Achieving precise docking, reliable locking and damage-free emergency unlocking under complex ocean current conditions remains a key challenge for deep-water multi-way quick connectors (MQCs). This study proposes a novel MQC prototype characterised by a tiered tolerance guidance mechanism, an innovative L-shaped spatial helical cam locking system, and a real-time visual attitude indicator. Using Ansys 2023 R2 and its tools, the safe operating limits were determined through explicit non-linear finite element collision analysis. The results demonstrate that, under a controlled docking speed of 10 mm/s, the hierarchical guidance mechanism successfully accommodated extreme initial misalignments (25 mm lateral offset, 5° horizontal rotation and 15° axial rotation), whilst keeping the peak collision stress within the elastic limit. Furthermore, the L-shaped locking guide was analysed using a fifth-order polynomial motion law and a macro-micro elastoplastic Hertzian contact mechanics model, effectively eliminating rigid-flexible impact forces. Under extreme separation loads of 10,000 psi, the maximum equivalent plastic strain at the base of the locking shaft was strictly controlled at 0.00926. This is well below the failure threshold of 0.0865 specified by ASME, providing a substantial safety margin and completely preventing local yielding. Crucially, the emergency release strategy based on precision locating pins was validated through full-scale prototype testing. Destructive tests conducted under simulated severe jamming conditions demonstrated clean, damage-free disengagement under shear torques ranging from 2100 Nm to 2200 Nm. This threshold ensures that accidental triggering will absolutely not occur during routine operations (1400 Nm) and establishes a safe underwater robotic (ROV) operating speed of ≤4 r/min. This study provides a robust theoretical framework and empirical data for the future design of yield-resistant subsea connectors and safe emergency recovery. Full article

Post-rotation jacking is a critical construction stage for load-path reconstruction and alignment adjustment in rotation-constructed bridges, particularly for ultra-wide double-deck composite girder systems. Taking a two-span continuous steel truss–concrete composite girder bridge with spans of 2 × 85 m as the engineering background, this study investigates the mechanical behavior during post-rotation jacking through theoretical derivation, finite element simulation, and on-site monitoring. Based on the force method of structural mechanics, a linear relationship between vertical synchronous jacking force and displacement is derived, and an analytical formulation for bearing reaction redistribution under laterally asynchronous jacking is established by considering the coupling effects of vertical bending, torsion, and transverse multi-bearing support. A full-bridge spatial finite element model was developed in MIDAS Civil NX 2024 V1.1 to analyze the redistribution of bearing reactions and the stress response of the concrete crossbeam under different jacking conditions. The results show that, for the investigated bridge, the jacking force–displacement response remains highly linear during synchronous jacking. The B-axis middle bearing is more sensitive to jacking displacement than the two side bearings, with its fitted stiffness being approximately 2.19 times the average stiffness of the side bearings. Eccentric jacking causes reaction concentration at the jacked point and reaction reduction at adjacent supports, and the magnitude of reaction variation increases approximately linearly with jacking displacement. When the transverse non-uniform jacking magnitude reaches 20 mm, a tensile stress of 0.3 MPa appears at the bottom flange of the concrete crossbeam; therefore, a project-specific stroke-difference limit of 20 mm is recommended for this bridge, while the actual construction achieved a stroke control accuracy of ±0.5 mm and a transverse elevation difference within 1 mm. Field monitoring results validate the proposed analytical and numerical methods. The Pearson correlation coefficients of the measured jacking forces with the finite element and theoretical results are 0.9987 and 0.9988, respectively, and the corresponding mean relative errors are 3.84% and 4.23%. For stress responses, the measured and calculated values show a strong correlation, with a Pearson correlation coefficient of 0.9980 and a mean relative error of 12.77%; the critical mid-span monitoring point shows a relative error of only 0.65%. The final bridge alignment deviation is controlled within ±3 cm. The overall mean verification coefficient is 0.968, with a 95% empirical agreement range of [0.888, 1.048], indicating that the proposed mechanical analysis framework and combined force–displacement control strategy can provide a useful reference for refined construction control of similar ultra-wide double-deck composite girder bridges with comparable span arrangement and transverse bearing layout. Full article

This study investigates the quasi-static mechanical behavior of a flexible anti-collision ring (FACR) for bridge protection through axial tests and finite element (FE) simulations. The FACR features a multi-layer steel wire rope coil (SWRC) encased in a chloroprene rubber matrix. Quasi-static tensile and compressive tests (80 mm/s) were conducted on both the SWRC and the FACR, with full-field strain distributions captured via digital image correlation (DIC). The results demonstrate that the rubber matrix significantly enhances load-bearing capacity (by 200% in compression and 337% in tension) and energy dissipation (by 403% and 620%, respectively), with bending identified as the dominant deformation mode. An FE model was developed and validated against experimental data, then employed for parametric analysis. The cross-sectional ratio, governed by the number of SWRC layers, exhibits a strong nonlinear influence on the tensile response, and a three-layer configuration is identified as optimal, achieving the highest energy absorption without compromising compressive performance. A layer-dependent mechanism analysis reveals that excessive layers lead to a drastic stiffness reduction in outer coils, impeding coordinated load sharing. Building upon this mechanism, an optimized two-layer arrangement maximizing the inner-layer SWRC proportion is proposed, achieving 2.0× and 1.9× improvements in peak tensile force and energy dissipation, respectively, while using fewer steel wires. This work provides a fundamental understanding and an efficient optimization strategy for FACRs. Full article

This study aims to develop an efficient and accurate method for identifying joint parameters in assembled structures. A novel neural network-based joint identification framework is proposed. Frequency response function (FRF) datasets are generated by combining finite element simulation with frequency-domain substructure synthesis. The Uniform Manifold Approximation and Projection (UMAP) algorithm is employed for nonlinear dimensionality reduction in FRF sequences, preserving critical characteristics. A multilayer perceptron (MLP) network is then trained to regress joint parameters from the reduced-dimension FRF data. The necessity of the nonlinear dimensionality reduction within this joint identification framework is verified through comparison with the linear dimensionality reduction technique of principal component analysis (PCA). This methodology is implemented and validated using a tool–collet–holder system. Comparative studies with the global optimization method reveal that the proposed approach maintains superior identification accuracy while achieving significant improvements in computational efficiency across varying preload conditions. Furthermore, the identified joint parameters exhibit strong predictive capability when tested under tool/holder component changes, preload variations, and when coupled with a spindle, proving robustness under complex operational scenarios. This study provides a new technical pathway for the joint identification of assembly structure. Full article

Cosmic large-scale structure formation is commonly described in terms of the evolution of density fluctuations and correlation statistics. However, such approaches primarily characterize amplitude variations and do not directly capture the spatial rearrangement of mass distributions. Recent developments based on optimal transport theory have introduced a complementary perspective, in which structure formation is understood as a transport process in the space of probability measures equipped with Wasserstein geometry. In this work, we extend this framework by introducing transport–information geometry, which unifies transport geometry with information geometry. Within this formulation, cosmological states are represented as elements of the product space of probability measures and statistical manifolds, allowing gravitational mass transport and generative deformations associated with galaxy formation to be treated in a unified manner. Using entropic optimal transport, we demonstrate that Wasserstein geometry and Kullback–Leibler-based information geometry are connected within a single mathematical structure, leading to a geometric interpretation of cosmological evolution as a coupled transport–information process endowed with a dual-affine structure. In this picture, gravitational evolution corresponds to generative deformation associated with e-geometry, while observational processes, including finite sampling and survey selection, are described as mixing and projection in m-geometry. This dual-affine cosmology provides a unified framework in which gravitational transport, galaxy bias, observational effects, and nonlinear multi-stream structures are consistently incorporated. The resulting formulation offers a systematic basis for cosmological inference, data analysis, and stochastic descriptions of structure formation. Full article

This study proposes a printed circuit board (PCB) stator pattern for alleviating the trade-off between DC copper loss and AC winding loss in a slotless axial flux permanent magnet motor (AFPM). The proposed pattern has a structure in which the width of the effective conductor region directly exposed to time-varying magnetic flux is reduced, and two additional conductors with the same width are placed within the available axial space and then connected in parallel through vias. Three-dimensional finite element analysis was performed while varying the effective conductor width ratio from 0.3 to 0.8, and an additional refined sweep was conducted in the range of $\alpha$ = 0.5–0.6, where the minimum total winding loss appeared in the initial sweep. Under the rated operating condition, the minimum total winding loss was obtained at $\alpha =0.53$ based on the refined sweep results. Under this condition, the phase resistance, DC copper loss, AC winding loss, and total winding loss were reduced by 11.82%, 12.1%, 15.09%, and 12.48%, respectively. As a result, the efficiency increased from 81.53% to 83.5%, while the back electromotive force (BEMF), torque, and output were nearly unchanged. In addition, the AC winding loss distribution decreased in both the coil region closest to the magnets and the coil region farthest from the magnets. These results demonstrate that the proposed pattern is an effective design method for improving the winding loss characteristics of slotless PCB AFPM without meaningful degradation of the fundamental electromagnetic performance. Full article

Automotive roof racks are important lightweight accessories for vehicles, and their extrusion performance is affected by the coupled effects of material hot deformation behavior, die flow resistance and billet surface layer transport. In this study, Al-0.9Mg-0.6Si alloy samples were subjected to hot compression tests at 350–500 °C and strain rates of 0.01–10 s⁻¹. The corrected true stress–true strain data were used to establish and validate an Arrhenius-type constitutive model, which was then implemented in HyperXtrude to simulate the hot extrusion of an automotive roof rack profile. The hot working map showed that the main rheological instability region was located at high strain rates, and the preferred processing window was 437–500 °C and 0.01–0.6 s⁻¹. EBSD analysis showed that hot compression refined the microstructure relative to the initial average grain size of 173.147 μm, and the most uniform grain size distribution was obtained at 500 °C and 0.1 s⁻¹. The ODF results indicated strengthened {111}<121> and <110>//TD texture components after compression. The finite-element results showed that the standard deviation of outlet velocity (SDV), used here as an index of outlet flow uniformity, increased with ram speed, billet preheating temperature and die preheating temperature, but decreased with increasing container temperature. Finally, grain size and texture measurements from butt discard samples were compared with simulated surface layer flow paths, supporting the predicted difference between simple axial flow and complex recirculating flow near the die. Full article

The structural strength requirements for timber buildings have been significantly tightened in the second generation of Eurocodes (EN 1990:2023, EN 1991-1-7), which poses a particular challenge for solid timber frames with a beam-and-column structure, where the transfer of tensile forces via dowel connections is inherently limited. Existing multiscale frameworks for timber post-and-beam robustness lack operational detail at each scale, and no validated workflow currently bridges joint-level continuum damage mechanics and frame-level progressive failure analysis in compliance with the second-generation Eurocodes. This paper addresses this gap by proposing an effective two-scale finite element method (FEM) modelling framework for assessing the strength of such frames during column removal. Existing multiscale models describing the strength of timber structures with beam-and-column systems lack the operational details necessary to integrate failure mechanics at the joint level and progressive failure modelling at the frame level within a single, validated workflow. In this paper, this gap is addressed through three specific contributions: a physically modified quadratic Hashin-type failure criterion for timber, which eliminates the non-physical increase in shear strength under combined stress states perpendicular to the grain; a two-scale structure based on the finite element method (FEM), in which the results of continuous damage mechanics at the joint level directly parameterise non-linear joint elements with six degrees of freedom at the frame level, taking into account coupled directional wear and erosion of the elements; and quantitative validation of both scales against experimental data and the conversion factors for characteristic values of the second generation of Eurocode 5 (prEN 1995-1-1:2023). At the connection level, the simulated strength and stiffness values agree with the experiments to within an error of no more than 5%. At the frame level, the model correctly reproduces the non-linear ‘load–displacement’ relationship, the sequence of joint failure, and the axial forces in the chain line for vertical displacements up to 390 mm, which corresponds to experimental observations. Full article

This paper presents a new plane stress model for the dynamic analysis of multilayer composite beams with interlayer slip effects. In this model, the cross section of a multilayer composite beam is transformed into an equivalent plane stress cross section. Based on the equilibrium, constitutive and geometric equations of the plane stress problem, state equations are derived in terms of a set of state variables. The state variables are then expanded in Fourier series, and the state equations are solved using the state-space method. The proposed computational model makes it convenient to account for slip at each interface and can represent the entire transition of an interface from fully slipped to fully bonded. Interlayer slip and the corresponding interaction forces are incorporated naturally into the derivation of the governing equations, and the model gives accurate results. A steel–concrete–steel composite beam, a four-layer composite beam and a laminated timber beam are analyzed as examples of multilayer composite beams under both static and dynamic loading. The static analysis results are in good agreement with the literature results, with a maximum error of 0.63% for the maximum mid-span deflection and only 0.143% for the maximum interlayer slip value. Compared with finite element results, the natural frequencies and buckling loads obtained from the dynamic analysis exhibit maximum relative errors of 2.87% and 3.77%, respectively. The relationship between axial force and natural frequency is also presented, which verifies the accuracy and reliability of the proposed model and calculation method. Full article

The influence of internal substrate geometry on thermal stability during Laser Directed Energy Deposition Repair (DED-R) remains insufficiently understood, particularly for components containing internal cavities and cooling channels. This study investigates the thermal response of solid (Alpha), blind-hole (Bravo), and channeled (Charlie) AISI 316L substrates using dual infrared thermography, transient finite element modeling, and Short-Time Fourier Transform (STFT)-frequency-domain analysis. Despite substantial differences in internal heat-dissipation pathways, all substrate configurations exhibited similar peak surface temperatures (~1700–2100 °C), indicating that conventional temperature monitoring alone is insufficient to distinguish geometry-dependent melt-pool behavior. To address this limitation, a Spectral Entropy Index (SEI) derived from STFT analysis was proposed to quantify thermal stability. The channeled substrate exhibited the lowest entropy value (H_s = 0.172), compared with the solid (H_s = 0.181) and blind-hole (H_s = 0.183) configurations, indicating a more ordered and predictable thermal response. Furthermore, distinct variations in the spectral stability shadow revealed geometry-dependent oscillatory behavior that was not observable from thermal histories. Finite element simulations showed good agreement with experimental measurements in conduction-dominated regions (RMSE ≈ 46 °C), whereas deviations were observed within the melt-pool region (~250–310 °C), highlighting the increasing influence of fluid-flow phenomena not captured by the conduction-based model. The results demonstrate that internal substrate architecture primarily influences melt-pool stability through frequency-domain thermodynamics rather than significant changes in peak temperature. The proposed STFT method provides a quantitative approach for monitoring thermal stability and assessing the feasibility of L-DED repair over complex internal geometries. Full article

The bending stiffness of cables is an important influencing parameter in the analysis of cable structures, and the modeling of cables with bending stiffness has always been a key concern. This paper proposes an accurate beam formulation for planar cables with bending stiffness, in which the deformation–strain relationship is accurately described, thus enabling the geometrically exact form finding of planar cables. After the kinematics of the cable geometry are described, the strong- and weak-form equilibrium equations of the cable are derived, and then the finite element implementations are presented. Three typical examples of cable structures are also presented; the numerical results demonstrate that the presented beam formulation shows stable and accurate numerical performance. The proposed formulation achieves rapid convergence when the number of elements reaches 20. The analysis of a suspension bridge shows that considering bending stiffness has little influence on the completed bridge state, with the error between the calculated hanger forces and the design values remaining within 1.5%. However, in the free cable state, considering bending stiffness causes a saddle pre-offset variation of approximately 5 cm, while the sag difference reaches approximately 1 m. The results demonstrate that the proposed formulation is of significant importance for planar cable form finding problems. Full article

High-speed permanent magnet synchronous motors (PMSMs) used in electric pump-fed liquid rocket engines require stator shielding sleeves to prevent corrosive propellants from causing harm under cyclic pressure. However, metallic sleeves suffer significant losses due to eddy currents. Conversely, pure carbon fiber reinforced polymer (CFRP) sleeves have failed when exposed to 98% H₂O₂. Micro-CT analysis of a failed pump sleeve reveals a four-stage failure mechanism. Manufacturing defects caused matrix cracking, which propagated under pressure and thermal cycling. This progression resulted in the formation of through-thickness leakage paths, which ultimately triggered catalytic decomposition and explosion. To address these issues, an improved dual-layer sleeve is proposed, featuring a 2.5 mm PEEK 450G liner and a 2.0 mm T700S/epoxy CFRP overwrap. Finite Element Analysis (FEA) indicates peak von-Mises stresses of 86.25 MPa and 112.16 MPa, yielding Tsai–Wu safety factors of 2.9 and 1.7. Furthermore, various tests, including immersion, fatigue, burst, hydraulic, and thermal evaluations, demonstrate a burst margin of 2.37× at 7.12 MPa, with only 0.19% increase in mass. This design effectively eliminates leakage pathways while preserving zero eddy-current loss and ensuring a low weight. Full article

As the offshore wind industry scales toward 15 MW capacity, the reliability of Direct-Drive Permanent Magnet Synchronous Generators (DD-PMSGs) becomes critical. However, real-world run-to-failure data for these massive, multi-pole machines is virtually non-existent, creating a barrier for developing effective data-driven diagnostic systems. This study proposes a high-fidelity framework for detecting permanent magnet faults in the International Energy Agency (IEA) 15 MW Reference Wind Turbine. Using Finite Element Analysis (FEA), a dataset (magnetic flux and back electromotive-force (EMF)) capturing the electromagnetic signatures of healthy and faulty states of a PMSG under varying severities is generated. To improve the power of computer vision, 1D time-series signals were transformed into 2D images. Specifically, Gramian Angular Fields (GAFs) and Recurrence Plots (RPs) were applied to magnetic flux density signals, while Markov Transition Fields (MTFs) were applied to back-EMF signals. These representations were then fused into multi-channel Red-Green-Blue (RGB) images and processed via a ResNet-18 Deep Transfer Learning model using a strictly non-overlapping, leakage-free dataset partitioning strategy. The proposed framework achieved a classification accuracy of 99.45% on noise-free data. Furthermore, robustness testing under varying levels of Additive White Gaussian Noise (AWGN) (30 dB, 40 dB, and 50 dB Signal-to-Noise Ratio (SNR)) demonstrated sustained high performance, maintaining over 90% accuracy even under severe 30 dB noise conditions. Comparative analysis proved that this multi-channel fusion significantly outperforms single-channel encoding methods, which collapse under heavy noise, validating the scalability of the framework and applicability for next-generation condition monitoring in harsh offshore environments. Full article

Tooth-supported fixed partial dentures (FPDs) exhibit complex biomechanical behaviour because occlusal loads are transferred through the periodontal ligament (PDL) and heterogeneous mandibular bone. This pilot study aimed to develop a patient-specific NURBS-based finite element analysis (FEA) workflow for anatomically realistic mandibular reconstruction and to evaluate the biomechanical effect of geometric simplification in tooth-supported FPD simulations. Cone beam computed tomography data from a single subject were segmented and reconstructed into a layered three-dimensional model of the mandible and dentition, including cortical bone, cancellous bone, teeth, and PDL. A high-fidelity reference model (V0) and four simplified variants (V1–V4) were analysed under static 500 N loads applied at 0° and 30°. The reference model yielded a maximum von Mises stress of 507 MPa and a peak displacement of 0.74 mm, with stress concentrations consistently localised at the retainer–pontic connector region. Inclusion of the PDL markedly affected the mechanical response, doubling denture displacement in simplified comparative models. Among the simplified configurations, V4, which preserved cortical morphology and PDL representation while omitting detailed trabecular architecture, showed the closest agreement with the reference model, with mean deviations of 6.1% and 5.8% under the two loading conditions, respectively. These findings suggest that patient-specific NURBS–FEA modelling provides a robust framework for biomechanical assessment of tooth-supported FPDs, while controlled simplification may improve computational efficiency without substantially compromising accuracy under static loading conditions. Full article

With the rapid expansion of urban underground space in China, anti-floating has become a critical challenge, and uplift piles are a key solution. Previous studies on composite anchor-cable uplift piles have primarily focused on small-diameter single-pipe types (≤600 mm), often simplifying the pile as an integral component, leaving the multi-interface stress transfer mechanisms of large-diameter piles inadequately understood. This study proposes a back-analysis method based on orthogonal experiments, implemented using Abaqus 3D finite element software, to determine interfacial mechanical parameters for three critical contact pairs (strand-grout, grout-steel pipe, steel pipe-concrete) in large-diameter multi-pipe composite anchor-cable uplift piles. These parameters are then implemented in a refined 3D finite element model to simulate the load-deformation behavior of such piles. Quantitative results show that the back-calculated parameters are highly reliable, with maximum simulation errors for pile head displacement limited to 13.0% and 9.6% for fully bonded and semi-bonded piles, respectively. Unlike conventional piles, stress and strain in this new pile type transfer progressively from the inner steel strands outward and from the top downward, resulting in reduced pile-soil displacement mismatch, fuller mobilization of side interfacial strength, and effective mitigation of concrete cracking. This study provides a systematic parameter-calibration framework and numerical platform, offering theoretical and technical support for optimized design and engineering application of large-diameter composite uplift piles. Full article
