Aerosols significantly impact the brightness temperature (BT) in thermal infrared (IR) channels, and ignoring their effects can lead to relatively large observation-minus-background (OMB) bias in radiance calculations. The accuracy of aerosol datasets is essential for BT simulations and bias reduction. This study incorporated aerosol reanalysis datasets from the Modern-Era Retrospective Analysis for Research and Applications, Version 2 (MERRA-2) and Copernicus Atmosphere Monitoring Service (CAMS) into the Advanced Radiative Transfer Modeling System (ARMS) to compare their impacts on BT simulations from the Geostationary Interferometric Infrared Sounder (GIIRS) and their effectiveness in reducing OMB biases. The results showed that, for a sandstorm event on 10 April 2023, incorporating total aerosol data from the MERRA-2 improved the BT simulations by 0.56 K on average, surpassing CAMS’s 0.11 K improvement. Dust aerosols notably impacted the BT, with the MERRA-2 showing a 0.17 K improvement versus CAMS’s 0.06 K due to variations in the peak aerosol level, thickness, and column mass density. Improvements for sea salt and carbonaceous aerosols were concentrated in the South China Sea and Bay of Bengal, where the MERRA-2 outperformed CAMS. For sulfate aerosols, the MERRA-2 excelled in the Bohai Sea and southern Bay of Bengal, while CAMS was better in the northern Bay of Bengal. These findings provide guidance for aerosol assimilation and retrieval, emphasizing the importance of quality control and bias correction in data assimilation systems. Full article

The statistical retrieval of atmospheric parameters will be greatly affected by the accuracy of the simulated brightness temperatures (BTs) derived from the radiative transfer model. However, it is challenging to further improve a physical-based radiative transfer model (RTM) developed based on the physical mechanisms of wave transmission through the atmosphere. We develop a deep neural network-based RTM (DNN-based RTM) to calculate the simulated BTs for the Microwave Temperature Sounder-II onboard the Fengyun-3D satellite under different weather conditions. The DNN-based RTM is compared in detail with the physical-based RTM in retrieving the atmospheric temperature profiles by the statistical retrieval scheme. Compared to the physical-based RTM, the DNN-based RTM can obtain higher accuracy for simulated BTs and enables the statistical retrieval scheme to achieve higher accuracy in temperature profile retrieval in clear, cloudy, and rainy sky conditions. Due to its ability to simulate microwave observations more accurately, the DNN-based RTM is valuable for the theoretical study of microwave remote sensing and the application of passive microwave observations. Full article

Satellite remote sensing is the best way to derive sea surface skin temperature (SST_skin) in the Arctic. However, as surface temperature retrieval algorithms in the infrared (IR) part of the electromagnetic spectrum are designed to compensate for atmospheric effects mainly due to water vapor, MODIS SST_skin retrievals have larger uncertainties at high latitudes where the atmosphere is very dry and cold, which is an extreme in the distribution of global conditions. MODIS R2019 SST_skin fields are currently derived using latitudinally and monthly dependent algorithm coefficients, including an additional band above 60°N to better represent the effects of Arctic atmospheres. However, the R2019 processing of MODIS SST_skin still has some unrevealed error characteristics. This study uses 21 years (2002–2022) of collocated, simultaneous satellite brightness temperature (BT) data from Aqua MODIS and in situ buoy-measured subsurface temperature data from iQuam for validation. Unlike elsewhere over the oceans, the 11 μm and 12 μm BT differences are poorly related to the column water vapor at high latitudes, resulting in poor atmospheric water vapor correction. Anomalous BT difference signals are identified, caused by the temperature and humidity inversions in the lower troposphere, which are especially significant during the summer. Although the existence of negative BT differences is physically reasonable, this makes the retrieval algorithm lose its effectiveness. Moreover, the statistics of the MODIS SST_skin data when compared with the iQuam buoy temperature data show large differences (in terms of mean and standard deviation) for the matchups at the Northern Atlantic and Pacific sides of the Arctic due to the disparity of in situ measurements and distinct surface and vertical atmospheric conditions. Therefore, it is necessary to further improve the retrieval algorithms to obtain more accurate MODIS SST_skin data to study surface ocean processes and climate change in the Arctic. Full article

Aerosols exert a significant influence on the brightness temperature observed in the thermal infrared (IR) channels, yet the specific contributions of various aerosol types remain underexplored. This study integrated the Copernicus Atmosphere Monitoring Service (CAMS) atmospheric composition reanalysis data into the Radiative Transfer for TOVS (RTTOV) model to quantify the aerosol effects on brightness temperature (BT) simulations for the Advanced Himawari Imager (AHI) aboard the Himawari-8 geostationary satellite. Two distinct experiments were conducted: the aerosol-aware experiment (AER), which accounted for aerosol radiative effects, and the control experiment (CTL), in which aerosol radiative effects were omitted. The CTL experiment results reveal uniform negative bias (observation minus background (O-B)) across all six IR channels of the AHI, with a maximum deviation of approximately −1 K. Conversely, the AER experiment showed a pronounced reduction in innovation, which was especially notable in the 10.4 μm channel, where the bias decreased by 0.7 K. The study evaluated the radiative effects of eleven aerosol species, all of which demonstrated cooling effects in the AHI’s six IR channels, with dust aerosols contributing the most significantly (approximately 86%). In scenarios dominated by dust, incorporating the radiative effect of dust aerosols could correct the brightness temperature bias by up to 2 K, underscoring the substantial enhancement in the BT simulation for the 10.4 μm channel during dust events. Jacobians were calculated to further examine the RTTOV simulations’ sensitivity to aerosol presence. A clear temporal and spatial correlation between the dust concentration and BT simulation bias corroborated the critical role of the infrared channel data assimilation on geostationary satellites in capturing small-scale, rapidly developing pollution processes. Full article

For synthetic aperture microwave radiometers, the problem of Radio Frequency Interference (RFI) is becoming more and more serious, which affects both the scientific retrieval of remote sensing data and the imaging quality of brightness temperature (BT) images. In the visibility data domain, the array factor synthesis algorithm is commonly employed to mitigate RFI sources and their Gibbs trailing. In the BT image domain, the CLEAN algorithm is typical applied to mitigate RFI sources and their Gibbs trailing. However, the array factor synthesis algorithm can result in anomalous BT points near the “zero trap” region, and the CLEAN algorithm will miss some BT points below a certain threshold. In this paper, a Bi-domain combined mitigation algorithm is proposed to mitigate RFI sources and their Gibbs trailing. Following initial mitigation in the visibility data domain, dual thresholds are applied to normalize anomalous BT points near the “zero trap” region, thereby enhancing imaging quality. The effectiveness of the Bi-domain combined mitigation algorithm is verified by using both measured data from SMOS L1A and simulated data. The experimental results demonstrate that the Bi-domain combined mitigation algorithm is superior to the array factor synthesis algorithm and the CLEAN algorithm in mitigating RFI sources and their Gibbs trailing. Full article

The infrared (IR) satellite remote sensing of sea surface skin temperature (SST_skin) is challenging in the northern high-latitude region, especially in the Arctic because of its extreme environmental conditions, and thus the accuracy of SST_skin retrievals is questionable. Several Saildrone uncrewed surface vehicles were deployed at the Pacific side of the Arctic in 2019, and two of them, SD-1036 and SD-1037, were equipped with a pair of IR pyrometers on the deck, whose measurements have been shown to be useful in the derivation of SST_skin with sufficient accuracy for scientific applications, providing an opportunity to validate satellite SST_skin retrievals. This study aims to assess the accuracy of MODIS-retrieved SST_skin from both Aqua and Terra satellites by comparisons with collocated Saildrone-derived SST_skin data. The mean difference in SST_skin from the SD-1036 and SD-1037 measurements is ~0.4 K, largely resulting from differences in the atmospheric conditions experienced by the two Saildrones. The performance of MODIS on Aqua and Terra in retrieving SST_skin is comparable. Negative brightness temperature (BT) differences between 11 μm and 12 μm channels are identified as being physically based, but are removed from the analyses as they present anomalous conditions for which the atmospheric correction algorithm is not suited. Overall, the MODIS SST_skin retrievals show negative mean biases, −0.234 K for Aqua and −0.295 K for Terra. The variations in the retrieval inaccuracies show an association with diurnal warming events in the upper ocean from long periods of sunlight in the Arctic. Also contributing to inaccuracies in the retrieval is the surface emissivity effect in BT differences characterized by the Emissivity-introduced BT difference (EΔBT) index. This study demonstrates the characteristics of MODIS-retrieved SST_skin in the Arctic, at least at the Pacific side, and underscores that more in situ SST_skin data at high latitudes are needed for further error identification and algorithm development of IR SST_skin. Full article

This study investigates the long-term stability of the Suomi National Polar-orbiting Partnership (S-NPP) Visible Infrared Imaging Radiometer Suite (VIIRS) moderate-resolution Thermal Emissive Bands (M TEBs; M12–M16) covering a period from February 2012 to August 2020. It also assesses inter-sensor consistency of the VIIRS M TEBs among three satellites (S-NPP, NOAA-20, and NOAA-21) over eight months spanning from 18 March to 30 November 2023. The field of interest is limited to the ocean surface between 60°S and 60°N, specifically under clear-sky conditions. Taking radiative transfer modeling (RTM) as the transfer reference, we employed the Community Radiative Transfer Model (CRTM) to simulate VIIRS TEB brightness temperature (BTs), incorporating European Centre for Medium-range Weather Forecasts (ECMWF) reanalysis data as inputs. Our results reveal two key findings. Firstly, the reprocessed S-NPP VIIRS TEBs exhibit a robust long-term stability, as demonstrated through analyses of the observation minus background BT differences (O-B ∆BTs) between VIIRS measurements (O) and CRTM simulations (B). The drifts of the O-B BT differences are consistently less than 0.102 K/Decade across all S-NPP VIIRS M TEB bands. Notably, observations from VIIRS M14 and M16 stand out with drifts well within 0.04 K/Decade, reinforcing their exceptional reliability for climate change studies. Secondly, excellent inter-sensor consistency among these three VIIRS instruments is confirmed through the double-difference analysis method (O-O). This method relies on the O-B BT differences obtained from daily VIIRS operational data. The mean inter-VIIRS O-O BT differences remain within 0.08 K for all M TEBs, except for M13. Even in the case of M13, the O-O BT differences between NOAA-21 and NOAA-20/S-NPP have values of 0.312 K and 0.234 K, respectively, which are comparable to the 0.2 K difference observed in overlapping TEBs between VIIRS and MODIS. These disparities are primarily attributed to the significant differences in the Spectral Response Function (SRF) of NOAA-21 compared to NOAA-20 and S-NPP. It is also found that the remnant scene temperature dependence of NOAA-21 versus NOAA-20/S-NPP M13 O-O BT difference after accounting for SRF difference is ~0.0033 K/K, an order of magnitude smaller than the corresponding rates in the direct BT comparisons between NOAA-21 and NOAA-20/S-NPP. Our study confirms the versatility and effectiveness of the RTM-based TEB quality evaluation method in assessing long-term sensor stability and inter-sensor consistency. The double-difference approach effectively mitigates uncertainties and biases inherent to CRTM simulations, establishing a robust mechanism for assessing inter-sensor consistency. Moreover, for M12 operating as a shortwave infrared channel, it is found that the daytime O-B BT differences of S-NPP M12 exhibit greater seasonal variability compared to the nighttime data, which can be attributed to the idea that M12 radiance is affected by the reflected solar radiation during the daytime. Furthermore, in this study, we’ve also characterized the spatial distributions of inter-VIIRS BT differences, identifying variations among VIIRS M TEBs, as well as spatial discrepancies between the daytime and nighttime data. Full article

The Advanced Meteorological Image (AMI) onboard GEOKOMPSAT 2A (GK-2A) enables the retrieval of dust aerosol optical depth (DAOD) from geostationary satellites using infrared (IR) channels. IR observations allow the retrieval of DAOD and the dust layer altitude (24 h) over surface properties, particularly over deserts. In this study, dust events in northeast Asia from 2020 to 2021 were investigated using five GK-2A thermal IR bands (8.7, 10.5, 11.4, 12.3, and 13.3 μm). For the dust cloud, the brightness temperature differences (BTDs) of 10.5 and 12.3 μm were consistently negative, while the BTD of 8.7 and 10.5 μm varied based on the dust intensity. This study exploited these optical properties to develop a physical approach for DAOD lookup tables (LUTs) using IR channels to retrieve the DAOD. To this end, the characteristics of thermal radiation transfer were simulated using the forward model; dust aerosols were explained by BTD (10.5, 12.3 μm)—an intrinsic characteristic of dust aerosol. The DAOD and dust properties were gained from a brightness temperature (BT) of 10.5 μm and BTD of 10.5, 12.3 μm. Additionally, the cumulative distribution function (CDF) was employed to strengthen the continuity of 24-h DAOD. The CDF was applied to the algorithm by calculating the conversion value coefficient for the DAOD error correction of the IR, with daytime visible aerosol optical depth as the true value. The results show that the DAOD product can be successfully applied during the daytime and nighttime to continuously monitor the flow of yellow dust from the GK-2A satellite in northeast Asia. In particular, the validation results for IR DAOD were similar to the active satellite product (CALIPSO/CALIOP) results, which exhibited a tendency similar to that for IR DAOD at night. Full article

For an aperture synthesis radiometer (ASR), the visibility and the modified brightness temperature (BT) are related to the Fourier transform when the distance between the system and the source is in the far-field region. BT reconstruction can be achieved using G-matrix imaging. However, for ASRs with large array sizes, the far-field condition is not satisfied when performing performance tests in an anechoic chamber due to size limitations. Using far-field imaging methods in near-field conditions can introduce errors in the images and fail to correctly reconstruct the BT. Most of the existing methods deal with visibilities, converting near-field visibilities to far-field visibilities, which are suitable for point sources but not good for extended source correction. In this paper, two near-field imaging methods are proposed based on the near-field distance. These methods enable BT reconstruction in near-field conditions by generating improved resolving matrices: the near-field G-matrix and the F-matrix. These methods do not change the visibility measurements and can effectively image both the point source and the extended source in the near field. Simulations of point sources and extended sources in near-field conditions demonstrate the effectiveness of both methods, with F-matrix imaging outperforming near-field G-matrix imaging. The feasibility of both near-field imaging methods is further validated by carrying out experiments on a 10-element Y-array system. Full article

Observations from the Advanced Microwave Sounding Unit-A (AMSU-A) onboard polar-orbiting satellites are considered to be the most effective satellite data in terms of obviously reducing operational prediction errors. However, there are still significant difficulties in the application of AMSU-A low-level channel data assimilation over land. One of them is the inaccurate surface skin temperature (SKT) of the background on land areas, which leads to significant uncertainty in the accuracy of simulating brightness temperature (BT) in these channels. Therefore, improving the accuracy of SKT in the background field is a direct way to improve the assimilation effect of these low-level channel data over land. In this study, both high-spatio-temporal-resolution automatic weather station (AWS) observation data from China in September 2021 and the AMSU-A observation data from NOAA-15/18/19 and MetOp-A were used. Based on the Advanced Research version of the Weather Research and Forecast model (WRF-ARW) and Gridpoint Statistical Interpolation (GSI) assimilation system, we first analyzed the differences in SKT between AWS observations and model simulations and then attempted to directly replace the simulated SKT with the observation data. On this basis, the differences in BT simulation effects over the land area of Southwest China before and after replacement were meticulously analyzed and compared. In addition, the impacts of SKT replacement in areas with different terrain elevations and in cloudy areas were also evaluated. The results indicate that the SKTs of background fields were generally lower than the surface observations, whereas the diurnal variation in SKT was not well simulated. After replacing the SKT of the background field with station observations, the BT differences between the observation and background (O–B, observation minus background) were remarkably reduced, especially for channels 3–5 and 15 of the AMSU-A. The volume of data passing the GSI quality control significantly increased, and the standard deviation of O–B decreased. Further analysis showed that the improvement effect was better in areas at an elevation above 1600 m. Moreover, introducing SKT observations leads to a significant and stable improvement over BT simulations in cloudy areas over land. Full article

The lake water surface temperature (LWST) is a critical parameter influencing lake ecosystem dynamics and addressing challenges posed by climate change. Traditional point measurement techniques exhibit limitations in providing comprehensive LWST data. However, the emergence of satellite remote sensing and unmanned aerial vehicle (UAV) Thermal Infrared (TIR) technology has opened new possibilities. This study presents an approach for retrieving plateau lake LWST (p-LWST) from UAV TIR data. The UAV TIR dataset, obtained from the DJI Zenmuse H20T sensor, was stitched together to form an image of brightness temperature (BT). Atmospheric parameters for atmospheric correction were acquired by combining the UAV dataset with the ERA5 reanalysis data and MODTRAN5.2. Lake Water Surface Emissivity (LWSE) spectral curves were derived using 102 hand-portable FT-IR spectrometer (102F) measurements, along with the sensor’s spectral response function, to obtain the corresponding LWSE. Using estimated atmospheric parameters, LWSE, and UAV BT, the un-calibrated LWST was calculated through the TIR radiative transfer model. To validate the LWST retrieval accuracy, the FLIR Infrared Thermal Imager T610 and the Fluke 51-II contact thermometer were utilized to estimate on-point LWST. This on-point data was employed for cross-calibration and verification. In the study area, the p-LWST method retrieved LWST ranging from 288 K to 295 K over Erhai Lake in the plateau region, with a final retrieval accuracy of 0.89 K. Results demonstrate that the proposed p-LWST method is effective for LWST retrieval, offering technical and theoretical support for monitoring climate change in plateau lakes. Full article

A unique End-of-Life (EOL) Deep Space View Test (DSVT) was performed on 27 November 2021 for the Advanced Microwave Sounding Unit-A (AMSU-A) and the Microwave Humidity Sounder (MHS) onboard the first EUMETSAT MetOp-A satellite in the deorbiting process. The purpose of this test is to recalibrate the antenna sidelobe, to derive antenna emission, and to quantify the in-orbit asymmetric scan biases of AMSU-A and MHS to, ultimately, improve Near Real-Time (NRT) products for MetOp-B and -C and the entire Fundamental Climate Data Records (FCDR). In this study, MetOp-A AMSU-A and MHS EOL DSVT data on 27 November 2021 have been analyzed. The deep space scene antenna temperatures were first applied for the antenna pattern correction; then, the antenna reflector channel emissivity values were derived from the corrected temperatures. For the MHS, the observed scan-angle-dependent brightness temperatures (BTs) for all channels were well behaved after the antenna pattern correction, except for channel 1. The derived antenna reflector emissivity values from this test are 0.0016, 0.0036, 0.0036, and 0.0019 for channels 1, 3, 4, and 5, respectively. For AMSU-A, the deep space view counts were not homogeneous during the test period, exhibiting large variations in the along-track and cross-track directions, mainly due to the instrument temperature’s rapid change during the test period. The large relative noise in the deep space view observations negatively impacted the data quality and limits the value of this test. The large relative noise may contribute to the different emissivity values derived from the same frequency for channels 9 to 14. We also found unexpected scan-angle-dependent BT after antenna pattern correction for quasi-vertical (QV) channels 1 and 2 when compared to the emission model. Further investigation using a simulation confirmed that channels 1 and 2 are QV channels, as designed. Full article

Haiyang-1D (HY-1D) is the second operational satellite in China’s Haiyang-1 series of satellites, carrying the Chinese Ocean Color and Temperature Scanner (COCTS) to provide ocean color and temperature observations. The radiometric calibration is a prerequisite to guarantee the quality of the satellite observations and the derived products, and the radiometric calibration of the thermal emissive bands of HY-1D/COCTS can effectively improve the accuracy of sea surface temperature (SST) derived from the thermal infrared data. In this paper, a study on the regional cross-calibration of the COCTS thermal emissive bands is conducted for high-accuracy SST observations in the South China Sea. The Visible Infrared Imaging Radiometer Suite (VIIRS) on board the NOAA-20 satellite launched by the National Oceanic and Atmospheric Administration (NOAA) is selected as the calibration reference sensor, and a double-difference cross-calibration method is used for HY-1D/COCTS thermal infrared brightness temperature (BT) evaluation. The results show that the bias of the 11 µm and 12 µm thermal emissive bands of COCTS and VIIRS in the South China Sea are 0.101 K and 0.892 K, respectively, and the differences in BTs between the two sensors show temperature dependence. The cross-calibration coefficients are obtained and used to correct the BT of the COCTS thermal emissive bands. The bias of the BT of the 11 µm and 12 µm bands of COCTS are about 0.01 K after cross-calibration. To further validate the results, COCTS post-calibration data were examined using the NOAA-20 Cross-track Infrared Sounder (CrIS) data as a third-party source. The BT is calculated with the spectral response functions of the COCTS thermal emissive bands using the convolution calculation of the CrIS hyperspectral region observations. The comparison shows a small bias between the post-calibration COCTS thermal emissive band observations and CrIS, which is consistent with the comparison between VIIRS and CrIS. The accuracy of the post-calibration COCTS thermal emissive band BT data in the South China Sea has been significantly improved. Full article

The cloud phase is one of the most important parameters of clouds. In this paper, we propose a method for cloud phase classification that synergistically utilizes the far- and thermal-infrared bands based on the Atmospheric Emitted Radiance Interferometer (AERI) at the Atmospheric Radiation Measurement West Antarctic Radiation Experiment (AWARE) observatory in 2016. The possible features in the far- and thermal-infrared bands are analyzed based on the differences in the simulated cloud brightness temperature (BT) spectra with different cloud phases. Using the support vector machine (SVM) algorithm, four features are determined to identify the cloud phase, which include the BT at 900 cm⁻¹, the slope of the fitted function of BT in the 900–1000 cm⁻¹ interval, the BT difference (BTD) between 512 cm⁻¹ and 726 cm⁻¹, and the BTD between 550 cm⁻¹ and 726 cm⁻¹. Here, the performance of the proposed method is evaluated with Shupe’s and Turner’s method. The monthly average accuracy of the proposed method, the method without the two far-infrared features, and Turner’s method are about 76%, 36%, and 49%, respectively, which infer the good performance of the proposed method and also indicate that the far-infrared band features can effectively enhance cloud phase classification. It is notable that, compared to Shupe’s method, the accuracy for the proposed method is only 61% during the Antarctic summer, which results from the definitions of cloud phase and radiative effect. In addition, the accuracy is only 44% for Turner’s method in seasons with a low frequency of mixed clouds due to the significant effect of water vapor. Full article

Enhancing the spatial resolution of real-aperture microwave radiometers is an essential research topic. The accuracy of the numerical values of brightness temperatures (BTs) observed using microwave radiometers directly affects the precision of the retrieval of marine environmental parameters. Hence, ensuring the accuracy of the enhanced brightness temperature values is of paramount importance when striving to enhance spatial resolution. A spectrum extension (SE) method is proposed in this paper, which restores the suppressed high-frequency components in the scene BT spectrum through frequency domain transformation and calculations, specifically, dividing the observed BT spectrum by the conjugate of the antenna pattern spectrum and applying a Taylor approximation to suppress error amplification, thereby extending the observed BT spectrum. By using a convolutional neural network to correct errors in the calculated spectrum and then reconstructing the BT through inverse fast Fourier transform (IFFT), the enhanced BTs are obtained. Since the extended BT spectrum contains more high-frequency components, namely, the spectrum is closer to that of the original scene BT, the reconstructed BT not only achieves an enhancement in spatial resolution, but also an improvement in the accuracy of BT values. Both the results from simulated data and satellite-measured data processing illustrate that the SE method is able to enhance the spatial resolution of real-aperture microwave radiometers and concurrently improve the accuracy of BT values. Full article
