-disciplinary optimization was performed targeting the minimum block fuel on a 1600 NM mission. Optimum solutions were compared with both a regional jet such as the Airbus A220-300 operated on 1600 NM and with a jet aircraft specifically designed for this range. Full article
