A dynamically operated sorption-enhanced water–gas shift reactor is modelled to leverage its performance by means of model-based process design. This reactor shall provide CO₂-free synthesis gas for e-fuel production from pure CO. The nonlinear model equations describing simultaneous adsorption and reaction are solved with three numerical approaches in MATLAB: a built-in solver for partial differential equations, a semi-discretization method in combination with an ordinary differential equation solver, and an advanced graphic implementation of the latter method in Simulink. The novel implementation in Simulink offers various advantages for dynamic simulations and is expanded to a process model with six reaction chambers. The continuous conditions in the reaction chambers and the discrete states of the valves, which enable switching between reactive adsorption and regeneration, lead to a hybrid system. Controlling the discrete states in a finite-state machine in Stateflow enables automated switching between reactive adsorption and regeneration depending on predefined conditions, such as a time span or a concentration threshold in the product gas. The established chemical reactor simulation approach features unique possibilities in terms of simulation-driven development of operating procedures for intensified reactor operation. In a base case simulation, the sorbent usage for serial operation with adjusted switching times is increased by almost 15%. Full article

In the development of fault-tolerant systems, simulation is a common technique used to obtain insights into performance and dependability because it saves time and avoids the risks of testing the behavior of real-world systems in the presence of faults. Fault injection in a simulation offers a high controllability and observability, and thus is ideal for an early dependability analysis and fault-tolerance evaluation. Heating, ventilation, and air conditioning (HVAC) systems in critical infrastructures, such as airports and hospitals, are safety-relevant systems, which not only determine energy consumption, system efficiency, and occupancy comfort but also play an essential role in emergency scenarios (e.g., fires, biological hazards). Hence, fault injection serves as a practical and essential solution to assess dependability in different fault scenarios of HVAC systems. Hence, in this paper, we present a simulation-based fault injection framework with a combination of two techniques, simulator command and simulation code modification, which are applied to fault injector blocks as saboteurs and an automated fault injector algorithm to automatically activate fault cases with certain fault attributes. The proposed fault injection framework supports a comprehensive range of faults and various fault attributes, including fault persistence, fault type, fault location, fault duration, and fault interarrival time. This framework considers noise in a demand-controlled ventilation (DCV) and heating system as a type of HVAC system since it has been demonstrated that any fault injection scenario is accompanied by some impacts on energy consumption, occupancy comfort, and a fire risk. It also supports the reproducibility for a set of specific fault scenarios or random fault injection scenarios. The system model was implemented and simulated in Matlab/Simulink, and fault injector blocks were developed by Stateflow diagrams. An experimental evaluation serves as the assessment of the presented fault injection framework with a defined example of fault scenarios. The results of the evaluation show the correctness, system behavior, accuracy, and other parameters of the system, such as the heater energy consumption and heater duty cycle of the fault injection framework in the presence of different fault cases. In conclusion, the present paper provides a novel simulation-based fault injection framework, which combines simulator command techniques and simulation code modifications for a realistic and automatic fault injection with comprehensive coverage of various fault types and a consideration of noise and uncertainty, allowing for reproducibility of the results. The outputs achieved from the fault injection framework can be applied to fault-tolerant studies in other application domains. Full article

This study investigates the potential application of Stateflow (SF) to design an energy management strategy (EMS) for a renewable-based hybrid energy system (HES). The SF is an extended finite state machine; it provides a platform to design, model, and execute complex event-driven systems using an interactive graphical environment. The HES comprises photovoltaics (PV), energy storage units (ESU) and a diesel generator (Gen), integrated with the power grid that experiences a regular load shedding condition (scheduled power outages). The EMS optimizes the energy production and utilization during both modes of HES operation, i.e., grid-connected mode and the islanded mode. For islanded operation mode, a resilient power delivery is ensured when the system is subjected to intermittent renewable supply and grid vulnerability. The contributions of this paper are twofold: first is to propose an integrated framework of HES to address the problem of load shedding, and second is to design and implement a resilient EMS in the SF environment. The validation of the proposed EMS demonstrates its feasibility to serve the load for various operating scenarios. The latter include operations under seasonal variation, abnormal weather conditions, and different load shedding patterns. The simulation results reveal that the proposed EMS not only ensures uninterrupted power supply during load shedding but also reduces grid burden by maximizing the use of PV energy. In addition, the SF-based adopted methodology is envisaged to be a useful alternative to the popular design method using the conventional software tools, particularly for event-driven systems. Full article

In order to conduct risk assessment for collision-free decision making of intelligent vehicles in a complex road traffic environment, it is essential to conduct stable tracking and state estimation of multiple vehicle targets. Therefore, this paper proposes a multitarget tracking method in line with the priority data association rule. Firstly, a standard coordinate turn process model is deduced as the existence of translation and rotation of the vehicle on the two-dimensional ground plane. Secondly, an unscented Kalman filter algorithm is developed due to the nonlinear radar measurement model. Thirdly, a priority data association rule, which puts the targets in a priority queue according to the number of times they are associated, is designed to filter out noise, given that it is unlikely for a vehicle target as an inertial system to appear or disappear instantly in practice. In addition, the data association rule specifies that the closer the target is to the front of the queue, the more prioritized the association with the newly observed target would be. Finally, the track management algorithm is constructed. On this basis, a series of real vehicle tests were conducted on real roads with four typical scenarios. According to the test results, the proposed algorithm is effective in filtering out noise and is suboptimal as the nearest neighbor data association. Full article
