The flatness of semiconductor substrates is an important parameter for evaluating the surface quality of semiconductor substrates. However, existing technology cannot simultaneously achieve high measurement efficiency, large-range thickness measurement, and nanometer-level measurement accuracy in the thickness measurement of semiconductor substrates. To solve the problems, we propose to apply the method that combines spectral-domain optical coherence tomography (SD-OCT) with the Hanning-windowed energy centrobaric method (HnWECM) to measure the thickness of semiconductor substrates. The method can be employed in the full-chip thickness measurement of a sapphire substrate, which has a millimeter measuring range, nanometer-level precision, and a sampling rate that can reach up to 80 kHz. In this contribution, we measured the full-chip thickness map of a sapphire substrate by using this method and analyzed the machining characteristics. The measurement results of a high-precision mechanical thickness gauge, which is widely used for thickness measurement in the wafer fabrication process, were compared with the proposed method. The difference between these two methods is 0.373%, which explains the accuracy of the applied method to some extent. The results of 10 sets of repeatability experiments on 250 measurement points show that the maximum relative standard deviation (RSD) at this point is 0.0061%, and the maximum fluctuation is 71.0 nm. The above experimental results prove that this method can achieve the high-precision thickness measurement of the sapphire substrate and is of great significance for improving the surface quality detection level of semiconductor substrates. Full article

This review article presents a summary of currently used and proposed methods of manufacturing fir tree slots of discs in turbine engines. The production of aircraft, including aircraft engines during times of overlapping global economic crises related to the COVID-19 pandemic or the war in Eastern Europe requires a quick response to the changing numbers of passengers and cargo. Similarly, the aviation industry must adapt to these conditions, and thus utilize flexible production methods allowing for a quick change in the design or type of a given part. Due to the constant adoption of new materials for the most critical aero engine parts and the necessity of complying with environmental regulations, it is necessary to search for new methods of manufacturing these parts, including fir tree slots. As an alternative to currently used expensive and energy-intensive broaching, many manufacturers try to implement creep feed grinding CFG or contour milling. However, other manufacturing methods, thus far rarely used for crucial machine parts such as WEDM, ECDM or AWJ, are gaining more and more popularity in the aviation industry. This article presents the advantages and shortcomings of these methods in the context of manufacturing fir tree slots. Full article

This study presents a novel and highly accurate method of measuring the geometric thickness of the self-lubricating fabric liner of bearings by combining the optical coherence tomography (OCT) technology and the Hanning-windowed energy centrobaric method (HnWECM). The geometric thickness of wear-resistant coating material is one of the important indicators for evaluating its wear, and the measurement of its geometric thickness is of great significance for preventing coating failure. To address the issue of significant measurement errors caused by using the refractive index of the sample instead of the group refractive index to calculate the material’s geometrical thickness in previous OCT research and applications, our proposed method can accurately measure the geometrical thickness of materials without the influence of the refractive index of the material. Moreover, this method exhibits the advantages of non-contact and high precision, since it utilizes an SD-OCT system, making it a novel method for extracting the physical parameters of composite materials. The geometric thickness of the peeled-off liner obtained from our method is compared with the thickness measured by the spiral micrometer to evaluate its accuracy. The experimental results indicate that the thickness measured by the spiral micrometer was 172 μm, while the maximum difference in the data obtained by our method was 171.261 μm. This suggests that the difference between the two methods is less than 0.430%, which verifies the accuracy and validity of our method. Additionally, the obtained geometric thickness and the optical thickness of the peeled-off liner are used to evaluate the group refractive index of this material. The inside geometrical structure of the self-lubricating fabric liner on the end face and inner ring of the sliding bearing is imaged with this group refractive index. The measurement of the inner ring liner of the sliding bearing proves the flexibility of the fiber-optic OCT and provides a non-contact, nondestructive testing method for measuring the geometric thickness and internal geometric structure of composite materials. Full article

The growth of using wind energy on a large scale increases the demand for wind energy conversion machines (WECMs), among these converters, the doubly-fed induction generator (DFIG) is the favorite choice. However, DFIG is very sensitive to wind speed variations and grid faults during operation. In order to overcome these undesirable characteristics, this paper proposes a hierarchical fault tolerant control (FTC) to improve the performance of DFIG. The hierarchical fault tolerant control (FTC) approach consists of pitch angle control (PAC) and maximum power point tracking (MPPT). This hierarchical approach demonstrates the robust response under various (low, rated, and high) wind speed ranges and reduces the undesirable DC voltage overshoots during short-circuit disorder. The simulation results are summarized in a logical table, which depicts the order of controlling scheme and operation for a sustainable energy generation system. The proposed control scheme achieved the healthy and the robust dynamic response without deteriorating the grid power quality or stressing the converters, and approved the effectiveness to suppress the DC voltage overshoots and tolerate the lower down short-circuit disorder to its rated range. Full article

Wire electrochemical machining (WECM) has great advantages and potential for fabricating parts with ruled surfaces made of difficult-to-machine materials. Characterized by a relatively short flow path, a pulsating radial electrolyte supply in WECM is proposed to improve the machining capability for thick workpieces. The tool is a tube electrode with a line of micro-holes on cylindrical surface. This paper introduces research into the processing of micro-holes in the tube electrode using a rotating helical electrode. The quantitative relationship among the feed rate, the applied voltage, and the diameter of the outlet holes was determined experimentally. A tube electrode with holes of varying diameters was fabricated by adjusting the applied voltage. Using it as a tool electrode, kerfs with a length of 10 mm and an averaged width of 0.903 mm were machined at a feed rate of 6 μm/s in a 30 mm-thick block, and there was no short circuit during processing. It was shown experimentally that using a tube electrode with holes of varying diameters as a tool electrode provides better process capacity for pulsating radial electrolyte supply in WECM. Full article
