Search Results (64)

Recently, camera sensors have been widely used in a variety of applications, including advanced driver assistance systems (ADASs), surveillance systems, and unmanned aerial vehicles (UAVs). These sensors are often integrated with intelligent algorithms to automatically analyze information and perform specific functions. However, during rainy weather, droplets on the camera lens surface can obstruct the view, leading to degraded image quality and reduced algorithm performance. This paper quantitatively evaluates the effect of droplet contamination on image quality and object detection performance. Image quality degradation was analyzed using the modulation transfer function (MTF), with droplet volume and number as variables. Results show that the MTF50 decreased by up to 80% when the droplet volume reached 10 μL. To assess the effect on object detection, performance changes were evaluated across different detection algorithms. The findings reveal that droplet contamination can reduce the detection performance of small objects by up to 90%, as measured by the mean average precision (mAP) metric. Furthermore, degradation was more severe on hydrophilic surfaces compared to hydrophobic ones. This study demonstrates that droplet characteristics such as volume, number, and shape significantly influence both image quality and object detection performance. It provides critical insights into selecting appropriate camera lens materials by comparing hydrophilic and hydrophobic surfaces while also highlighting the susceptibility of intelligent algorithms to environmental factors and underscoring the importance of effective cleaning techniques. Full article

Background/Objectives: Eccentric loading during landing is considered a key factor in the development of patellar tendinopathy and is associated with stiff landings and patellar tendinopathy. This study aims to investigate the relationship between tendon structure, presence of pain, and sex differences in landing kinematics and kinetics during countermovement jumps (CMJ) and tuck jump tests (TJT) in professional volleyball players. Methods: Professional volleyball players aged 18 to 30 years old (14 females and 25 males) participated in a cross-sectional study. Data included the Victorian Institute of Sport Assessment Patellar Tendon (VISA-P) questionnaire; patellar tendon ultrasound characterization tissue (UTC) scans, in order to identify groups with misaligned tendon fibers (MTF) or aligned tendon fibers (ATF); and biomechanical assessments for CMJ and TJT. The joint angle (JA) at the lower limb was measured at peak ground reaction force (peak_vGRF) and maximal knee flexion (max_KF). A general linear model was used to evaluate joint JA differences between tendon alignment, pain, and sex variables. Sample t-tests compared peak_vGRF, load time, load rate, and area based on tendon alignment, pain presence, sex, and jump. The statistical significance of p-value is >0.05, and the effect size (ES) was also calculated. Results: The MTF group revealed decreased knee JA during TJT at peak_vGRF (p = 0.01; ES = −0.66) and max_KF (p = 0.02; ES = −0.23). The presence of pain was associated with increased JA during the CMJ, particularly at peak_vGRF and max_KF for trunk, hip, and ankle joints. Females showed decreased peak_vGRF than males. Landing with misaligned tendon fibers showed longer load times compared to aligned tendon fibers (p = 0.021; ES = −0.80). The TJT exhibited a greater load rate than the CMJ (p = 0.00; ES = −0.62). Conclusions: Pain is a critical factor influencing greater JA during landing, particularly at the trunk, hip, and ankle joints in CMJ. Misaligned tendon fibers compromise landing dynamics by increasing trunk JA during TJT. Kinetics varied significantly by sex and jump type, while pain and tendon structure revealed limited differences. Full article

In the development, evaluation, and application of medical flat-panel detectors, the modulation transfer function (MTF) is crucial, as it reflects the device’s ability to restore detailed information. Medical flat-panel detectors encompass both image data acquisition and digitization processes, and detectors with varying pixel sizes exhibit differing capabilities for observing details. Accurately quantifying MTF is a critical challenge. The complexity of MTF calculation, combined with unclear principles and details, may result in erroneous outcomes, thereby misleading research and decision-making processes. This paper presents an improved MTF oversampling method based on the slit model. MTF testing is conducted under various sample conditions and using different focal spot diameters of the X-ray tube to analyze the impact of focal spot size. High-precision tungsten plates and fixtures are designed and fabricated, and MTF results with varying line spread function (LSF) sampling intervals are compared. The results demonstrate that the improved slit model offers distinct advantages, with MTF measurements achieving 92.4% of the ideal value. Compared to traditional tungsten edge and point (aperture) model testing methods, the accuracy of the proposed method is improved by 5–13%. The optimal sampling interval is approximately 1/29 of the pixel pitch, offering a more accurate method for evaluating detector performance. Full article

With the rapid development of electronic business, there has been a surge in incidents of trademark infringement, making it imperative to improve the accuracy of trademark retrieval systems as a key measure to combat such illegal behaviors. Evidently, the textual information encompassed within trademarks substantially influences the precision of search results. Considering the diversity of trademark text and the complexity of its design elements, accurately locating and analyzing this text poses a considerable challenge. Against this background, this research has developed an original self-prompting text removal model, denoted as “Self-prompting Trademark Text Removal Based on Multi-scale Texture Aggregation” (abbreviated as MTF-STTR). This model astutely applies a text detection network to automatically generate the required input cues for the Segment Anything Model (SAM) while incorporating the technological benefits of diffusion models to attain a finer level of trademark text removal. To further elevate the performance of the model, we introduce two innovative architectures to the text detection network: the Integrated Differentiating Feature Pyramid (IDFP) and the Texture Fusion Module (TFM). These mechanisms are capable of efficiently extracting multilevel features and multiscale textual information, which enhances the model’s stability and adaptability in complex scenarios. The experimental validation has demonstrated that the trademark text erasure model designed in this paper achieves a peak signal-to-noise ratio as high as 40.1 dB on the SCUT-Syn dataset, which is an average improvement of 11.3 dB compared with other text erasure models. Furthermore, the text detection network component of the designed model attains an accuracy of up to 89.9% on the CTW1500 dataset, representing an average enhancement of 10 percentage points over other text detection networks. Full article

In this paper, we propose a zoom auxiliary imaging lens based on the four-component mechanical zoom method for a modulation transfer function (MTF) test system. The auxiliary imaging lenses of the current MTF test system typically use fixed-focus optical systems, which are unable to meet the test scenarios of fast and batch measurement and measure lenses with an extensive focal length range. Compared with the fixed-focus auxiliary imaging lens, the zoom auxiliary imaging lens can simultaneously satisfy the measurement of wide-angle and telephoto miniature lenses without losing measurement accuracy. The entrance pupil distance of the zoom lens is greater than that of traditional lenses, and it is constant for each focal length of the zoom lens. The zoom lens uses an intermediate real image surface to obtain the perfect image quality and lower the diameter of the rear group. Additionally, the zoom lens dynamically adjusts magnification to optimize image size and align with the detector’s pixel resolution, thereby preventing undersampling and enhancing measurement precision. The optical design is optimized for stability, delivering high resolution and minimal aberrations across the zoom range. The image quality of the zoom lens is nearly at the diffraction limit at each focal length, which significantly reduces the impact of the auxiliary lens on MTF test results, enhancing both flexibility and accuracy. This design is particularly well suited for testing miniature lenses in optoelectronic technology applications. Full article

Objectives: This laboratory study aims to assess the effects of misaligning different trifocal intraocular lenses (IOLs) under varying spectral and corneal spherical aberration (SA) conditions. Methods: With an IOL metrology device under monochromatic and polychromatic conditions, the following models were studied: AT ELANA 841P, AT LISA Tri 839MP, FineVision HP POD F, Acrysof IQ PanOptix, and Tecnis Synergy ZFR00V. The SA was simulated using an aberration-free and average-SA cornea. The modulation transfer function (MTF) was measured at different pupil sizes for the on- and off-axis lens positions. Results: The IOLs exhibited varying responses to decentration up to 1 mm, showing the lowest impact in polychromatic light. The least affected was AT ELANA, with an MTF loss of 15.7% to 28.4% at 50 lp/mm across the studied conditions. It was followed by PanOptix and FineVision, with the MTF loss ranging from 19.1% to 36.0% and from 21.2% to 46.6%. AT LISA showed a more substantial reduction, i.e., 41.2% to 64.8%, but it was still lower than that of Synergy (51.1% to 78.8%). When decentration was induced at a 4.5 mm distance, its effect was more evident in conditions that were closer to each IOL’s SA correction. A tilt of 5° had a lesser impact than 1 mm decentration, with the effect being more severe at 4.5 mm. Conclusions: The off-axis position affects the optical quality of trifocal IOLs. Low- rather than high-SA-correcting trifocals perform better under misalignment. In polychromatic light, the impact of misalignment is less evident, suggesting a potential mitigating effect of chromatic aberration. Full article

In the optical satellite on-orbit imaging quality estimation system, the calculation of Modulation Transfer Function (MTF) is not fully standardized, and the influence of atmosphere is often simplified, making it difficult to obtain completely consistent on-orbit MTF measurements and comparisons. This study investigates the effects of various factors—such as edge angle, edge detection methods, oversampling rate, and interpolation techniques—on the accuracy of MTF calculations in the commonly used slanted-edge method for on-orbit MTF assessment, informed by simulation experiments. A relatively optimal MTF calculation process is proposed, which employs the Gaussian fitting method for edge detection, the adaptive oversampling rate, and the Lanczos (a = 3) interpolation method, minimizing the absolute deviation in the MTF results. A method to quantitatively analyze the atmospheric scattering and absorption MTF is proposed that employs a radiative transfer model. Based on the edge images of GF-2 satellite, images with various atmospheric conditions and imaging parameters are simulated, and their atmospheric scattering and absorption MTF is obtained through comparing the MTFs of the ground and top atmosphere radiance. The findings reveal that aerosol optical depth (AOD), viewing zenith angle (VZA), and altitude (ALT) are the primary factors influencing the accuracy of GF-2 satellite on-orbit MTF measurements in complex scenarios. The on-orbit MTF decreases with the increase in AOD and VZA and increases with the increase in ALT. Furthermore, a collaborative analysis of the main influencing factors of atmospheric scattering and absorption MTF indicates that, taking the PAN band of the GF-2 satellite as an example, the atmospheric MTF values are consistently below 0.7905. Among these, 90% of the data are less than 0.7520, with corresponding AOD conditions ranging from 0 to 0.08, a VZA ranging from 0 to 50°, and an ALT ranging from 0 to 5 km. The results can provide directional guidance for the selection of meteorological conditions, satellite attitude, and geographical location during satellite on-orbit testing, thereby enhancing the ability to accurately measure satellite MTF. Full article

After the launch of a high-resolution remote sensing satellite, representative spatial quality estimators (RER, FWHM, MTF50, MTFA) are measured from images taken of ground Edge targets. In this work, the best spatial quality estimator is proposed by quantitatively comparing and analyzing the precision between the Relative Edge Response (RER), the Full Width at Half Maximum (FWHM), the MTF value at the Nyquist frequency (MTF50), and the MTF Area between 0 and the Nyquist frequency (MTFA). While the basic method for the measurement of spatial quality estimators on Edge targets is already well established, this work summarizes and explains the uncertain factors and problems in the measurement procedure that affect the accuracy and precision of spatial quality estimators. It also considers how to improve the precision of spatial quality estimators during the measurement procedure. The contents and results of this work were discussed by various satellite development organizations in the Geo-Spatial Working Group within CEOS WGCV IVOS from 2012 to 2019, and the Edge target Spatial quality Measurement Python code (ESMP) was developed in 2019 to reflect the findings of this workshop. Using 483 Edge targets from worldwide images taken by KOMPSAT-3A, which has been in operation since 2017, the results obtained via ESMP show that the precision levels of RER, FWHM, and MTFA are approximately three to four times higher than that of MTF50 when comparing the Coefficient of Variance (CV) statistics. This is the first statistical comparison of spatial quality estimators using 7 years of ground Edge target imagery from a single satellite of KOMPSAT-3A. Full article

Endoscopes are crucial for assisting in surgery and disease diagnosis, including the early detection of cancer. The effective use of endoscopes relies on their optical performance, which can be characterized with a series of metrics such as resolution, vital for revealing anatomical details. The modulation transfer function (MTF) is a key metric for evaluating endoscope resolution. However, the 2020 version of the ISO 8600-5 standard, while introducing an endoscope MTF measurement method, lacks empirical validation and excludes opto-electronic video endoscopes, the largest family of endoscopes. Measuring the MTF of video endoscopes requires tailored standards that address their unique characteristics. This paper aims to expand the scope of ISO 8600-5:2020 to include video endoscopes, by optimizing the MTF test method and addressing parameters affecting measurement accuracy. We studied the effects of intensity and uniformity of image luminance, chart modulation compensation, linearity of image digital values, auto gain control, image enhancement, image compression and the region of interest dimensions on images of slanted-edge test charts, and thus the MTF based on these images. By analyzing these effects, we provided recommendations for setting and controlling these factors to obtain accurate MTF curves. Our goal is to enhance the standard’s relevance and effectiveness for measuring the MTF of a broader range of endoscopic devices, with potential applications in the MTF measurement of other digital imaging devices. Full article

In modern scientific practice, it is necessary to consistently observe predetermined zones, with the expectation of detecting and identifying emerging targets or events inside such areas. This research presents an innovative imaging spectrometer system for the continuous monitoring of specific areas. This study begins by providing detailed information on the features and optical structure of the constructed instrument. This is then followed by simulations using optical design tools. The device has an F-number of 5, a focal length of 100 mm, a field of view of 3 × 7, and a wavelength range spanning from 400 nm to 600 nm. The optical path diagram demonstrates that the system’s dispersion and imaging pictures can be distinguished, hence fulfilling the system’s specifications. Furthermore, the utilization of a Modulation Transfer Function (MTF) graph has substantiated that the image quality indeed satisfies the specified criteria. To evaluate the instrument’s performance in the spectrum observation of fixed regions, a region-monitoring-type slitless imaging spectrometer was built. The equipment has the capability to identify a specific region and rapidly capture the spectra of objects or events that are present inside that region. The spectral data were collected effectively by the implementation of image processing techniques on the captured photos. The correlation coefficient between these data and the reference data was 0.9226, showing that the device successfully measured the target’s spectrum. Therefore, the instrument that was created successfully demonstrated its ability to capture images of the observed areas and collect spectral data from the targets located within those regions. Full article

Sex differences have been a rarely addressed aspect in digital game-based learning (DGBL). Likewise, mixed results have been presented regarding the effects according to sex and the conditions that generate these effects. The present work studied the effects of a drill-and-practice mathematical game on primary students. The study focused on an analysis by sex, measuring motivation and learning in the practice activity. Also, two instructional mechanics were considered regarding the question answering to search for possible differences: a multiple-try feedback (MTF) condition and a single-try feedback (STF) condition. A total of 81 students from four courses and two schools participated in the intervention. The study’s main findings were as follows: (a) the girls outperformed the boys in terms of the students’ learning gains; (b) the girls presented lower levels of competence and autonomy than the boys; (c) under MTF, the girls presented lower levels of autonomy but no differences in competence contrasted with the boys; (d) under STF, the girls presented lower levels of competence but no differences in autonomy contrasted with the boys; (e) no sex differences existed in interest, effort, and value, in general, as per the instructional condition. This study enhances the knowledge of sex differences under diverse instructional settings, in particular providing insights into the possible differences by sex when varying the number of attempts provided to students. Full article

Water quality has a significant impact on public health. Inadequate water conditions are associated with diseases such as cholera, dysentery (shigella), hepatitis, and typhoid fever. Established techniques like Membrane Filtration (MF), Multiple Tube Fermentation (MTF), and enzyme-based defined substrate technology (DST) assays are used tomonitor bacteriological water quality, measuring indicators like Enterococcus faecalis (E. faecalis), Escherichia coli (E. coli), and total coliforms. Despite their high sensitivity and specificity, these methods take 24 to 48 h to produce results, as well as requiring access to laboratory facilities, specialized equipment, sample preparation steps, and trained personnel. This study presents a portable and low-cost UV-LED/RGB water quality sensor which includes a microfluidic device, a fluorogenic defined substrate assay for the detection of E. faecalis, RGB sensors for fluorescent data acquisition, ultraviolet-light-emitting diode (UV-LED) for sample excitation, a portable incubation system, and embedded systems for data storage and processing. The microfluidic device has a number of independent wells used to carry out Most Probable Number (MPN) analysis for bacteria quantification. The device is pre-loaded with the defined substrate assay and is self-loading when immersed in the target water sample for sample-preparation-free analysis. RGB sensors detect fluorescence from each well to automate the MPN results. Results from fluorescence-versus-time curves are used to generate a comprehensive database. Machine learning (ML) algorithms and real-time RGB data are used to predict whether each individual well will be positive or negative using only the first three hours of fluorescent data. Coupled with MPN, this method significantly reduces the timeframe of bacteria detection and quantification, making it a cost-effective and efficient solution for on-the-go water quality monitoring, addressing critical public health concerns, and underscoring the importance of swift and reliable water quality assessments. Full article

Multiple-thermal-fluid (MTF) stimulation technology has been successfully applied in heavy-oil reservoir development, resulting in the significant enhancement of oil production. However, the underlying mechanism of multi-component coupling remains unclear. This paper constructs a coupling model for MTF stimulation, investigates the coupling mechanism of different media in various zones during multiple-cycle stimulation operations, and compares the implementation effect with field results. The findings reveal that (1) based on media distribution, the area from near-wellbore to far well locations can be divided into four zones: high-temperature oil-viscosity-reduction zones, compound action zones, energy-replenishment zones, and unaffected zones. (2) In the high-temperature oil-viscosity-reduction zone, the latent heat of vaporization is released by steam, and ultra-heavy oil absorbs heat and reduces its viscosity, which plays a dominant role in the production of MTF. In the compound action zone, hot water, CO₂, and N₂ exhibit a synergistic effect which enhances overall performance. In the energy-replenishment zone, a small amount of N₂ provides pressure maintenance and an additional energy supply. (3) As more cycles of stimulation are conducted, the compound action zone expands, while the energy-replenishment zone contracts. Simultaneously, there is a decrease in contribution rate from the high-temperature viscosity-reduction zone to oil production but an increase from both the compound action zone and energy-replenishment zone up to 30%. Based on the dynamic law of representative wells, this paper proposes a multi-media zonal coupling mechanism, providing a reference for subsequent research on MTF stimulation mechanisms and the adjustment of production measures. Full article

Large-sized step shafts are important devices for supporting and transferring heavy parts, and online inspection equipment for runout errors is affected by the environment and is subject to coaxiality errors and center-position errors, leading to problems such as reduced measurement accuracy in imaging systems. In view of the above problems, this paper proposes an improved optical imaging system design for runout error detection based on the plane-mirror-group correction method. Zemax was used to optimize the structure and simulate the optical path of the optical imaging system. The total length of the structure was 50 mm, and the MTF function for each field of view was greater than 0.3 at the spatial level up to a frequency of 42 lp/mm. The system was applied to a test platform for runout error detection, achieving the detection of runout errors of a large size in the radial direction and at the end face with a diameter range of 500–700 mm. The measurement repeatability was less than 30 μm, and the system corrected the coaxiality error of the stepped-shaft online inspection equipment considered in this paper. Full article

Addressing the prevalent issues of low accuracy, low efficiency, and poor image quality in online diameter measurement of large-sized stepped shafts, this study introduces a novel method based on a symmetrical dual-telecentric optical path utilizing dual CCDs, specifically designed for step shafts with diameters ranging from 600 mm to 800 mm. By developing and optimizing an imaging system grounded in the object-image dual-telecentric optical path principle and employing Zemax software for comprehensive analysis and optimization, this research achieves significant findings. The system’s Airy disk radius is calculated at 3.204 μm; the modulation transfer function (MTF) remains above 0.6 across various fields of view at a spatial cutoff frequency of 71.4 lp/mm, with smooth MTF curves; the field curvature is confined within 0.1 μm; and the distortion is maintained below 0.1%, fulfilling high-quality imaging requirements. Additionally, a tolerance analysis is conducted to ensure the system’s stability and reliability. Applied to an experimental setup for measuring the diameter of large-sized step shafts, the system demonstrates an improved measurement precision of 0.02 mm. This research offers a robust technical solution for the high-precision online measurement of large stepped shaft diameters, presenting significant practical implications for enhancing productivity and product quality. Full article
