Search Results (33)

In high-precision inertial navigation systems, suppressing the random errors of a fiber-optic gyroscope is of great importance. However, the traditional rule-based autoregressive moving average modeling method, when applied in Kalman filtering considering colored noise, presents inherent disadvantages in principle, including inaccurate state equations and difficulties in state dimension expansion. To this end, the noise characteristics in the fiber-optic gyroscope signal are first deeply analyzed, a random error model form is clarified, and a new model-order determination criterion is proposed to achieve the high-precision modeling of random errors. Then, based on the effective suppression of the angle random walk error of the fiber-optic gyroscope, and combined with the linear system equation of its colored noise, an adaptive Kalman filter based on noise-spectrum information decoupling is designed. This breaks through the principled limitations of traditional methods in suppressing colored noise and provides a scheme for modeling and suppressing fiber-optic gyroscope random errors under static conditions. Experimental results show that, compared with existing methods, the initial alignment accuracy of the proposed method based on 5 min data of fiber-strapdown inertial navigation is improved by an average of 48%. Full article

In this work, an adaptive robust control method based on Radial Basis Function Neural Network (RBFNN) is proposed. Inspired by the local response characteristics of biological neurons, this method can reduce the influence of nonlinear errors and unknown perturbations in the extreme working conditions of the aircraft, such as high dynamics and strong vibration, so as to achieve high tracking accuracy. In this method, the dynamic model of the nonlinear error of the fiber optic gyroscope is proposed, and then the unknown external interference observer is designed for the system to realize the estimation of the unknown disturbances. The controller design method combines the design of the adaptive law outside the finite approximation domain of the achievable condition design of the sliding mode surface, and adjusts the controller parameters online according to the conditions satisfied by the real-time error state, breaking through the limitation of the finite approximation domain of the traditional neural network. In the finite approximation domain, an online adaptive controller is constructed by using the universal approximation ability of RBFNN, so as to enhance the robustness to nonlinear errors and external disturbances. By designing the output constraint mechanism, the dynamic stability of the system is further guaranteed under the constraints, and finally its effectiveness is verified by simulation analysis, which provides a new solution for high-precision inertial navigation. Full article

Inertial navigation systems (INSs) provide autonomous position estimation capabilities independent of global navigation satellite systems (GNSSs). However, the high cost of traditional sensors, such as fiber-optic gyroscopes (FOGs), limits their widespread adoption. In contrast, micro-electromechanical system (MEMS)-based inertial measurement units (IMUs) offer a low-cost alternative; however, their lower accuracy and sensor bias issues, particularly in maritime environments, remain considerable obstacles. This study proposes an improved method for bias estimation by comparing the estimated values from a trajectory generator (TG)-based acceleration and angular-velocity estimation system with actual measurements. Additionally, for X- and Y-axis accelerations, we introduce a method that leverages the correlation between altitude differences derived from an INS/GNSS/gyrocompass (IGG) and those obtained during the TG estimation process to estimate the bias. Simulation datasets from experimental voyages validate the proposed method by evaluating the mean, median, normalized cross-correlation, least squares, and fast Fourier transform (FFT). The Butterworth filter achieved the smallest angular-velocity bias estimation error. For X- and Y-axis acceleration bias, altitude-based estimation achieved differences of 1.2 × 10⁻² m/s² and 1.0 × 10⁻⁴ m/s², respectively, by comparing the input bias using 30 min data. These methods enhance the positioning and attitude estimation accuracy of low-cost IMUs, providing a cost-effective maritime navigation solution. Full article

A positioning method for a roadheader based on fiber-optic strap-down inertial navigation and binocular vision is proposed to address the issue of low measurement accuracy of the mining machine position caused by single-sensor methods in underground coal mines. A vision system for the mining machine position is constructed based on the four-point target fixed on the body of the roadheader, and the position and attitude information of the roadheader are obtained by combining the inertial navigation on the body. To deal with the problem of position detection inaccuracies caused by the accumulation of errors in inertial navigation measurements over time and disturbances from body vibrations to the combined positioning system, an Adaptive Derivative Unscented Kalman Filtering (ADUKF) algorithm is proposed, which can suppress the impact of process variance uncertainties on the filtering. The simulation results demonstrate that, compared to the Unscented Kalman Filtering algorithm, the position errors in the three directions are reduced by 20%, 20.68%, and 28.57%, respectively. Experiments demonstrate that the method can compensate for the limitations of single-measurement methods and meet the positioning accuracy requirements for underground mining standards. Full article

When using a fiber optic gyroscope as the core measurement element in an inertial navigation system, its work stability and reliability directly affect the accuracy of the navigation system. The modeling and fault diagnosis of the gyroscope is of great significance in ensuring the high accuracy and long endurance of the inertial system. Traditional diagnostic models often encounter challenges in terms of reliability and accuracy, for example, difficulties in feature extraction, high computational cost, and long training time. To address these challenges, this paper proposes a new fault diagnostic model that performs a fault diagnosis of gyroscopes using the enhanced capsule neural network (iCaps NN) optimized by the improved gray wolf algorithm (NIGWO). The wavelet packet transform (WPT) is used to construct a two-dimensional feature vector matrix, and the deep feature extraction module (DFE) is added to extract deep-level information to maximize the fault features. Then, an improved gray wolf algorithm combined with the adaptive algorithm (Adam) is proposed to determine the optimal values of the model parameters, which improves the optimization performance. The dynamic routing mechanism is utilized to greatly reduce the model training time. In this paper, effectiveness experiments were carried out on the simulation dataset and real dataset, respectively; the diagnostic accuracy of the fault diagnosis method in this paper reached 99.41% on the simulation dataset; the loss value in the real dataset converged to 0.005 with the increase in the number of iterations; and the average diagnostic accuracy converged to 95.42%. The results show that the diagnostic accuracy of the NIGWO-iCaps NN model proposed in this paper is improved by 13.51% compared with the traditional diagnostic methods. It effectively confirms that the method in this paper is capable of efficient and accurate fault diagnosis of FOG and has strong generalization ability. Full article

In the last decade, substantial progress has been made to improve the performance of optical gyroscopes for inertial navigation applications in terms of critical parameters such as bias stability, scale factor stability, and angular random walk (ARW). Specifically, resonant fiber optic gyroscopes (RFOGs) have emerged as a viable alternative to widely popular interferometric fiber optic gyroscopes (IFOGs). In a conventional RFOG, a single-wavelength laser source is used to generate counter-propagating waves in a ring resonator, for which the phase difference is measured in terms of the resonant frequency shift to obtain the rotation rate. However, the primary limitation of RFOG performance is the bias drift, which can be attributed to nonreciprocal effects such as Rayleigh backscattering, back-reflections, polarization instabilities, Kerr nonlinearity, and environmental fluctuations. In this paper, we review the challenges and opportunities of achieving performance enhancement in RFOGs. Full article

Autonomous Underwater Vehicles (AUVs) are widely used for hydrological monitoring, underwater exploration, and geological surveys. However, AUVs face limitations in underwater navigation due to the high costs associated with Strapdown Inertial Navigation System (SINS) and Doppler Velocity Log (DVL), hindering the development of low-cost vehicles. Micro Electro Mechanical System Inertial Measurement Units (MEMS IMUs) are widely used in industry due to their low cost and can output acceleration and angular velocity, making them suitable as an Attitude Heading Reference System (AHRS) for low-cost vehicles. However, poorly calibrated MEMS IMUs provide an inaccurate angular velocity, leading to rapid drift in orientation. In underwater environments where AUVs cannot use GPS for position correction, this drift can have severe consequences. To address this issue, this paper proposes Underwater Gyros Denoising Net (UGDN), a method based on dilated convolutions and LSTM that learns and extracts the spatiotemporal features of IMU sequences to dynamically compensate for the gyroscope’s angular velocity measurements, reducing attitude and heading errors. In the experimental section of this paper, we deployed this method on a dataset collected from field trials and achieved significant results. The experimental results show that the accuracy of MEMS IMU data denoised by UGDN approaches that of fiber-optic SINS, and when integrated with DVL, it can serve as a low-cost underwater navigation solution. Full article

The pipe jacking guidance system based on a fiber optic gyroscope (FOG) has gained extensive attention due to its high degree of safety and autonomy. However, all inertial guidance systems have accumulative errors over time. The zero-velocity update (ZUPT) algorithm is an effective error compensation method, but accurately distinguishing between moving and stationary states in slow pipe jacking operations is a major challenge. To address this challenge, a “MV + ARE + SHOE” three-conditional zero-velocity detection (TCZVD) algorithm for the fiber optic gyroscope inertial navigation system (FOG-INS) is designed. Firstly, a Kalman filter model based on ZUPT is established. Secondly, the TCZVD algorithm, which combines the moving variance of acceleration (MV), angular rate energy (ARE), and stance hypothesis optimal estimation (SHOE), is proposed. Finally, experiments are conducted, and the results indicate that the proposed algorithm achieves a zero-velocity detection accuracy of 99.18% and can reduce positioning error to less than 2% of the total distance. Furthermore, the applicability of the proposed algorithm in the practical working environment is confirmed through on-site experiments. The results demonstrate that this method can effectively suppress the accumulated error of the inertial guidance system and improve the positioning accuracy of pipe jacking. It provides a robust and reliable solution for practical engineering challenges. Therefore, this study will contribute to the development of pipe jacking automatic guidance technology. Full article

The current new type of inertial navigation system, including rotating inertial navigation systems and three-autonomy inertial navigation systems, has been increasingly widely applied. Benefited by the rotating mechanisms of these inertial navigation systems, alignment accuracy can be significantly enhanced by implementing IMU (Inertial Measurement Unit) rotation during the alignment process. The principle of suppressing initial alignment errors using rotational modulation technology was investigated, and the impact of various component error terms on alignment accuracy of IMU during rotation was analyzed. A corresponding error suppression scheme was designed to overcome the shortcoming of the significant scale factor error of fiber optic gyroscopes, and the research content of this paper is validated through corresponding simulations and experiments. The results indicate that the designed alignment scheme can effectively suppress the gyro scale factor error introduced by angular motion and improve alignment accuracy. Full article

An inertial guidance system based on a fiber optic gyroscope (FOG) is an effective way to guide long-distance curved pipe jacking. However, environmental disturbances such as vibration, electromagnetism, and temperature will cause the FOG signal to generate significant random noise. The random noise will overwhelm the effective signal. Therefore, it is necessary to eliminate the random noise. This study proposes a hybrid de-noising method, namely complete ensemble empirical mode decomposition with adaptive noise (CEEMDAN)—lifting wavelet transform (LWT). Firstly, the FOG signal is extracted using a sliding window and decomposed by CEEMDAN to obtain the intrinsic modal function (IMF) with N different scales and one residual. Subsequently, the effective IMF components are selected according to the correlation coefficient between the IMF components and the FOG signal. Due to the low resolution of the CEEMDAN method for high-frequency components, the selected high-frequency IMF components are decomposed with lifting wavelet transform to increase the resolution of the signal. The detailed signals of the LWT decomposition are de-noised using the soft threshold de-noising method, and then the signal is reconstructed. Finally, pipe-jacking dynamic and environmental interference experiments were conducted to verify the effectiveness of the CEEMDAN-LWT de-noising method. The de-noising effect of the proposed method was evaluated by SNR, RMSE, and Deviation and compared with the CEEMDAN and LWT de-noising methods. The results show that the CEEMDAN-LWT de-noising method has the best de-noising effect with good adaptivity and high accuracy. The navigation results of the pipe-jacking attitude before and after de-noising were compared and analyzed in the environmental interference experiment. The results show that the absolute error of the pipe-jacking pitch, roll, and heading angles is reduced by 39.86%, 59.45%, and 14.29% after de-noising. The maximum relative error of the pitch angle is improved from −0.74% to −0.44%, the roll angle is improved from 2.07% to 0.79%, and the heading angle is improved from −0.07% to −0.06%. Therefore, the CEEMDAN-LWT method can effectively suppress the random errors of the FOG signal caused by the environment and improve the measurement accuracy of the pipe-jacking attitude. Full article

The foundation of intelligent collaborative control of a shearer, scraper conveyor, and hydraulic support (three-machines) is to achieve the precise perception of the status of the three-machines and the full integration of information between the equipment. In order to solve the problems of information isolation and non-flow, independence between equipment, and weak cooperation of three-machines due to an insufficient fusion of perception data, a fusion method of the equipment’s state perception system on the intelligent working surface was proposed. Firstly, an intelligent perception system for the state of the three-machines in the working face was established based on fiber optic sensing technology and inertial navigation technology. Then, the datum coordinate system is created on the working surface to uniformly describe the status of the three-machines and the spatial position relationship between the three-machines is established using a scraper conveyor as a bridge so that the three-machines become a mutually restricted and collaborative equipment system. Finally, an indoor test was carried out to verify the relational model of the spatial position of the three-machines. The results indicate that the intelligent working face three-machines perception system based on fiber optic sensing technology and inertial navigation technology can achieve the fusion of monitoring data and unified expression of equipment status. The research results provide an important reference for building an intelligent perception, intelligent decision-making, and automatic execution system for coal mines. Full article

Autonomous underwater vehicles (AUVs) are extensively utilized in various autonomous underwater missions, encompassing ocean environment monitoring, underwater searching, and geological exploration. Owing to their profound underwater capabilities and robust autonomy, AUVs have emerged as indispensable instruments. Nevertheless, AUVs encounter several constraints in the domain of underwater navigation, primarily stemming from the cost-intensive nature of inertial navigation devices and Doppler velocity logs, which impede the acquisition of navigation data. Underwater simultaneous localization and mapping (SLAM) techniques, along with other navigation approaches reliant on perceptual sensors like vision and sonar, are employed to augment the precision of self-positioning. Particularly within the realm of machine learning, the utilization of extensive datasets for training purposes plays a pivotal role in enhancing algorithmic performance. However, it is common for data obtained exclusively from inertial sensors, a Doppler Velocity Log (DVL), and depth sensors in underwater environments to not be publicly accessible. This research paper introduces an underwater navigation dataset derived from a controllable AUV that is equipped with high-precision fiber-optic inertial sensors, a DVL, and depth sensors. The dataset underwent rigorous testing through numerical calculations and optimization-based algorithms, with the evaluation of various algorithms being based on both the actual surfacing position and the calculated position. Full article

An optimized scheme can improve the navigation accuracy of RINS without changing the inertial devices. In the multi-position stop scheme, the IMU remains stationary for most of the time, which makes motor control easier. However, the installation errors and the scale factor errors of FOG can cause platform misalignment after a certain angle of rotation around the horizontal axis, resulting in a velocity error. Continuous rotation can suppress time-varying errors better, which is of particular importance for FOG, but it can also increase the sawtooth error of the navigation output, and the error in the direction of rotation cannot be offset. To integrate the advantages of both rotation schemes, we propose an improved rotational modulation scheme for tri-axis RINS. In this scheme, the inner gimbal rotates in a two-position and four-order manner, while the middle and outer gimbals rotate continuously in the order of forward-reverse-reverse-forward. Simulation and navigation test results demonstrate that this improved rotational modulation scheme can effectively improve navigation accuracy by 50% and 25% compared with continuous rotation around the azimuth axis and a 16-position scheme with the same inertial devices, which is of great importance for RINS with FOG. Full article

Fiber Optic Gyroscope Inertial Navigation System (FOG-INS) is a navigation system using fiber optic gyroscopes and accelerometers, which can offer high-precision position, velocity, and attitude information for carriers. FOG-INS is widely used in aerospace, marine ships, and vehicle navigation. In recent years, it has also played an important role in underground space. For example, in the deep earth, FOG-INS can be used in directional well drilling, which can enhance recovery in resource exploitation. While, in shallow earth, FOG-INS is a high-precision positioning technique that can guide construction in trenchless underground pipelaying. This article extensively reviews the application status and latest progress of FOG-INS in underground space from three aspects—FOG inclinometer, FOG drilling tool attitude measurement while drilling (MWD) unit, and FOG pipe-jacking guidance system. First, measurement principles and product technologies are introduced. Second, the research hot spots are summarized. Finally, the key technical issues and future trends for development are put forward. The findings of this work are useful for further research in the field of FOG-INS in underground space, which not only provides new ideas and directions for scientific research, but also offers guidance for subsequent engineering applications. Full article

High-sensitivity uniaxial opto-mechanical accelerometers provide very accurate linear acceleration measurements. In addition, an array of at least six accelerometers allows the estimation of linear and angular accelerations and becomes a gyro-free inertial navigation system. In this paper, we analyze the performance of such systems considering opto-mechanical accelerometers with different sensitivities and bandwidths. In the six-accelerometer configuration adopted here, the angular acceleration is estimated using a linear combination of accelerometers’ read-outs. The linear acceleration is estimated similarly but requires a correcting term that includes angular velocities. Accelerometers’ colored noise from experimental data is used to derive, analytically and through simulations, the performance of the inertial sensor. Results for six accelerometers, separated by 0.5 m in a cube configuration show noise levels of 10${}^{-7}$ m s${}^{-2}$ and 10${}^{-5}$ m s${}^{-2}$ (in Allan deviation) for time scales of one second for the low-frequency (Hz) and high-frequency (kHz) opto-mechanical accelerometers, respectively. The Allan deviation for the angular velocity at one second is ${10}^{-5}$ rad s${}^{-1}$ and $5\times {10}^{-4}$ rad s${}^{-1}$. Compared to other technologies such as MEMS-based inertial sensors and optical gyroscopes, the high-frequency opto-mechanical accelerometer exhibits better performance than tactical-grade MEMS for time scales shorter than 10 s. For angular velocity, it is only superior for time scales less than a few seconds. The linear acceleration of the low-frequency accelerometer outperforms the MEMS for time scales up to 300 s and for angular velocity only for a few seconds. Fiber optical gyroscopes are orders of magnitude better than the high- and low-frequency accelerometers in gyro-free configurations. However, when considering the theoretical thermal noise limit of the low-frequency opto-mechanical accelerometer, $5\times {10}^{-11}$ m s${}^{-2}$, linear acceleration noise is orders of magnitude lower than MEMS navigation systems. Angular velocity precision is around ${10}^{-10}$ rad s${}^{-1}$ at one second and $5\times {10}^{-7}$ rad s${}^{-1}$ at one hour, which is comparable to fiber optical gyroscopes. While experimental validation is yet not available, the results shown here indicate the potential of opto-mechanical accelerometers as gyro-free inertial navigation sensors, provided the fundamental noise limit of the accelerometer is reached, and technical limitations such as misalignments and initial conditions errors are well controlled. Full article
