Search Results (18)

Quantum cascade lasers (QCLs) are important laser sources in the mid-infrared band. Among them, single-mode quantum cascade lasers show significant advantages in key performance such as output wavelength stability and narrow linewidth. These lasers have broad application prospects in fields such as gas detection, component analysis, and medical diagnosis. Single-mode quantum cascade lasers are mainly achieved through distributed feedback (DFB) gratings and distributed Bragg reflector (DBR) gratings. This paper presents the basic principles of quantum cascade lasers and summarizes the research progress of distributed feedback quantum cascade lasers and distributed Bragg reflector quantum cascade lasers in recent years, respectively. Finally, an in-depth discussion and outlook on the development direction and research trends of single-mode quantum cascade lasers are presented. Full article

We reported on a single-longitudinal-mode operated distributed Bragg reflector laser diode emitting at 1950 nm with an on-chip integrated power amplifier. Second-order Chromium–Bragg gratings are carefully designed and fabricated at the end of the ridge waveguide. Achieving a stable single-mode operation with a large injecting current range of 800 mA from 15 °C to 40 °C. The maximum side-mode suppression ratio (SMSR) is up to 42 dB. To increase the output power, an on-chip integrated master oscillator power amplifier (MOPA) is also introduced. MOPA-DBR lasers with different matching configurations between the gain peak and Bragg wavelength are fabricated, resulting in various amplification consequences. The best device is realized with 40 nm red-shifted between Bragg wavelength and photoluminescence (PL) peak. A power amplification of 5.6 times is achieved with the maximum output power of 45 mW. Thus, we put up the feasibility and key design parameters of on-chip integrated power amplification DBR lasers towards mid-infrared. Full article

Thin metal layers such as silver (Ag) are being utilized for various optical and plasmonic applications as well as for electrical purposes, e.g., as transparent electrodes in display devices or solar cells. This paper focuses on optical MEMS applications such as the Fabry–Pérot interferometer (FPI). Within such filters, reflector materials such as distributed Bragg reflectors (DBRs) or subwavelength gratings (SWGs) have been widely used so far, whereas metallic thin films (MTFs) were limited in application due to their comparatively higher absorption. In this paper, thin sputtered Ag layers with thicknesses of 20, 40 and 60 nm on glass substrates have been investigated, and it is shown that the absorption is very low in the visible spectral range (VIS) and increases only in near-infrared (NIR) with increasing wavelength. Thus, we consider Ag-thin layers to be an interesting reflector material at least for the VIS range, which can be easily fabricated and integrated. However, Ag is not inert and stable when exposed to the atmosphere. Hence, it needs a passivation material. For this purpose, AlN has been chosen in this contribution, which can be deposited by sputtering as well. In this contribution, we have chosen thin AlN layers for this purpose, which can also be deposited by sputtering. Thus, various AlN/Ag/AlN-reflector stacks were created and patterned by lift-off technology preferably. The fabricated reflectors were characterized with respect to adhesion, stress, cohesion, homogeneity, and most importantly, their optical properties. It was found that the thickness of the AlN can be used to adjust the reflectance–transmittance ratio in the VIS range, and influences the adsorption in the NIR range as well. Based on the measured values of the reflectors with 40 nm Ag, an exemplary transmission filter characteristics has been predicted for a wavelength range from 400 to 800 nm. Both the maximum transmittance and the full width at half maximum (FWHM) can be tuned by variation of the AlN thickness from 20 to 60 nm. Full article

We propose a highly polarized vertical-cavity surface-emitting laser (VCSEL) consisting of staggered InGaN multiple quantum wells (MQWs), with the resonance cavity and polarization enabled by a bottom nanoporous (NP) n-GaN distributed Bragg reflectors (DBRs), and top TiO₂ high-index contrast gratings (HCGs). Optoelectronic simulations of the 612 nm VCSEL were systematically and numerically investigated. First, we investigated the influences of the NP DBR and HCG geometries on the optical reflectivity. Our results indicate that when there are more than 17 pairs of NP GaN DBRs with 60% air voids, the reflectance can be higher than 99.7%. Furthermore, the zeroth-order reflectivity decreases rapidly when the HCG’s period exceeds 518 nm. The optimal ratios of width-to-period (52.86 ± 1.5%) and height-to-period (35.35 ± 0.14%) were identified. The staggered MQW design also resulted in a relatively small blue shift of 5.44 nm in the emission wavelength under a high driving current. Lastly, we investigated the cavity mode wavelength and optical threshold gain of the VCSEL with a finite size of HCG. A large threshold gain difference of approximately 67.4–74% between the 0th and 1st order transverse modes can be obtained. The simulation results in this work provide a guideline for designing red VCSELs with high brightness and efficiency. Full article

Optical phased arrays (OPAs) have great potential in the fields of integrated solid-state light detection and ranging. The ranging distance of an OPA can be further enlarged by improving the directionality of the grating antenna. A high-directionality silicon nitride grating antenna with a distributed Bragg reflector (DBR) is proposed. The DBR consists of a stack of silicon nitride and silicon dioxide layers, which are utilized as the bottom reflectors to further reduce downward radiation. In a simulation, the directionality of the antenna exceeded 71.6% within the wavelength range of 1420–1740 nm. Additionally, the directionality of the antenna can achieve 97.6% at 1550 nm. Compared to a grating antenna without a DBR, the directionality is improved by 1.52 dB. Moreover, the proposed silicon nitride grating antenna has a large fabrication tolerance and is compatible with CMOS fabrication techniques, showing great potential for enhancing the performance of the integrated optical phased array. Full article

A distributed Bragg reflector (DBR) laser with a specially designed, heavily Er³⁺-doped composite fiber of a length as short as 1.8 cm is demonstrated. The DBR laser, pumped by a 980 nm laser diode with power of up to 370 mW, generates single-frequency radiation at a wavelength of 1535 nm with a narrow instantaneous linewidth of <100 Hz and a high output power of 2 mW. The obtained Er³⁺-doped fiber laser parameters pave the way toward a broad range of practical applications from telecommunications and sensing to scientific research. Full article

Vertical-cavity surface-emitting lasers (VCSELs) have been widely used in consumer electronics, light detection and ranging, optical interconnects, atomic sensors, and so on. In this paper, a VCSEL with the surface metastructure like one-dimensional high-contrast grating (HCG), based on the HCG-DBR vertical cavity, was first designed and fabricated. The polarization characteristic of the HCG-VCSEL were experimentally studied. The p-doped top 4-pair DBR for the current spreading and the direction shift between the HCG and the elliptical oxide aperture may result in a low orthogonal polarization suppression ratio in the HCG-VCSEL. Then, the Bloch surface wave surface-emitting laser (BSW-SEL), based on the HCG-DBR metastructure, is proposed for single-mode, high-efficiency, and high-power output with a low divergence angle. The mode field and the far field profile of the BSW-SEL are calculated for verification. The surface-emitting lasers with surface metastructures are useful for the sensing applications and optical interconnects. Full article

We consider Tamm plasmon polariton in a subwavelength grating patterned on top of a Bragg reflector. We demonstrate dynamic control of the phase and amplitude of a plane wave reflected from such metagrating due to resonant coupling with the Tamm plasmon polariton. The tunability of the phase and amplitude of the reflected wave arises from modulation of the refractive index of a transparent conductive oxide layer by applying the bias voltage. The electrical switching of diffracted beams of the ±1st order is shown. The possibility of doubling the angular resolution of beam steering by using asymmetric reflected phase distribution with integer and half-integer periods of the metagrating is demonstrated. Full article

Electromagnetic (EM) absorbers and emitters have attracted much interest because of their versatile applications. A photonic heterostructure composed of silicon carbide (SiC) layer/germanium (Ge) cavity/distributed Bragg reflector (DBR) has been proposed. Selective emission properties have been investigated through rigorous coupled wave analysis (RCWA) method. The results illustrate that Tamm phonon-polaritons can be excited, and the magnetic field is partially centralized at the junction of Ge cavity and SiC film, aimed to improve the interactions of photon–phonon. The absorptivity/emissivity of the structure can be better optimized by controlling the coupling of surface modes with the incident wave. Near-unity absorption can be achieved through optimizing the SiC grating/Ge cavity/distributed Bragg reflector (DBR) multilayer structure with geometrical parameters of d_s = 0.75 μm, d_g = 0.7 μm, d₁ = 1.25 μm and d₂ = 0.75 μm, respectively. Physical mechanism of selective emission characteristics is deliberated. In addition, the simulation results demonstrate that the emitter desensitizes to the incidence angle and polarization state in the mid-infrared (MIR) range. This research ameliorates the function of the selective emitters, which provides more efficient design for SiC-based systems. Full article

We demonstrate a kind of grating coupler that generates a high quality flat-top beam with a small beamwidth from photonic integrated circuits into free-space. The grating coupler is designed on a silicon-on-insulator wafer with a 220-nm-thick silicon layer and consists of a dual-etch grating (DG) and a distributed Bragg reflector (DBR). By adjusting the structural parameters of DG and DBR, a pixel-level (6.6 µm) flat-top beam with a vertical radiation of −0.5 dB and a mode match of 97% at 1550 nm is realized. Furthermore, a series of high-efficiency grating couplers are designed to create a flat-top beam with different scales. Full article

Since the first demonstration of (Al, In, Ga)N-based blue vertical-cavity surface-emitting lasers (VCSELs) in 2008, the maximum output power (P_max) and threshold current density (J_th) has been improved significantly after a decade of technology advancements. This article reviewed the key challenges for the realization of VCSELs with III-nitride materials, such as inherent polarization effects, difficulties in distributed Bragg’s reflectors (DBR) fabrication for a resonant cavity, and the anti-guiding effect due to the deposited dielectrics current aperture. The significant tensile strain between AlN and GaN hampered the intuitive cavity design with two epitaxial DBRs from arsenide-based VCSELs. Therefore, many alternative cavity structures and processing technologies were developed; for example, lattice-matched AlInN/GaN DBR, nano-porous DBR, or double dielectric DBRs via various overgrowth or film transfer processing strategies. The anti-guiding effect was overcome by integrating a fully planar or slightly convex DBR as one of the reflectors. Special designs to limit the emission polarization in a circular aperture were also summarized. Growing VCSELs on low-symmetry non-polar and semipolar planes discriminates the optical gain along different crystal orientations. A deliberately designed high-contrast grating could differentiate the reflectivity between the transverse-electric field and transverse-magnetic field, which restricts the lasing mode to be the one with the higher reflectivity. In the future, the III-nitride based VCSEL shall keep advancing in total power, applicable spectral region, and ultra-low threshold pumping density with the novel device structure design and processing technologies. Full article

In this paper, we consider several designs for nitride-based vertical-cavity surface-emitting lasers (VCSELs) with a top semiconductor-metal subwavelength grating (SMSG) as the facet mirror. The constructions of the bottom distributed Bragg reflectors (DBRs) used in the VCSEL designs were inspired by devices demonstrated recently by several research groups. A multiparameter numerical analysis was performed, based on self-consistent thermal and electrical simulations. The results show that, in the case of small aperture VCSEL designs, dielectric-based DBRs with metallic or GaN channels enable equally efficient heat dissipation to designs with monolithically integrated DBRs. In the case of broad aperture designs enabled by SMSGs, monolithically integrated DBRs provide much more efficient heat dissipation in comparison to all other considered designs. Full article

A variety of emerging technologies, such as visible light communication systems, require narrow linewidths and easy-to-integrate light sources. Such a requirement could be potentially fulfilled with the distributed Bragg reflector (DBR) lasers, which are also promising for the monolithical integration with other optical components. The InGaN/GaN-based surface etched DBR is designed and optimized using the finite-difference-time-domain (FDTD) method to obtain very narrow-band reflectors that can serve as a wavelength filter. The results reveal that the ultimate reflectivity depends on the grating period and duty ratio of the DBR. Based on the design, the DBR lasers with various duty ratios are fabricated, specifically, the 19th, 13th and 3rd order DBR grating with duty ratio set as 50%/75%/95%. The minimum linewidth could be achieved at 0.45 nm from the 19th order grating with a 75% duty ratio. For comparison, the Fabry–Pérot (F–P) based on the same indium gallium nitride/gallium nitride (InGaN/GaN) epitaxial wafer are fabricated. The full width at half maximum (FWHM) of the DBR laser shrank by 65% compared to that of the conventional F–P laser, which might be helpful in the application of the visible light communication system. Full article

A new type of quasi-distributed sensor system is implemented using an active mode locking (AML) laser cavity with multiple partially reflecting segments. The mode locking frequency of the AML laser is linearly proportional to the overall lasing cavity length. To implement multiple resonators having multiple reflection points installed in a sensing fiber, two types of partial reflectors (PRs) are implemented for an in-line configuration, one with fiber Bragg grating and the other with a fiber Fabry–Perot interferometer. Since the laser has oscillated only when the modulation frequencies for the mode locking frequency match with the corresponding resonator lengths, it is possible to read the multiple partially reflecting segments along the sensing fiber. The difference between two corresponding mode locking frequencies is changing proportionally with the segment length variation between two PRs upon strain application. The segment length change caused by the applied strain can be successfully measured with a linear sensitivity between mode locking frequency and displacement, linearity over 0.99, and spatial position resolution below meter order. Full article

We theoretically analyze the phase noise transfer issue between the pump and the wavelength-converted idler for a nondegenerate four-wave mixing (FWM) scheme, as well as study the vector theory in nonlinear semiconductor optical amplifiers (SOAs), in order to design a polarization-insensitive wavelength conversion system employing dual co-polarized pumps. A tunable sampled grating distributed Bragg reflector (SG-DBR) pump laser has been utilized to enable fast wavelength conversion in the sub-microsecond timescale. By using the detailed characterization of the SGDBR laser, we discuss the phase noise performance of the SGDBR laser. Finally, we present a reconfigurable SOA-based all-optical wavelength converter using the fast switching SGDBR tunable laser as one of the pump sources and experimentally study the wavelength conversion of the single polarization quadrature phase shift keying (QPSK) and polarization multiplexed (Pol-Mux) QPSK signals at 12.5-Gbaud. A wide tuning range (>10 nm) and less than 50 ns and 160 ns reconfiguration time have been achieved for the wavelength conversion system for QPSK and PM-QPSK signals, respectively. The performance under the switching environment after the required reconfiguration time is the same as the static case when the wavelengths are fixed. Full article
