Search Results (24)

This research project envisions using a lunar observation platform to measure the full-wave (0.2~100 μm) and shortwave (0.2~4.3 μm) radiation of the Earth, achieving an accurate estimation of the overall radiation budget of the Earth. Based on the lunar platform, the system analyzes Earth’s radiation characteristics and geometric attributes, as well as the sampling properties of observation times. Informed by these analyses, an Earth-facing optical radiation measurement system tailored to these specifications is designed. The optical system adopts an off-axis three-mirror configuration with a secondary image plane, incorporating a field stop at the primary image plane to effectively suppress solar stray light, scattered lunar surface light, and background radiation from the instrument itself, ensuring the satisfactory signal-to-noise ratio, detection sensitivity, and observation duration of the instrument. At the same time, stringent requirements are imposed for the surface treatments of instrument components and temperature control accuracy to further ensure accuracy. Simulation analyses confirm that the design satisfies requirements, achieving a measurement accuracy of better than 1% across the entire optical system. This Moon-based Earth-radiation measurement system, with capabilities for Earth-pointing tracking, radiation energy detection, and stray-light suppression, furnishes a more comprehensive dataset, helping to advance our understanding of the mechanisms driving global climate change Full article

The unceasing quest for a profound comprehension of the Earth system propels the continuous evolution of novel methods for Earth observation. Of these, the Lagrange points situated in the cislunar space proffer noteworthy prospects for space-based Earth observation. Although extant research predominantly centers on Moon-based Earth observation and the L1 point within the Sun-Earth system, the realm of cislunar space remains relatively unexplored. This paper scrutinizes the overarching characteristics of the L1 point within the Earth-Moon system concerning Earth observation. A pivotal enhancement is introduced through the incorporation of the halo orbit. This research comprehensively analyzes the relative motion between the halo orbiter and the Earth, achieved via orbit determination within a rotating coordinate system, followed by a transformation into the Earth coordinate system. Subsequently, numerical simulations employing ephemeris data unveil the observing geometry and Earth observation characteristics, encompassing the distribution of nadir points, viewing angles, and the spatiotemporal ground coverage. As a point of reference, we also present a case study involving a Moon-based platform. Our findings reveal that the motion of the halo orbit, perpendicular to the lunar orbital plane, results in a broader range of nadir point latitudes, which can extend beyond 42°N/S, contingent upon the orbit’s size. Additionally, it manifests a more intricate latitude variation, characterized by the bimodal peaks of the proposed temporal complexity curve. The viewing angles and the spatiotemporal ground coverage closely resemble those of Moon-based platforms, with a marginal enhancement in coverage frequency for polar regions. Consequently, it can be deduced that the Earth observation characteristics of the L1 point within the Earth-Moon system bear a close resemblance to those of Moon-based platforms. Nevertheless, considering the distinct advantages of Moon-based platforms, the lunar surface remains the paramount choice, boasting the highest potential for Earth observation within cislunar space. In summation, this study demonstrates the Earth observation characteristics of the L1 point within the Earth-Moon system, emphasizing the distinctions between this and Moon-based platforms. Full article

With the rapid development of Earth system science, a new understanding of the complete Earth system has highlighted the crucial importance of integrated observations, especially in research involving large-scale geoscience phenomena. As an active sensor with all-time and all-weather capabilities, synthetic aperture radar (SAR) has been widely used in recent decades for Earth observation. However, the existing spaceborne, airborne, and ground-based SAR systems have difficulty providing temporally consistent and spatially continuous Earth observation data on a global scale. As Earth’s only natural satellite, the Moon is a very promising Earth observation platform. By deploying a transmitter on the Moon and a receiver on the high-orbit satellite, a Moon-based/spaceborne bistatic synthetic aperture radar (MS-BiSAR) can be formed. In this paper, the MS-BiSAR geometric model of Earth observation was established using ephemeris and orbit propagators with reference system transformations, and three different MS-BiSAR configurations were used to calculate and analyze their geometric characteristics and Earth observation coverage. The results show that with the advantage of wide swaths, continuous observation capabilities, and large coverage, such an MS-BiSAR could significantly contribute to monitoring and understanding large-scale geoscience phenomena. Full article

The detection and counting of lunar impact craters are crucial for the selection of detector landing sites and the estimation of the age of the Moon. However, traditional crater detection methods are based on machine learning and image processing technologies. These are inefficient for situations with different distributions, overlaps, and crater sizes, and most of them mainly focus on the accuracy of detection and ignore the efficiency. In this paper, we propose an efficient lunar crater detection (ELCD) algorithm based on a novel crater edge segmentation network (AFNet) to detect lunar craters from digital elevation model (DEM) data. First, in AFNet, a lightweight attention mechanism module is introduced to enhance the feature extract capabilities of networks, and a new multiscale feature fusion module is designed by fusing different multi-level feature maps to reduce the information loss of the output map. Then, considering the imbalance in the classification and the distributions of the crater data, an efficient crater edge segmentation loss function (CESL) is designed to improve the network optimization performance. Lastly, the crater positions are obtained from the network output map by the crater edge extraction (CEA) algorithm. The experiment was conducted on the PyTorch platform using two lunar crater catalogs to evaluate the ELCD. The experimental results show that ELCD has a superior detection accuracy and inference speed compared with other state-of-the-art crater detection algorithms. As with most crater detection models that use DEM data, some small craters may be considered to be noise that cannot be detected. The proposed algorithm can be used to improve the accuracy and speed of deep space probes in detecting candidate landing sites, and the discovery of new craters can increase the size of the original data set. Full article

This paper presents a control design strategy for the soft-landing problem on the Moon using solid propellant engines (SPEs). While SPEs have controllability issues and issues relating to the fact that they cannot be restarted, they are characterized by their reliability, simplicity, and cost-effectiveness. Consequently, our main contribution is to tackle this disadvantage by formulating a 1-dimensional landing optimization problem using an array of SPEs in a CubeSat platform, which is analyzed for different numbers of engines in the array and for three types of propellant grain cross-section (PGCS). The engines and control parameters are optimized by a genetic algorithm (GA) due to the non-linearity of the problem and the uncertainties of the state variables. Two design approaches for control are analyzed, where the robust design based on the uncertainties of the variables shows the best performance. The results of Monte Carlo simulations were used to demonstrate the effectiveness of the robust design, which decreases the impact velocity as the number of SPEs increases. Using an arrangement of ten SPEs, the landing was at −2.97 m/s with a standard deviation of 0.99 m/s; using sixteen SPEs, the landing was at −2.04 m/s with a standard deviation of 0.48 m/s. Both have regressive PGCS. Full article

Missions targeting the extreme and rugged environments on the moon and Mars have rich potential for a high science return, although several risks exist in performing these exploration missions. The current generation of robots is unable to access these high-priority targets. We propose using teams of small hopping and rolling robots called SphereX that are several kilograms in mass and can be carried by a large rover or lander and tactically deployed for exploring these extreme environments. Considering that the importance of minimizing the mass and volume of these robot platforms translates into significant mission-cost savings, we focus on the optimization of an integrated power and propulsion system for SphereX. Hydrogen is used as fuel for its high energy, and it is stored in the form of lithium hydride and oxygen in the form of lithium perchlorate. The system design undergoes optimization using Genetic Algorithms integrated with gradient-based search techniques to find optimal solutions for a mission. Our power and propulsion system, as we show in this paper, is enabling, because the robots can travel long distances to perform science exploration by accessing targets not possible with conventional systems. Our work includes finding the optimal mass and volume of SphereX, such that it can meet end-to-end mission requirements. Full article

Nowadays, the Earth observation based on the Moon has attracted attention from many researchers and relevant departments. There also exists a considerable amount of interest in monitoring large-scale and long-term geoscience phenomena using the Moon-based SAR (MBS). However, the Earth’s observation from MBS has long transmission time, and the relative motion of MBS with its Earth ground target (EGT) is much different to the space-borne SAR, the above reasons indicate that the traditional stop-and-go model is no longer suitable for MBS in frequency domain imaging. Here a dual-path separate calculation method for single pulse is presented in this paper for a better match of a real scenario, and then the slant range is fitted to a high-order polynomial series. The MBS’s location, the synthetic aperture time and other factors have effects on length of the dual- path and fit bias. Without thoroughly investigated phase de-correlation processing in frequency domain, and to avoid computational costs in traditional back-projection (BP) algorithm, the paper first proposes a fast back-projection (FBP) algorithm in time domain for MBS, a platform that has long transmission time and long synthetic aperture time. In the FBP algorithm, the original method, that projected echo on all pixels in the imaging area, is changed to projected echo on a centerline instead. A suitable interpolation for points on the centerline is adopted to reduce the projected error; the synthetic aperture length and imaging area are also divided into subsections to reduce computation cost. The formula indicates that the range error could be control once the product of sub-imaging area’s length and sub-aperture’s length stay constant. Through the theoretical analysis, the detailed range difference mainly at apogee, perigee, ascending, and descending nodes indicate the necessity to separately calculate the dual-path for MBS’s single pulse transmission in Earth-Moon motion, with real ephemeris been adopted; then, the high-order polynomial fitting will better describe the motion trajectory. Lastly, the FBP algorithm proposed is simulated in a specific scenario under acceptable resolution, and the result shows its feasibility for image compression. Full article

Observation angles are of great importance with respect to Earth observation platforms. The richness of angular combination, i.e., the combination of three observational angles (viewing zenith angle, solar zenith angle, and relative azimuth angle), is an important parameter to illustrate the angle sampling capability of an Earth observation platform. Here, the angular combination characteristics of a Moon-based platform were investigated and compared with existing artificial satellites. Furthermore, the effects of the time sampling interval on the angular combination characteristics were analyzed using a newly established angular combination number index (ACNI). Results show that a Moon-based platform can complement angular sampling observations from existing satellites. We found that the time sampling interval has different effects on the angular combination for different observed points. Accordingly, the Earth’s surface can be divided into two zones with respect to its sensitivity to the time sampling interval. When the time sampling interval increased from 10 min to 2 h, the maximum loss of the angular combination reached 50% for the observed points in the mid–low latitude zone. Full article

When planning lunar rover missions, it is important to develop intuition and driving skills for unfamiliar environments before incurring the costs of reaching the moon. Simulators make it possible to operate in environments that have the physical characteristics of target locations without the expense of extensive physical tests. This paper proposes a motion simulation and human–computer interaction system based on a parallel mechanism to realize high-fidelity manned lunar rover simulations. The system consists of an interactive operating platform and a lunar surface simulation environment based on Unity3D. To make the 6-DOF platform simulate the posture changes of the rover, we improved the motion simulation algorithm. We designed a posture adjustment system and built virtual sensors to help astronauts perceive the lunar environment. Finally, this paper discusses the method for the realization of the multi-channel human–computer interaction system; astronauts can interactively control the rover through five channels. Experiments show that this system can realize high-fidelity rover simulation and improve the efficiency of human-computer interaction. Full article

The variation in the radiation budget at Earth’s top of the atmosphere (TOA) represents the most fundamental metric defining the status of global climate change. The accurate estimation of Earth’s shortwave radiant exitance is of critical importance to study Earth’s radiation budget (ERB) at TOA. Measuring Earth’s outgoing shortwave radiance (OSR) is a key point to estimate Earth’s shortwave radiant exitance. Compared with space-borne satellite systems, Moon-based sensors (MS) could provide large-scale, continuous, and long-term data for Earth radiation observations, bringing a new perspective on ERB. However, the factors affecting the estimation of Earth’s OSR in the lunar direction have not yet been fully explored, for example, anisotropic surface reflection and the effects of clouds and aerosols on radiation budget. In this work, we only focused on the influence of anisotropic surface reflection. To evaluate the extent of this influence, we constructed a model to estimate Earth’s OSR in the lunar direction (EOSRiLD), integrating the variables of anisotropic surface reflection (scene types, solar zenith angles, viewing zenith angles, and relative azimuth angles) and radiant flux in Moon-viewed sunlit regions. Then, we discussed it over three time periods (Earth’s rotation, revolution period, and synodic month cycle) and analyzed the impact of three variables (area of the Moon-viewed sunlit region, scene types, and incident-viewing angular bins) on anisotropic EOSRiLD. Our results indicate that EOSRiLD based on the assumptions of anisotropic and isotropic reflection is different but they all show the same monthly cycle change, which is related to the area of the Moon-viewed sunlit region. At the beginning and end of the lunar month, the differences between anisotropy and isotropy are greatest in each cycle; when it is close to the first half of each cycle, there is a small difference peak. Both anisotropy and isotropy are caused by the relative azimuth angles between the Sun and Moon. In conclusion, even if the Moon-based platform has a wider scope than space-borne satellites, the difference is still large between anisotropy and isotropy. Therefore, we still need to consider the anisotropic surface reflection based on the Moon-based observation. Full article

The Moon-Based Earth Radiation Observatory (MERO) is a new platform, which is expected to advance current Earth radiation budget (ERB) research with better observations. For the instrument design of a MERO system, ascertaining the spatial resolution and sampling scheme is important. However, current knowledge about this is still limited. Here we proposed a simulation method for the MERO-measured Earth top of atmosphere (TOA) outgoing shortwave radiation (OSR) and outgoing longwave radiation (OLR) fluxes and constructed the “true” Earth TOA OSR and OLR fluxes based on the Clouds and Earth’s Radiant Energy System (CERES) data. Then we used them to reveal the effects of spatial resolution and temporal scheme (sampling interval and the temporal sampling sequence) on the measurement error of a MERO. Our results indicate that the spatial sampling error in the unit of percentage reduces linearly as the spatial resolution varies from 1000 km to 100 km; the rate is 2.5%/100 km for the Earth TOA OSR flux, which is higher than that (1%/100 km) of the TOA OLR flux. Besides, this rate becomes larger when the spatial resolution is finer than 40 km. It is also demonstrated that a sampling temporal sequence of starting time of 64 min with a sampling interval of 90 min is the optimal sampling scheme that results in the least temporal sampling error for the MERO system with a 40 km spatial resolution, note that this conclusion depends on the temporal resolution and quality of the data used to construct the “true” Earth TOA OSR and OLR fluxes. The proposed method and derived results in this study could facilitate the ascertainment of the optimal spatial resolution and sampling scheme of a MERO system under certain manufacturing budget and measurement error limit. Full article

Moon-based Earth observations have attracted significant attention across many large-scale phenomena. As the only natural satellite of the Earth, and having a stable lunar surface as well as a particular orbit, Moon-based Earth observations allow the Earth to be viewed as a single point. Furthermore, in contrast with artificial satellites, the varied inclination of Moon-based observations can improve angular samplings of specific locations on Earth. However, the potential for estimating the global outgoing longwave radiation (OLR) from the Earth with such a platform has not yet been fully explored. To evaluate the possibility of calculating OLR using specific Earth observation geometry, we constructed a model to estimate Moon-based OLR measurements and investigated the potential of a Moon-based platform to acquire the necessary data to estimate global mean OLR. The primary method of our study is the discretization of the observational scope into various elements and the consequent integration of the OLR of all elements. Our results indicate that a Moon-based platform is suitable for global sampling related to the calculation of global mean OLR. By separating the geometric and anisotropic factors from the measurement calculations, we ensured that measured values include the effects of the Moon-based Earth observation geometry and the anisotropy of the scenes in the observational scope. Although our results indicate that higher measured values can be achieved if the platform is located near the center of the lunar disk, a maximum difference between locations of approximately 9 × 10⁻⁴ W m⁻² indicates that the effect of location is too small to remarkably improve observation performance of the platform. In conclusion, our analysis demonstrates that a Moon-based platform has the potential to provide continuous, adequate, and long-term data for estimating global mean OLR. Full article

Increasing attention is being paid to the monitoring of global change, and remote sensing is an important means for acquiring global observation data. Due to the limitations of the orbital altitude, technological level, observation platform stability and design life of artificial satellites, spaceborne Earth observation platforms cannot quickly obtain global data. The Moon-based Earth observation (MEO) platform has unique advantages, including a wide observation range, short revisit period, large viewing angle and spatial resolution; thus, it provides a new observation method for quickly obtaining global Earth observation data. At present, the MEO platform has not yet entered the actual development stage, and the relevant parameters of the microwave sensors have not been determined. In this work, to explore whether a microwave radiometer is suitable for the MEO platform, the land surface temperature (LST) distribution at different times is estimated and the design parameters of the Moon-based microwave radiometer (MBMR) are analyzed based on the LST retrieval. Results show that the antenna aperture size of a Moon-based microwave radiometer is suitable for 120 m, and the bands include 18.7, 23.8, 36.5 and 89.0 GHz, each with horizontal and vertical polarization. Moreover, the optimal value of other parameters, such as the half-power beam width, spatial resolution, integration time of the radiometer system, temperature sensitivity, scan angle and antenna pattern simulations are also determined. Full article

In light of an upcoming series of missions beyond low Earth orbit (LEO) through NASA’s Artemis program and the potential establishment of bases on the Moon and Mars, the effects of the deep space environment on biology need to be examined and protective countermeasures need to be developed. Even though many biological experiments have been performed in space since the 1960s, most of them have occurred in LEO and for only short periods of time. These LEO missions have studied many biological phenomena in a variety of model organisms, as well as utilized a broad range of technologies. Given the constraints of the deep space environment, however, future deep space biological missions will be limited to microbial organisms using miniaturized technologies. Small satellites like CubeSats are capable of querying relevant space environments using novel instruments and biosensors. CubeSats also provide a low-cost alternative to more complex and larger missions, and require minimal crew support, if any. Several have been deployed in LEO, but the next iteration of biological CubeSats will go farther. BioSentinel will be the first interplanetary CubeSat and the first biological study NASA has sent beyond Earth’s magnetosphere in 50 years. BioSentinel is an autonomous free-flyer platform able to support biology and to investigate the effects of radiation on a model organism in interplanetary deep space. The BioSensor payload contained within the free-flyer is also an adaptable instrument that can perform biologically relevant measurements with different microorganisms and in multiple space environments, including the ISS, lunar gateway, and on the surface of the Moon. Nanosatellites like BioSentinel can be used to study the effects of both reduced gravity and space radiation and can house different organisms or biosensors to answer specific scientific questions. Utilizing these biosensors will allow us to better understand the effects of the space environment on biology so humanity may return safely to deep space and venture farther than ever before. Full article

The Swinomish Indian Tribal Community developed an informal environmental health and sustainability (EHS) curriculum based on Swinomish beliefs and practices. EHS programs developed and implemented by Indigenous communities are extremely scarce. The mainstream view of EHS does not do justice to how many Indigenous peoples define EHS as reciprocal relationships between people, nonhuman beings, homelands, air, and waters. The curriculum provides an alternative informal educational platform for teaching science, technology, engineering, art, and mathematics (STEAM) using identification, harvest, and preparation activities of First Foods and medicines that are important to community members in order to increase awareness and understanding of local EHS issues. The curriculum, called 13 Moons, is founded on a set of guiding principles which may be useful for other Indigenous communities seeking to develop their own curricula. Full article
