Search Results (36)

Thorough investigation into Tesla valve (TV) design was conducted across a large design of experiments (DOE) consisting of four varying geometric parameters and six different Reynolds number regimes in order to develop an optimized pressure drop device utilizing machine learning (ML) methods. A non-standard TV design was geometrically parameterized, and an automation suite was created to cycle through numerous combinations of parameters. Data were collected from completed computational fluid dynamics (CFD) simulations. TV designs were tested in the restricted flow direction for overall differential pressure, and overall minimum pressure with consideration to the onset of cavitation. Qualitative observations were made on the effects of each geometric parameter on the overall valve performance, and particular parameters showed greater influence on the pressure drop compared to classically optimized parameters used in previous TV studies. The overall minimum pressure demonstrated required system pressure for a valve to be utilized such that onset to cavitation would not occur. Data were utilized to train an ML model, and an optimized geometry was selected for maximized pressure drop. Multiple optimization efforts were made to meet design pressure drop goals versus traditional diodicity metrics, and two geometries were selected to develop a final design tool for overall pressure drop component development. Future work includes experimental validation of the large dataset, as well as further validation of the design tool for use in industry. Full article

This paper presents the results of preliminary numerical and experimental studies concerning the sealing performance of static seals (gaskets) with geometrically designed sealing surface microstructures. The concept of the microstructure, inspired by the operating principle of Tesla’s one-way valve, relies on the generation of localized flow circulation within the microchannels formed between the contact surfaces, which increases flow resistance and reduces leakage. CFD simulations were performed to assess the influence of the geometric parameters of the microstructure on the leakage rate. The numerical calculations demonstrated that introducing microstructures into the gap formed between the contact interfaces can significantly reduce leakage, with the most critical geometric parameters being the gap width between the microprotrusions, their packing density, and their height. Experimental studies confirmed the higher sealing performance of structured gaskets compared to quasi-smooth gaskets, particularly at lower contact pressures. An analysis of the effective contact surface revealed that the improvement in tightness is a result of both the local intensification of the contact pressure and the flow effects induced by the microprotrusions. The results obtained confirm that an appropriately designed surface microstructure can substantially enhance the sealing performance of flange-bolted joints, even under relatively low clamping loads. Full article

Flow field design in proton exchange membrane fuel cells (PEMFCs) is a critical issue, as it plays an important role in governing reactant transport dynamics and cell performance. In this work, numerical studies of a single Tesla-valve flow field were conducted. The influence of loop radius, channel angle, and channel height on the performance of PEMFCs were fully explored. Then, aiming to maximize the output current density, this study optimized the Tesla-valve flow field configuration through a framework that integrates Gaussian process modeling with a Genetic Algorithm (GA). The approach efficiently identifies the optimal geometric parameters, highlighting effective synergy between the surrogate model and intelligent evolutionary optimization for enhanced performance. Simulation results show that the current density at 0.4 V and the highest power density have been improved by more than 10% compared to the baseline design for both forward and reverse flow. The optimized Tesla valve design has been compared with conventional parallel and serpentine flow fields of the same flow area. Results show that, despite the larger pressure drop for the single channel case—which is due to the insufficient length of the serpentine channel—the Tesla-valve flow field demonstrated superior performance in other metrics, including current and power density, under both flow directions. Full article

The Polish Free-Electron Laser (PolFEL), which is currently under construction in the National Centre for Nuclear Research in Świerk near Warsaw, will comprise an electron gun and from four to six cryomodules, each accommodating two nine-cell TESLA RF superconducting resonant cavities. To cool the superconducting resonant cavities, the cryomodules will be supplied with superfluid helium at a temperature of 2 K. Other requirements regarding the cooling power of PolFEL result from the need to cool the power couplers for the accelerating cryomodules (5 K) and thermal shields, which limit the heat inleaks due to radiation (40–80 K). The machine will utilize several thermodynamic states of helium, including two-phase superfluid helium, supercritical helium, and low-pressure helium vapours. Supercritical helium will be supplied from a cryoplant by a cryogenic distribution system (CDS)—transfer line and valve boxes—where it will be thermodynamically transformed into a superfluid state. This article presents the architecture of the CDS, discusses several design solutions that could have been decided on with the use of second law analysis, and presents the design methodology of the chosen CDS elements. Full article

The Tesla valve (TV) is a valvular conduit that allows fluid to flow in one direction while restricting flow in the opposite direction, making it useful for enhancing fluid control in the field of microfluidics. Our previous research has found that the enhancement of multi-stage TVs’ diodicity is mainly due to the interstage non-uniform flow field. In this study, we introduce baffles in different positions to discover the effect of non-uniform flow field on single-stage TV’s diodicity. We employed 3D printing technology to fabricate a TV for experimental purposes. The experimental data revealed that flow distortion can lead to an increase in diodicity of up to 30% for the studied single-stage TV. Concurrently, we conducted simulations, establishing a simulation model, and then compared the results of the simulation model with the experimental outcomes. This comparison demonstrated the reliability of the model. The detailed analysis indicates that the high-performance optimization is attributed to the baffle design, which preferentially directs fluid into the arc channel, enhancing reverse flow resistance while minimally affecting forward flow resistance. These findings provide valuable strategies for the optimization of the design and performance prediction of single-stage Tesla valves. Full article

Efficient heat dissipation remains a critical challenge in the research and development of automotive permanent magnet synchronous motors. In this study, a Tesla valve cooling channel is innovatively designed, and a corresponding flow model is established using computational fluid dynamics (CFD) simulations. The effects of the spacing between adjacent Tesla valves, the number of stages, and inlet velocities on motor temperature rise and pressure drop within the channel are analyzed under varying flow directions. A comprehensive evaluation of 25 simulation samples reveals that the reverse flow Tesla valve-type channel, with an inlet velocity of 1 m/s, 90 mm spacing, and 16 stages, achieves an optimal balance between cooling performance and energy consumption. Compared to the conventional spiral waterway design, this configuration reduces the maximum temperature and temperature difference by 1.5% and 2.2%, respectively, while maintaining a relatively low pressure drop. Additionally, the structure enhances the coolant’s heat exchange capacity, effectively lowering the peak temperature of the motor. These findings provide valuable insights for advancing motor cooling technologies. Full article

The Tesla valve is a fluidic diode that enables unidirectional flow while impeding the reverse flow without the assistance of any moving parts. Conventional Tesla valves share a distinctive feature of a bifurcated section that connects the inlet and outlet. This study uses computational fluid dynamic (CFD) simulations to analyze the importance of the bifurcated design to the efficiency of the Tesla valve, quantified by diodicity. Simulations over the range of the Reynolds number, Re = 50–2000, are performed for three designs: the T45-R, D-valve, and GMF valve, each with two versions with and without the bifurcated section. For the T45-R valve, removing the bifurcated section leads to a consistent increase in diodicity, particularly at high Re. In contrast, the diodicity of the GMF valve drops significantly when the bifurcated section is removed. The D-valve exhibits a mixed behavior. Without the bifurcated section, its diodicity is suppressed at low Re but begins to increase for Re > 1100, eventually matching the diodicity of the bifurcated version at Re = 2000. The results highlight the intricate relationship between valve geometry and efficiency of Tesla-type valves and the dependence of this relationship on the Reynolds number. Full article

This study investigates the transient flow dynamics and pressure interactions within Tesla valve configurations through comprehensive CFD simulations. Tesla valves offer efficient passive fluid control without the need for external power, making them favorable in various applications. Previous observations indicated that Tesla valves effectively reduce the amplitude of pressure transients, prolonging their duration and distributing energy over an extended timeframe. While suggesting a potential role for Tesla valves as pressure dampers during transient events, the specific mechanisms behind this behavior remain unexplored. This research focuses on elucidating the internal dynamics of Tesla valves during transient events, aiming to unravel the processes responsible for the observed attenuation in pressure transients. This study reveals the emergence of “pressure pockets” within Tesla valves, deviating from conventional uniform pressure fronts. These pockets manifest as discrete chambers with varying lengths and volumes, contributing to the non-uniform propagation of pressure throughout the system. This investigation employs advanced CFD simulations as a crucial tool to unravel the governing dynamics of transient flow within Tesla valve configurations. By elucidating underlying fluid dynamics, this study lays the groundwork for future Tesla valve design optimization, holding potential implications for applications where the control of transient flow events is crucial. Full article

Recently, battery electric vehicles (BEVs) have faced various technical challenges, such as reduced driving range due to ambient temperature, slow charging speeds, fire risks, and environmental regulations. This numerical study proposes an integrated thermal management system (ITMS) utilizing R290 refrigerant and a 14-way valve to address these issues, proactively meeting future environmental regulations, simplifying the system, and improving efficiency. The performance evaluation was conducted under high-load operating conditions, including driving and fast charging in various environmental conditions of 35 °C and −10 °C. As a result, the driving efficiency was 4.82 km/kWh in high-temperature conditions (35 °C) and 4.69 km/kWh in low-temperature conditions (−10 °C), which demonstrated higher efficiency than the Octovalve-ITMS applied to the Tesla Model Y. Furthermore, in fast charging tests, the high voltage battery was charged from a 10% to a 90% state of charge in 26 min at 35 °C and in 31 min at −10 °C, outperforming the Octovalve-ITMS-equipped Tesla Model Y’s fast charging time of 27 min under moderate ambient conditions. This result highlights the superior fast-charging performance of the 14-way valve-based ITMS, even under high cooling load conditions. Full article

Contaminated water has remained an unsolved problem for decades, particularly when the contamination derived from heavy metals. A possible solution is to mix the contaminated water with magnetic nanoparticles so that an adsorption process can take place. In that frame, Tesla valve micromixer and ${\mathrm{Fe}}_3{\mathrm{O}}_4$ magnetic nanoparticles were selected to perform simulations for encounter maximum mixing efficiency. These simulations focus on inlet velocities ratios between contaminated water and nanoparticles and inlet rates of nanoparticles. The maximum mixing efficiency was 44% for the inverse double Tesla micromixer found for the combination of ${\mathrm{Fe}}_3{\mathrm{O}}_4$ nanoparticles as the inlet rate and with inlet velocity ratios of ${\displaystyle \frac{V_p}{V_c}}=10$. Full article

This study investigates the transient flow dynamics and pressure interactions within Tesla valve configurations through comprehensive computational fluid dynamics (CFD) simulations. Previous observations indicated that Tesla valves effectively reduce the amplitude of pressure transients, prolonging their duration and distributing energy over an extended timeframe. While suggesting a potential role for Tesla valves as pressure dampers during transient events, the specific mechanisms behind this behavior remain unexplored. The research focuses on elucidating the internal dynamics of Tesla valves during transient events, aiming to unravel the processes responsible for the observed attenuation in pressure transients. The study reveals the emergence of distinctive “pressure pockets” within Tesla valves, deviating from conventional uniform pressure fronts. These pockets manifest as discrete chambers with varying lengths and volumes, contributing to a non-uniform propagation of pressure throughout the system. Full article

The optimization of flow channel structures significantly impacts the performance enhancement of proton exchange membrane fuel cells (PEMFCs). In this paper, the influences of the loop radius, inclination angle, and presence of the island in the Tesla valve flow field on the performance of a fuel cell were investigated numerically. The results indicated that increasing the inclination angle and curvature radius of the Tesla valve increased the voltage by 16.3% and 31.1%, respectively, compared to the parallel flow field at 0.8 A/cm². Elevating the inclination angle amplified the resistance effect exerted by tributaries on the main stream, consequently fostering channel-to-membrane mass transfer. Increasing the curvature radius contributed to a heightened total oxygen concentration, but also led to water accumulation problems. The removal of islands increased the reactant contact area, but also created more dead zones, resulting in an observed improvement compared to the parallel flow field, but only marginal improvements over the basic Tesla flow field. Full article

In this study, a modular, multi-step, photometric microflow injection analysis (micro-FIA) system for the automatic determination of Cu(II) in a bioreactor was developed. The system incorporates diverse 3D-printed modules, including a platform formed by a mixer module to mix Cu(II) with hydroxylamine, which reduces Cu(II) to Cu(I) linked to a diluter module via a Tesla valve, a chelation mixer module, a disperser module, and a detector module provided by an LED light source at λ = 455 nm and a light dependence resistor (LDR) as a light intensity detector. The system measures the color intensity resulting from the chelation between Cu(I) and neocuproine. The micro-FIA system demonstrated good capability for automatic and continuous Cu(II) determination, in a wide range of Cu concentrations, from 34 to 2000 mg L⁻¹. The device exhibits a good repeatability (coefficient of variation below 2% across the measured concentration range), good reproducibility, and has an accuracy of around 100% between 600 and 1900 mg L⁻¹. Real samples were analyzed using both the micro-FIA system and an atomic absorption spectroscopy method, revealing no statistically significant differences. Additionally, a Tesla valve located before the detector substituted a 3-way solenoid valve, eliminating the need for moving parts. Full article

The utilization of liquid-cooled plates has been increasingly prevalent within the thermal management of batteries for new energy vehicles. Using Tesla valves as internal flow channels of liquid-cooled plates can improve heat dissipation characteristics. However, conventional Tesla valve flow channels frequently experience challenges such as inconsistencies in heat dissipations and unacceptably high levels of pressure loss. In light of this, this paper proposes a new type of Tesla valve with partitions, which is used as internal channel for liquid-cooled plate. Its purpose is to solve the shortcomings of existing flow channels. Under the working conditions of Reynolds number equal to 1000, the neural network prediction-NSGA-II multi-objective optimization method is used to optimize the channel structural parameters. The objective is to identify the optimal structural configuration that exhibits the greatest Nusselt number while simultaneously exhibiting the lowest Fanning friction factor. The variables to consider are the half of partition thickness H, partition length L, and the fillet radius R. The study result revealed that the optimal parameter combination consisted of H = 0.25 mm, R = 1.253 mm, L = 0.768 mm, which demonstrated the best performance. The Fanning friction factor of the optimized flow channel is substantially reduced compared to the reference channel, reducing by approximately 16.4%. However, the Nusselt number is not noticeably increased, increasing by only 0.9%. This indicates that the optimized structure can notably reduce the fluid’s friction resistance and pressure loss and slightly enhance the heat dissipation characteristics. Full article

Accurately predicting the thermal characteristics and heat transfer distribution of the rotating detonation engine (RDE) and acquiring a clear understanding of the performance and mechanism of the rotating detonation are of great significance for achieving the safe and reliable long-duration operation of RDEs. Using RP-3 as fuel, a long-duration experimental study is performed on a 220 mm-diameter RDC to investigate the details with respect to the thermal environment. The heat flux at the typical location and the average heat flux of both the inner and outer cylinders are measured, respectively. Meanwhile, the peak pressure of the rotating detonation wave (RDW) and specific thrust are analyzed. When the ER is between 0.5 and 1 (oxidizer 2 kg/s), the stable rotating detonation mode is obtained, and the detonation duration is set as 40 s to accurately calculate the heat released by the detonation combustion. The heat flux in the upstream region of the RDW location ranges from 2.40 × 10⁵ W/m² to 3.17 × 10⁵ W/m², and the heat flux in the downstream area of the RDW location ranges from 1.05 × 10⁶ W/m² to 1.28 × 10⁶ W/m². The results demonstrate the important role of the detonation combustion zone, and the thrust performance of RDC can be improved by making the RDW move forward along the RDC axis, which is the optimal direction of detonation combustion. Through a comparison of average heat flux under different conditions, it is found that the heat released by the RDC is directly related to its thrust. In addition, the average heat flux of the inner cylinder is about three times that of the outer cylinder for the two-phase RDC with a Tesla valve intake structure, indicating that the high-temperature combustion product is closer to the inner wall. Therefore, more thermal protection should be allocated to the inner cylinder, and a more systematic analysis of the two-phase flow field distribution in the annular combustion chamber should be carried out to improve the thrust performance. In this paper, the average heat flux of the inner and outer cylinders of the RDC as well as the typical local heat flux of the outer cylinders is quantitatively measured by means of experiments, which not only deepens the understanding of RDC flow field distribution, but also provides quantitative boundary conditions for the thermal protection design of RDCs. Full article
