This study proposes a design method for a novel bolted endplate rigid connection between circular concrete-filled steel tube (CCFT) columns and wide-flange (WF) steel beams, with particular emphasis on the parametric behavior governing joint performance. Based on the preliminary quasi-static tests, finite element simulations are conducted to evaluate the flexural behavior and failure mechanisms under beam-end maximum moment, followed by an extensive parametric study examining the effects of square tube dimensions, high-strength grout, and column axial load. The numerical results show that the wall thickness of the square steel tube significantly affects grout indentation. A 60% reduction in wall thickness led to a 503% increase in indentation. In contrast, variations in tube dimensions, grout strength, and column axial load within the studied range caused less than a 16% change and did not influence the flexural performance. These results indicate that the constraints on tube dimensions and axial load may be relaxed. The proposed connection effectively overcomes the limitations of conventional CCFT-to-beam joints, including unfavorable stress transfer, complex detailing, and construction inefficiency, by modifying the load-transfer mechanism and reducing the demand on tensile-critical welds, thereby enhancing ductility. Based on the parametric findings, a design method is established, and theoretical analysis confirms that the proposed connection satisfies the stiffness requirements for fully rigid connections. Future quasi-static tests with different member sizes are recommended to validate these findings. Full article

To explore the stress-bearing characteristics of the “inner tensioned steel ring–segment–surrounding rock” composite structure in TBM (Tunnel Boring Machine) pressurized water conveyance tunnels, a 3D refined finite element model for this composite structure was established, with the Class V surrounding rock section of the TBM pressurized water conveyance tunnel in the Rongjiang-Guanbu water diversion project selected as the research subject. The effects of the internal water pressure, surrounding rock type and tunnel burial depth on the mechanical properties of the composite structures are studied. The findings demonstrate that reinforcing the tunnel structure with an inner tensile steel ring can effectively constrain tunnel deformation, diminish the tensile stress of segments and the extent of tensile zones, and enhance the bearing capacity of the composite structure. Under the effect of internal water pressure, the compressive stress of segments, vertical deformation, joint opening degree, stress of connecting bolts, stress of the inner tension ring, and stress of anchor rods all exhibit a reduction compared to the scenario without internal water pressure. Under the combined action of external water–soil pressure and internal water pressure, variations in surrounding rock types lead to respective increases of 37.16%, 15.75%, and 15.12% in the stress of connecting bolts, segment joint misalignment, and anchor bolt stress. As the tunnel burial depth increases, the stress of connecting bolts and the vertical deformation of segment and the joint misalignment of the pipe segment increase by 140%, 107% and 60.61%, respectively. In addition, under the combined action of external water and soil pressure and internal water pressure, the load-sharing ratios of the surrounding rock, pipe segment, inner tension ring and anchor rod are 34.87%, 34.59%, 21.59% and 8.95%, respectively, and the load-sharing ratio of the inner tensioned ring is 85.80% higher than that observed in the absence of internal water pressure, indicating that internal water pressure effectively enhances the load-sharing performance of the inner tensioned steel ring. In the composite structure, the load-sharing ratio of surrounding rock decreases as the surrounding rock class increases (from Class III to Class V). Under the same load condition, the load-sharing ratio of Class III surrounding rock is 7.14% higher than that of Class V. As the tunnel burial depth increases, the inner tensioned steel ring and anchor rods function more prominently as reserve-bearing components. When the tunnel burial depth reaches 71 m, the load-sharing ratio of the inner tension steel ring and anchor rod increases by 19.91% and 55.72%, respectively, compared with that of the buried depth of 31 m. The research results can provide a theoretical reference for the lining design and late reinforcement measures of similar tunnel projects. Full article

Threaded fasteners and tapping joints are essential for the structural integrity and leak-proof performance of subsea systems subjected to high external pressure, aggressive corrosion, and complex cyclic loading. This study presents a comprehensive, systematically structured review of experimental, analytical, and numerical investigations of nut–bolt and threaded connections used in deep- and ultra-deepwater applications. The literature is classified based on governing performance parameters, including thread engagement mechanics, preload retention, fracture behavior, corrosion–fatigue interaction, material evolution, and environmental effects such as hydrostatic pressure and thermal gradients. Experimental observations are critically synthesized with finite element modeling to interpret stress distributions, failure mode transitions, and sealing reliability. A comparative material selection framework is developed by linking conventional carbon steels with advanced alloys such as duplex stainless steels, titanium, and nickel-based materials for long-term subsea service. The novelty of this review lies in the development of an integrated, design-oriented framework that unifies engagement optimization, preload control, fracture modeling strategies, material selection, and environmental coupling into a single engineering interpretation for subsea fastening systems, which has not been collectively addressed in previous studies. The presented synthesis provides direct application guidelines for improving the design, analysis, and operational reliability of subsea bolted joints. Full article

To address the challenges encountered during the in situ welding reinforcement process of hollow spherical joints, including complex construction, limited quality control, and low efficiency, this study proposed a prefabricated reinforced hollow spherical joint. A three-dimensional finite element (FE) model was developed and validated against experimental results to quantify the effects of T-rib web width (b), web thickness (t₁), ferrule thickness (t₂), hollow-sphere diameter (D), and bolt pretension (f_v) on the bearing capacity of the prefabricated joint. Based on these analyses, a predictive model was established for the axial compressive bearing capacity of the prefabricated joint. The results showed that, under compression, the reinforcing components primarily provided a supporting role to the hollow sphere, thereby improving the buckling resistance of the prefabricated joint under compression. The reinforcement mechanism primarily relied on friction between the ferrule and the steel stub for load transfer, with the available frictional resistance governed primarily by bolt pretension and the stiffness of the reinforcing components. When sufficient friction existed between the ferrule and the steel tube, increasing the T-rib web width from 0 mm to 80 mm improved the bearing capacity of the prefabricated joint by 33%. At a T-rib flange height (h)-to-web width ratio of h/b = 1.0, the T-rib satisfied the reinforcement requirement through its inherent strength and stiffness. As the hollow-sphere diameter-to-thickness ratio decreased, the incremental gain in bearing capacity diminished. A predictive model was proposed for compressive bearing capacity by accounting for the support provided by the reinforcing components and the effects of hollow-sphere diameter, steel-tube diameter, and the tube-to-sphere diameter ratio. The proposed model predicted the FE results with errors within ±10%, and the findings can provide a practical reference for designing the compressive bearing capacity of prefabricated reinforced hollow spherical joints. Full article

The stiffness of connections between machine elements depends on the geometry of the product and the condition of the material from which the joined elements are made. This stiffness is also influenced by the state of the surface geometrical texture and the technological parameters during the assembly process. This study examined whether, under normal load, there is a significant change in the geometrical state of the surfaces joined by a multi-bolted connection. It was shown that by properly performing the preloading process for such a connection, loss of the elastic properties of the jointed surfaces can be avoided. The 3D images of the surfaces of the joined elements obtained as a result of the measurements can be used to model multi-bolted connections in a systemic approach. Full article

As critical infrastructures, long, large-diameter shield tunnels require a reliable long-term seismic safety assessment. This study investigates the coupled effects of spatially non-uniform ground motions and bolt corrosion on the seismic response of long, large-diameter shield tunnels. Three types of non-uniform seismic waves (coherent, traveling, and coherent traveling) consistent with the design spectrum were generated, and a 3D discontinuous finite element model was used to analyze tunnel response under various corrosion locations and rates. Results show that non-uniform excitation significantly amplifies the seismic response in the order coherent traveling waves > traveling waves > coherent waves > uniform waves, with coherent traveling waves amplifying key seismic responses by up to 10 times compared with uniform excitation. Corrosion at circumferential joints causes more substantial responses than at longitudinal joints, and combined longitudinal corrosion shows a greater effect than single-joint corrosion. Under coherent traveling waves with high corrosion rates, the seismic response exhibits a distinct “top stronger than bottom” distribution. This study concludes that accurate seismic performance evaluation requires consideration of both variability in spatial ground motion and bolt corrosion, thereby supporting the seismic design and long-term maintenance of such structures. Full article

This paper proposes a novel prefabricated beam-to-column joint to increase the seismic performance and post-earthquake recoverability of steel frames, which use the shape memory alloy (SMA) bolts and replaceable steel ring dampers. The comparative analysis of the seismic behavior was conducted for three beam-to-column connection types using finite element models. The three connection types include those installed using internal SMA bolts, external SMA bolts, and external SMA bolts with novel ring dampers. In addition, the novel ring damper was analyzed separately. These analysis results indicate that the connection type installed using external SMA bolts is superior to that by internal SMA bolts for the seismic performance of beam-to-column joints. The beam-to-column joints have the best seismic performance among the three joints when equipped with the additional steel ring damper, which can be easily replaced. This ring damper can increase the energy dissipation by approximately 11% and effectively reduce the stress of SMA bolts, which can delay their failure. The increasing preload of SMA bolts and high-strength bolts has a certain positive effect on the improvement of the seismic performance. All of the three joints exhibit excellent self-centering characteristics, with residual displacements nearly at zero. The gap of replaceable ring dampers can keep the re-centering capacity and improve the energy dissipation of joints. However, the changes in the steel strength of dampers have little impact on the seismic performance. This study verifies the improvement of the replaceable ring dampers on the seismic performance and post-earthquake recoverability, providing a reference for the seismic design of resilient structures. Full article

The steel frame-shear wall composite system has excellent lateral resistance performance in prefabricated steel structure buildings. However, the traditional steel plate concrete shear wall is prone to early buckling of the steel plate and concentrated interface damage under cyclic loading, which limits its energy dissipation capacity. This study presents a steel plate-enhanced reinforced concrete shear wall (SPRCSW) with an internal corrugated steel plate and double-layer steel mesh working together and conducts a selection study based on finite element analysis. Under the same design conditions, the peak bearing capacity in the positive and reverse directions of the SPRCSW is increased by approximately 55.4% and 46.9%, respectively, compared to the ordinary reinforced concrete shear wall, with a ductility coefficient reaching 6.08. The stiffness decline is mild, and the hysteretic curve is complete. Then, this paper forms an SR-SPRCSW composite structural system by combining the new shear wall with a steel frame using semi-rigid joints. Through the comparison of the finite element analysis and low-cycle reverse loading test results of the SR-SPRCSW structure, it is verified that the overall structural system shows good agreement in hysteretic response, skeleton curve characteristics, and failure mode under both research methods, with the peak shear bearing capacity error of less than 1% and the overall bearing capacity deviation controlled within 8%. On this basis, the key parameters of the semi-rigid joints in the SR-SPRCSW structure are analyzed. The results show that the strengthening of the “top and bottom + double web” angle steel joint can raise the peak bearing capacity of the SR-SPRCSW structure by approximately 26.1% and the yield displacement by approximately 29.5%; increasing the strength grade and diameter of high-strength bolts can heighten the initial stiffness and bearing capacity of the overall structure, but ductility slightly decreases; the thickness of the angle steel has a significant impact on the stiffness and deformation capacity of the structure, and a recommended range of values with better comprehensive performance is provided. The findings offer valuable insights for designing seismic-resistant semi-rigid steel frames with steel plate reinforced concrete shear walls and optimizing their parameters. Full article

Beam-to-column connections govern both seismic performance and post-earthquake repairability of steel moment-resisting frames. Yet direct, apples-to-apples comparisons among welded, bolted, and repair-oriented replaceable-fuse moment connections are still scarce, which hinders rational selection for resilient construction. This study conducts a unified finite-element comparison of three representative joint archetypes—W-RBS, Bolted, and Prefab-web-fuse—under monotonic and cyclic loading. Consistent moment-rotation definitions are adopted, and normalized indices are introduced to compare hysteresis shape, degradation, and energy dissipation across joint concepts with different strength scales. Component-wise plastic dissipation is also extracted to quantify damage localization and assess main-frame protection and replaceability. Results reveal clear trade-offs: W-RBS provides the highest strength and dissipation but degrades most in stiffness; the bolted joint shows pinching due to interface compliance; and the web-fuse concept concentrates inelastic demand in a replaceable segment, supporting repairability-oriented design. The proposed framework offers mechanism-based guidance for selecting steel moment connections toward resilient and repairable frames. Full article

Bolted joints are extensively used in a wide range of industrial and commercial structures, making their condition monitoring essential for ensuring structural integrity and operational safety. Under the influence of vibration, cyclic loading, and environmental factors, bolts may gradually lose preload, which can degrade joint stiffness and eventually lead to structural failure. To address this issue, this study presents a smart percussion system developed on a Raspberry Pi platform that integrates acoustic signal acquisition, real-time signal processing, and visualization of diagnostic results. A bolt looseness detection strategy combining audio feature extraction with unsupervised learning is proposed. In contrast to traditional percussion-based approaches that depend on supervised learning and predefined baseline datasets, the proposed method does not require prior reference data, significantly improving its adaptability and ease of deployment across different structures, which shows essential practical significance. Experimental investigations demonstrate the effectiveness and advantages of the proposed system, indicating its strong potential to enhance percussion-based bolt looseness detection and to support real-time structural health monitoring, which are real-world engineering applications. Full article

The mechanical method has become a new construction method for connected aisles in metro tunnels due to its advantages of fast construction speed, high safety, and minimal ground disturbance. During the tunneling process, the interaction mechanism between the composite segment and the shield cutterhead is complex. Taking Shenzhen Metro Line 8 No. 1 Connected Aisle as the research object, a 3D refined model of the shield cutterhead, composite segments and bolt system were built with Abaqus to investigate their dynamic response under cutting. The Drucker–Prager damage model and contact algorithm were introduced to describe the nonlinear behavior of the cutting process. The reliability of the numerical model was verified by concrete cutting tests and on-site Fiber Bragg Grating monitoring, and good agreements were observed. Results show cutterhead cutting first induces circumferential squeezing, then extends longitudinally with a notable time lag, and longitudinal dynamic response is much stronger than transverse. Affected by cutterhead thrust–rotation coupling, cuttable segments have larger displacement with maximum 0.07 mm, forming an asymmetric deformation zone. Ring joint opening follows “a distal attenuation of the opening amount” rule with maximum 0.018 mm, while bolt stress and displacement show “near-end concentration with gradient attenuation”, with longitudinal bolts being more responsive. Mechanical disturbance from small-shield cutting is minimal, with tunnel segment deformation, joint openings, and bolt stress all remaining well below code-specified allowable values. Numerical results show good agreement with field monitoring data of ring joint openings obtained using Fiber Bragg Grating (FBG) sensors, confirming the reliability of the simulation. The results can provide references for structural design and construction parameter optimization of composite segments in a connected aisle. Full article

Bolted joints are extensively used in mechanical and civil engineering structures because of their low cost, standardized design, and ease of installation and maintenance. The preload in a bolted connection is critical for ensuring joint stability and service reliability; however, preload degradation commonly occurs under complex operating conditions, particularly in environments involving sustained or cyclic vibration. To tackle this problem, this study proposes a portable, force-controllable percussion system for bolt looseness detection. The system integrates a solenoid-driven automatic percussion device, acoustic signal acquisition, onboard data-processing, and real-time visualization of diagnostic results. By adjusting the driving current of the solenoid, the percussion force can be accurately controlled, ensuring stable and repeatable excitation. Benefiting from its compact structure and low cost, the proposed system is suitable for real-time, on-site inspection of bolt looseness. Furthermore, a novel audio-processing approach based on a Siamese Capsule Network is developed to identify bolt looseness conditions. Compared with existing percussion-based techniques, the proposed method exhibits improved classification performance, especially in recognizing bolt states that are unseen during training. Exploratory experimental results validate the effectiveness of the proposed system and demonstrate its strong potential for practical engineering applications. Full article

Hydrodynamic cavitation (HC) is an efficient technique for biodiesel production. The main contribution of this study is the development of a modular reactor with a universal stainless steel joint, whose design facilitates the installation, replacement, and maintenance of the orifice plate by eliminating flanges and bolts during assembly. Using this reactor, the study evaluated the synergistic interaction between feed pressure and methanol:oil molar ratio in the transesterification of soybean oil, employing a 3² factorial design. The orifice plate was 3 mm thick and had 19 holes with a diameter of 1.0 mm, installed downstream of the pump. The process was carried out for 45 min, using NaOH at 1 wt% relative to the oil and at 60 ± 5 °C. Feed pressures of 1.72, 2.41, and 3.10 bar and methanol:oil molar ratios of 6:1, 8:1, and 10:1 were evaluated, reaching a maximum yield of 92.98% at 3.10 bar and 8:1. Analysis of variance (ANOVA) confirmed a significant interaction (p < 0.0001) and allowed a second-order polynomial model to be fitted (R² = 0.9981). In contrast, conventional mechanical agitation required 90 min to achieve 95% yield. The biodiesel produced met most American Society for Testing and Materials (ASTM) D6751 requirements, confirming the potential of HC as a viable alternative for intensifying biodiesel production. Full article

This study investigates the mechanical behavior of jointed rock mass tunnels through numerical simulations using UDEC software. Focusing on the time-dependent variation in joint shear stiffness, a theoretical model is proposed to characterize the evolution of shear stiffness over time. Based on this model, numerical simulations are conducted to analyze tunnel stability and associated deformation patterns. A variable shear stiffness model is first established in UDEC, which effectively captures the evolution of shear creep displacement along rock joints. Incorporating this model, an adaptive support scheme involving locally extended rock bolts is introduced to improve long-term tunnel stability. The proposed approach is further validated through a comparative analysis with field monitoring data obtained from a tunnel in Yunnan Province. The results indicate that creep effects significantly influence tunnel behavior, leading to rapid increases in crown settlement and expansion of the surrounding rock disturbance zone during the early stages following excavation. Optimizing the bolt layout is shown to effectively reduce the extent of the disturbed zone and enhance the tunnel’s load-bearing capacity. Finally, a novel reinforcement optimization method for jointed rock mass tunnels is proposed, along with a key threshold value for assessing tunnel stability, thereby providing theoretical support for practical engineering applications. Full article

A focus-control mechanism is essential for maintaining the optical performance of spaceborne telescopes, the mirror alignment of which is degraded by gravity release, moisture desorption, and thermal distortion in orbit. Achieving submicrometer-level drive accuracy is challenging because bearing deformation and bolted-joint hysteresis introduce nonlinear behavior, which must be addressed in ultraprecision mechanisms. In this study, the 1D Computer-Aided Engineering (1DCAE) approach was applied to the early-phase design of a spaceborne focus-control mechanism for developing practical design equations that accurately represent the stiffness and deformation characteristics of key components. Modification functions derived from finite element analysis (FEA) and the indirect fictitious boundary integral method (IFBIM) were incorporated into the equations for a linear guide, rectangular spring, and bearing deformation. These equations showed excellent agreement with analytical solutions, numerical simulations, and experimental data, achieving accuracies within 3% and 2.5% for the linear guide and rectangular spring, respectively, and close correspondence with the IFBIM-based bearing deformation reference values. Integrating the equations into the 1DCAE model enabled accurate prediction of the nonlinear drive characteristics of the mechanism and improved the overall drive accuracy to one-fortieth that of the initial design. In conclusion, 1DCAE provides an effective and computationally efficient framework for optimizing ultraprecision mechanisms used in space applications. Full article
