Based on the need to enhance the seismic performance of point-supported steel frame precast cladding panel systems, this study proposes a novel friction-energy-dissipating connection joint. Through establishing refined finite element models, low-cycle reversed loading analyses and elastoplastic time-history analyses were conducted on three frame systems. These included a benchmark bare frame and two cladding-panel-equipped frame structures configured with energy-dissipating joints using different specifications of high-strength bolts (M14 and M20, respectively). The low-cycle reversed loading results demonstrate that the friction energy dissipation of the novel joints significantly improved the seismic performance of the frame structures. Compared to the bare frame, the frames equipped with cladding panels using M14 bolts demonstrated 10.9% higher peak lateral load capacity, 17.6% greater lateral stiffness, and 45.6% increased cumulative energy dissipation, while those with M20 bolts showed more substantial improvements of 22.8% in peak load capacity, 32.0% in lateral stiffness, and 64.2% in cumulative energy dissipation. The elastoplastic time-history analysis results indicate that under seismic excitation, the maximum inter-story drift ratios of the panel-equipped frames with M14 and M20 bolts were reduced by 42.7% and 53%, respectively, compared to the bare frame. Simultaneously, the equivalent plastic strain in the primary structural members significantly decreased. Finally, based on the mechanical equilibrium conditions, a calculation formula was derived to quantify the contribution of joint friction to the horizontal load-carrying capacity of the frame. Full article

(1) Research background: The aim of this study was to investigate the response patterns of double-layer isolation structures under seismic actions. (2) Methods: A numerical model of an 18-story reinforced concrete frame, with a core tube double-layer isolation structure designed using YJK (3.0), was established. Three seismic waves were inputted into the model, and numerical simulations were carried out using the finite element calculation software ABAQUS (2022). Additionally, the seismic responses of different double-layer isolation models were analyzed. (3) Results: The double-layer isolated structure had a significantly prolonged natural vibration period, and the seismic effects were reduced by adding an upper isolation layer. This layer decreased the maximum displacement of the isolation layer and reduced the acceleration response of the superstructure by 16.1% to 53.3%, effectively controlling story shear forces and overturning moments. Compared with inter-story isolation systems, the shear force below the isolation layer can be 1.3~3 times higher in double-layer isolation structures, thereby mitigating threats to equipment and personnel safety. (4) Conclusions: The double-layer isolation structure demonstrated optimal seismic performance when the upper isolation layer was positioned within the bottom one-third of the structure. Full article

In this study, the impact of seismic time histories (STHs) on structural damage was examined, focusing on maximum elastoplastic displacement (${\mathsf{\delta }}_{\mathrm{m}\mathrm{a}\mathrm{x}}$) and cumulative hysteretic energy (${\mathrm{E}}_{\mathrm{h}}$). A specialized STH Damage Analysis Program (STHDAP) was developed to create a deformation energy time-history damage model, accounting for the behavior of hysteretic restoring force models under various loading and motion conditions. An elastoplastic motion equation, based on uniform stiffness and load parameters ($\overline{\mathrm{K}}$ − $\overline{\mathrm{P}}$), was formulated to calculate cumulative ${\mathrm{E}}_{\mathrm{h}}$ during elastoplastic time histories in a single-degree-of-freedom (SDOF) system. The computational method integrates time series and damage values ($\mathrm{D}\left(\mathrm{t}\right)$), enabling detailed analysis of structural responses, energy dissipation, and damage evaluation using seismic waves from the El Centro, Tri-treasure, and TianjinNS earthquakes. The results revealed that cumulative damage in similar structural members increased progressively with varying amplitudes and patterns, corresponding to the initial stages of ground motion. The STHDAP offers a comprehensive view of structural damage evolution in elastoplastic time histories. The deformation energy damage model facilitates the evaluation of elastoplastic damage in high-strength reinforced concrete structures under ground motion, providing valuable insights for performance-based seismic design and retrofitting strategies in structural engineering. Full article

The primary motivation of this study is to develop a compound intensity measure (IM) to evaluate ground motion damage potential based on principal component analysis (PCA) and canonical correlation analysis (CCA). To illustrate this, this study examines the correlation among intragroup IMs and intergroup IMs, as well as the correlation between various IMs and response variables. A compound IM, which can be obtained by a linear combination of ten IMs in the log-scale, is utilized to measure the ground motion damage potential. Elastoplastic, bilinear and hysteretic models are utilized to determine peak deformation and hysteretic energy as the response variables of Single-Degree-of-Freedom (SDOF) systems. On the basis of the SDOF systems, the overall structural damage index is obtained by a nonlinear time–history analysis for two reinforced concrete moment frame systems. It is clear that the developed compound IM shows significantly high-level correlation with structural response. The better the correlations, the more one can measure the earthquake damage potential. A single IM alone inadequately characterizes structural damage, highlighting the necessity of multiple IMs to estimate the possibility of structural damage. Full article

Against the backdrop of China’s continuous promotion of green and low-carbon transformation and the development of construction industrialization, high-strength composite structural systems have significant development prospects. However, their research and application in the field of construction are insufficient. In response to this issue, the study proposes a new high-performance structural system, namely the composite frame–high-strength steel plate wall core tube resilient structural system, which includes a core tube composed of double steel plate concrete composite shear walls and replaceable energy dissipation coupling beams, as well as composite frames. The highest strength grades of the steel plate and concrete used in the composite walls of the core tube are Q550 and C100, respectively. Using a 200 m building as an example, this study designs and establishes models for this high-performance structure and a conventional reinforced concrete frame–core tube structure. Subsequently, the dynamic elastoplastic time history analysis and seismic resilience assessment of structures are conducted under design basis earthquakes (DBEs), maximum considered earthquakes (MCEs), and extremely rare earthquakes (EREs). Research has shown that, compared to conventional structures, the thickness of shear walls of new high-performance structures can be effectively reduced, which helps decrease the self-weight of the structure and improve the available space in buildings. Additionally, high-performance structures exhibit a better performance in controlling the story drift ratio, lower plastic damage and overall stiffness degradation of the structure, and better seismic performance. The seismic resilience of the high-performance structure has been significantly enhanced, especially in terms of minimizing casualties, thereby better ensuring the safety of people’s lives and property. Full article

Current seismic regulations neglect the influence of multiple seismic events on the seismic response, which, as already recognized in the literature, may influence the seismic behavior of reinforced concrete structures. Symmetrical and asymmetrical low-rise reinforced concrete frames are investigated here via nonlinear time-history (NLTH) analysis considering multiple earthquake events, as well as under a respective single seismic event, for comparison purposes. The two horizontal directions, as well as the vertical one, of the ground excitation are considered in the dynamic analysis, assuming the elastoplastic action of reinforced concrete sections under heavy loading. A simple ratio is defined to express the geometrical in-plane asymmetry of the buildings. The nonlinear response outcomes of the time-history analyses are appropriately plotted by using unitless parameters for an objective estimation of the structural behavior under multiple earthquakes. The dimensionless response results and plots are presented and discussed in view of the relative geometrical asymmetry of the 3D frames. The effect of the multiple seismic events, as well as the one of a simple geometrical symmetry/asymmetry, is identified and discussed in the presented plots resulting from the dynamic analysis. Thus, practical remarks are presented regarding the significance of the in-plane symmetry/asymmetry of frames for improvements in the provisions of the current seismic regulations to develop safer structures. Full article

In the current research, the elastoplastic behaviour of symmetrical and asymmetrical reinforced concrete buildings is explored by dynamic analysis. The used ground excitations are of sequential type, which is found in the literature to possibly strongly affect the dynamic structural behaviour. The contemporary seismic codes neglect the impact of sequential earthquakes on the seismic response, highlighting a scientific gap necessary to be studied. Within the scope of this study, ordinary 3D reinforced concrete low-rise building frames are forced to sequential ground excitations, as well as to a respective single-occurrence corresponding ground excitation, for comparability reasons. In the present dynamic analyses, the two horizontal directions of the excitations, along with the vertical one, are included in the analysis input. The nonlinear behaviour of reinforced concrete sections under strong strain is considered in the present analyses. The geometrical in-plan asymmetry of the 3D models is expressed by a simply defined ratio. Selected unitless resulting plots of the current dynamic analyses are presented and appropriately discussed given the relative geometrical asymmetry. The role of sequential ground excitations on the dynamic response is recognized, along with the role of simple geometrical symmetry or asymmetry, in the resulting response plots. Thus, useful conclusions are acquired, pointing to remarks on the geometrical structural design helpful for the development of recommendations of seismic provisions. Full article

The uplift-restricted and slip-permitted (URSP) connector is a new type of connector used in steel–concrete composite structures that has been proven to improve the structural performance of negative moment regions. Since this connector changes the interface restraint between the slab and steel beam, there is an imperative to study the seismic performance of steel–concrete composite frame systems with this new type of connector. In this study, the dynamic behavior of composite frame structures with URSP connectors under seismic loads was numerically investigated. First, a beam–shell mixed model was used and complex interfaces of different connectors were considered while establishing a numerical model to conduct elasto–plastic time history analysis under various seismic loads. This numerical model was validated with the frame sub-assemblage experimental results of quasi-static cyclic tests. Second, the model analysis results of structures with URSP connectors were obtained and compared with those of traditional structures. Third, dynamic response results including roof displacement, inter-story displacement, and the distribution and failure modes of plastic hinges were analyzed and compared. The comparisons indicated that the arrangement of full-span URSP connectors had a non-negligible influence on the dynamic behavior of the systems. The arrangement increased the maximum inter-story displacement by 31.5% and induced adverse effects in certain cases, which is not suggested in the application of URSP connectors. The partial arrangement of URSP connectors had little influence on the dynamic behavior of the systems, and the frame systems still showed a good seismic performance, which was the same as the traditional composite structural system. These findings may promote the application of URSP connectors in composite structures. Full article

A numerical investigation of the seismic behaviour of asymmetrical low-rise reinforced concrete (R/C) frames is performed considering the deformability of the supporting soil. The typical rigid base assumption is adopted by most current seismic design codes for ordinary buildings, implicitly assuming that the “beneficial” influence of the Soil-Structure Interaction (SSI) effects results in a decrease of the internal forces of a structure. However, in recent research works, SSI is found to affect the structural response in not always a beneficial manner and occasionally in a detrimental one. In the current study, the non-linear time-domain seismic analyses of selected 2D and 3D symmetric and asymmetric R/C framed buildings are presented considering initially the fixed base assumption. Subsequently, these R/C building models, subjected to the same seismic excitations, are analysed considering SSI, by applying a set of orthogonal footings with tie beams which interact with the soil medium. In addition, in the 3D models, the case of a foundation mat supporting the frames is examined. Comparisons between the numerical response results obtained for the examined supporting conditions yield useful conclusions regarding the modified elastoplastic estimated behaviour of common low-rise R/C buildings due to SSI, which can be used for the improvement of the seismic design codes. Full article

The main objective of this article was to show for the first time that heat transfer plays a major role in residual stress generation during the dry drilling of Inconel 718, and to propose a numerical strategy capable of simulating such thermo-mechanical phenomena. An X-ray diffraction (XRD) analysis shows that without lubrication, high tensile residual stresses can be observed on the surface of a deep through drilled hole. Such a situation can be highly detrimental for the fatigue lifetime of a mechanical component. A thermal history in five phases is first identified by means of temperature measurements exhibiting an overheating of approximately 500 ${}^{\circ }$C on the created hole surface just before the end of the drilling operation. A 3D thermo-viscoplastic model is herein improved in terms of boundary conditions to show that this phenomenon is triggered by the progressive decrease in the Inconel 718 volume under the cutting zone. To the authors’ knowledge, such a phenomenon has never been reported and simulated before in the literature. Then, a 3D thermo-elasto-plastic simulation including elasticity is proposed to compute residual stresses from the thermal results of the previous model. It shows for the first time that the overheating stage induces sufficiently intense plasticity to produce high tensile residual stresses of approximately 900 MPa as we experimentally observed. Full article

The main purpose of this study is to perform shaking table tests to validate the inelastic seismic analysis method applicable to pressure-retaining metal components in nuclear power plants (NPPs). To do this, the test mockup was designed and fabricated to be able to describe the hot leg surge line nozzle with a piping system, which is known to be one of the seismically fragile components in nuclear steam supply systems (NSSS). The used input motions are the displacement time histories corresponding to the design floor response spectrum at an elevation of 136 ft in the in-structure building in NPPs. Two earthquake levels are used in this study. One is the design-basis safe shutdown earthquake level (SSE, PGA = 0.3 g) and the other is the beyond-design-basis earthquake level (BDBE, PGA = 0.6 g), which is linearly scaled from the SSE level. To measure the inelastic strain responses, five strain gauges were attached at the expected critical locations in the target nozzle, and three accelerometers were installed at the shaking table and piping system to measure the dynamic responses. From the results of the shaking table tests, it was found that the plastic strain response at the target nozzle and the acceleration response at the piping system were not amplified by as much as two times the input earthquake level because the plastic behavior in the piping system significantly contributed to energy dissipation during the seismic events. To simulate the test results, elastoplastic seismic analyses with the well-known Chaboche kinematic hardening model and the Voce isotropic hardening model for Type 316 stainless steel were carried out, and the results of the principal strain and the acceleration responses were compared with the test results. From the comparison, it was found that the inelastic seismic analysis method can give very reasonable results when the earthquake level is large enough to invoke plastic behavior in nuclear metal components. Full article

The damage to structures caused by the velocity pulse effect of near-fault earthquake waves cannot be ignored, yet there are few studies on the risk assessment of seismic performance for precast concrete frame under near-fault earthquake waves. A novel self-centering precast concrete (SCPC) frame with hysteretic dampers is proposed to obtain great self-recovering and energy consumption characteristics. To accurately assess the seismic behaviors of the novel SCPC frame under the near-fault earthquake waves, a prototype structure is modelled and elastoplastic dynamic analysis is conducted at the design basis earthquake (DBE) and the maximum considered earthquake (MCE) seismic levels. Incremental dynamic analysis and the vulnerability analysis are performed. Annual and 50-year exceeding probabilities of the novel SCPC frame are calculated afterwards. In addition, the reinforced concrete (RC)frame and the traditional SCPC frame are also modelled, whose section sizes, reinforcements arrangement and seismic intensity are consistent with the novel SCPC frame. The dynamic time-history analysis at the two seismic levels are also carried out for two types of frames. The analysis results demonstrate that the novel SCPC frame has great seismic performance and low seismic risk possibility under the near-fault earthquakes loading. Full article

With the aim to model the seismic behavior of steel reinforced concrete (SRC) frame columns, in this research, hysteresis and skeleton curves were obtained based on the damage test results of SRC frame columns under low cyclic repeat loading and the hysteretic behavior of the frame columns was further analyzed. Then, the skeleton curve and hysteresis loops were further simplified. The simplified skeleton curve model was obtained through the corresponding feature points obtained by mechanical and regression analysis. The nonlinear combination seismic damage index, which was developed by the test results and can well reflect the effect of the loading path and the number of loading cycle of SRC frame columns, was used to establish the cyclic degradation index. The strength and stiffness degradation rule of the SRC frame columns was analyzed further by considering the effect of the accumulated damage caused by an earthquake. Finally, the hysteresis model of the SRC frame columns was established, and the specific hysteresis rules were given. The validity of the developed hysteresis model was verified by e comparison between the calculated results and the test results. The results showed that the model could describe the hysteresis characteristics of the SRC frame columns under cyclic loading and provide guidance for the elastoplastic time-history analysis of these structures. Full article

This paper aims to investigate the seismic performance of a novel type of steel–concrete hybrid supporting structure consisting of reinforced concrete (RC) tubular columns, steel solid web girder platform, and A-shaped steel frames. It is typically used to house air-cooled condensers (ACC) in thermal power plants (TPPs). First, the finite-element (FE) model was implemented in ABAQUS and the simulation approaches were validated by pseudo-dynamic test results of a scaled steel-concrete hybrid supporting structure. Then, the elasto-plastic time-history analysis of the steel solid web girder-RC tubular column hybrid structure was conducted. The El Centro (NS) record was scaled to peak ground acceleration (PGA) of 0.07, 0.20, 0.40 and 0.62 g to reflect the frequent, basic, rare, and very rare earthquakes. The dynamic characteristics, base shear force, lateral deformation performance, stiffness deterioration, and damage evolution characteristics were analyzed. The numerical results showed that the first vibration mode of this hybrid structure is torsion, due to its small torsional stiffness and the nonuniform distribution characteristics of stiffness and mass in the vertical direction; the lateral deformation shape is shear mode; and the damage mainly occurred on the RC tubular columns, while the steel components did not yield under severe earthquakes. In general, the overall seismic performance of the steel solid web girder-RC tubular column hybrid structural system could meet the seismic design requirements with respect to the high-intensity earthquakes. Full article
