This study addresses the characterization of two-phase flow phenomena in a microchannel heat sink designed to cool high-concentration photovoltaic cells. Two-phase flows can introduce instabilities that affect heat exchange efficiency, a challenge intensified by the small dimensions of microchannels. A single polydimethylsiloxane (PDMS) microchannel was fixed on a stainless steel sheet, heated by the Joule effect, which was cooled by the working fluid HFE 7100 as it undergoes phase change. Experiments were performed using two microchannel widths with a fixed height and length, testing two heat fluxes and three values of the Reynolds number, within the laminar flow regime. Temperature and pressure drop data were collected alongside high-speed and time- and space-resolved thermal images, enabling the observation of flow boiling patterns and the identification of instabilities. Enhanced surfaces with microcavities depict a positive effect of a regular pattern of microcavities on the surface, increasing the heat transfer coefficient by 34–279% and promoting a more stable flow with decreased pressure losses. Full article

Improving the pool boiling heat transfer by changing the properties of the heating surface has been experimentally studied by many researchers. In this paper, two novel microstructured surfaces with open channels were simulated and investigated. The two microstructured surfaces had different cavity positions and different groove widths of open channels. At the same time, a pool boiling experiment on the plain-heated surface was carried out to verify the reliability and accuracy of the CFD model. The results showed the relationship between the heat flux and wall superheat. Moreover, the bubble dynamic behaviors of different surfaces were obtained. It was found that both microstructured surfaces could enhance the pool boiling heat transfer coefficient (HTC) and critical heat flux (CHF). Enlarging the length of the groove gap can not only increase the heat transfer area, but also increase the bubble nucleation rate. However, constantly increasing the groove width will cause the horizontal coalescence of bubbles on the heating surface at low heat flux. When the negative effect of bubble coalescence is higher than the enhancement effect, the boiling heat transfer capacity of the heating surface will decrease unless the heat flux is high enough to delay bubble coalescence. Full article

In this paper, the pool boiling of ethanol was analyzed. The experiments were carried out at atmospheric pressure. Heat transfer surfaces in the form of deep minichannels were made of copper. The channels with a depth of 0.2 to 0.5 mm were milled in parallel. The width of the minichannels was 0.6–1.2 mm, and the depth was 5.5, 6, and 10 mm. The highest heat transfer coefficient, 52 kW/m²K, was achieved for the minichannels with a depth of 6 mm and a width of 0.8 mm. The maximum heat flux of 953 kW/m² was produced using minichannels 5.5 mm deep and 0.5 mm wide. An over threefold increase in the heat transfer coefficient and over a twofold increase in the maximum heat flux in relation to the plain surface were obtained. In the heat flux range 21.2–1035 kW/m², the influence of channel width and depth on the heat exchange process was determined. The diameters of the detaching vapor bubbles were determined on the experimental setup using a high-speed camera. An analytical model was developed to determine the diameter of the departing bubble for the analyzed enhanced surfaces. The model correctly represented the changes in bubble diameter with increasing heat flux. Full article

The International Maritime Organization (IMO) is currently rolling out more restrictive regulations in order to achieve net-zero GHG emissions by 2050. In response, the shipping industry is planning to pivot to green energy sources such as hydrogen fuel. However, since hydrogen has an extremely low boiling point (−253 °C), materials for storing liquid hydrogen must be highly resistant to low-temperature brittleness and hydrogen embrittlement. A 316L stainless steel is a typical material that meets these requirements, and various welds have been studied. In this study, 3 pass butt welding was performed by applying the FCAW (flux cored arc welding) process to 10 mm thick ASTM-A240M-316L stainless steel, with the size of the fusion zone and HAZ investigated by mechanical testing and heat transfer FE analysis according to process variables, such as heat input, welding speed, and the number of passes. In all cases, the yield and tensile strengths were about 10% and 3% higher than the base metal, respectively. Furthermore, heat transfer FE analysis showed an average error rate of 1.3% for penetration and 10.5% for width and confirmed the size of the HAZ, which experienced temperatures between 500 °C and 800 °C. Full article

In this paper, pool boiling of ethanol at atmospheric pressure was analyzed. The enhanced surfaces were made of copper, on which grooves with a depth ranging from 0.2 to 0.5 mm were milled in parallel. The widths of the microchannels and the distances between them were 0.2 mm, 0.3 mm and 0.4 mm, respectively. The highest heat transfer coefficient, 90.3 kW/m²K, was obtained for the surface with a microchannel depth of 0.5 mm and a width of 0.2 mm. The maximum heat flux was 1035 kW/m². For the analyzed surfaces, the maximum heat flux increase of two and a half times was obtained, while the heat transfer coefficient increased three-fold in relation to the smooth surface. In the given range of heat flux 21.2–1035 kW/m², the impact of geometric parameters on the heat transfer process was presented. The diameters of the departing bubbles were determined experimentally with the use of a high-speed camera. A simplified model was proposed to determine the diameter of the departure bubble for the studied surfaces. Full article

In this paper, fluorinated compounds based on sulfolane, cyclopentanone, and gamma-butyrolactone are studied computationally, focusing on their applicability in electrochemical devices and acid–base-related studies. Candidates for solvents with (1) high polarity, (2) good electrochemical stability, and (3) low basicity were searched for. Some of the compounds are studied here for the first time. Electrochemical stabilities, dielectric constants, boiling points, basicities, and lipophilicities were estimated using DFT and COSMO-RS methods with empirical corrections. The effect of fluorination on these properties as well as the bond parameters was studied. The possible synthesis routes of the proposed compounds are outlined. Some molecules display a combination of estimated properties favorable for a solvent, although none of the studied compounds are expected to surpass acetonitrile and propylene carbonate by the width of the electrochemical stability window. Full article

Liquid ammonia is an ideal zero-carbon fuel for internal combustion engines. High-pressure injection is a key technology in organizing ammonia combustion. Characteristics of high-pressure liquid ammonia injection is lack of research. Spray behaviors are likely to change when a high-pressure diesel injector uses liquid ammonia as its fuel. This study uses high-speed imaging with a DBI method to investigate the liquid penetration, width, and spray tip velocity of high-pressure liquid ammonia injection up to 100 MPa. Non-flash and flash boiling conditions were included in the experimental conditions. Simulation was also used to evaluate the results. In non-flash boiling conditions, the Hiroyasu model provided better accuracy than the Siebers model. In flash boiling conditions, a phenomenon was found that liquid penetration and spray tip velocity were strongly suppressed in the initial stage of the injection process, this being the “spray resistance phenomenon”. The “spray resistance phenomenon” was observed when ambient pressure was below 0.7 MPa during 0–0.05 ms ASOI and was highly related to the superheated degree. The shape of near-nozzle sprays abruptly changed at 0.05 ms ASOI, indicating that strong cavitation inside the nozzle caused by needle lift effects is the key reason for the “spray resistance phenomenon”. Full article

Significant amounts of heat flow can be removed with small temperature differences by boiling. This process is used in a variety of industries, e.g., cooling electronics, digital circuits, power sources, etc. Heat dissipation from equipment that generates significant heat flows involves the movement of thermal energy through a wall into a cooling fluid. In the present study, this mechanism was analysed during the boiling of Novec-649 fluid at atmospheric pressure. The heat transfer surfaces were samples made of copper with milled, parallel grooves with a depth of 0.3 mm and a width ranging from 0.2 to 0.5 mm in 0.1 mm increments for straight channels and channels inclined with respect to the vertical by 30° and 60°, respectively. The study was carried out from the onset of nucleate boiling, approximately q = 7 kWm⁻² with a heat flux increase until the critical heat flux was reached. The maximum heat flux was 262 kWm⁻² and the heat transfer coefficient was 19.4 kWm⁻²K⁻¹, achieved for surfaces with straight microchannels. A maximum heat flux increased by 80% and a heat transfer coefficient twice as high compared to a smooth surface was obtained. The performance of the experiment can be deemed adequate, considering that it compares well with the correlation results of different authors. Full article

Traditional microchannel needs to face the flow-reversal difficulty in high heat fluxes due to limited space. It results in large pressure and temperature fluctuation. Porous microchannels arouse more interest to provide a new solution to this problem. Flow boiling experiments in porous microchannels with PFA were investigated. Porous microchannels were sintered by 10 μm (or 30 μm) spherical copper particles with pore-forming agent (Na₂CO₃, 60–90 μm). Porous microchannels were composed of 23 parallel porous microchannels with 600 μm in width and 1200 μm in depth.The addition of PFA (pore-forming agent) could increase the sample porosity. For Q10 series, sample porosities increase from 20.4% to 52.9% with the PFA percentage change from 0% to 40%, while for the Q30 series they increase from 26.6% to 47.5%. Experimental results showed the boiling heat transfer coefficient (HTC) reached the maximum at the moderate porosity for both Q10 and Q30 series. Too large or too small porosity would degrade boiling heat transfer performance. It demonstrated that there existed an optimal range of PFA content for sintered microchannels. PFA content has a minor effect on the average pressure drop and would not cause the rapid increase in flow resistance. Visual observation disclosed that the sample porosity would affect the pressure instability significantly. The sample with moderate porosity showed periodic pressure fluctuation and could establish rhythmical boiling. Particle size also exerted a certain influence on the boiling heat transfer performance. Q30 series could achieve higher HTC and CHF (Critical heat flux) than Q10 series. This is attributed to the larger ratio of layer-thickness-to-particle-size (δ/d) for Q10-series samples. Full article

Stretch fabric provides good formability and does not restrict the movement of the body for increased tension levels. The major expectations of a wearer in an apparel fabric are a high level of mechanical comfort and good aesthetics. The prediction of shrinkage in stretch fabric is a very complex and unexplored topic. There are no existing formulas that can effectively predict the shrinkage of stretch fabrics. The purpose of this paper is to develop a novel model based on an artificial neural network to predict the shrinkage of stretch fabrics. Different stretch fabrics (core-spun lycra yarn) with stretch in the weft direction were manufactured in the industry using a miniature weaving machine. A model was built using an artificial neural network method, including training of the data set, followed by testing of the model on the test data set. The correlation of factors, such as warp count, weft count, greige PPI, greige EPI, and greige width, was established with respect to boil-off width. Full article

To study the processes of boiling on a smooth surface with contrast wettability, a hybrid model was developed based on Lattice Boltzmann method and heat transfer equation. The model makes it possible to describe the phenomena of natural convection, nucleate boiling, and transition to film boiling, and, thus, to study heat transfer and the development of crisis phenomena in a wide range of surface superheats and surface wetting characteristics. To find the optimal configuration of the biphilic surface, at the first stage a numerical simulation was carried out for a single lyophobic zone on a lyophilic surface. The dependences of the bubble departure frequency and the departure diameter of the bubble on the width of the lyophobic zone were obtained, and its optimal size was determined. At the next stage, the boiling process on an extended surface was studied in the presence of several lyophobic zones of a given size with different distances between them. It is shown that in the region of moderate surface superheat, the intensity of heat transfer on biphilic surfaces can be several times (more than 4) higher compared to surfaces with homogeneous wettability. Based on numerical calculations, an optimal configuration of the biphilic surface with the ratios of the lyophobic zones’ width of the order of 0.16 and the distance between the lyophobic zones in the range of 0.9–1.3 to the bubble departure diameter was found. Full article

A combined solar phase-change thermal-storage heating system is proposed, wherein erythritol is used as the phase-change material (PCM) used to fill the thermal-storage device, and the storage cavity is heated and stored with a disc concentrator. The Solidification/Melting, Volume-of-Fluid (VOF) model of ANSYS Fluent software was used to simulate the phase-change process of erythritol inside the thermal-storage device. The thermal-storage device was designed based on our numerical calculations, and its performance was tested. We found that larger PCM-volume fractions correlated with lower PCM volume-expansion rates and longer total melting times during the heat storage process. When the φ value equaled 80%, the PCM solid–liquid-phase interface and temperature distribution were most uniform and showed the best heat storage. In addition, the size of the heat-storage device affected the heat-exchange area, and the total melting time of the PCM decreased and then increased as the width-to-height ratio (I) increased. With this design capacity, the late stage of the charging process of the heat-storage device accounted for 70% of the total time, and the heat energy-utilization rate during the boiling process was 66.3%. Overall, this combined heating system can be considered a very efficient solar energy-utilization terminal for basic domestic energy needs. Full article

Microchannel structures possess high efficiency and high boiling heat transfer coefficient of two-phase flow. In particular, the grid structure has the advantages of a simple pattern, large load capacity, and good surface adaptability. Employing the laser-based powder bed fusion (L-PBF) manufacturing technology, a new method of forming heat transfer grids with a controllable structure is proposed in this study. The formation principle, process, and the reasons for improvements in the boiling heat transfer performance were investigated with stainless steel materials. Laser scanning with varying scan spacings was used to prepare multiple structures with different grid widths and wall heights. On this basis, the porosity and pore morphology of the grid structures were analyzed, followed by pool boiling heat transfer experiments. The results revealed that the grid structure significantly affected the nucleate boiling behavior and increased the critical heat flux (CHF). It was found that the 0.5 mm sample exhibited optimum critical heat transfer performance, with an improvement of 10–27% compared to those of the other four samples (minimum of 63.3 W·cm⁻² and maximum of 93.9 W·cm⁻²). In addition, for samples with a grid width greater than 0.5 mm, the boiling slightly decreased by <5%. When the grid width was further increased, the flow resistance effect and the bubble synapse generation effect tended to converge. In these cases, boiling heat transfer only occurred in a single phase along the direction of the medium wall thickness, thus failing to achieve two-phase heat transfer through bubble growth and collapse. Full article

The paper presents the results of experimental research on pool boiling heat transfer of dielectric liquid FC-72. Measurements were made at atmospheric pressure on open surfaces with microchannels. Heat transfer surfaces, in the form of parallel milled microchannels, were made of copper. The rectangular cross-sectional microchannels were 0.2 to 0.5 mm deep and 0.2 to 0.4 mm wide. The surfaces, compared to a smooth flat surface, provided a five-fold increase in the heat transfer coefficient and a two-fold increase in the critical heat flux. The article analyses the influence of the width and height of the microchannel on the heat transfer process. The maximum heat flux was 271.7 kW/m², and the highest heat transfer coefficient obtained was 25 kW/m²K. Furthermore, the experimental results were compared with selected correlations for the nucleate pool boiling. Full article

Boiling, as the most efficient type of convective heat transfer, is an area of interest in many fields of industry and science. Many works have focused on improving the heat transfer efficiency of boiling by altering the physical and chemical properties of surfaces by using different technological processes in their fabrication. This paper presents experimental investigations into pool boiling on enhanced surfaces with open microchannels. The material of the fabricated surface was copper. Parallel microchannels made by machining were about 0.2, 0.3, and 0.4 mm wide, 0.2 to 0.5 mm deep, and spaced with a pitch equal to twice the width of the microchannel. The experiments were carried out in water at atmospheric pressure. The experimental results obtained showed an increase in the heat flux and the heat transfer coefficient for surfaces with microchannels. The maximum (critical) heat flux was 2188 kW/m², and the heat transfer coefficient was 392 kW/m²K. An improvement in the maximum heat flux of more than 245% and 2.5–4.9 times higher heat transfer coefficient was obtained for the heat flux range of 992–2188 kW/m² compared to the smooth surface. Bubble formation and growth cycle in the microchannel were presented. Two static computational models were proposed to determine the bubble departure diameter. Full article
