Search Results (120)

Conventionally, tomography is an inspection technique in which tomographic images are intended for human perception and interpretation. In this work, we shift this paradigm by transforming tomography into an autonomous estimator of industrial reactor states, enabling fully automated process control. Alcoholic fermentation was employed as an example of a controlled process in the current study. The work presents an original concept utilizing transfer learning in conjunction with a ResNet-type artificial neural network, which converts electrical measurements into a sequence of values correlated with the conductivity of pixels constituting the cross-section of the examined biochemical reactor. The conductivity vector is transformed into a parameter determining substrate concentration, enabling dynamic process regulation in response to signals generated from EIT (Electrical Impedance Tomography). Within the scope of the described research, calibration of the conductivity vector against substrate concentrations was performed, and a Matlab/Simulink-based dynamic Monod kinetics model was developed. The obtained results demonstrate high accuracy in substrate concentration estimation relative to reference values throughout a forty-six-hour process. The same signals enable energy-efficient process control, in which cooling and mixing intensity are regulated according to energy prices and renewable energy availability. This strategy may possess particular application in facilities where fermentation installations are co-located with bioenergy production units. Full article

Mannitol dehydration is routinely used to prevent and treat cerebral damage after total aortic arch replacement (TAAR), but existing neuroimaging technologies cannot achieve bedside real-time quantitative assessment of its impact on cerebral perfusion in different patients. This study applied dynamic cerebral perfusion electrical impedance tomography (DCP-EIT), a non-invasive neuroimaging technique, for bedside cerebral perfusion monitoring in TAAR patients during dehydration. Seventeen patients with normal neurological function and nineteen with neurological dysfunction (ND) were enrolled. The variation patterns and differences in perfusion impedance, images, and the relative ratios (RY) of mean perfusion velocity (MV), height of systolic wave (Hs), inflow volume velocity (IV), and angle between the ascending branch and baseline (A_ab) were analyzed. Results showed DCP-EIT could visualize cerebral perfusion changes, with detected poorly perfused regions showing good consistency with ischemic areas identified by computed tomography (CT). RY of normal patients fluctuated around 0.97–1.04, with no significant difference from baseline. RY of ND patients peaked at 14–20 min after dehydration and remained higher than baseline even at 100 min (p < 0.001). DCP-EIT holds potential to optimize individualized cerebral protection strategies for other cerebral damage scenarios and neurocritical care. Full article

This study investigates the influence of variable electrode positions on image reconstruction in capacitively coupled electrical impedance tomography (CC-EIT) of the human thorax. Images were reconstructed by an adversarial neural network trained on a synthetic dataset generated using a tomographic model that included a wearable elastic band with 32 electrodes attached. Dataset generation was conducted using a previously developed numerical phantom of the thorax, combined with a newly developed algorithm for random selection of electrode positions based on physical limitations resulting from the elasticity of the band and possible position inaccuracies while putting the band on the patient’s chest. The thorax phantom included the heart, lungs, aorta, and spine. Four training and four testing datasets were generated using four different levels of electrode displacement. Reconstruction was conducted using four versions of neural networks trained on the datasets, with random ellipses included and noise added to achieve an SNR of 30 dB. The quality was assessed using pixel-to-pixel metrics such as the root-mean-square error, structural similarity index, 2D correlation coefficient, and peak signal-to-noise ratio. The results showed a strong negative influence of electrode displacement on reconstruction quality when no samples with displaced electrodes were present in the training dataset. Training the network on the dataset containing samples with electrode displacement allowed us to significantly improve the quality of the reconstructed images. Introducing samples with misplaced electrodes increased neural network robustness to electrode displacement while testing. Full article

Much as the information generated by our fingertips is used for fine-scale grasping and manipulation, closed-loop dexterous robotic manipulation requires rich tactile information to be generated by artificial fingertip sensors. In particular, fingertip shear sensing dominates modalities such as twisting, dragging, and slipping, but there is limited research exploring soft shear predictions from an increasingly popular single-material tactile technology: electrical impedance tomography (EIT). Here, we focus on the twisting of a screwdriver as a representative shear-based task in which the signals generated by EIT hardware can be analyzed. Since EIT’s analytical reconstructions are based upon conductivity distributions, we propose and investigate five reduced-order models which relate shear-based screwdriver twisting to the conductivity maps of a robot’s single-material sensorized fingertips. We show how the physical basis of our reduced-order approach means that insights can be deduced from noisy signals during the twisting tasks, with respective torque and diameter correlations of 0.96 and 0.97 to our reduced-order parameters. Additionally, unlike traditional reconstruction techniques, all necessary FEM model signals can be precalculated with our approach, promising a route towards future high-speed closed-loop implementations. Full article

As a visual detection technique, Electrical Impedance Tomography (EIT) can reconstruct the distribution of electrical parameters within a detection field. EIT reconstruction greatly depends on a physical equation that includes a sensitivity matrix and measurements, but the sensitivity matrix fails to be optimized for various reconstruction tasks. This issue decreases the applicable range of the physical equation and EIT reconstruction quality. To address this issue, this paper optimizes both the residual error for measurements and the sensitivity matrix in the equation, which leads to higher EIT reconstruction quality. The optimization solution is theoretically and experimentally verified. Results indicate that the proposed methods can reduce the relative error of EIT reconstruction quality by about 12.0%. Full article

Thoracic electrical impedance tomography (EIT) provides real-time, bedside imaging of pulmonary function and has demonstrated significant clinical value in guiding treatment strategies for critically ill patients. However, the practical application of EIT remains challenging due to its susceptibility to measurement disturbances, such as electrode contact problems and patient movement. These disturbances often manifest as spike-like noise that can severely degrade EIT image quality. To address this issue, we propose a robust Principal Component Analysis (RPCA)-based approach that models EIT data as the sum of a low-rank matrix and a sparse matrix. The low-rank matrix captures the underlying physiological signals, while the sparse matrix contains spike-like noise components. In simulation studies considering different spike magnitudes, widths and channels, all the image correlation coefficients between RPCA-processed images and the ground truth exceeded 0.99, and the image error of the original fEIT image with spike-like noise was much larger than that after RPCA processing. In eight patient cases, RPCA significantly improved the image quality (image error: p < 0.001; image correlation coefficient: p < 0.001) and enhanced the clinical EIT-based indexes accuracy (p < 0.001). Therefore, we conclude that RPCA is a promising technique for reducing spike-like noise in clinical EIT data, thereby improving data quality and potentially facilitating broader clinical application of EIT. Full article

The rapid advancement of edge computing and Tiny Machine Learning (TinyML) has created new opportunities for deploying intelligence in resource-constrained environments. With the growing demand for intelligent Internet of Things (IoT) devices that can efficiently process complex data in real-time, there is an urgent need for innovative optimisation techniques that overcome the limitations of IoT devices and enable accurate and efficient computations. This study investigates a novel approach to optimising Convolutional Neural Network (CNN) models for Hand Gesture Recognition (HGR) based on Electrical Impedance Tomography (EIT), which requires complex signal processing, energy efficiency, and real-time processing, by simultaneously reducing input complexity and using advanced model compression techniques. By systematically reducing and halving the input complexity of a 1D CNN from 40 to 20 Boundary Voltages (BVs) and applying an innovative compression method, we achieved remarkable model size reductions of 91.75% and 97.49% for 40 and 20 BVs EIT inputs, respectively. Additionally, the Floating-Point operations (FLOPs) are significantly reduced, by more than 99% in both cases. These reductions have been achieved with a minimal loss of accuracy, maintaining the performance of 97.22% and 94.44% for 40 and 20 BVs inputs, respectively. The most significant result is the 20 BVs compressed model. In fact, at only 8.73 kB and a remarkable 94.44% accuracy, our model demonstrates the potential of intelligent design strategies in creating ultra-lightweight, high-performance CNN-based solutions for resource-constrained devices with near-full performance capabilities specifically for the case of HGR based on EIT inputs. Full article

The grounding grid is an important piece of equipment to ensure the safety of a power system, and thus research detecting on its corrosion status is of great significance. Electrical impedance tomography (EIT) is an effective method for grounding grid corrosion imaging. However, the inverse process of image reconstruction has pathological solutions, which lead to unstable imaging results. This paper proposes a grounding grid electrical impedance imaging method based on an improved conditional generative adversarial network (CGAN), aiming to improve imaging precision and accuracy. Its generator combines a preprocessing module and a U-Net model with a convolutional block attention module (CBAM). The discriminator adopts a PatchGAN structure. First, a grounding grid forward problem model was built to calculate the boundary voltage. Then, the image was initialized through the preprocessing module, and the important features of ground grid corrosion were extracted again through the encoder module, decoder module and attention module. Finally, the generator and discriminator continuously optimized the objective function and conducted adversarial training to achieve ground grid electrical impedance imaging. Imaging was performed on grounding grids with different corrosion conditions. The results showed a final average peak signal-to-noise ratio of 20.04. The average structural similarity was 0.901. The accuracy of corrosion position judgment was 94.3%. The error of corrosion degree judgment was 9.8%. This method effectively improves the pathological problem of grounding grid imaging and improves the precision and accuracy, with certain noise resistance and universality. Full article

As a non-invasive imaging method, electrical impedance tomography (EIT) technology has become a research focus for grounding grid corrosion diagnosis. However, the existing algorithms have not produced ideal image reconstruction results. This article proposes an electrical impedance imaging method based on sparse representation, which can improve the accuracy of reconstructed images obviously. First, the basic principles of EIT are outlined, and the limitations of existing reconstruction methods are analyzed. Then, an EIT reconstruction algorithm based on sparse representation is proposed to address these limitations. It constructs constraints using the sparsity of conductivity distribution under a certain sparse basis and utilizes the accelerated Fast Iterative Shrinkage Threshold Algorithm (FISTA) for iterative solutions, aiming to improve the imaging quality and reconstruction accuracy. Finally, the grounding grid model is established by COMSOL simulation software to obtain voltage data, and the reconstruction effects of the Tikhonov regularization algorithm, the total variation regularization algorithm (TV), the one-step Newton algorithm (NOSER), and the sparse reconstruction algorithm proposed in this article are compared in MATLAB. The voltage relative error is introduced to evaluate the reconstructed image. The results show that the reconstruction algorithm based on sparse representation is superior to other methods in terms of reconstruction error and image quality. The relative error of the grounding grid reconstructed image is reduced by an average of 12.54%. Full article

Background/Objectives: The induction of general anesthesia leads to the development of atelectasis and redistribution of ventilation to non-dependent lung regions with subsequent impairment of gas exchange. However, it remains unclear how rapidly atelectasis occurs after the induction of anesthesia in obese patients. We therefore investigated the extent of atelectasis formation in obese patients in the first few minutes after the induction of general anesthesia and initiation of mechanical ventilation in the operating room. Methods: In 102 patients with morbid obesity (BMI ≥ 35 kg m⁻²) scheduled for laparoscopic intrabdominal surgery, induction of general anesthesia was performed while continuously monitoring regional pulmonary ventilation using electrical impedance tomography. Distribution of ventilation to non-dependent lung areas as a surrogate for atelectasis formation was determined by taking the mean value of five consecutive breaths for each minute starting five minutes before to five minutes after intubation. Ventilation inhomogeneity was assessed using the Global Inhomogeneity Index. Results: Median tidal volume in non-dependent lung areas was 58.3% before and 71.5% after intubation and increased by a median of 13.79% after intubation (p < 0.001). Median Global Inhomogeneity Index was 49.4 before and 71.4 after intubation and increased by a median of 21.99 units after intubation (p < 0.001). Conclusions: Atelectasis forms immediately after the induction of general anesthesia and increases the inhomogeneity of lung ventilation. Full article

This paper presents an energy optimization approach to applying electrical impedance tomography (EIT) for medical diagnostics, particularly in detecting lung diseases. The designed Lung Electrical Tomography System (LETS) incorporates 102 electrodes and advanced image reconstruction algorithms. Energy efficiency is achieved through the use of modern electronic components and high-efficiency DC/DC converters that reduce the size and weight of the device without the need for additional cooling. Special attention is given to minimizing energy consumption during electromagnetic measurements and data processing, significantly improving the system’s overall performance. Research studies confirm the device’s high energy efficiency while maintaining the accuracy of the classification of lung disease using the LightGBM algorithm. This solution enables long-term patient monitoring and precise diagnosis with reduced energy consumption, marking a key step towards sustainable medical diagnostics based on EIT technology. Full article

Accurate human cerebrospinal fluid (CSF) dielectric parameters are critical for biological electromagnetic applications such as the electromagnetic field modelling of the human brain, the localization and intensity assessment of electrical generators in the brain, and electromagnetic protection. To detect brain damage signals during temperature changes by electrical impedance tomography (EIT), the change in CSF dielectric parameters with frequency (10 Hz–100 MHz) and temperature (17–39 °C) was investigated. A Debye model was first established to capture the complex impedance frequency and temperature characteristics. Furthermore, the receiver operating characteristic (ROC) analysis based on the dielectric parameters of normal and diseased CSF was carried out to identify lesions. The Debye model’s characteristic f_c parameters linearly increased with increasing temperature (R² = 0.989), and R₀ and R₁ linearly decreased (R² = 0.990). The final established formula can calculate the complex impedivity of CSF with a maximum fitting error of 3.79%. Furthermore, the ROC based on the real part of impedivity at 10 Hz and 17 °C yielded an area under the curve (AUC) of 0.898 with a specificity of 0.889 and a sensitivity of 0.944. These findings are expected to facilitate the application of electromagnetic technology, such as disease diagnosis, specific absorption rate calculation, and biosensor design. Full article

Background: Changes in lung ventilation are well documented in term neonates while in late preterm neonates these patterns are poorly understood despite their increased risk of respiratory morbidity. Objectives: The study aimed to compare and clarify the differences in regional lung ventilation of late preterm and term neonates during the early adaptation period using electrical impedance tomography (EIT). Material and methods: The case-control study was conducted in the years 2020–2022. It included 51 late preterm neonates (LPN, Study group) and 45 term neonates (TN, Control) born by normal vaginal delivery (NVD). EIT examinations were performed with a Swisstom BB2 (Switzerland) equipment. The data recordings were performed no later than 30 (I Record), 60 (II), and 90 (III) minutes after the birth. Results: Statistically significant differences between LPN and TN were observed in the non-dependent lung areas at I record, with more silent spaces observed in the LPN (p < 0.001). Differences in the dependent lung regions were observed across all recordings, with LPN demonstrating more silent spaces (p < 0.001). LPN demonstrated greater stretch-related changes in the 10% and 20% stretch categories across all recordings, while TN showed greater changes in the 50%, 70%, and 90% categories. Tidal volumes in the right lung of TN are distributed more towards the ventral and central ventral regions. In contrast, tidal volumes of LPN are distributed to the central dorsal and dorsal regions of the right lung. Conclusions: LPN during the first 90 min after the birth show reduced lung ventilation assessed by EIT, suggesting a possible impairment of early postnatal adaptation. Full article

This work contributes to the improvement of novel medical technologies for the prevention and treatment of diseases. Electrical impedance tomography (EIT) has gained attention as a valuable tool for non-invasive monitoring providing real-time insights. The purpose of this work is to develop and validate a novel portable EIT system with a small form factor for respiratory monitoring. The device uses a 16-electrode architecture with adjacent stimulation and measurement patterns, an integrated circuit current source and a single high-speed ADC operating with multiplexers to stimulate and measure across all electrodes. Tests were conducted on 25 healthy subjects who performed a pulmonary function test with a flowmeter while using the EIT device. The results showed a good performance of the device, which was able to recognize all respirations correctly, and from the EIT signals and images, correlations of 96.7% were obtained for instantaneous respiratory rate and 96.1% for tidal volume prediction. These results validate the preliminary technical feasibility of the EIT system and demonstrates its potential as a reliable tool for non-invasive respiratory assessment. The significance of this work lies in its potential to democratize advanced respiratory monitoring technologies, making them accessible to a wider population, including those in remote or underserved areas. Full article

This paper presents a prototype of a portable and modular electrical impedance tomography (EIT) system for breast tumor detection. The proposed system uses MATLAB to generate three-dimensional representations of breast tissue. The modular architecture of the system allows for flexible customization and scalability. It consists of several interconnected modules. Each module can be easily replaced or upgraded, facilitating system maintenance and future enhancements. Testing of the prototype has shown promising results in preliminary screening based on experimental studies. Agar models were used for the experimental stage of this project. The 3D representations provide clinicians with valuable information for accurate diagnosis and treatment planning. Further research and refinement of the system is warranted to validate its performance in future clinical trials. Full article
