Search Results (11)

Dams play a vital role in securing water and electricity supplies for households and industry, and they contribute significantly to flood protection. Regular monitoring of dam deformations holds fundamental socio-economic and ecological importance. Traditionally, this has relied on time-consuming in situ techniques that offer either high spatial or temporal resolution. Persistent Scatterer Interferometry (PSI) addresses these limitations, enabling high-resolution monitoring in both domains. Sensors such as TerraSAR-X (TSX) and Sentinel-1 (S-1) have proven effective for deformation analysis with millimeter accuracy. Combining TSX and S-1 datasets enhances monitoring capabilities by leveraging the high spatial resolution of TSX with the broad coverage of S-1. This improves monitoring by increasing PS point density, reducing revisit intervals, and facilitating the detection of environmental deformation drivers. This study aims to investigate two objectives: first, we evaluate the benefits of a spatially and temporally densified PS time series derived from TSX and S-1 data for detecting radial deformations in individual dam segments. To support this, we developed the TSX2StaMPS toolbox, integrated into the updated snap2stamps workflow for generating single-master interferogram stacks using TSX data. Second, we identify deformation drivers using water level and temperature as exogenous variables. The five-year study period (2017–2022) was conducted on a gravity dam in North Rhine-Westphalia, Germany, which was divided into logically connected segments. The results were compared to in situ data obtained from pendulum measurements. Linear models demonstrated a fair agreement between the combined time series and the pendulum data ($R^2$ = 0.5; MAE = 2.3 mm). Temperature was identified as the primary long-term driver of periodic deformations of the gravity dam. Following the filling of the reservoir, the variance in the PS data increased from 0.9 mm to 3.9 mm in RMSE, suggesting that water level changes are more responsible for short-term variations in the SAR signal. Upon full impoundment, the mean deformation amplitude decreased by approximately 1.7 mm toward the downstream side of the dam, which was attributed to the higher water pressure. The last five meters of water level rise resulted in higher feature importance due to interaction effects with temperature. The study concludes that integrating multiple PS datasets for dam monitoring is beneficial particularly for dams where few PS points can be identified using one sensor or where pendulum systems are not installed. Identifying the drivers of deformation is feasible and can be incorporated into existing monitoring frameworks. Full article

The analysis of deformation dynamics in Guatemala city and its surrounding region presented in this paper holds significant relevance due to the high vulnerability of this area to natural disasters, combined with its rapid urbanization, similar to most Central American cities, contrasting with a lack of InSAR and deformation studies in the region. A total of 226 SAR images from Sentinel-1 A and B satellites in both ascending and descending geometries were processed with the Persistent Scatterer Interferometry (PSI) technique employing the SNAP-StaMPS integrated processing chain. The study area encompasses the Metropolitan Region of Guatemala, which is characterized by a diverse and active geological framework, with a historical record of earthquakes, intense groundwater extraction, and local subsidence phenomena, causing fissures and sinkholes. Four active areas were identified in the study area, each covering more than 50 hectares, with subsidence velocities greater than 10 mm/yr. This study provides valuable insights into fostering the sustainable development of this region by identifying deformation patterns, characterizing main active areas, and evaluating associated risks for disaster management and prevention. The results can also aid informed decision-making processes and guide urban planning and resource management strategies in other Central American countries. The application of InSAR studies is crucial for improving safety and sustainability in urban environments and natural resource management in vulnerable regions. Full article

In the last five years, the urban development of the city of Limassol has rapidly increased in the sectors of industry, trade, real estate, and many others. This exponentially increased urban development arises several concerns about the aggravation of potential land subsidence in the Limassol coastal front. Forty six Copernicus Sentinel-1 acquisitions from 2017 to 2021 have been processed and analyzed using the Sentinel Application Platform (SNAP) and the Stanford Method for Persistent Scatterers (StaMPS). A case study for the identification and analysis of the persistent scatterers (PS) in pixels in a series of interferograms and the quantity of the land displacements in the line of sight of the Limassol coastal front is presented in this research, with subsidence rates up to about (−5 to 4 mm/year). For the validation of the detected deformation, accurate ground-based geodetic measurements along the coastal area were used. Concordantly, considering that there is a significant number of skyscrapers planned or currently under construction, this study attempts a preliminary assessment of the impact these structures will pose on the coastal front of the area of Limassol. Full article

Landslides are a major threat for population and urban areas. Persistent Scatterer Interferometry (PSI) is a powerful tool for identifying landslides and monitoring their evolution over long periods and has proven to be very useful especially in urban areas, where a sufficient number of PS can be generated. In this study, we applied PS interferometry to investigate the landslide affecting Santo Stefano d’Aveto (Liguria, NW Italy) by integrating classic interferometric techniques with cross-correlation analysis of PS time-series and with geological and geotechnical field information. We used open-source software and packages to process Synthetic Aperture Radar (SAR) images from the Copernicus Sentinel-1A satellite for both ascending and descending orbits over the period 2015–2021 and calculate both the vertical motion and the E-W horizontal displacement. By computing the cross-correlation of the PS time-series, we identified three families of PS with a similarity greater than 0.70. The cross-correlation analysis allowed subdividing the landslide in different sectors, each of which is characterized by a specific type of movement. The geological meaning of this subdivision is still a matter of discussion but it is presumably driven by the geomorphological setting of the area and by the regional tectonics. Full article

This paper discusses a full interferometry processing chain based on dual-orbit Sentinel-1A and Sentinel-1B (S1) synthetic aperture radar data and a combination of open-source routines from the Sentinel Application Platform (SNAP), Stanford Method for Persistent Scatterers (StaMPS), and additional routines introduced by the authors. These are used to provide vertical and East-West horizontal velocity maps over a study area in the south-western sector of the Po Plain (Italy) where land subsidence is recognized. The processing of long time series of displacements from a cluster of continuous global navigation satellite system stations is used to provide a global reference frame for line-of-sight–projected velocities and to validate velocity maps after the decomposition analysis. We thus introduce the main theoretical aspects related to error propagation analysis for the proposed methodology and provide the level of uncertainty of the validation analysis at relevant points. The combined SNAP–StaMPS workflow is shown to be a reliable tool for S1 data processing. Based on the validation procedure, the workflow allows decomposed velocity maps to be obtained with an accuracy of 2 mm/yr with expected uncertainty levels lower than 2 mm/yr. Slant-oriented and decomposed velocity maps provide new insights into the ground deformation phenomena that affect the study area arising from a combination of natural and anthropogenic sources. Full article

The road network of metropolitan Rome is determined by a large number of structures located in different geological environments. To maintain security and service conditions, satellite-based monitoring can play a key role, since it can cover large areas by accurately detecting ground displacements due to anthropic activities (underground excavations, interference with other infrastructures, etc.) or natural hazards, mainly connected to the critical hydrogeological events. To investigate the area, two different Differential Interferometry Synthetic Aperture Radar (DInSAR) processing methods were used in this study: the first with open source using the Persistent Scatterers Interferometry (PSI) of SNAP-StaMPS workflow for Sentinel-1 (SNT1) and the second with the SBAS technique for Cosmo-SkyMed (CSK). The results obtained can corroborate the displacement trends due to the characteristics of the soil and the geological environments. With Sentinel-1 data, we were able to obtain the general deformation overview of the overall highways network, followed by a selection and classification of the PSI content for each section. With Cosmo-SkyMed data, we were able to increase the precision in the analysis for one sample infrastructure for which high-resolution data from CSK were available. Both datasets were demonstrated to be valuable for collecting data useful to understand the safety condition of the infrastructure and to support the maintenance actions. Full article

Development of synthetic aperture radar (SAR) technology and the dedicated suite of processing tools have aided the evolution of remote sensing techniques for various Earth Observation (EO) applications. Interferometric SAR (InSAR) is a relatively new geodetic technique which provides high-speed and reliable geographic, geologic, and hazards information allowing the prognosis of future environmental and urban planning. In this study, we explored the applicability of two differential interferometry techniques, conventional and advanced differential InSAR (A-DInSAR), for topographic mapping and long-term geotechnical monitoring by exploiting satellite data, particularly Sentinel-1 SAR data, which is publicly shared. We specifically used the open-source tools of SeNtinel Application Platform (SNAP) and Stanford Method for Persistent Scatterers (StaMPS) for interferometric data processing to implement A-DInSAR. This study presents various applications, which include generation of a digital elevation model (DEM), mapping of seismically induced displacement and associated damages, and detection and long-term monitoring of tunneling-induced ground deformation and rainfall-induced landslide. Geometric and temporal decorrelations posed challenges and limitations in the successful implementation of Sentinel-1 SAR interferometry specifically in vegetated areas. The presented results proved the validity and reliability of the exploited SAR data and InSAR techniques for addressing geotechnical engineering related problems. Full article

Surface deformations were observed in Bolvadin, located in the province of Afyon (western Turkey) in the last decade which occurred without any destructive earthquakes. In this study, ground deformation of the Bolvadin region is analyzed by means of multi-temporal interferometric synthetic aperture radar (InSAR) technique with Sentinel-1 synthetic aperture radar (SAR) data. Sentinel-1 data acquired in ascending and descending orbits between October 2014 and October 2018 are processed with the Sentinel Application Platform (SNAP) and Stanford Method for Persistent Scatterers (StaMPS) open source software tools. Deformation velocity maps and line-of-sight (LOS) displacement time series are produced and compared with geology, groundwater level and the water surface area of Eber Lake nearby. Deformation velocity maps reveal significant subsidence in most of the town and surrounding regions, which is confirmed by field observations that show severe damage to the settlements and infrastructure of the town. The most severe subsidence is observed to be in the southern part of Bolvadin with rates up to 35 mm/year, which is characterized by the presence of soft alluvial deposits. Composed of slope debris/talus and conglomerate, the northeastern part of the deforming region experiences a relatively lower rate of subsidence. A strong correlation between LOS displacement time series and groundwater level exists both in the short and long term. Moreover, short term variations in LOS displacement time series also show high similarity with seasonal variations in the water surface area of Eber Lake located a few km southeast of the town. We conclude that the primary cause of subsidence is most probably the overexploitation of groundwater and hydrological changes because of (1) the strong correlation of subsidence with lithological units, (2) the similarity between deformation rate and groundwater level changes, (3) the correspondence of seasonal variations in water surface area and short-term deformation rate oscillations, and (4) the absence of InSAR velocity contrast across the active faults. Full article

The sub-Saharan African coast is experiencing fast-growing urbanization, particularly around major cities. This threatens the equilibrium of the socio-ecosystems where they are located and on which they depend: underground water resources are exploited with a disregard for sustainability; land is reclaimed from wetlands or lagoons; built-up areas, both formal and informal, grow without adequate urban planning. Together, all these forces can result in land surface deformation, subsidence or even uplift, which can increase risk within these already fragile socio-ecosystems. In particular, in the case of land subsidence, the risk of urban flooding can increase significantly, also considering the contribution of sea level rise driven by climate change. Monitoring such fast-changing environments is crucial to be able to identify key risks and plan adaptation responses to mitigate current and future flood risks. Persistent scatterer interferometry (PSI) with synthetic aperture radar (SAR) is a powerful tool to monitor land deformation with high precision using relatively low-cost technology, also thanks to the open access data of Sentinel-1, which provides global observations every 6 days at 20-m ground resolution. In this paper, we demonstrate how it is possible to monitor land subsidence in urban coastal areas by means of permanent scatterer interferometry and Sentinel-1, exploiting an automatic procedure based on an integration of the Sentinel Application Platform (SNAP) and the Stanford Method for Persistent Scatterers (StaMPS). We present the results of PSI analysis over the cities of Banjul (the Gambia) and Lagos (Nigeria) showing a comparison of results obtained with TerraSAR-X, Constellation of Small Satellites for the Mediterranean Basin Observation (COSMO-SkyMed) and Environmental Satellite advanced synthetic aperture radar (Envisat-ASAR) data. The methodology allows us to highlight areas of high land deformation, information that is useful for urban development, disaster risk management and climate adaptation planning. Full article

Land subsidence in urban environments is an increasingly prominent aspect in the monitoring and maintenance of urban infrastructures. In this study we update the subsidence information over Rome and its surroundings (already the subject of past research with other sensors) for the first time using Copernicus Sentinel-1 data and open source tools. With this aim, we have developed a fully automatic processing chain for land deformation monitoring using the European Space Agency (ESA) SentiNel Application Platform (SNAP) and Stanford Method for Persistent Scatterers (StaMPS). We have applied this automatic processing chain to more than 160 Sentinel-1A images over ascending and descending orbits to depict primarily the Line-Of-Sight ground deformation rates. Results of both geometries were then combined to compute the actual vertical motion component, which resulted in more than 2 million point targets, over their common area. Deformation measurements are in agreement with past studies over the city of Rome, identifying main subsidence areas in: (i) Fiumicino; (ii) along the Tiber River; (iii) Ostia and coastal area; (iv) Ostiense quarter; and (v) Tivoli area. Finally, post-processing of Persistent Scatterer Inteferometry (PSI) results, in a Geographical Information System (GIS) environment, for the extraction of ground displacements on urban infrastructures (including road networks, buildings and bridges) is considered. Full article

Multi-temporal synthetic aperture radar interferometry techniques (MT-InSAR) are nowadays a well-developed remote sensing tool for ground stability monitoring of areas afflicted by natural hazards. Its application capability has recently been emphasized by the Sentinel-1 satellite mission, providing extensive spatial coverage, regular temporal sampling and free data availability. We perform MT-InSAR analysis over the wider Upper Nitra region in Slovakia, utilizing all Sentinel-1 images acquired since November 2014 until March 2017. This region is notable for its extensive landslide susceptibility as well as intensive brown coal mining. We focus on two case studies, being impaired by recent activation of these geohazards, which caused serious damage to local structures. We incorporate a processing chain based on open-source tools, combining the current Sentinel Application Platform (SNAP) and Stanford Method for Persistent Scatterers (StaMPS) implementation. MT-InSAR results reveal substantial activity at both case studies, exceeding the annual displacement velocities of 30 mm/year. Moreover, our observations are validated and their accuracy is confirmed via comparison with ground truth data from borehole inclinometers and terrestrial levelling. Detected displacement time series provide valuable insight into the spatio-temporal evolution of corresponding deformation phenomena and are thus complementary to conventional terrestrial monitoring techniques. At the same time, they not only demonstrate the feasibility of MT-InSAR for the assessment of remediation works, but also constitute the possibility of operational monitoring and routine landslide inventory updates, regarding the free Sentinel-1 data. Full article
