The fatigue strength of structural components is strongly affected by notches and imperfections. Both can be treated similarly, as local notch fatigue strength methods can also be applied to interior defects. Even though Murakami’s √area approach is commonly used in the threshold-based fatigue design of single imperfections, advanced concepts such as the Theory of Critical Distances (TCD), Notch Stress Intensity Factors (N-SIF), or Elastic Strain Energy Density (ESED) methods provide additional insight into the local fatigue strength distribution of irregularly shaped defects under varying uniaxial load vectors. The latter methods are based on the evaluation of the elastic stress field in the vicinity of the notch for each single load vector. Thus, this work provides numerically efficient methods to assess the local fatigue strength by means of TCD, N-SIF, and ESED, targeting the minimization of the required load case count, optimization of stress field evaluation data points, and utilization of multi-processing. Furthermore, the Peak Stress Method (PSM) is adapted for large opening angles, as in the case of globular defects. In detail, two numerical strategies are devised and comprehensively evaluated, either using a sub-case-based stress evaluation of the defect vicinity with an unchanged mesh pattern and varying load vector on the exterior model region with optimized load angle stepping or by the invocation of stress and strain tensor transformation equations to derive load angle-dependent result superposition while leaving the initial mesh unaltered. Both methods provide numerically efficient fatigue post-processing, as the mesh in the evaluated defect region is retained for varying load vectors. The key functions of the fatigue strength assessment, such as the evaluation of appropriate planar notch radius and determination of notch opening angle for the discretized imperfections, are presented. Although the presented numerical methods apply to planar simulation studies, the basic methodology can be easily expanded toward spatial fatigue assessment. Full article

Approaches based on calculating Residual Notch Stress Intensity Factors (R-NSIFs) assume the weld toe to be a sharp V-notch that gives rise to a residual singular stress distribution close to the weld toe. Once R-NSIFs are determined, they might be included in local fatigue criteria for the structural strength assessment of welded joints based on NSIFs due to external cyclic loading. However, the numerical calculation of R-NSIFs through finite element (FE) simulations of the welding process requires extremely refined meshes to properly capture the residual stress singularity. In this context, the Peak Stress Method (PSM) has recently been adopted to estimate R-NSIFs due to residual stresses by means of coarse meshes of 2D 4-node plane or 3D 8-node brick elements. The aim of this work is to investigate the applicability of the PSM to estimate R-NSIFs in a butt-welded joint using coarse meshes of 3D 10-node tetra elements. The R-NSIF distribution at the weld toe line is estimated by applying the PSM to coarse meshes of 3D 10-node tetra elements, and the results are in agreement with those obtained using 3D 8-node brick elements. Accordingly, the PSM based on tetra elements further enhances the rapid estimation of R-NSIFs using coarse meshes and could be effective in analyzing complex 3D joint geometries. Full article

Shrinkage porosities and non-metallic inclusions are common manufacturing process based defects that are present within cast materials. Conventional fatigue design recommendations, such as the FKM guideline (“Forschungskuratorium Maschinenbau”), therefore propose general safety factors for the fatigue assessment of cast structures. In fact, these factors mostly lead to oversized components and do not facilitate a lightweight design process. In this work, the effect of shrinkage porosities on the fatigue strength of defect-afflicted large-scale specimens manufactured from the cast steel G21Mn5 is studied by means of a notch stress intensity factor-based (NSIF-based) generalized Kitagawa diagram. Additionally, the mean stress sensitivity of the material is taken into account and establishes a load stress ratio enhanced diagram. Thereby, the fatigue assessment approach is performed by utilizing the defects sizes taken either from the fracture surface of the tested specimens or from non-destructive X-ray investigations. Additionally, a numerical algorithm invoking cellular automata, which enables the generation of artificial defects, is presented. Conclusively, a comparison to the results of the experimental investigations reveals a sound agreement to the generated spatial pore geometries. To sum up, the generalized Kitagawa diagram, as well as a concept utilizing artificially generated defects, is capable of assessing the local fatigue limit of cast steel G21Mn5 components and features the mapping of imperfection grades to their corresponding fatigue strength limit. Full article

In recent years, the need of surgical procedures has continuously increased and, therefore, researchers and clinicians are broadly focusing on the development of new biocompatible materials. Among them, polyetheretherketone (PEEK) has gained wide interest in load-bearing applications due to its yielding behaviour and its superior corrosion resistance. To assure its reliability in these applications where notches and other stress concentrators weaken implants resistance, a design tool for assessing its tensile and fatigue behaviour in the presence of geometrical discontinuities is highly claimed. Herein, a new fatigue design method based on a local approach is proposed for PEEK implant, and the results are compared with those obtained using the two main biomaterial design approaches available in literature, i.e., the theory of critical distances (TCD) and the notch stress intensity factor (NSIF) approach. To this aim, previously published datasets of PEEK-notched specimens are used, and the proposed method is reported to provide more accurate results and to be robust for different notch geometries. Full article

Welded joints are one of the most widely applied methods to join different steel components. However, they introduce stress concentrators that are commonly known to reduce the fatigue strength of structures. Several methods have been developed to assess the fatigue behavior of welded components, such as the Notch Stress Intensity Factors (NSIFs) approach. However, this approach has been reported to be geometry dependent, and does not allow for a direct comparison of failures occurring at the weld toes with those occurring at the weld roots. This drawback has been overcame by considering the value of the strain energy density (SED) range averaged in a control volume ahead of the notch tip. More than 900 fatigue data of welded joints have been summarized within a single scatter band ΔW-N (strain energy range–umber of cycles to failure) using this approach. The reliability of the just mentioned scatter band in summarizing the fatigue data of real components such as steel welded rollers produced by Rulmeca is herein evaluated. The results prove the reliability of the SED approach to assess the fatigue behavior of welded rollers, paving the way to its diffusion in assessing real components. Full article
