In tunnel construction in western China, a vast amount of carbonaceous slate is encountered. High in situ stress and foliation structures cause the rock mass to exhibit pronounced anisotropic creep, readily inducing a series of engineering disasters like collapses and lining cracks. Investigating the anisotropic time-dependent characteristics of carbonaceous slate is beneficial to the long-term stability of tunnel construction and operation. In view of this, carbonaceous slate specimens with different angles, β, between the foliation plane and loading direction were studied using a graded loading method through uniaxial compression creep tests. The results show that the instantaneous axial strain, ε_i, the axial creep strain, ε_c, the duration time of decelerating creep stage, t_d, and the steady creep strain rate, ${\dot{\epsilon }}_s$, increased with the rise in the loading ratio, k. Their variations followed a power law relationship, with the R² (Coefficient of Determination) values all exceeding 0.95. The value of ${\dot{\epsilon }}_s$ was observed to be less than 1.5 × 10⁻⁴/h when β < 45°, while it was found to exceed 1.5 × 10⁻⁴/h in the cases of $\beta \ge 45°$. The long-term strength, σ_L, of carbonaceous slate showed a U-shaped pattern with the variation in β. The maximum σ_L occurred at β = 90° and the minimum was observed at β = 15°. A fractional nonlinear creep model (FNC model) was developed. The sensitivity analysis reveals that the larger the fractional order n is, the t_d and ${\dot{\epsilon }}_s$ increase. η₂ and E₂ primarily affect the decelerated creep stage, while the ${\dot{\epsilon }}_s$ exhibits a rapid increase with the rise of η₁. To further validate the FNC model, a comparison is made with the traditional Nishihara model. The R² of the FNC model is larger than 0.965, which is higher than that of the Nishihara model (R² ≤ 0.911). The FNC model can effectively cope with the impact of the sudden increase in strain and well describe the characteristics of the decelerating, steady-state, and accelerating creep stages at any stress level and any angle. The results provide a reference for the study of the creep mechanism of layered rocks. Full article

The Huangjindong gold deposit in northeastern Hunan is one of the most representative gold deposits in the Jiangnan Orogenic Belt. The orebodies are mainly hosted in the Neoproterozoic Lengjiaxi Group, which comprises carbonaceous slates. Abundant carbonaceous material (CM) can be found in the host rocks and ore-bearing quartz veins, but its geological characteristics and genesis, as well as its association with gold mineralization, are still unclear. Systematic petrographic observation demonstrated two types of CM in host rocks and ores, i.e., CM1 and CM2. Among them, CM1 is the predominant type and mainly occurs in the layered carbonaceous slates, while CM2 is mostly present in quartz veins and mineralized host rocks. Laser Raman spectroscopic analyses of CM1 were performed at higher temperatures (376–504 °C), and CM2 was generated at similar temperatures (255–435 °C) to gold mineralization. Combined with previous studies, we can conclude that CM1 was produced by Neoproterozoic to early Paleozoic metamorphism before gold mineralization, while CM2 is of hydrothermal origin. Geochemical modeling indicates that CM1 could promote gold precipitation through reduction, as well as facilitate structure deformation and metal absorption as previously proposed. However, hydrothermal CM2 is favorable for gold mineralization because it triggers sulfidation, similar to other Fe-bearing minerals (such as siderite) in the host rocks. Consequently, both types of CM in the Huangjindong deposit are favorable for gold mineralization and carbonaceous slates could be important gold-bearing units for future ore prospecting in the Jiangnan Orogen as well as other places in South China. Full article

Multi-scale assessment of shear behavior in the tunnel carbonaceous slate is critical for evaluating the stability of the surrounding rock. In this study, direct shear tests were conducted on carbonaceous slates from the Muzhailing Tunnel, considering five bedding dip angles (β) and four normal stresses (σ_n). The micro-mechanism was also examined by combining acoustic emission (AE) and energy rate with PFC2D Version 5.0 (particle flow code 2D Version 5.0 software) numerical simulations. The results showed a linear relationship between peak shear stress and normal stress, with the rate of increase inversely related to β. Cohesion increased linearly with β, while internal friction angle and AE activity decreased; the energy release rate is 3.92 × 10⁸ aJ/s at 0° and 1.93 × 10⁸ aJ/s at 90°. Shearing along the preset fracture plane was the main failure mode. Increased normal stress led to lateral cracks perpendicular to or intersecting the shear plane. Cracks along the bedding plane formed a broad shear band with concentrated compressive force, and inclined bedding was accompanied by a dense tension chain along the bedding plane. Full article

The southwest region of China has abundant groundwater and high-temperature geothermal energy. Carbonaceous shale, as one of the typical surrounding rocks in this region, often suffers from deterioration effects due to the coupled action of groundwater chemical erosion and high temperature, which affects the long-term stability of tunnel engineering. In order to investigate the deterioration effects of carbonaceous shale under the coupled action of chemical erosion and high temperature, carbonaceous shale from a tunnel of Lixiang Railway in Yunnan Province was taken as the research object. The microstructure and mineral composition of the samples before and after chemical erosion were obtained with a scanning electron microscope-energy dispersive spectrometer and an X-ray diffraction test. Then, triaxial compression tests were conducted on the samples under different time points and different temperature effects of chemical erosion, and the stress–strain curves and the deterioration laws under a single factor were obtained. An improved numerical simulation method based on the parallel bond model was developed, which can account for the coupled effects of chemical erosion and high temperature on the rock. By simulating the triaxial compression test of carbonaceous shale, the deterioration law of carbonaceous shale under the coupled action was discussed. The results show that chemical erosion has a significant deterioration effect on the triaxial compressive strength of carbonaceous shale, and the degree of deterioration is related to the erosion time. In the first 30 days of erosion, the triaxial compressive strength of carbonaceous shale decreased by 11.38%, which was the largest deterioration range. With the increase in erosion time, the deterioration rate gradually decreased; temperature had a significant threshold effect on the strength of carbonaceous shale, and a clear turning point appeared at about 200 °C. By simulating the deterioration effects of carbonaceous shale under the coupled action of chemical erosion and high temperature, it was found that the longer the duration of chemical erosion, the stronger the temperature sensitivity of carbonaceous shale, and the more serious the loss of compressive strength during the heating process. When the temperature was low, the strength of carbonaceous shale changed little, and some samples even showed an increase in strength; when the temperature was high, the strength of carbonaceous shale decreased significantly, showing deterioration characteristics. The numerical simulation method was compared and verified with the indoor test results, and it was found that the numerical calculation had a good agreement with the test results. Full article

The Dahai Pb-Zn mining area is located in the northwestern Pb-Zn district in northeastern Yunnan Province in the Sichuan-Yunnan-Guizhou Pb-Zn metallogenic triangle (SYGT), east of the Xiaojiang fault. Numerous Pb-Zn deposits (spots) occur in clastic rocks in this area. In this study, the Maliping, Laoyingqing, and Jinniuchang Pb-Zn deposits, representative clastic rocks in the Dahai mining area, were selected as research objects. The results of H-O-S-Sr-Pb isotope analyses show that the three deposits mainly formed through the mixing of a basinal brine with a hydrothermal fluid derived from deep within the underlying (deformed) basement, and brines leached organic matter from wall rocks. The δ³⁴S values range from −2.62–30.30‰. The S isotope results show two different sources of reduced S: one in the Laoyingqing deposit derived from the S reduction generated by the pyrolysis of sulfur-bearing organic matter in the carbonaceous slate of the Kunyang Group, and the second in the Maliping and Jinniuchang deposits derived from the S reduction generated by the thermochemical sulfur reduction (TSR) of seawater sulfate in the Lower Cambrian Yuhucun Formation and Sinian Dengying Formation. The Pb isotope results show that the Pb sources of the three deposits are derived from basement rocks (Kunyang Group) with a small portion derived from Devonian–Permian carbonate rocks and Dengying Formation dolomite, both of which have undergone homogenization during mineralization. The Sr content varied from 0.09629 to 0.2523 × 10⁻⁶, and the study shows that the main source of Sr is a mixture of ore-forming fluid flowing through basement rocks (Kunyang Group) and through sedimentary cover. However, most of the Sr in the Maliping deposit is derived from marine carbonate, and in the Laoyingqing deposit, it is provided by basement rocks (Kunyang Group). Based on a comparative study of the deposits, the Pb-Zn deposits in the clastic rocks of the Dahai mining area and the SYGT belong to the same metallogenic system and were formed under the same metallogenic geological background. Finally, a unified metallogenic model of the two types of fluid migration and mixed mineralization of the Pb-Zn deposit in clastic rocks of the Dahai mining area is proposed. The metallogenic model provides a basis for the study of the Pb-Zn metallogenic system and guidance for deep and peripheral prospecting in this area. Full article

Tunnel projects in the southwestern mountainous area of China are in full swing. According to the tunnel burial depth, structural characteristics, and chemical erosion environments of the Lixiang railway tunnel, carbonaceous slate specimens obtained in the field were taken to experimentally investigate the physical, mechanical, and creep characteristics of the bedding’s slate specimens after chemical erosion. The results of scanning electron microscopy (SEM) indicate that chemical erosion leads to internal damage in the carbonaceous slate specimens, and the internal damages are increasing with the increase of erosion days. Moreover, the specimens’ ultrasonic test (UT) results prove that specimens with smaller bedding angles suffer a more serious erosion and induce more internal cracks. Under conventional triaxial compression conditions with 40 MPa of confining pressures, the conventional triaxial compressive strength (σ_s) decreases with the decrease of the bedding angle and the increase of erosion days, and the failure modes of the specimens are mainly controlled by oblique shear fractures and accompanied by the occurrence of slip dislocation fractures between the bedding inclination. Under creep conditions with 40 MPa of confining pressures, the final deformations of specimens are increasing with the increase of erosion days, which means the longer the erosion days, the greater the deformations. The failure modes of the specimens under creep conditions are controlled by shear fractures, and for the specimen with a 60° bedding angle and long-term erosion, there are block separations and many cavities along the shear planes. Therefore, more attention should be paid to prevent serious failure of the surrounding rock if the surrounding rock has a bedding angle of 60° or suffers long-term erosion. Full article

The transverse isotropy of rock masses formed by sedimentation is a common stratum environment in engineering, and the physical–mechanical properties can degrade due to water–rock interaction (WRI) and natural weathering, which potentially lead to the instability or collapse of tunneling, slopes and mining. Taking the carbonaceous slate of the Muzhailing tunnel as the research object, two types of specimens, which include oven-drying (instant drying in oven after fabrication) and natural air-drying (static weathering for 60 days after fabrication) were prepared, respectively, after which Brazilian tests were carried out and the tensile properties were analyzed under the two conditions. The experimental results showed that the two kinds of carbonaceous slate all show brittle failure, but the mechanical response such as failure displacement and peak load is obviously different. The tensile strength of the specimens is significantly all affected by the bedding, while the cleavage failure patterns of the two kinds are affected to different degrees. The softening coefficient of the natural air-drying specimen is 0.11–0.13, which implies that WRI and natural weathering play a vital role in the course of rock failure but have little influence on the transverse isotropy tensile property of bedding. Moreover, the mechanisms of specimen failure subject to WRI and 60 days’ weathering were explained by the SEM technique, which analyzed the micro-components and observes the process of specimen deterioration due to physicochemical reaction, the gradual development of cracks and erosion by weathering. Full article

To determine the anisotropic mechanical characteristics of carbonaceous slate at the Jinman Mine located in Lancang River Gorge, China, uniaxial compression, acoustic emission (AE) monitoring, and scanning electron microscopy (SEM) tests were conducted. The results show that stress loading directions and bedding effects have a significant impact on strain characteristics. The deformation of slate undergoes compaction, elastic, damage accumulation, and failure stages, and there are significant differences in strain paths. The mechanical properties of grey and carbonaceous slate have significant features, and variations of these properties of carbonaceous slate are more than that of grey slate. The discrete degree is significantly related to the direction of stress loading and different types of slate structures. The AE response intensity is related to the loading mode and slate type. A sudden increase in the AE cumulative ring number near peak stress indicates instability and rupture and is a precursor of rock rupture. The failure patterns and fracture characteristics are significantly correlated to the layered structure of the slate. Slates subjected to vertical loading and parallel loading conditions are dominated by shear fracture and tensile fracture, respectively. The peak strains of gray and carbonaceous slate correspond to brittle failure. The SEM tests indicate that slate samples subjected to parallel loading primarily show a tensile failure compared with slate samples subjected to vertical loading, with fractured sections being of lesser roughness, and scattered fractures and sections being smooth without obvious protrusions or cracks. Full article

Uniaxial compressive strength (UCS) testing requires high-quality core samples, which is a difficult task for weak, highly fractured, thinly bedded, foliated, and weathered rocks. In addition, it is time-consuming and expensive. Because of the good relationship between rock point load strength (PLS) and UCS, the PLS could be used to estimate rock UCS quickly. The lump structure and layer structure of carbonaceous slate are revealed in the tunnels of the China–Laos Railway in the Laos Luang Prabang Suture Zone as one of the important factors leading to tunnel squeezing deformation and support structures. To reveal the relationship between the PLS and UCS of carbonaceous slate in the Luang Prabang Suture Zone, PLS tests and UCS tests of lump-structure carbonaceous slate (lamina plane inconspicuous) and layer-structure carbonaceous slate (lamina plane conspicuous) were performed. Results show that the I_s(50) of lump-structure carbonaceous slate ranged from 0.06 MPa to 0.30 Mpa, the I_s(50) of layer-structure carbonaceous slates which were loaded perpendicular to the lamina plane ranged from 0.64 MPa to 1.25 MPa, the I_s(50) of layer-structure carbonaceous slates which were loaded parallel to the lamina plane ranged from 0.49 MPa to 0.71 MPa, and the correction power index m ranged from 0.42 to 0.51 with an average value of 0.47. Four correlation expressions of carbonaceous slate relationships between PLS and UCS were fitted by zero-intercept linear expression, nonzero intercept linear expression, power expression, and logarithmic expression, and the calculation results were compared with results calculated by the International Society of Rock Mechanics (ISRM) correlation equation. It is concluded that the correlation equation between UCS and PLS recommended by ISRM specifications easily causes soft rock strength overestimation, which affects the correct evaluation of the surrounding rock property and the structural design safety of tunnels and underground projects. The zero-intercept linear equation UCS = 18.45I_s(50) has better goodness of fit and higher accuracy in predicting the UCS of the carbonaceous slate in the Luang Prabang Suture Zone. Full article

There are as many as 25 kinds of minerals (including non-ferrous metals, ferrous metals, rare and dispersed elements, precious metals, non-metallic and energy minerals) enriched in uranium-polymetallic fertile beds in black rock series, which is therefore widely attracting scholars all over the world. However, there is still great controversy in terms of the metallogenic mechanism in such beds. The black rock series have been systematically sampled from the Baizhuyu deposit in northwestern Hunan Province, China based on field geological and radioactivity surveys. Major and trace elements as well as rare earth elements (REE) of uranium-polymetallic phosphorite and its wall rocks were analyzed. Furthermore, carbon and oxygen isotopes, Sm-Nd isotopes, and mineralogy of the Baizhuyu deposit were studied. The results show that dolomite is a normal marine sediment, while and uranium-polymetallic elements were pre-enriched in phosphorites and black carbonaceous argillaceous shales and slates that formed from marine sedimentation and submarine exhalative sedimentation. Hydrothermal reworking to uranium-polymetallic phosphorites is significant as a result of submarine exhalative sedimentation. The research results of this paper can support a better understanding of metallogenesis and the future exploration of uranium-polymetallic phosphorite in the Lower Cambrian Niutitang Formation in the study area. Full article

The decay rates of building stones and, the processes leading to their deterioration is governed by intrinsic properties such as texture, mineralogy, porosity and pore size distribution, along with other extrinsic factors related to the climate and anthropogenic activities. For urban cities such as London, the influence of extrinsic factors like temperature and rainfall, as well as the concentrations of air pollutants, such as sulphur and nitrogen oxides, along with the emissions of carbonaceous aerosols, can be particularly significant. While considering the long-term preservation of building stones used in various heritage sites in the city, it is imperative to consider how the stone could be affected by the changing air pollutant concentrations, superimposed on the effects of climate change in the region, including rising average annual temperature and precipitation with a hotter, drier summer and, warmer, wetter winter months. This paper deals with the intrinsic rock properties of the common building stones of London, including limestone, marble, granite, sandstone, slate, flint as well as bricks, building on known characteristics including strength and durability that determine how and where they are placed in a building structure. The study reviews how these stones decay due to different processes such as salt weathering in sandstone, microcracking of quartz with kaolinisation of K-feldspar and biotite in granite and dissolution of calcite and dolomite, followed by precipitation of sulphate minerals in the carbonate rocks of limestone and marble. In the urban environment of London, with progressive build up in the concentration of atmospheric nitrogen oxides leading to an increasingly acidic environment and, with predicted climate change, the diverse stone-built heritage will be affected. For example, there can be enhanced carbonate dissolution in limestone with increased annual precipitation. Due to the prolonged wetter winter, any sandstone building stone will also undergo greater damage with a deeper wetting front. On the other hand, due to predicted wetter and warmer winter months, microcracking of any plagioclase in a granite is unlikely, thereby reducing the access of fluid and air pollutants to the Ca-rich core of the zoned crystals limiting the process of sericitisation. Management of the building stones in London should include routine expert visual inspection for signs of deterioration, along with mineralogical and compositional analyses and assessment of any recession rate. Full article

The influence of the environment and bacterial cultures on the degree of gold leaching from Au-containing raw materials of different compositions, origins, and with different contents of gold, selected in the Ural Federal District (Russia), was determined. The leaching degree was determined according to the change of the gold concentration in the ore by means of mass-spectrometry with inductively-coupled plasma. It was demonstrated that the degree of Au bioleaching from carbonaceous-argillaceous slates, containing 2.17 g/t of gold, and from pyritic technogenic raw materials, containing 1.15 g/t, when holding them in peptone water and Leten medium reached 92.17% and 87.83%, respectively. Full article
