To address compacted soils with high power consumption and waterlogging risks in rice–rapeseed rotation areas of the Yangtze River, this study designed a ditching machine combining a stepped cutter head and trapezoidal cleaning blade, where the mechanical synergy between components minimizes energy loss during soil-cutting and -throwing processes. We mathematically modeled soil cutting–throwing dynamics and blade traction forces, integrating soil rheological properties to refine parameter interactions. Discrete Element Method (DEM) simulations and single-factor experiments analyzed impacts of the inner/outer blade widths, blade group distance, and blade opening on power consumption. Results indicated that increasing the inner/outer blade widths (200–300 mm) by expanding the direct cutting area significantly reduced the cutter torque by 32% and traction resistance by 48.6% from reduced soil-blockage drag; larger blade group distance (0–300 mm) initially decreased but later increased power consumption due to soil backflow interference, with peak efficiency at 200 mm spacing; the optimal blade opening (586 mm) minimized the soil accumulation-induced power loss, validated by DEM trajectory analysis showing continuous soil flow. Box–Behnken experiments and genetic algorithm optimization determined the optimal parameters: inner blade width: 200 mm; outer blade width: 300 mm; blade group distance: 200 mm; and blade opening: 586 mm, yielding a simulated power consumption of 27.07 kW. Field tests under typical 18.7% soil moisture conditions confirmed a <10% error between simulated and actual power consumption (28.73 kW), with a 17.3 ± 0.5% reduction versus controls. Stability coefficients for the ditch depth, top/bottom widths exceeded 90%, and the backfill rate was 4.5 ± 0.3%, ensuring effective drainage for rapeseed cultivation. This provides practical theoretical and technical support for efficient ditching equipment in rice–rapeseed rotations, enabling resource-saving design for clay loam soils. Full article

Crop straw chopping and returning technology has gained global implementation to enhance soil structure and fertility, facilitating increased crop yield. Nevertheless, technological adoption faces challenges from inherent limitations in machinery performance, including poor chopping and returning quality and high energy consumption. Consequently, this review first presented a theoretical framework that described the mechanical properties of straw, its fracture dynamics, interactions with airflow, and motion characteristics during the chopping process. Then, based on the straw returning process, the chopping devices were classified into five types: the chopped blade, the chopping machine, the chopping device combined with a no-tillage or reduced-tillage seeder, the chopping and ditch-burying machine, the chopping and mixing machine, and the harvester-powered chopping device. Advancements in spreading devices were also summarized. Finally, six key directions for future research were proposed: developing an intelligent field straw distribution mapping system, engineering adaptive self-regulating mechanisms for chopping and returning equipment, elucidating the mechanics and kinematics of straw in the chopping and returning process, implementing real-time quality assessment systems for straw returning operations, pioneering high forward-speed (>8 km/h) straw returning machines, and establishing context-specific straw residue management frameworks. This review provided a reference and offered support for the global application of straw returning technology. Full article

The characteristics of soil ditching and backfilling are crucial for orchard ditching operations. However, experimentally investigating the dynamic ditching and backfilling process is currently not feasible. To address this issue, the 3DGZ-50A self-propelled orchard ditching machine (SPODM) was designed using a modular concept, incorporating three types of ditching cutter discs (01#, 02#, and 03#). These discs were designed, trial-manufactured, and tested in orchard ditching experiments. A corresponding simulation model was also constructed using EDEM 2022 software. This study evaluated the ditching and backfilling process, analyzing the performance of the three cutter discs through experimental and simulation methods. Results indicated that the 01# and 02# cutter discs created V-shaped furrows, whereas the 03# cutter disc formed an arc-shaped furrow. The relative errors in the final furrow depth (D_f) and width (W_f) between experimental and simulated results were 30.70% and 8.61%, respectively, while those in the maximum furrow depth (D_m) and width (W_m) were 9.44% and 3.00%. These minor relative errors confirmed the accuracy of the simulation model. Regarding maximum power consumption, the 01# cutter disc used 86.3% of the power consumed by the 02# cutter disc and 85.1% of that used by the 03# cutter disc. During the ditching process, the blades penetrated the soil to create the maximum furrow cross-section, which then gradually decreased due to backfilling. Both simulation and test results demonstrated that the 01# cutter disc performed best, achieving a maximum furrow cross-sectional area (46.70%), minimum final surface furrow cross-sectional area (6.04%), and lower power consumption (31.03 kW). This study provides equipment for ditching operations in low-height close-planting orchards in northern China. Full article

This research initiative, developed in response to the need for enhanced mechanization efficiency within solar greenhouses, particularly under yellow sand cultivation conditions, introduces an integrated ditching and film-covering machine. A novel spiral staggered throw-cut combined ditching knife was specifically engineered and optimized to meet the exacting agronomic requirements of embedded substrate cultivation. Extensive analyses of soil interactions and the formulation of dynamic equations for soil particles facilitated the determination of key operational parameters: a tangent height of 650 mm for the ditching knife, a soil-throwing width of 300 mm, a piece width of 120 mm, and an inclination angle of 30°. Performance simulations of the ditching knife, conducted using the discrete element method (DEM), revealed superior soil disturbance control and improved soil return compared to conventional designs. Critical operational variables such as forward speed, knife shaft speed, and ditching depth were rigorously tested, with trench depth quality and power consumption as primary evaluation metrics. The results demonstrated that knife shaft speed profoundly influences performance, with optimal operating parameters established through detailed field testing: a speed of 0.5 m/s, a blade shaft speed of 200 rpm, and a ditching depth of 300 mm. Under these optimized conditions, the machine achieved power consumption of 0.668 kW, trench depth stability of 86.7%, a surface width of 413 mm, a bottom width of 304 mm, and an average ditching depth of 310 mm, achieving a qualification rate of 87.1%. The post-ditching soil crushing rate was 92.4%. Both simulation and field evaluations validated that the innovative ditching knife markedly enhances ditching and soil-throwing quality in sandy soil, fulfills agronomic requirements for tomato sowing, and provides an essential reference for the mechanized planting of crops in the yellow sand matrix cultivation mode of solar greenhouses. Full article

A vibration ditching machine is a machine that can effectively reduce ditching resistance and energy consumption. In this paper, taking a self-developed, self-excited vibration ditching machine as the research object, we explore its internal dynamic vibration characteristics upon excitement when ditching, which reduces its resistance and energy consumption. The vibration characteristics of a ditching machine with three degrees of freedom (Y, Ry, and Rx directions), which are generated by the vibration of the self-excited ditching machine, are evaluated; the rotating speed, spring stiffness, spring damping coefficient, and blade weight are taken as factors, and their effects on the vibration characteristics are analyzed by an Adams–Edem coupling simulation model and a theoretical dynamics model of the self-excited ditching machine. Finally, a comparative analysis of the ditching machine of self-excited and nonself-excited ditching machines is conducted. The results of the analysis show that the rotating speed, spring stiffness, spring damping coefficient, and blade weight are important factors affecting the vibration characteristics. The theoretical dynamics model and the Adams–Edem coupling simulation model can represent the internal vibration mechanism of the self-excited ditching machine during ditching. The self-excited vibrating ditching machine is helpful in reducing the energy consumption of ditching. Full article

In order to satisfy the soil preparation requirements of a rapeseed combined transplanter in the middle-lower Yangtze River region in China where rice–rapeseed rotation cropping system was performed, a seedbed preparation machine composed of a rotary tillage device, ditch cleaning shovel, and soil leveling auger was designed to realize the function of rotary tillage, stubble ploughing, ditching, and soil leveling. The seedbed preparation machine was designed as the two parts of the middle section and the left–right symmetrical section to realize the need for middle ditching. Based on the principle of active scraping and anti-blocking, the curves of the soil contact section, soil throwing section, and transition section of the ditch cleaning shovel were analyzed. The structure parameters of the soil leveling auger with end reversal structure were designed. In order to further improve the working performance of the seedbed preparation machine, the response surface tests were designed, selecting the forward speed(X₁), the rotation speed of rotary tillage blade roller(X₂), and the rotation speed of soil leveling auger(X₃) as the main influencing factors, taking the soil breaking rate and the straw coverage rate and the soil flatness as the test indexes. The optimal parameter combination was obtained as a forward speed of 0.94 m/s, rotation speed of rotary blade roller of 268 rpm, and rotation speed of soil leveling auger of 204 rpm. Under the optimal parameters combination, the soil breaking rate, straw coverage rate, and soil flatness were 92.06%, 93.01%, and 8.35 mm respectively, which satisfied the agronomic requirements of rapeseed blanket seedling transplanting. This study can provide a reference for the design of a seedbed preparation machine of a rapeseed combined transplanter. Full article

In order to solve the problems of blocking the drainage ditch and reducing the soil flatness caused by soil accumulation when using compound planter with plowshare to ditch, a spiral soil separation mechanism (SSSM) is designed. The SSSM is analyzed. In order to obtain the optimal parameters of the SSSM, based on the discrete element method, the multifactor test is carried out with the embedded depth, pitch, and rotation speed of the spiral blade as the test factors and the soil separation distance and uniformity as the evaluation index. The optimal parameters are the embedded depth 49 mm, pitch 331 mm, and rotation speed of the spiral blade 318 r min⁻¹. The field experiment is carried out with these parameters, with soil separation distance 900 mm and standard deviation of soil height 7.8 mm, which is consistent with the simulation results. No blockage of drainage ditch was found, which shows that this device can effectively solve the problem. This study can provide a reference for the design of soil separation equipment using spiral soil separation device. Full article

In order to solve the problems of serious soil reflux and poor stability of ditch depth in the existing ditching organic fertilizer fertilization device in grey desert and loess orchards, rotary tillage theory and software simulation were used to conduct kinematic analysis of soil particles and ditching blade in the ditching process, and meanwhile, modeling and simulation are carried out for sand soil particles by using EDEM software, so as to determine the action mechanism of soil, blade and fairing in ditching process of grey desert and loess. The abstract on this basis, the quadratic orthogonal regression-rotation combination experiment was designed. The soil bin test was carried out by taking the cutter wheel speed, ditching depth and inclination of curved surface as the influencing factors, and the throwing distance and the stability of ditch depth as the test indexes. And it was concluded that the order of the influence of the operating parameters of the ditching device on the soil throwing distance is ditching depth > inclination of curved surface > cutter speed, and the order of the influence on the stability of the ditch depth is ditching depth > cutter speed > Inclination of curved surface. Finally, the optimized operating parameters of the ditching device are as follows: the cutter wheel speed is 119.61 r·min⁻¹, the inclination of curved surface is 30.07°, the ditching depth is 35.52 mm, the soil throwing distance is 57.31, and the stability of ditch depth is 87.43. With these parameters as test objects, 10 groups of single factor tests were carried out to obtain that the soil throwing distance is 58.33, and the stability of ditch depth is 86.51, which were basically consistent with the expected results of the optimization test, and also in line with the relevant agronomic standards. Full article
