Tunnel linings play a vital role in underground infrastructure, yet their performance can be severely affected by pre-existing cracks. This study investigates the mechanical behavior and failure mechanisms of C30 concrete with artificial cracks under uniaxial compression, simulating various crack conditions observed in tunnel linings. Specimens were designed with varying crack lengths and orientations. Acoustic emission (AE) monitoring was employed to capture the evolution of internal damage and micro-cracking activity during loading. Fractal dimension analysis was performed on post-test crack patterns to quantitatively evaluate the complexity and branching characteristics of crack propagation. The AE results showed clear correlations between amplitude characteristics and macroscopic crack growth, while fractal analysis provided an effective metric for assessing the extent of damage. To complement the experiments, discrete element modeling (DEM) using PFC3D was applied to simulate crack initiation and propagation, with results compared against experimental data for validation. The study demonstrates the effectiveness of DEM in modeling cracked concrete and highlights the critical role of crack orientation and size in strength degradation. These findings provide a theoretical and numerical foundation for assessing tunnel lining defects and support the development of preventive and reinforcement strategies in tunnel engineering. Full article

Ultra-High-Performance Concrete (UHPC) is a game-changing, innovative material with the merits of exceptional tensile strength, making it suitable for stirrup-free UHPC beams. In this study, two 4.0 m-long large-scale stirrup-free I-shaped UHPC beams were experimentally explored in bending tests and shear tests. Cracking patterns, failure modes, and ultimate load-bearing capacity were obtained. Experimental findings revealed that the shear capacity of the stirrup-free I-shaped UHPC beams with a web thickness of merely 50.0 mm reached more than 20.0 MPa and demonstrated excellent post-cracking shear behavior. Finite element models were established and verified with experimental results to investigate the shear behaviors of stirrup-free I-shaped UHPC beams, considering the parameters of shear span-depth ratio and longitudinal reinforcement strength. The results demonstrated that as the shear span-depth ratio increases, the shear capacity of UHPC beams exhibits a declining trend, accompanied by increased mid-span deflection and a degradation in stiffness. French code and PCI report were suggested for design purposes, due to rationally conservative prediction and explicit physical indication. Full article

Highly efficient shielding materials, transparent in the visible and IR ranges are becoming important in practice. This stimulates the development of cheap methods for creating transparent conductors with low sheet resistance and high optical transparency. This work presents a complex approach based on preliminary modeling of the shielding characteristics of two-layer sandwich structures based on irregular aluminum mesh (IAM) formed by the cracked template method. Experimentally measured spectral dependences of the transmission coefficient of single-layer IAM are used as a reference point for modeling. According to the simulation results, two types of sandwich structures were designed using IAM, with varying filling factors and a fixed PMMA layer thickness of 4 mm. The experimentally measured shielding characteristics of the sandwich structures in the range of 0.01–7 GHz are in good agreement with the calculated data. The obtained structures demonstrate a shielding efficiency of 55.96 dB and 65.55 dB at a frequency of 3.5 GHz (the average range of 5G communications). At the same time, their optical transparency at a wavelength of 550 nm are 84.07% and 75.78%, respectively. Our sandwich structures show electromagnetic shielding performance and uniform diffraction pattern. It gives them an advantage over structures based on regular meshes. The obtained results highlight the prospect of the proposed comprehensive approach for obtaining highly efficient, low-cost optically transparent shielding structures. Such materials are needed for modern wireless communication systems and metrology applications. Full article

External lighting is essential for autonomous inspections of concrete structures in low-light environments. However, previous studies have primarily relied on uniformly diffused lighting to illuminate images and faced challenges in detecting complex crack patterns. This paper proposes two novel algorithms that use directional lighting to classify concrete defects. The first method, named fused neural network, uses the maximum intensity pixel-level image fusion technique and selects the maximum intensity pixel values from all directional images for each pixel to generate a fused image. The second proposed method, named multi-channel neural network, generates a five-channel image, with each channel representing the grayscale version of images captured in the Right (R), Down (D), Left (L), Up (U), and Diffused (A) directions, respectively. The proposed multi-channel neural network model achieved the best performance, with accuracy, precision, recall, and F1 score of 96.6%, 96.3%, 97%, and 96.6%, respectively. It also outperformed the FusedNet and other models found in the literature, with no significant change in evaluation time. The results from this work have the potential to improve concrete crack classification in environments where external illumination is required. Future research focuses on extending the concepts of multi-channel and image fusion to white-box techniques. Full article

The growing use of weathering steel in bridge engineering has highlighted the increasing impact of fatigue damage caused by the combined effects of welding residual stress and vehicular loading. This study investigates the fatigue performance of Q500qENH weathering steel bridge decks by proposing a coupled analysis method for residual stress and fatigue crack growth, utilizing collaborative simulations with Abaqus 2023 and Franc3D 7.0. An interaction model integrating welding-induced residual stress fields and dynamic vehicular loads is developed to systematically examine crack propagation patterns in critical regions, including the weld toes of the top plate and the weld seams of the U-ribs. The results indicate that the crack propagation rate at the top plate weld toe exhibits the most rapid progression, reaching the critical dimension (two-thirds of plate thickness) at 6.98 million cycles, establishing this location as the most vulnerable failure point. Residual stresses significantly amplify the stress amplitude under tension–compression cyclic loading, with life degradation effects showing 48.9% greater severity compared to pure tensile stress conditions. Furthermore, parametric analysis demonstrates that increasing the top plate thickness to 16 mm effectively retards crack propagation, while wheel load pressures exceeding 1.0 MPa induce nonlinear acceleration of life deterioration. Based on these findings, engineering countermeasures including welding defect control, optimized top plate thickness (≥16 mm), and wheel load pressure limitation (≤1.0 MPa) are proposed, providing theoretical support for fatigue-resistant design and maintenance of weathering steel bridge decks. Full article

Fractal theory provides a powerful tool for quantifying complex geometric patterns such as concrete cracks. The box-counting method is widely employed for fractal dimension (FD) calculation due to its intuitive principles and compatibility with image data. However, two critical limitations persist in existing studies: (1) the selection of scale parameters (including minimum measurement scale and cutoff scale) lacks systematization and exhibits significant arbitrariness; (2) insufficient attention to the sensitivity of counting origins compromises the stability and comparability of FDs, severely limiting reliable engineering application. To address these limitations, this study first employs classical fractal images and crack samples to systematically analyze the impact of four minimum measurement scales (2, $\sqrt{2}$, 3, $\sqrt{3}$) and three cutoff scale coefficients (cutoff-to-minimum image side ratios: 1, 1/2, 1/3) on computational accuracy. Subsequently, the farthest point sampling (FPS) method is adopted to select counting origins, comparing two optimization strategies—Count-FD-Mean (mean of fits from multiple origins) and Count-Min-FD (fit using minimal box counts across scales). Finally, the optimized approach is validated through static loading tests on concrete beams. Key findings demonstrate that: the optimal scale combination (minimum scale: $\sqrt{2}$; cutoff coefficient: 1) yields a mere 0.5% average error from theoretical FDs; the Count-Min-FD strategy delivers the highest stability and closest alignment with theoretical values; FDs of beam cracks increase continuously with loading, exhibiting an exponential correlation with midspan deflection that effectively captures crack evolution; uncalibrated scale parameters and counting strategies may induce >40% errors in inferred mechanical parameters; results stabilize with 40–45 counting origins across three tested fractal patterns. This work advances standardization in fractal analysis, enhances reliability in concrete crack assessment, and provides critical support for the practical application of fractal theory in structural health monitoring and damage evaluation. Full article

Tunnel systems are often confronted with issues such as cracks, water seepage, and exposed tendons, all of which compromise their structural integrity. This study utilizes an advanced robotic system equipped with a 3D laser scanner to capture data on visible lining defects. By analyzing the distribution of defects across various tunnel segments, we explore the mechanisms underlying structural cracks. Finite element software is employed to assess stress, deformation, and crack progression within the tunnel linings. The result found that the diversion tunnel’s segments exhibit notable variations: 66.0% of the defects are concentrated in the upper flat section, while 34.0% are found in the inclined shaft segment. Cracks, primarily located in the vault area, characterize these defects. Under water pressure, stress deformation in the intact lining follows a linear escalation pattern. Specifically, after the formation of cracks measuring 0.1 m, 0.2 m, and 0.3 m, circumferential stresses increase by approximately 4.50%, 9.10%, and 15.10%, respectively. Numerical simulations reveal significant stress concentration near the cave entrance at the upper flat break. Crack propagation at the arch crown is found to pose a greater risk than at the sides of the arch waist. These findings offer valuable scientific insights and practical implications for improving safety and enabling intelligent monitoring of power station tunnels. Full article

This study develops a vibration model for functionally graded material (FGM) plates with embedded planar cracks. Based on thin plate theory and von Kármán-type geometric nonlinear strain assumptions, the kinetic and potential energies of each region are derived. Displacement field trial functions are constructed according to boundary conditions, and the Ritz method is employed to determine natural frequencies and vibration modes under small deformation conditions. The investigation focuses on how crack parameters and material gradient coefficients affect vibration characteristics in exponentially graded FGM plates. The results show that natural frequencies decrease with increasing crack length, while crack presence alters nodal line patterns and mode symmetry. During free vibration, the upper and lower surfaces of the crack region exhibit relative displacement. Material gradient effects induce thickness–direction asymmetry, causing non-uniform displacements between the plate’s upper and lower sections. Full article

The microcrack initiation and evolution behavior of Fe-C alloy under uniaxial tensile loading are investigated using molecular dynamics (MD) simulations. The model is stretched along the z-axis at a strain rate of 2 × 10⁹ s⁻¹ and temperatures ranging from 300 to 1100 K, aiming to elucidate the microscopic deformation mechanisms during crack evolution under varying thermal conditions. The results indicate that the yield strength of Fe-C alloy decreases with a rising temperature, accompanied by a 25.2% reduction in peak stress. Within the temperature range of 300–700 K, stress–strain curves exhibit a dual-peak trend: the first peak arises from stress-induced transformations in the internal crystal structure, while the second peak corresponds to void nucleation and growth. At 900–1100 K, stress curves display a single-peak pattern, followed by rapid stress decline due to accelerated void coalescence. Structural evolution analysis reveals sequential phase transitions: initial BCC-to-FCC and -HCP transformations occur during deformation, followed by reversion to BCC and unidentified structures post-crack formation. Elevated temperatures enhance atomic mobility, increasing the proportion of disordered/unknown structures and accelerating material failure. Higher temperatures promote faster potential energy equilibration, primarily through accelerated void growth, which drives rapid energy dissipation. Full article

The destabilizing damage of rock structures in coal beds engineering is greatly influenced by the bearing rupture features and energy evolution laws of rock–coal assemblages with varying height ratios. In this study, we used PFC3D to create rock–coal assemblages with rock–coal height ratios of 2:8, 4:6, 6:4, and 8:2. Uniaxial compression simulation was then performed, revealing the expansion properties and damage crack dispersion pattern at various bearing phases. The dispersion and migration law of cemented strain energy zoning; the size and location of the destructive energy level and its spatiotemporal evolution characteristics; and the impact of height ratio on the load-bearing characteristics, crack extension, and evolution of multiple energies (strain, destructive, and kinetic energies) were all clarified with the aid of a self-developed destructive energy and strain energy capture and tracking Fish program. The findings indicate that the assemblage’s elasticity modulus and compressive strength slightly increase as the height ratio increases, that the assemblage’s cracks begin in the coal body, and that the number of crack bands inside the coal body increases as the height ratio increases. Also, the phenomenon of crack bands penetrating the rock through the interface between the coal and rock becomes increasingly apparent. The total number of cracks, including both tensile and shear cracks, decreases as the height ratio increases. Among these, tensile cracks are consistently more abundant than shear cracks, and the proportion between the two types remains relatively stable regardless of changes in the height ratio. The acoustic emission ringing counts of the assemblage were not synchronized with the development of bearing stress, and the ringing counts started to increase from the yield stage and reached a peak at the damage stage (0.8${\sigma }_{\mathrm{c}}$) after the peak of bearing stress. The larger the rock–coal height ratio, the smaller the peak and the earlier the timing of its appearance. The main body of strain energy accumulation was transferred from the coal body to the rock body when the height ratio exceeded 1.5. The peak values of the assemblage’s strain energy, destructive energy, and kinetic energy curves decreased as the height ratio increased, particularly the energy amplitude of the largest destructive energy event. In order to prevent and mitigate engineering disasters during deep mining of coal resources, the research findings could serve as a helpful reference for the destabilizing properties of rock–coal assemblages. Full article

This study investigates the flexural performance, tensile splitting strength, and fracture behaviour of self-compacting concrete (SCC) reinforced with polypropylene (PP) and basalt (BF) fibres. A total of eleven SCC mixtures with varying fibre types and volume fractions (0.025–0.25%) were tested at 7 and 28 days. In this study, the term high-performance concrete (HPC) refers to SCC mixtures with a 28-day compressive strength exceeding 60 MPa, as commonly accepted in European standards and literature. The control SCC achieved 68.2 MPa at 28 days. While fibre addition enhanced the tensile and flexural properties, it reduced workability, demonstrating the trade-off between mechanical performance and flowability in high-performance SCC. The experimental results demonstrate that both fibre types improve the tensile behaviour of SCC, with distinct performance patterns. PP fibres, owing to their flexibility and crack-bridging capability, were particularly effective at early ages, enhancing the splitting tensile strength by up to 45% and flexural toughness by over 300% at an optimal dosage of 0.125%. In contrast, BF fibres significantly increased the 28-day toughness (up to 15.7 J) and post-cracking resistance due to their superior stiffness and bonding with the matrix. However, high fibre contents adversely affected workability, particularly in BF-reinforced mixes. The findings highlight a dosage-sensitive behaviour, with optimum performance observed at 0.05–0.125% for PP and 0.125–0.25% for BF. While PP fibres improve crack distribution and early-age ductility, BF fibres offer higher stiffness and energy absorption in post-peak regimes. Statistical analysis (ANOVA and Tukey’s test) confirmed significant differences in the mechanical performance among fibre-reinforced mixes. The study provides insights into selecting appropriate fibre types and dosages for SCC structural applications. Further research on hybrid fibre systems and long-term durability is recommended. The results contribute to sustainable concrete design by promoting enhanced performance with low-volume, non-metallic fibres. Full article

Compressed air energy storage in aquifers (CAESA) offers advantages of wide availability and low cost, but natural cracks in aquifers may initiate, propagate, and coalesce under mechanical fields, posing potential security risks for CAESA projects. Most previous research has predominantly addressed straight cracks, while folded cracks, which are commonly encountered in geological formations, remain insufficiently studied. This gap in understanding the mechanical behavior of brittle rocks with folded cracks under wetting conditions presents a critical challenge to ensuring the stability of CAESA operations. In this study, uniaxial compression tests were carried out on sandstone specimens with different crack inclination angles (β) and crack folded numbers (n) under wetting and drying conditions using the MTS 815 testing system combined with an acoustic emission system and digital image correlation system. The deformation behavior, peak strength, crack initiation, and coalescence modes under wetting conditions were comprehensively investigated and compared with those under drying conditions. It can be found that the peak strength increases with β (with the maximum peak strength at 1.59–3.44 times the minimum for the same n), while the effect of n is relatively minor (only 1.09–1.21 times variation); the peak strength under wetting conditions is consistently lower than that under drying conditions (all wet/dry strength ratios < 1). Six distinct crack initiation modes and two coalescence patterns were identified. These findings provide valuable insights into the failure mechanisms of brittle rocks containing folded cracks under varying moisture conditions, offering practical references for anti-cracking design and risk assessment of CAESA cavern structures. Full article

Alteration is a common metamorphic process in igneous formations and recorded geological information in different times and spaces. Owing to its unique location, the igneous rocks of the buried hills in the northern South China Sea exhibit complex lithology and alteration patterns resulting from multi-phase tectonic, magmatic, and climatic influences. Here, we report buried hills igneous rock samples with both hydrothermal alteration and weathering leaching. Based on multi-scale geophysical–chemical data—including scanning electron microscopy, core slice identification, petrophysical–chemical experiments, zircon dating, wireline logs, element cutting logs, seismic profiles, and others—we analyzed the multi-scale alteration characteristics of buried hills igneous rocks and proposed a four-stage alteration model related to Earth activities. Results demonstrate that tectonic movements develop continuous cracks enabling hydrothermal alteration, while burial-hill uplift facilitates weathering leaching. We further find that multi-phase tectonic movements and associated magmatic activities not only influence global hydrothermal cycles but also govern elemental migration patterns, driving distinct alteration mechanisms in these igneous rocks—including plagioclase metasomatism, hornblende replacement, and carbonate dissolution. Additionally, we identify the Cretaceous arid–cold climate as the primary controller for generating chlorite-dominated hydrothermal alteration products. These multi-scale alteration characteristics confirm Late Jurassic Pacific Plate subduction and Cretaceous South China Plate orogeny and may indicate an earlier initial expansion of the South China Sea. Full article

Sustainability in the construction and building sector with the use of greener and more eco-friendly building materials can minimize carbon footprint, which is one of the prime goals of the twenty-first century. The use of natural fibers in ancient and traditional buildings and structures is not new, but in the last fifty years, only man-made fibers have predominantly occupied the market for structural retrofitting or upgrading. This research investigated the potential of utilizing natural fibers, particularly jute fiber products, to enhance masonry’s thermal and structural characteristics. The study meticulously investigated the utilization of materials such as jute net (with a mesh size of 2.5 cm × 1.25 cm), jute fiber diatons, and jute fiber composite mortar (with 1% jute fiber with respect to the dry mortar mass) in the context of masonry upgrading. The research evaluated the structural and thermal performance of these upgraded walls. Notably, the implementation of natural fiber textile-reinforced mortar (NFTRM) resulted in an astounding increase of over 500% in the load-bearing capacity of the walls, while simultaneously enhancing insulation by more than 36%. Furthermore, the study involved a meticulous analysis of crack patterns during in-plane cyclic testing utilizing the advanced Digital Image Correlation (DIC) tool. The upgraded/retrofitted wall exhibited a maximum crack width of approximately 7.84 mm, primarily along the diagonal region. Full article

Micro-crack defects on the surfaces of plate heat exchanger sheets often exhibit a linear grayscale pattern when clustered. In defect detection, traditional methods are more suitable than deep learning models in controlled production environments with limited computing resources to meet stringent national standards, which require low miss rates. However, deep learning models commonly suffer feature loss when detecting individual, small-scale defects, leading to higher leak detection rates. Moreover, in grayscale image line detection using traditional methods, the varying direction, width, and asymmetric grayscale profiles of defects can result in filled grayscale valleys due to width-adaptive smoothing coefficients, complicating accurate defect extraction. To address these issues, this study establishes a theoretical foundation for parameter selection in variable-width defect detection. We propose a directional gradient-based algorithm that mathematically constrains the Gaussian template width to cover variable-width defects with a fixed σ, reframing the detection defect from ridge edges to centrally symmetric double-ridge edges in gradient images. Experimental results show that, when tested in the defective boards library and under simulated factory CPU conditions, this algorithm achieves a miss detection rate of 14.55%, a false detection rate of 21.85%, and an 600 × 600 pixel image detection time of 0.1402 s. Compared to traditional line detection and deep learning object detection methods, this algorithm proves advantageous for detecting micro-crack defects on plate heat exchanger sheets in industrial production, particularly in data-scarce and resource-limited scenarios. Full article
