Daylight discomfort glare evaluation is important when selecting shading properties. New standards recommend allowable glare frequency limits but do not specify the modeling accuracy required for annual glare risk assessment. Fast simulation tools allow users to perform hourly glare evaluations within minutes. However, reliable evaluation of glare through roller shades requires accurate modeling of their specular and diffuse transmission characteristics, affected by color, materials, and weaving technology. This study presents a systematic comparison between commonly used glare simulation methods against the “ground truth” Radiance ray-tracing tool rpict in terms of hourly daylight glare probability (DGP), hourly vertical illuminance (Ev), and annual visual discomfort frequency. The results are presented for two shade fabrics using light transmission models with and without a peak extraction algorithm (Radiance–aBSDF and Radiance–BSDF) for the specular component. The impact of sky/sun discretization on glare prediction is also discussed. The results show that the Radiance 5–Phase Method (5PM) is superior when modeling direct sunlight and DGP through shades, while other investigated methods (3–Phase Method, imageless DGP, ClimateStudio Annual Glare) are not as robust for that purpose. Users are encouraged to understand the underlying assumptions in the imageless methods to avoid errors when simulating glare, especially due to the contrast effects. Full article

Evaluating the stray light cancellation performance of an optical system is an essential step in the search for superior optical systems. However, the existing evaluation methods, such as the Monte Carlo method and the ray tracing method, suffer from the problems of vast arithmetic and cumbersome processes. In this paper, a method for a rapid stray light performance evaluation model and quantitatively determining high-magnitude stray light outside the field of view are proposed by adopting the radiative transfer theory based on the scattering property of the bidirectional scattering distribution function (BSDF). Under the global coordinates, based on the derivation of the light vector variation relationship in the near-linear system, the specific structural properties of the off-axis reflective optical system, and the specular scattering properties, a fast quantitative evaluation model of the optical system’s stray light elimination capability is constructed. A loop nesting procedure was designed based on this model, and its validity was verified by an off-axis reflective optical system. It successfully fitted the point source transmittance (PST) curve in the range of specular radiation reception angles and quantitatively predicted the prominence due to incident stray light outside the field of view. This method does not require multiple software to work in concert and requires only 10^–5 orders of magnitude of computing time, which is suitable for the rapid stray light assessment and structural screening of off-axis reflective optical systems with a good symmetry. The method is promising for improving imaging radiation accuracy and developing lightweight space cameras with low stray light effects. Full article

This study delves into the innovation of mini light-emitting diode (mini-LED) backlight module designs, a significant advancement in display technology. The module comprises a substrate, a receiving plane, and an LED structure, which uses a blue light with specific spectral characteristics. When combined with a red-green quantum dot (QD) film, it produces white light. For improved illumination uniformity, the Mini-LED structure was optimized with a focus on the thickness and concentration of layers, especially the TiO₂ diffusion layer. A comprehensive design methodology using LightTools (8.6.0) optical simulation software was employed, linked with MATLAB (R2022a) for varied parameters and using the double deep Q-network (DDQN) algorithm via Python as a reinforcement learning agent. This approach facilitated optimal architecture design based on illumination uniformity. Also, the bidirectional scattering distribution function (BSDF) was employed to calculate the scattering properties of the backlight module’s surface, providing accurate simulation results. The DDQN algorithm enhanced the learning design, reducing simulation runs by 76.7% compared to traditional methods. The optimized solution achieved an impressive illumination uniformity of 83.8%, underscoring the benefits of integrating advanced algorithms into display technology optimization. Full article

We fabricated amorphous photonic structures (APSs) with different periods and hole diameters. The GaN-based white light emitting diodes (LEDs) at nominal correlated color temperatures (CCTs) of 5000 and 6000 K were surface mounted by these APSs. The electroluminescence (EL) measurements showed less luminous efficiency (LE) and higher CCT than the ones of the virginal white LEDs. However, the LEs of many APS-mounted white LEDs increased compared to white the LEDs without APSs at the same CCTs. A finite-difference time-domain (FDTD) simulation was carried out on the ASPs surface-mounted white LEDs and bidirectional scattering distribution functions (BSDFs) of different emissions were transferred to a Monte Carlo ray tracing simulation. The simulated LEs and CCTs conformed well to the experimental ones. The effects of the blue emission transmission and phosphor concentration were simulated to predict the absolute LE enhancement methods for white LEDs. At last, the hopeful APSs for high Les’ general lighting were discussed. Full article

The environmental trace gas monitoring instrument (EMI) is a space-borne imaging spectrometer onboard GaoFen-5, which was launched in May 2018, covering wavelengths in the range of 240–710 nm to measure NO₂, O₃, HCHO, and SO₂. An advanced EMI-2 instrument with a higher spatial resolution and sufficient signal-to-noise is currently planned for launch on the GaoFen-5(02) satellite in 2021. The EMI-2 instrument bidirectional scattering distribution function (BSDF) is obtained from the absolute irradiance and radiance calibration on-ground. Based on EMI-2 earth and sun optical paths, the key factors of BSDF parameters are introduced. An NIST-calibrated 1000 W FEL quartz tungsten halogen lamp and a 2D turntable are adopted for the absolute irradiance calibration. A large aperture integrating sphere system is used for the absolute radiance calibration. Based on absolute irradiance and radiance calibration functions, the BSDF parameters are obtained, with accuracy of 4.9% for UV1, 4.3% for UV2, 4.1% for VIS1, and 4.2% for VIS2. The on-ground measurement results show that the reflectance spectrum can be calculated from BSDF parameters. On-orbit application of the EMI-2 instrument BSDF are also discussed. Full article

We present our efforts on estimating light scattering characteristics from commercial off-the-shelf (COTS) camera lenses in order to deduce thereof a set of generic scattering parameters valid for a specific lens class (double Gauss lenses). In previous investigations, we developed a simplified theoretical light scattering model to estimate the irradiance distribution in the focal plane of a camera lens. This theoretical model is based on a 3-parameter bidirectional scattering distribution function (BSDF), which describes light scattering from rough surfaces of the optical elements. Ordinarily, the three scatter parameters of the BSDF are not known for COTS camera lenses, which makes it necessary to assess them by own experiments. Besides the experimental setup and the measurement process, we present in detail the subsequent data exploitation. From measurements on seven COTS camera lenses, we deduced a generic set of scatter parameters. For a deeper analysis, the results of our measurements have also been compared with the output of an optical engineering software. Together with our theoretical model, now stray light calculations can be accomplished even then, when specific scatter parameters are not available from elsewhere. In addition, the light scattering analyses also allow considering the glare vulnerability of optical systems in terms of laser safety. Full article

Establishing linkages between light detection and ranging (lidar) data, produced from interrogating forest canopies, to the highly complex forest structures, composition, and traits that such forests contain, remains an extremely difficult problem. Radiative transfer models have been developed to help solve this problem and test new sensor platforms in a virtual environment. Many forest canopy studies include the major assumption of isotropic (Lambertian) reflecting and transmitting leaves or non-transmitting leaves. Here, we study when these assumptions may be valid and evaluate their associated impacts/effects on the lidar waveform, as well as its dependence on wavelength, lidar footprint, view angle, and leaf angle distribution (LAD), by using the Digital Imaging and Remote Sensing Image Generation (DIRSIG) remote sensing radiative transfer simulation model. The largest effects of Lambertian assumptions on the waveform are observed at visible wavelengths, small footprints, and oblique interrogation angles relative to the mean leaf angle. For example, a 77% increase in return signal was observed with a configuration of a 550 nm wavelength, 10 cm footprint, and 45° interrogation angle to planophile leaves. These effects are attributed to (i) the bidirectional scattering distribution function (BSDF) becoming almost purely specular in the visible, (ii) small footprints having fewer leaf angles to integrate over, and (iii) oblique angles causing diminished backscatter due to forward scattering. Non-transmitting leaf assumptions have the greatest error for large footprints at near-infrared (NIR) wavelengths. Regardless of leaf angle distribution, all simulations with non-transmitting leaves with a 5 m footprint and 1064 nm wavelength saw around a 15% reduction in return signal. We attribute the signal reduction to the increased multiscatter contribution for larger fields of view, and increased transmission at NIR wavelengths. Armed with the knowledge from this study, researchers will be able to select appropriate sensor configurations to account for or limit BSDF effects in forest lidar data. Full article

With the increasing adoption of building integrated photovoltaics (BIPV), concerns arise about potential glare. While recommended criteria to assess glare exist, it is challenging to apply these in the spatial and temporal domains and communicate the complex data to planning authorities and clients. This paper presents a new computational workflow using annual daylight simulation, material modelling using bi-directional scattering distribution functions (BSDFs) and image-based postprocessing to obtain 3-dimensional renderings of cumulative annual irradiance and glare duration on the built environment. The annual daylight simulation considers relevant sun positions in high temporal resolution (15-min timesteps) and measured BSDFs to model different PV materials. The postprocessing includes a relative irradiance visualisation comparing the impact of a proposed PV proportional to a reference material. It also includes a new spatio-temporal workflow to assess the glare duration based on recommended thresholds. This workflow is demonstrated with a case study of a proposed PV roof for a church, assessing the glare potential of two different PV materials. The visualisations indicate glare durations well below the thresholds with satinated PVs, and in noncritical zones outside observer positions with standard PVs. Thus the proposed PV roof does not cause any disturbing glare. Full article

A multiscale model that enables quantitative understanding and prediction of the size effect on the scattering properties of micro- and nanostructures is crucial for the design of light-emitting diode (LED) surface textures optimized for high light extraction efficiency (LEE). In this paper, a hybrid process for combining full-wave finite-difference time-domain simulation and a ray-tracing technique based on a bidirectional scattering distribution function model is proposed. We apply this method to study the influence of different pattern sizes of a patterned sapphire substrate on GaN-based LED light extraction from the micro-scale to the nano-scale. The results show that near-wavelength–scale patterns with strong diffraction are not expected to enhance the LEE. By contrast, micro-scale patterns with optical diffusion behavior have the highest LEE at a specific aspect ratio, and subwavelength-scale patterns that have antireflection properties show a marked enhancement of the LEE for a wide range of aspect ratios. Full article
