Rotary abrasive waterjet (AWJ) cutting is an effective technique for industrial tube cutting and is widely used for oil and gas well tubing. This study presents a self-designed experimental apparatus for investigating the cutting performance of rotary AWJ. Based on the SPH-FEM coupling theory, a numerical model for rotary AWJ cutting of tubing was developed to investigate the cutting mechanism and optimize process parameters. Experimental results show that low peripheral speed leads to inefficient utilization of jet energy, whereas excessively high peripheral speed degrades cutting performance; the optimal range is 5.65–7.54 mm/s. Pump pressure below the cutting threshold or high pressure both decrease cutting efficiency, with optimal performance at 50 MPa. Both overly fine and overly coarse abrasive mesh sizes degrade cutting performance, with 80-mesh abrasive being optimal. Increasing standoff distance intensifies jet energy attenuation, decreases cutting capacity, and increases kerf taper; 8.5 mm is recommended. Cutting depth increases over cutting time until the jet no longer has enough energy to cut, at which point the depth stops increasing. A theoretical basis for the design and application of rotary AWJ cutting technology in oil and gas wells is provided in this study. Full article

Regarding the current issues in Xinjiang, China, during the harvesting of cotton stalks, the lack of specialized, efficient, and durable cutting blades for cotton stalks causes uneven cutting, high power consumption, and short blade life. In this study, a biomimetic serrated blade was designed based on the Trictenotomidae mandible for efficient, low-power-consumption cutting. The biomimetic design, FEM-SPH coupled simulation, bench test, combined with response surface methodology, and field test were used. The simulation results showed that under the same working conditions, the maximum shear stress was 34.81% lower than that for the ordinary blade and 22.05% lower than that for the ordinary serrated blade. And the bench test results showed that cutting power consumption was reduced by about 20.12% and 15.69% compared to the ordinary cutting blade and serrated cutting blade, respectively. When cutting velocity was 1.3 m/s, cutting inclination angle was 11°, and ratio of cutting velocity and feeding velocity was 1.1, the biomimetic serrated cutting blade could achieve effective cutting of cotton stalks and obtain better quality of cutting—the cutting power per unit area and the cutting-edge angle after cutting cotton stalks were 52.08 kJ/m² and 6°, respectively. The research results can provide a theoretical basis and support for the utilization of cotton stalks out of the field, as well as the cutting of other similar crop stalks. Full article

During the production, storage, and use of solid rocket motors, the impact generated by unexpected accidents, such as collision or drop, will cause damage to the propellant and affect the safety of the motor. However, the progressive evolution mechanism of mesoscopic damage in NEPE propellant under such impact conditions has not been fully elucidated, and there is still a lack of quantitative method to evaluate the impact-induced damage degree, which restricts the engineering safety assessment of solid rocket motors. To investigate the influence mechanism, the mesoscale damage characteristics of NEPE propellant under drop-weight impact is systematically studied. First, damaged NEPE specimens are obtained by conducting drop-weight experiments with a 10 kg hammer, where the drop height is varied to apply different impact impulses. The internal meso-structure of the propellant is then characterized using micro-CT, yielding detailed imagery of the refined meso-structural features and damage morphologies in the NEPE propellant. To capture the dynamic evolution process of mesoscale damage, a mesoscopic model incorporating AP, Al, HMX particles and voids, is subsequently constructed based on the high-precision mesoscopic morphology characterized by micro-CT. By integrating the deviatoric constitutive model, Gurson plastic damage model, and bilinear cohesive zone model, high-fidelity numerical simulations of the drop-weight impact damage process are performed using the advanced SPH-FEM coupling algorithm. The results indicate that no significant damage occurs when the impact impulse is less than 13.85 N·s. As the impulse increases, phenomena including matrix microcracks, void collapse, particle/matrix interface debonding, and main crack formation appear sequentially. When the impulse exceeds 24.25 N·s, particle fragmentation and transgranular fracture occur, accompanied by plastic flow and frictional heating that induce ignition. Finally, the overall damage degree is fitted by the Boltzmann function, and a function for quantitatively describing the damage degree is obtained, which can provide theoretical support for the impact safety assessment of solid rocket motors. Full article

In this work, the Material Point Method (MPM) is reviewed for application in the microelectronics industry. Microelectronic processes often involve large deformations, evolving interfaces, multiphysics coupling, and complex geometries that challenge conventional mesh-based methods such as the finite element method (FEM). Meshless methods provide an alternative solution that avoids these issues. A comparison is made between Smoothed Particle Hydrodynamics (SPH), Element Free Galerkin (EFG), peridynamics, Radial Basis Function–Finite Difference (RBF-FD), and MPM, evaluated with respect to convergence, consistency and stability, boundary enforcement, adaptivity, coupling, and industrial applicability. Based on this assessment, MPM and its main variants (BSMPM, GIMP, CPDI, and TLMPM) are examined in depth. The method’s ability to address large deformations, moving interfaces, contact, history-dependent material behavior, and multiphysics interactions is examined. The underfill process is used as a representative use case to illustrate challenges such as free surface flow, void formation, thermomechanical coupling, and residual stress. Overall, MPM shows strong potential, although further benchmarking and validation are required for widespread industrial adoption. Full article

This paper investigates the prediction of the depth of penetration (DOP) for concrete targets under high-speed projectile impact using multiple simulation algorithms in LS-DYNA. Three numerical methods, i.e., the traditional finite element method (FEM), a fixed-coupling FEM-SPH (Smooth Particle Hydrodynamics) model, and an adaptive coupling FEM-SPH model, are employed to simulate the penetration processes. The computational results are compared against established empirical formulas to evaluate their predictive accuracy and efficiency. The findings indicate a distinct trade-off between numerical precision and computational cost. The adaptive FEM-SPH algorithm achieves the highest accuracy, with a maximum error of less than 10% across considered velocity ranges, and effectively captures cavity expansion effects. The standard FEM algorithm offers the highest computational efficiency, requiring less than half the time of the other methods, albeit with a maximum error of up to 25%. The fixed-coupling FEM-SPH model provides an intermediate solution, showing improved accuracy at velocities above 400 m/s but lower efficiency. This comparative analysis offers a practical guideline for selecting appropriate simulation techniques in protective structure design, balancing the demands for rapid estimation, detailed physical insight, and final safety verification. Full article

The drilling and blasting method remains fundamental to mining and tunneling projects, prized for its simplicity and economy. However, conventional techniques are increasingly challenged by modern safety and environmental standards, particularly in complex geological settings. Slotted charge blasting technology addresses these limitations by offering exceptional control over fracture propagation and damage. This paper provides a comprehensive review of the field, synthesizing global research on its theoretical foundations, advanced diagnostic methodologies, key performance parameters, and engineering applications. We critically analyze the current challenges facing the technology, particularly in weak rock conditions, where extensive plastic deformation and rapid energy dissipation often compromise directional control, and identify promising trends for its future development. Specifically, the integration of intelligent adaptive control and additive manufacturing is highlighted as a key direction. By mapping out a clear trajectory for future research, this work provides a scientific basis to advance the efficacy and safety of slotted charge blasting in demanding engineering environments. Full article

Ultra-high-molecular-weight polyethylene (UHMWPE) thin films are considered promising shielding materials against hypervelocity microparticle impacts in space environments. In this study, a finite element-smoothed particle hydrodynamics (FEM-SPH) adaptive coupling simulation method was developed to reveal the damage mechanisms of UHMWPE films impacted by alumina (Al₂O₃) particles with a diameter of 10 μm. A 100 μm thick single-layer UHMWPE film was subjected to normal impacts at velocities ranging from 1 to 30 km/s. The morphology and characteristics of craters formed on the film surface were analyzed, revealing the velocity-dependent transition from plastic deformation to complete perforation. At 10 km/s, additional oblique impact simulations at 30°, 45°, 60° and 75° were performed to assess the effect of impact angle on damage morphology. Furthermore, the damage evolution in double-layer UHMWPE films was examined under impact velocities of 5, 10, 15, 20 and 25 km/s, showing enhanced protective performance compared to single-layer films. Finally, the critical influence parameters for UHMWPE failure were discussed, providing criteria for evaluating the shielding limits. This work offers computational methods and predictive tools for assessing hypervelocity microparticle impact and contributes to the structural protection design of spacecraft operating in the harsh space environment. Full article

In this study, the joining of Cu/Al tubes was achieved using the magnetic pulse-assisted semi-solid brazing (MPASSB) technique. A coupled finite element method–smoothed particle hydrodynamics (FEM-SPH) model was established to analyze the influence mechanism of solid–liquid interface interaction on pore formation during the brazing forming process. The results indicate that the MPASSB technique can produce Cu/Al tube joints with excellent metallurgical bonding and performance at 390 °C, and no brittle Cu/Al intermetallic compounds (IMCs) are formed in the joints. Additionally, a stronger solid–liquid interface interaction and a higher surface roughness of the tubes lead to easier peeling of the copper matrix from the interface, thereby promoting pore formation. Mechanical property tests show that the shear strength of the joints prepared by this method can reach 63.3 MPa, and the fracture occurs in the brazing seam area adjacent to the copper–side interface. The MPASSB technique is expected to provide a feasible technical approach for the high-quality joining of dissimilar Cu/Al materials. Full article

Supercritical carbon dioxide (SC-CO₂) jetting has emerged as a promising technique for rock fracturing due to its superior physical properties such as low viscosity, high diffusivity, and zero surface tension. However, the complex interaction mechanisms between SC-CO₂ jets and heterogeneous rock media remain inadequately understood. In this study, a coupled Smooth Particle Hydrodynamics–Finite Element Method (SPH-FEM) framework is established to simulate the dynamic fracturing process of rocks under SC-CO₂ jet impact. The Riedel–Hiermaier–Thoma (RHT) constitutive model is incorporated to describe the nonlinear damage evolution of brittle rocks, and key material parameters are calibrated via sensitivity analysis and SHPB experimental validation. A series of numerical simulations are performed to investigate the effects of jet standoff distance, jet velocity, and rock lithology (marble, granite, red sandstone) on fracturing efficiency. Damage area, damage volume, and a novel metric—block size distribution—are employed to quantify the fracturing quality from both macro and meso scales. The results indicate that SC-CO₂ jets outperform conventional water jets in creating more extensive and homogeneous fracture networks. An optimal standoff distance of 1–2 cm and a velocity threshold of 0.2 cm/μs are identified for maximum fracturing efficiency in marble. Furthermore, smaller block sizes are achieved under higher velocities, indicating a more complete and efficient rock fragmentation process. This study provides a comprehensive numerical insight into SC-CO₂ jet-induced rock failure and offers theoretical guidance for optimizing green and water-free rock fracturing techniques in complex geological environments. Full article

This study analyzed the dynamic behavior of EN C45 structural steel under impulse loading generated by a pressure wave. The experiments were conducted on a special test rig using two load configurations: (I) direct contact of the load with the sample surface and (II) detonation at a distance of 30 mm. Depending on the loading conditions, the specimens were fragmented or developed extensive internal cracks and plastic deformations. To complement the experimental program, hybrid numerical simulations were performed using the finite element method (FEM), smoothed particles hydrodynamics (SPH), and coupled Euler–Lagrange (CEL) approach. A modified Johnson–Cook (JC) model was used to account for dynamic damage and cracks. Computed tomography (CT) and metallographic analyses provided detailed information on the formation of cracks in MnS inclusions, brittle cracks near the sample axis, and shear deformation zones away from the axis. These observations allowed direct correlation with the predicted numerical deformation and damage fields. The innovative nature of this work lies in the combination of three complementary computational techniques with computed tomography analysis and microstructure analysis, providing a comprehensive framework for describing and confirming the mechanisms of damage and fragmentation of structural steels under explosive loading. Full article

Alloying AlN with ScN provides a robust strategy for engineering its intrinsic bandgap, phonons and dielectric functions, and ScAlN alloys have demonstrated great promise in applications including the 5G mobile network, surface acoustic wave devices and nanophotonics. Sc doping has been shown to greatly influence the phonons and infrared dielectric functions of AlN, yet few studies have focused on its influence on surface phonon polaritons, which are crucial to modulating the radiative properties of ScAlN metasurfaces. Herein, we combined first-principles and finite element method (FEM) simulations to fully investigate the effects of Sc incorporation on the phonon dispersion relation, propagation and localization of SPhPs and the modulated radiative properties of ScAlN nanoresonators. As the Sc doping concentration increases, the highest optical phonon frequencies are reduced and are largely directly related to enlarged lattice parameters. Consequently, the coupling strength among incident photons and phonons decreases, which leads to a reduced absorption peak in the infrared dielectric functions. Moreover, the propagation length of the SPhPs in ScAlN is largely reduced, and localized resonance modes gradually disappear at a higher Sc doping concentration. This work provides physical insights into the spectra tuning mechanisms of ScAlN nanoresonators via Sc doping and facilitates their applications in nanophotonic devices. Full article

Aiming at the lightweight design of a bridge-shed integration structure, this paper presents a three-layered absorbing system in which a part of the sand cushion is replaced by expanded polystyrene (EPS) geofoam and the reinforced concrete (RC) protective slab is arranged above the sand cushion to enhance the composite system’s safety. A three-dimensional Smoothed Particle Hydrodynamics–Finite Element Method (SPH-FEM) coupled numerical model is developed in LS-DYNA (Livermore Software Technology Corporation, Livermore, CA, USA, version R13.1.1), with its validity rigorously verified. The dynamic response of rockfall impacts on the shed slab with composite cushions of various thicknesses is analyzed by varying the thickness of sand and EPS materials. To optimize the cushion design, a specific energy dissipation ratio (SEDR), defined as the energy dissipation rate per unit mass (η/M), is introduced as a key performance metric. Furthermore, the complicated interactional mechanism between the rockfall and the optimum-thickness composite system is rationally interpreted, and the energy dissipation mechanism of the composite cushion is revealed. Using logistic regression, the ultimate stress state of the reactive powder concrete (RPC) slab is methodically analyzed, accounting for the speed and mass of the rockfall. The results are indicative of the fact that the composite cushion not only has less dead weight but also exhibits superior impact resistance compared to the 90 cm sand cushions; the impact resistance performance index SEDR of the three-layered absorbing system reaches 2.5, showing a remarkable 55% enhancement compared to the sand cushion (SEDR = 1.61). Additionally, both the sand cushion and the RC protective slab effectively dissipate most of the impact energy, while the EPS material experiences relatively little internal energy build-up in comparison. This feature overcomes the traditional vulnerability of EPS subjected to impact loads. One of the highlights of the present investigation is the development of an identification model specifically designed to accurately assess the stress state of RPC slabs under various rockfall impact conditions. Full article

The icebreaking process of water-exiting vehicles involves complex nonlinear interactions as well as multi-physical field coupling effects among ice, solids, and fluids, which poses enormous challenges for numerical calculations. Addressing the low solution accuracy of traditional grid methods in simulating large deformation and destruction of ice layers, a numerical model was established based on the FEM-SPH-SALE coupling algorithm to study the dynamic characteristics of the water-exiting vehicle on the icebreaking process. The FEM-SPH adaptive algorithm was used to simulate the damage performance of ice, and its feasibility was verified through the four-point bending test and vehicle breaking ice experiment. The S-ALE algorithm was used to simulate the process of fluid/structure interaction, and its accuracy was verified through the wedge-body water-entry test and simulation. On this basis, numerical simulations were performed for different ice thicknesses and initial velocities of vehicles. The results show that the motion characteristics of the vehicle undergoes a sudden change during the ice-breaking. The head and middle section of the vehicle are subject to greater stress, which is related to the transmission of stress waves and inertial effect. The velocity loss rate of the vehicle and the maximum stress increase with the thickness of ice. The higher the initial velocity of the vehicle, the larger the acceleration and maximum stress in the process of the vehicle breaking ice. The acceleration peak is sensitive to the variation in the vehicle’s initial velocity but insensitive to the thickness of the ice. Full article

Abrasive waterjet technology is a promising sustainable and green technology for cutting underground structures. Abrasive waterjet usage in demolition promotes sustainable and green construction practices by reduction of noise, dust, secondary waste, and disturbances to the surrounding infrastructure. In this study, a numerical framework based on a coupled Smoothed Particle Hydrodynamics (SPH)–Finite Element Method (FEM) algorithm incorporating the Riedel–Hiermaier–Thoma (RHT) constitutive model is proposed to investigate the damage mechanism of concrete subjected to abrasive waterjet. Numerical simulation results show a stratified damage observation in the concrete, consisting of a crushing zone (plastic damage), crack formation zone (plastic and brittle damage), and crack propagation zone (brittle damage). Furthermore, concrete undergoes plastic failure when the shear stress on an element exceeds 5 MPa. Brittle failure due to tensile stress occurs only when both the maximum principal stress (σ₁) and the minimum principal stress (σ₃) are greater than zero at the same time. The damage degree ($\chi$) of the concrete is observed to increase with jet diameter, concentration of abrasive particles, and velocity of jet. A series of orthogonal tests are performed to analyze the influence of velocity of jet, concentration of abrasive particles, and jet diameter on the damage degree and impact depth (h). The parametric numerical studies indicates that jet diameter has the most significant influence on damage degree, followed by abrasive concentration and jet velocity, respectively, whereas the primary determinant of impact depth is the abrasive concentration followed by jet velocity and jet diameter. Based on the parametric analysis, two optimized abrasive waterjet configurations are proposed: one tailored for rock fragmentation in tunnel boring machine (TBM) operations; and another for cutting reinforced concrete piles in shield tunneling applications. These configurations aim to enhance the efficiency and sustainability of excavation and tunneling processes through improved material removal performance and reduced mechanical wear. Full article

In the cotton fields in Xinjiang, residual film is present in the soil for a long period of time, leading to a decrease in the tensile strength of the residual film and increasing the difficulty of recycling. Existing technologies for residual film recovery focus on mechanical properties and ignore the dragging and tearing of residual film by cotton stubble. The effect of cotton straw–root stubble on residual film recovery can only be better determined by appropriate machine operating parameters, which are essential to improving residual film recovery. Through analyses of the pickup device, key parameters were identified, and a model was built by combining the FEM and SPH algorithms to simulate the interaction of nail teeth, residual film, soil and root stubble. The simulation revealed the force change law of residual film in root stubble-containing soil and the influence of root stubble. By simulating the changes in the characteristics of the residual film during the process, the optimum operating parameters for the nail teeth were determined: a forward speed of 1849.57 mm/s, a rotational speed of 5.5 r/s and a soil penetration angle of 30°. Under these optimized conditions, the maximum shear strain, pickup height (maximum deformation) and average peak stress of the residual film were 1293, 363.81 mm and 3.42 MPa, respectively. Subsequently, field trials were conducted to verify the change in the impact of the nail teeth at the optimized speed on the recovery of residual film in plots containing root stubble. The results demonstrated that when the root stubble height was 5–8 cm, the residual film averaged a recovery rate of 89.59%, with a dragging rate of only 4.10% at crossings. In contrast, 8–14 cm stubble plots showed an 82.86% average recovery and an 11.91% dragging rate. In plots with a root stubble height of 5–8 cm, compared with plots with a root stubble height of 8–14 cm, the recovery rate increased by 6.73%, and the dragging rate of residual film on root stubble decreased by 7.81%. The percentage of entangled residual film out of the total unrecovered film was 30.10% lower in the 5–8 cm stubble plots than in the 8–14 cm stubble plots. It was confirmed that the effect of cotton root stubble on residual film recovery could be reduced under appropriate machine operating parameters. This provides strong support and a theoretical and practical basis for future research on the correlation between root stubble and residual film and how to improve the residual film recovery rate. Full article
