Dynamic Line Rating (DLR) is increasingly important for maximizing capacity of existing overhead transmission lines. Conventional thermal rating methods, such as IEEE 738 and model conductors as single, isothermal cylinders and offer limited guidance for multi-conductor bundles, not fully capturing the complex aerodynamic and thermal interactions present in high-voltage networks. This study addresses these limitations by presenting a high-fidelity, two-dimensional coupled thermal-fluid model developed in COMSOL Multiphysics 4.3b. Single and bundled configurations (two-conductor, three-conductor and four-conductor) are analyzed under steady-state conditions using the Shear Stress Transport (SST) turbulence model, accounting for sub-conductor spacing, wind speed, and interactions between temperature distribution and airflow. Simulation results are compared with ampacity calculations from relevant standards to evaluate limitations of simplified models. Results show that leeward conductors reach temperatures up to ~4 °C higher than windward conductors, forming the thermal bottleneck, with peak temperatures of ~103.3 °C versus ~99 °C for single conductors. For bundled conductors, the current required to keep the maximum temperature at 100 °C was calculated, and this value was found to be approximately 3% lower than the current predicted by IEEE 738. The study emphasizes the importance of multiphysics, position-aware simulations to prevent overloading and optimize transmission line utilization. Full article

Ultra-high-voltage (UHV) transmission lines are prone to galloping and oscillations under ice and wind loads, posing risks to system reliability and safety. Accurate aerodynamic coefficients are essential for evaluating these effects, but conventional wind tunnel and CFD methods are costly and inefficient for practical applications. To address these challenges, this study develops a surrogate model for rapid and accurate prediction of aerodynamic coefficients for six-bundle conductors. Initially, a CFD model to calculate the aerodynamic coefficients of six-bundle conductors was proposed and validated against wind tunnel experimental results. Subsequently, Latin hypercube sampling (LHS) was employed to generate datasets covering wind speed, icing shape, icing thickness, and wind attack angle. High-throughput numerical simulations established a comprehensive aerodynamic database used to train and validate multiple tree-based surrogate models, including decision tree (DT), random forest (RF), extremely randomized trees (ERTs), gradient boosted decision tree (GBDT), and extreme gradient boosting (XGBoost). Comparative analysis revealed that the XGBoost-based model achieved the highest prediction accuracy, with an R² of 0.855 and superior generalization performance. Feature importance analysis further highlighted wind speed and icing shape as the dominant influencing factors. The results confirmed the XGBoost surrogate as the most effective among the tested models, providing a fast and reliable tool for aerodynamic prediction, vibration risk assessment, and structural optimization in UHV transmission systems. Full article

This study investigates the effect of seasonal conductor sag on electromagnetic field (EMF) exposure to near 400 kV double-bundle overhead transmission lines. The conductor sag study resulted in clearance values of 28.0 m for winter (−10 °C, sag ≈ 7.0 m) and 23.4 m for summer (+35 °C, sag ≈ 11.65 m). For both seasonal examples, the electric field strength and magnetic flux density were calculated at a pedestrian height of 1.5 m, and the image approach to account for ground effects. The winter setup resulted in maximum values of 1.35 kV/m (E) and 27.2 µT (B), while the summer configuration produced higher values of 1.96 kV/m and 38.5 µT, respectively. Autumn field measurements, representing intermediate seasonal circumstances, produced average values of 1.294 kV/m and 1.399 µT, with peaks of 8.39 kV/m and 6.85 µT for electric field and magnetic flux density, respectively. The electric field projections were nearly identical to measurements; however, the magnetic field predictions were significantly higher, most likely due to the model’s assumptions of balanced currents and ideal geometry. These findings suggest that seasonal conductor sag variation is a real and substantial factor in assessing EMF exposure, with the electric field being particularly sensitive to clearance changes. The findings emphasize the need to incorporate a large analysis into EMF compliance assessments, especially in cases where terrain relief between towers may further diminish clearance in mid-span regions. Full article

Icing on eight-bundled conductors can significantly alter their aerodynamic behavior, potentially leading to structural instabilities such as galloping. This study employed wind tunnel experiments and numerical simulations to analyze the aerodynamic parameters of each iced conductor across various angles of attack. The simulations incorporated detailed stranded conductor geometries to assess their influence on aerodynamic accuracy. Incorporating stranded geometry in simulations reduced average errors in lift and drag coefficients by 45–50% compared to smooth models. The Den Hartog coefficient prediction error decreased from 15.6% to 3.9%, indicating improved reliability in oscillation predictions. Additionally, conductors with larger windward areas exhibited more pronounced wake effects, with lower sub-conductors experiencing greater wake interference than upper ones. The above results illustrate that explicit modeling of stranded conductor surfaces enhances the precision of aerodynamic simulations, providing a more accurate framework for predicting icing-induced galloping in multi-bundled conductors. Full article

Icing on transmission lines in cold regions can cause asymmetry in the conductor cross-section. This asymmetry can lead to low-frequency, large-amplitude oscillations, posing a serious threat to the stability and safety of power transmission systems. In this study, the aerodynamic characteristics of crescent-shaped and sector-shaped iced eight-bundled conductors were systematically investigated over an angle of attack range from 0° to 180°. A combined approach involving wind tunnel tests and high-precision computational fluid dynamics (CFD) simulations was adopted. In the wind tunnel tests, static aerodynamic coefficients and dynamic time series data were obtained using a high-precision aerodynamic balance and a turbulence grid. In the CFD simulations, transient flow structures and vortex shedding mechanisms were analyzed based on the Reynolds-averaged Navier–Stokes (RANS) equations with the SST k-ω turbulence model. A comprehensive comparison between the two ice accretion geometries was conducted. The results revealed distinct aerodynamic instability mechanisms and frequency-domain characteristics. The analysis was supported by Fourier’s fourth-order harmonic decomposition and energy spectrum analysis. It was found that crescent-shaped ice, due to its streamlined leading edge, induced a dominant single vortex shedding. In this case, the first-order harmonic accounted for 67.7% of the total energy. In contrast, the prismatic shape of sector-shaped ice caused migration of the separation point and introduced broadband energy input. Stability thresholds were determined using the Den Hartog criterion. Sector-shaped iced conductors exhibited significant negative aerodynamic damping under ten distinct operating conditions. Compared to the crescent-shaped case, the instability risk range increased by 60%. The strong agreement between simulation and experimental results validated the reliability of the numerical approach. This study establishes a multiscale analytical framework for understanding galloping mechanisms of iced conductors. It also identifies early warning indicators in the frequency domain and provides essential guidance for the design of more effective anti-galloping control strategies in resilient power transmission systems. Full article

High-voltage underground cables inevitably experience frequency-dependent electromagnetic (EM) losses, driven primarily by skin and proximity effects. These losses become more severe at higher harmonic frequencies, which are increasingly common in modern power networks. In traditional multi-segment cable designs, uninsulated conductor bundles enable large circular eddy current loops that elevate AC resistance and exacerbate both skin and proximity phenomena. This paper investigates the impact of introducing a thin insulating layer between individual conductor strings in a five-segment high-voltage cable model. Two insulation thicknesses, 75 µm and 100 µm, are examined via two-dimensional finite element (FE) harmonic analysis at 0, 50, 150, and 250 Hz. By confining eddy currents to smaller loops within each conductor, the insulating layer achieves up to a 60% reduction in AC losses compared to the baseline uninsulated model, lowering the ratio of AC to DC resistance from about 3.66 down to 1.47–1.49 at 250 Hz. The findings confirm that adding even a modest inter-strand insulation is highly effective at mitigating skin and proximity effects, with only marginal additional benefit from thicker insulation. Such designs offer improved energy efficiency and reduced thermal stress in underground cables, making them attractive for modern power distribution systems where harmonic content is pervasive. Full article

This study presents an experimental investigation for the galloping performance of the transmission line system with rime under wind excitation. A full aeroelastic model wind-tunnel test is conducted to investigate the dynamic response of a two-bundled transmission line system with rime under different conditions. The time histories of the displacement of the conductor and the acceleration of the tower are measured in detail to analyze the characteristic of the wind-induced response. A comprehensive parametric experiment is performed to explore the effects of wind speed, wind direction, the number of conductor spans and the coupling between the conductor and the tower on the galloping performance of the transmission line system with rime. The results showed that the wind speed, wind direction and the number of conductor spans have significant influence on the galloping performance of conductor. The zero-degree wind direction is the most dangerous direction for the conductor. The multi-span conductor has different galloping initiation wind speed and vibration characteristics compared to the single-span conductor. The coupling effect between the conductor and the tower has trivial influence on the response of tower. This study uses 3D-printing models to simulate the aerodynamic shape of ice-covered wires with different thicknesses for wind-tunnel tests and obtains the influence of a series of parameters on the galloping vibration of transmission tower line systems. Full article

Aiming to improve on the low accuracy of current transmission line icing prediction models and ignoring the objective law of icing of transmission lines, a transmission line icing prediction model considering the effect of transmission line tension on the bundle of icing thickness is proposed, based on a convolutional neural network (CNN) and bidirectional gated recurrent unit (BiGRU). Firstly, the finite element calculation model of the conductor and insulator system was established, and the change rule between transmission line tension and icing thickness was studied. Then, the convolutional neural network and bidirectional gated recurrent unit were used to construct a transmission line icing thickness prediction model The model incorporated a weighted fusion of soft−dynamic time warping (Soft−DTW) and the icing change rule as the loss function. Optimal weights were determined through the utilization of the grid search algorithm and cross−validation, contributing to an enhancement of the model’s generalization capabilities and a reduction in prediction errors. The results indicate that the proposed prediction model can consider the impact of line operating parameters, avoiding the shortcomings of prediction results conflicting with actual physical laws. Compared with traditional non−mechanical models, the proposed model showed reductions in root mean square error (RMSE), mean absolute error (MAE), and mean absolute percentage error (MAPE) by 0.26–0.51%, 0.24–0.44%, and 5.77–13.33%, respectively, while the coefficient of determination (R2) increased by 0.07–0.13. Full article

In this study, the coupled ordinary differential equations for the galloping of the first two modes in iced bundled conductors, including in-plane, out-of-plane, and torsional directions, are derived. Furthermore, through numerical analysis, the critical conditions of this modal galloping are determined in the range of wind speed–sag parameters, and the galloping patterns and variation laws in different parameter spaces are analyzed. The parameter space is then divided into five regions according to the different galloping modes. Under the multimodal coupling mechanism of galloping, the impact of single and two kinds of coupled mode galloping on the spatial nonlinear behavior is explored. The results reveal that the system exhibits an elliptical orbit motion during single mode galloping, while an “8” motion pattern emerges during coupled mode galloping. Moreover, two patterns of “8” motion are displayed under different parameter spaces. This research provides a theoretical foundation for the design of transmission lines. Full article

Exposure to quasi-electrostatic field induced currents is a hazard of live-line transmission work. These steady-state induced currents are typically less than 1 mA, and their sensory effects range from imperceptible to painful depending on the person and conditions such as contact area and duration. Permanent injury from these currents is unlikely but they can distract workers, increasing the risk of injury from falls or other dangers. Identifying contact current severity and training workers can help reduce the risk of accidents. Measuring induced currents along a climbing route is time-consuming and simulation is challenging because of the geometric complexity of the worker, the transmission structure, conductor bundles, and electric fields in the climbing space. This research explores the suitability of a recently published adaptation of the charge simulation method for calculating worker-induced currents. The method uses Fourier principles to improve computational efficiency while explicitly modeling all bundle subconductors. The research also examines simplifications for modeling lattice structures and human geometry. Calculated currents compare well to measurements for a worker climbing a 400 kV lattice structure. This indicates the method is a practical option for calculating steady-state contact current severity. A simple calculation is suggested for estimating these currents. Full article

The galloping condition of an iced eight-bundle conductor tower line system, under different parameters, is studied by using a finite element model of a multi-span iced eight-bundle conductor tower line system. The galloping frequency, amplitude, traces of multi-span iced eight-bundle conductors under different wind velocities, span lengths, and initial angles of wind attack are discussed. The different tower line connection methods are compared, based on existing research on the relationship between the aerodynamic characteristics of the conductor and galloping conditions. The results show that the galloping situation of a multi-span iced eight-bundle conductor tower line system varies greatly depending on the conditions, which has a significant impact on the tower line. Full article

The use of time domain reflectometry (TDR) for real-time monitoring of bridge scour process has gone through several stages of development. The recently-proposed concept of bundled TDR sensing cable, in which two sets of insulated steel strands are twisted around and connected to a central coaxial cable to form a compact sensing cable, is a major change that has several advantages including the bottom-up sensing mechanism. Nevertheless, there is big room for improving its measurement sensitivity and signal to noise ratio (SNR). Changes in waveguide configuration also need to be made to avoid the adverse effect of insulation abrasion observed in field implementation. This study evaluated three new conductor and insulator configurations for constructing the sensing waveguide, including a balanced two-conductor waveguide (Type I), an unbalanced three-conductor waveguide with insulation coating on the middle conductor (Type II) and an unbalanced three-conductor with insulation coating on the two outer conductors (Type III). In all cases, the spacing between the two sets of steel strands (i.e., the waveguide conductors) was especially enlarged by replacing some steel strands with non-conductor wires to increases measurement sensitivity and avoid shorted conditions due to insulation abrasion. Experimental results show that Type III has the best performance on all counts. A new improved TDR sensing cable was hence proposed based on Type III configuration. Its performance was further evaluated by a full-scale experiment to take into consideration the long range of measurement in most field conditions. Detailed discussions on improvements of measurement sensitivity and SNR, limitation of sensing range, and mitigating the adverse effect of insulation abrasion are presented. Full article

Overhead high-voltage conductors are the chief components of power lines and their safety has a strong influence on social and daily life. In the recent decade, the airborne laser scanning (ALS) technique has been widely used to capture the three-dimensional (3D) information of power lines and surrounding objects. Most of the existing methods focused on extraction of single conductors or extracted all conductors as one object class by applying machine learning techniques. Nevertheless, power line corridors (PLCs) are built with multi-loop, multi-phase structures (bundle conductors) and exist in intricate environments (e.g., mountains and forests), and thus raise challenges to process ALS data for extraction of individual conductors. This paper proposes an automated method to extract individual subconductors in bundles from complex structure of PLCs using a combined image- and point-based approach. First, the input point cloud data are grouped into 3D voxel grid and PL points and separated from pylon and tree points using the fact that pylons and trees are vertical objects while power lines are non-vertical objects. These pylons are further separated from trees by employing a statistical analysis technique and used to extract span points between two consecutive pylons; then, by using the distribution properties of power lines in each individual span, the bundles located at different height levels are extracted using image-based processing; finally, subconductors in each bundle are detected and extracted by introducing a window that slides over the individual bundle. The orthogonal plane transformation and recursive clustering procedures are exploited in each window position and a point-based processing is conducted iteratively for extraction of complete individual subconductors in each bundle. The feasibility and validity of the proposed method are verified on two Australian sites having bundle conductors in high-voltage transmission lines. Our experiments show that the proposed method achieves a reliable result by extracting the real structure of bundle conductors in power lines with correctness of 100% and 90% in the two test sites, respectively. Full article

Power system load growth and transmission corridor constraints are driving industry activity in the area of high surge impedance loading (HSIL). Examples include compact structure design and uprating existing transmission lines. Recent research relating electric field uniformity to transmission line capacity and critical flashover voltage underscored the need for better overvoltage data to quantify insulation margins for HSIL design. To that end, this work extends the finite difference time domain (FDTD) method with distributed corona losses to transmission lines with bundled conductors. The model was adapted for practical use in high-volume statistical transient simulation and applied to an example 500 kV line. Transients included line energization and trapped charge reclosing. Overvoltage profiles and statistical distributions were generated from 9500 simulations obtained by random breaker close timing and variation in line length and altitude. Distributed corona losses reduced 98th percentile line-to-ground switching overvoltages by 4%–14% of nominal. The estimated line-to-ground switching surge flashover probability was 54%–80% lower with corona loss. Corona had less impact on line-to-line overvoltages, but the effects were still notable. Results highlight the importance of considering detailed overvoltage profiles and accounting for corona loss attenuation when seeking to carefully quantify insulation design margins. Full article

In this work, a method to compute the radio interference (RI) lateral profiles generated by corona discharge in high voltage direct current (HVDC) transmission lines is presented. The method is based on a transmission line model that considers the skin effect, through the concept of complex penetration depth, in the conductors and in the ground plane. The attenuation constants are determined from the line parameters and the bipolar system is decoupled by using modal decomposition theory. As application cases, ±500 and ±600 kV bipolar transmission lines were analyzed. Afterwards, parametric sweeps of five variables that affect the RI levels are presented. Both the RI and the maximum electric field were calculated as a function of sub-conductor radius, bundle spacing, and the number of sub-conductors in the bundle. Additionally, the RI levels were also calculated as a function of the soil resistivity, and the RIV (radio interference voltage) frequency. Following this, vector optimization was applied to minimize the RI levels produced by the HVDC lines and differences between the designs with nominal and optimal values are discussed. Full article
