The ability to predict lift is crucial for enabling flapping flights on planets with varying air densities and gravities. After determining the lift required for a flapping flight on Earth, it can be predicted under different conditions using a scaling equation as a function of air density and gravity, assuming the cycle-average lift coefficient remains constant. However, in flapping wings, passive deformation due to aerodynamic and inertial forces may alter the flapping-wing kinematics, complicating predictions. In this study, we investigated changes in the lift coefficient of flapping wings under various air density and gravity conditions simulated using a low-pressure chamber and tilting stand, respectively. The current study found that the cycle-averaged lift coefficients remained nearly constant, varying by less than 7% across the air density and gravity conditions. The difference between the measured and predicted hovering frequencies increased under a lower air density due to the higher vibration-induced friction. The power consumption analysis demonstrated higher energy demands in thinner atmospheres and predicted a required power of 5.14 W for a hovering flight on Mars, which is a 66% increase compared to that on Earth. Future experiments will test Martian air density and gravity conditions to enable flapping flights on Mars. Full article

Many Coccinella septempunctata flights, with their precise positioning capabilities, have provided rich inspiration for designing insect-styled micro air vehicles. However, researchers have not widely studied their flight ability. In particular, research on the maneuverability of Coccinella septempunctata using integrated kinematics and aerodynamics is scarce. Using three orthogonally positioned high-speed cameras, we captured the Coccinella septempunctata’s banking turns in the climbing flight in the laboratory. We used the measured wing kinematics in a Navier–Stokes solver to compute the aerodynamic forces acting on the insects in five cycles. Coccinella septempunctata can rapidly climb and turn during phototaxis or avoidance of predators. During banked turning in climbing flight, the translational part of the body, and the distance flown forward and upward, is much greater than the distance flown to the right. The rotational part of the body, through banking and manipulating the amplitude of the insect flapping angle, the stroke deviation angle, and the rotation angle, actively creates the asymmetrical lift and drag coefficients of the left and right wings to generate right turns. By implementing banked turns during the climbing flight, the insect can adjust its flight path more flexibly to both change direction and maintain or increase altitude, enabling it to effectively avoid obstacles or track moving targets, thereby saving energy to a certain extent. This strategy is highly beneficial for insects flying freely in complex environments. Full article

A novel tailless X-type flapping-wing micro air vehicle with two pairs of independent drive wings is designed and fabricated in this paper. Due to the complexity and unsteady of the flapping wing mechanism, the geometric and kinematic parameters of flapping wings significantly influence the aerodynamic characteristics of the bio-inspired flying robot. The wings of the vehicle are vector-controlled independently on both sides, enhancing the maneuverability and robustness of the system. Unique flight control strategy enables the aircraft to have multiple flight modes such as fast forward flight, sharp turn and hovering. The aerodynamics of the prototype is analyzed via the lattice Boltzmann method of computational fluid dynamics. The chordwise flexible deformation of the wing is implemented via designing a segmented rigid model. The clap-and-peel mechanism to improve the aerodynamic lift is revealed, and two air jets in one cycle are shown. Moreover, the dynamics experiment for the novel vehicle is implemented to investigate the kinematic parameters that affect the generation of thrust and maneuver moment via a 6-axis load cell. Optimized parameters of the flapping wing motion and structure are obtained to improve flight dynamics. Finally, the prototype realizes controllable take-off and flight from the ground. Full article

Dragonflies can independently control the movement of their forewing and hindwing to achieve the desired flight. In comparison with previous studies that mostly considered the same kinematics of the fore- and hindwings, this paper focuses on the aerodynamic interference of three-dimensional tandem flapping wings when the forewing kinematics is different from that of the hindwing. The effects of flapping amplitude (Φ₁), flapping mean angle ($\overline{{\varphi }_1}$), and pitch rotation duration (Δtr₁) of the forewing, together with wing spacing (L) are examined numerically. The results show that Φ₁ and $\overline{{\varphi }_1}$ have a significant effect on the aerodynamic forces of the individual and tandem systems, but Δtr₁ has little effect. At a small L, a smaller Φ₁, or larger $\overline{{\varphi }_1}$ of the forewing can increase the overall aerodynamic force, but at a large L, smaller Φ₁ or larger $\overline{{\varphi }_1}$ can actually decrease the force. The flow field analysis shows that Φ₁ and $\overline{{\varphi }_1}$ primarily alter the extent of the impact of the previously revealed narrow channel effect, downwash effect, and wake capture effect, thereby affecting force generation. These findings may provide a direction for designing the performance of tandem flapping wing micro-air vehicles by controlling forewing kinematics. Full article

This study aimed to enhance the stability and response speed of a passive stabilized double-wing flapping micro air vehicle (FMAV) by implementing a feedback-controlled biomimetic tail. A model for flapping wings accurately calculated the lift force with only a 2.4% error compared to the experimental data. Experimental tests established the relationship between control torque and tail area, swing angle, and wing–tail spacing. A stability model for the double-wing FMAV was developed, incorporating stabilizing sails. Linearization of the hovering state facilitated the design of a simulation controller to improve response speed. By adjusting the feedback loops of velocity, angle, and angular velocity, the tail controller reduced the angle simulation response time from 4 s to 0.1 s and the velocity response time from 5.64 s to 0.1 s. In take-off experiments, a passive stabilized prototype with an adjustable tail angle exhibited enhanced flight stability compared to fixed tails, reducing standard deviation by 72.96% at a 0° take-off angle and 56.85% at a 5° take-off angle. The control axis standard deviation decreased by 38.06% compared to the passive stability axis, confirming the effectiveness of the designed tail angle controller in reducing angular deflection and improving flight stability. Full article

The beetle, of the order Coleoptera, possesses outstanding flight capabilities. After completing flight, they can fold their hindwings under the elytra and swiftly unfold them again when they take off. This sophisticated hindwing structure is a result of biological evolution, showcasing the strong environmental adaptability of this species. The beetle’s hindwings can provide biomimetic inspiration for the design of flapping-wing micro air vehicles (FWMAVs). In this study, the Asian ladybird (Harmonia axyridis Pallas) was chosen as the bionic research object. Various kinematic parameters of its flapping flight were analyzed, including the flight characteristics of the hindwings, wing tip motion trajectories, and aerodynamic characteristics. Based on these results, a flapping kinematic model of the Asian ladybird was established. Then, three bionic deployable wing models were designed and their structural mechanical properties were analyzed. The results show that the structure of wing vein bars determined the mechanical properties of the bionic wing. This study can provide a theoretical basis and technical reference for further bionic wing design. Full article

In the design of flapping-wing micro-size air vehicles capable of hovering, wings serve as the primary source of hovering power, making the analysis of aerodynamics and aerodynamic efficiency crucial. Traditional quasi-steady models treat the wings as single rigid plane, neglecting the deformable characteristics of flexible wings. This paper proposes a multi-plane method that, in conjunction with various design parameters of flexible wings in a two-dimensional plane, analyzes their deformation characteristics under the assumption of multiple planes in three-dimensional space, and describes the deformation of wings during flapping. By combining the quasi-steady aerodynamic model, aerodynamic analysis of the deformed wings can be conducted. The relationship between the slack angle, wing flapping position, and wing deformation are analyzed, along with their effects on aerodynamics and aerodynamic efficiency. Experiments validate the deformation patterns of wings during flapping and compare the simulated aerodynamic forces with measured ones. The results indicate that wing deformation can be accurately described by adjusting the parameters in the multi-plane method and that the aerodynamic analysis using this method closely approximates the average lift results. Additionally, the multi-plane method establishes a connection between wing morphology and aerodynamic forces and efficiency, providing valuable insights for aerodynamic analysis. Full article

This paper describes a dragonfly-inspired Flapping Wing Micro Air Vehicle (FW-MAV), named HiFly-Dragon. Dragonflies exhibit exceptional flight performance in nature, surpassing most of the other insects, and benefit from their abilities to independently move each of their four wings, including adjusting the flapping amplitude and the flapping amplitude offset. However, designing and fabricating a flapping robot with multi-degree-of-freedom (multi-DOF) flapping driving mechanisms under stringent size, weight, and power (SWaP) constraints poses a significant challenge. In this work, we propose a compact microrobot dragonfly with four tandem independently controllable wings, which is directly driven by four modified resonant flapping mechanisms integrated on the Printed Circuit Boards (PCBs) of the avionics. The proposed resonant flapping mechanism was tested to be able to enduringly generate 10 gf lift at a frequency of 28 Hz and an amplitude of 180° for a single wing with an external DC power supply, demonstrating the effectiveness of the resonance and durability improvement. All of the mechanical parts were integrated on two PCBs, and the robot demonstrates a substantial weight reduction. The latest prototype has a wingspan of 180 mm, a total mass of 32.97 g, and a total lift of 34 gf. The prototype achieved lifting off on a balance beam, demonstrating that the directly driven robot dragonfly is capable of overcoming self-gravity with onboard batteries. Full article

Insects produce a variety of highly acrobatic maneuvers in flight owing to their ability to achieve various wing-stroke trajectories. Among them, beetles can quickly change their flight velocities and make agile turns. In this work, we report a newly discovered phasic wing-tip-folding phenomenon and its aerodynamic basis in beetles. The wings’ flapping trajectories and aerodynamic forces of the tethered flying beetles were recorded simultaneously via motion capture cameras and a force sensor, respectively. The results verified that phasic active spanwise-folding and deployment (PASFD) can exist during flapping flight. The folding of the wing-tips of beetles significantly decreased aerodynamic forces without any changes in flapping frequency. Specifically, compared with no-folding-and-deployment wings, the lift and forward thrust generated by bilateral-folding-and-deployment wings reduced by 52.2% and 63.0%, respectively. Moreover, unilateral-folding-and-deployment flapping flight was found, which produced a lateral force (8.65 mN). Therefore, a micro-flapping-wing mechanism with PASFD was then designed, fabricated, and tested in a motion capture and force measurement system to validate its phasic folding functions and aerodynamic performance under different operating frequencies. The results successfully demonstrated a significant decrease in flight forces. This work provides valuable insights for the development of flapping-wing micro-air-vehicles with high maneuverability. Full article

In this paper, we explore a nonlinear interactive network system comprising nodalized flapping-wing micro air vehicles (FMAVs) to address the distributed $H_{\infty }$ state estimation problem associated with FMAVs. We enhance the model by introducing an information fusion function, leading to an information-fusionized estimator model. This model ensures both estimation accuracy and the completeness of FMAV topological information within a unified framework. To facilitate the analysis, each FMAV’s received signal is individually sampled using independent and time-varying samplers. Transforming the received signals into equivalent bounded time-varying delays through the input delay method yields a more manageable and analyzable time-varying nonlinear network error system. Subsequently, we construct a Lyapunov–Krasovskii functional (LKF) and integrate it with the refined Wirtinger and relaxed integral inequalities to derive design conditions for the FMAVs’ distributed $H_{\infty }$ state estimator, minimizing conservatism. Finally, we validate the effectiveness and superiority of the designed estimator through simulations. Full article

Flapping-wing micro air vehicles (FWMAVs) have gained much attention from researchers due to their exceptional performance at low Reynolds numbers. However, the limited understanding of active aerodynamic modulation in flying creatures has hindered their maneuverability from reaching that of their biological counterparts. In this article, experimental investigations were conducted to examine the effect of the bilateral amplitude asymmetry of flexible flapping wings. A reduced bionic model featuring bat-like wings is built, and a dimensionless number $\Delta {\mathsf{\Phi }}^{*}$ is introduced to scale the degree of bilateral amplitude asymmetry in flapping motion. The experimental results suggest that the bilateral amplitude–asymmetric flapping motion primarily induces maneuvering control forces of coupling roll moment and yaw moment. Also, roll moment and yaw moment have a good linear relationship. To achieve more efficient maneuvers based on this asymmetric motion, it is advisable to maintain $\Delta {\mathsf{\Phi }}^{*}$ within the range of 0 to 0.4. The magnitude of passive pitching deformation during the downstroke is significantly greater than that during the upstroke. The phase of the peak of the passive pitching angle advances with the increase in flapping amplitude, while the valleys lag. And the proportion of pronation and supination in passive pitching motion cannot be adjusted by changing the flapping amplitude. These findings have important practical relevance for regulating turning maneuvers based on amplitude asymmetry and help to understand the active aerodynamic modulation mechanism through asymmetric wing kinematics. Full article

The flapping wings of insects undergo large deformations caused by aerodynamic forces, resulting in cambering. Insect-mimetic micro wings for flapping-wing nano air vehicles mimic these characteristic deformations. In this study, a 2.5-dimensional insect-mimetic micro wing model for flapping-wing nano air vehicles is proposed to realize this type of wing. The proposed model includes a wing membrane, a leading edge, a center vein, and a root vein, all of which are modeled as shell elements. The proposed wing is a 2.5-dimensional structure and can thus be fabricated using polymer micromachining. We conducted a design window search to demonstrate the capabilities of the wing. The design windows, which are areas of desirable design solutions in the design parameter space, are iteratively searched using nonlinear finite-element analysis under quasi-steady aerodynamic modeling. Here, thickness is selected as a design parameter. The properties of real insects, polymer materials, and fabrication conditions are used to determine the other parameters. A fabricable design solution that generates sufficient camber is found from the design windows. Full article

Mosquitoes’ self-generated air movements around their antennae, especially at the wing-beat frequency, are crucial for both obstacle avoidance and mating communication. However, the characteristics of these air movements are not well clarified. In this study, the air movements induced by wing tones (sound generated by flapping wings in flight) around the antennae of a mosquito-like model (Culex quinquefasciatus, male) are investigated using the acoustic analogy method. Both the self-generated wing tone and the wing tone reflected from the ground are calculated. Given that the tiny changes in direction and magnitude of air movements can be detected by the mosquito’s antennae, a novel method is introduced to intuitively characterize the air movements induced by the wing tone. The air movements are decomposed into two basic modes (oscillation and revolution). Our results show that, without considering the scattering on the mosquito’s body, the self-generated sound wave of the wing-beat frequency around the antennae mainly induces air oscillation, with the velocity amplitude exceeding the mosquito’s hearing threshold of the male wingbeat frequency by two orders of magnitude. Moreover, when the model is positioned at a distance from the ground greater than approximately two wing lengths, the reflected sound wave at the male wingbeat frequency attenuates below the hearing threshold. That is, the role of reflected wing tone in the mosquito’s obstacle avoidance mechanism appears negligible. Our findings and method may provide insight into how mosquitoes avoid obstacles when their vision is unavailable and inspire the development of collision avoidance systems in micro-aerial vehicles. Full article

This study focused on designing a single-degree-of-freedom (1-DoF) mechanism emulating the wings of rock pigeons. Three wing models were created: one with REAL feathers from a pigeon, and the other two models with 3D-printed artificial remiges made using different strengths of material, PLA and PETG. Aerodynamic performance was assessed in a wind tunnel under both stationary (0 m/s) and cruising speed (16 m/s) with flapping frequencies from 3.0 to 6.0 Hz. The stiffness of remiges was examined through three-point bending tests. The artificial feathers made of PLA have greater rigidity than REAL feathers, while PETG, on the other hand, exhibits the weakest strength. At cruising speed, although the artificial feathers exhibit more noticeable feather splitting and more pronounced fluctuations in lift during the flapping process compared to REAL feathers due to the differences in weight and stiffness distribution, the PETG feathered wing showed the highest lift enhancement (28% of pigeon body weight), while the PLA feathered wing had high thrust but doubled drag, making them inefficient in cruising. The PETG feathered wing provided better propulsion efficiency than the REAL feathered wing. Despite their weight, artificial feathered wings outperformed REAL feathers in 1-DoF flapping motion. This study shows the potential for artificial feathers in improving the flight performance of Flapping Wing Micro Air Vehicles (FWMAVs). Full article
