Helmets are crucial for protecting motorcycle riders from head injuries in accidents. This study proposes a helmet pad design based on a negative-Poisson’s-ratio (NPR) structure and comprehensively evaluates its protective effect on head injuries. A concave hexagonal honeycomb structure was embedded into the energy-absorbing lining of a motorcycle helmet, and finite element collision simulations were conducted according to the ECE R22.05 standard. These simulations compared and analyzed the differences in protective performance between concave hexagonal honeycomb helmets with different parameter configurations and traditional expanded polystyrene (EPS) helmets under flat anvil impact scenarios. Using biomechanical parameters, including peak linear acceleration (PLA), head injury criterion (HIC), intracranial pressure (ICP), maximum principal strain (MPS), and the probability of AIS2+ traumatic brain injury, the protective effect of the helmets on traumatic brain injury was evaluated. The results showed that when the wall angle of the honeycomb structure was 60°, honeycomb helmets with wall thicknesses of 0.8 mm and 1.0 mm significantly reduced PLA and HIC values. In particular, the honeycomb helmet with a wall thickness of 1.0 mm reduced ICP by 25.7%, while the honeycomb helmet with a wall thickness of 1.2 mm exhibited the lowest maximum principal strain in the skull compared to EPS helmets and reduced the probability of AIS2+ brain injury by 7.2%. Concave hexagonal honeycomb helmets demonstrated an excellent protective performance in reducing the risk of traumatic brain injury. These findings provide important theoretical foundations and engineering references for the design and optimization of new protective helmets. Full article

Traumatic brain injury (TBI) during snowboarding sports is a major concern. A robust evaluation of existing snowboarding helmets is desired. Head kinematics (i.e., linear acceleration, angular velocity, angular acceleration) and associated brain responses (brain pressure, equivalent (von Mises) stress, and maximum principal strain) of the head are a predominant cause of TBI or concussion. The conventional snowboarding helmet, which mitigates linear acceleration, is typically used in snow sports. However, the role of conventional snowboarding helmets in mitigating angular head kinematics is marginal or insignificant. In recent years, new anti-rotational technologies (e.g., MIPS, WaveCel) have been developed that seek to reduce angular kinematics (i.e., angular velocity, angular acceleration). However, investigations regarding the performance of snowboarding helmets in terms of the mitigation of head kinematics and brain responses are either extremely limited or not available. Toward this end, we have evaluated the performance of snowboarding helmets (conventional and anti-rotational technologies) against blunt impact. We also evaluated the performance of newly developed low-cost, silica-based anti-rotational pads by integrating them with conventional helmets. Helmets were mounted on a head surrogate–Hybrid III neck assembly. The head surrogate consisted of skin, skull, dura mater, and brain. The geometry of the head surrogate was based on the GHBMC head model. Substructures of the head surrogate was manufactured using additive manufacturing and/or molding. A linear impactor system was used to simulate/recreate snowfield hazards (e.g., tree stump, rock, pole) loading. Following the ASTM F2040 standard, an impact velocity of 4.6 ± 0.2 m/s was used. The head kinematics (i.e., linear acceleration, angular velocity, angular acceleration) and brain simulant pressures were measured in the head surrogate. Further, using the concurrent simulation, the brain simulant responses (i.e., pressure, von Mises stress, and maximum principal strain) were computed. The front and side orientations were considered. Our results showed that the helmets with anti-rotation technologies (i.e., MIPS, WaveCel) significantly reduced the angular kinematics and brain responses compared to the conventional helmet. Further, the performance of the silica pad-based anti-rotational helmet was comparable to the existing anti-rotational helmets. Lastly, the effect of a comfort liner on head kinematics was also investigated. The comfort liner further improved the performance of anti-rotational helmets. Overall, these results provide important data and novel insights regarding the performance of various snowboarding helmets. These data have utility in the design and development of futuristic snowboarding helmets and safety protocols. Full article

This article addresses manufacturing structures made via injection molding from biodegradable materials. The mentioned structures can be successfully used as energy-absorbing liners of all kinds of sports helmets, replacing the previously used expanded polystyrene. This paper is focused on injection technological tests and tensile tests (in quasi-static and dynamic conditions) of several composites based on a PLA matrix with the addition of other biodegradable softening agents, such as PBAT and TPS (the blends were prepared via melt blending using a screw extruder with mass compositions of 50:50, 30:70, and 15:85). Tensile tests showed a positive strain rate sensitivity of the mixtures and a dependence of the increase in the ratio of the dynamic to static yield stress on the increase in the share of the plastic component in the mixture. Technological tests showed that increasing the amount of the plasticizing additive by 35% (from 50% to 85%) results in a decrease in the minimal thickness of the thin-walled element that can be successfully injection molded by about 32% in the case of PLA/PBAT blends (from 0.22 mm to 0.15 mm) and by about 26% in the case of PLA/TPS blends (from 0.23 mm to 0.17 mm). Next, the thin-walled elements (dimensions of 55 × 55 × 20 mm) were manufactured and evaluated using a spring-loaded drop hammer. The 60 J impact energy was tested in accordance with the EN 1078 standard. The dynamic crushing test included checking the influence of the materials’ temperature (−20, 0, 20, and 40 °C) and the impact velocity. It was proven that the maximum deflection increases with increasing material temperature and an increase in the share of the plastic component in the mixture. The PLA15PBAT85 blend was selected as the most effective material in terms of its use as an energy-absorbing liner for sport helmets. Johnson–Cook and Cowper–Symonds material plasticizing models were constructed. Their use during dynamic FE simulation provided results that were in good agreement with those of the conducted experiment. Full article

As an important part of head protection equipment, research on the material and structural application of helmet liners has always been one of the hotspots in the field of helmets. This paper first discusses common helmet liner materials, including traditional polystyrene, polyethylene, polypropylene, etc., as well as newly emerging anisotropic materials, polymer nanocomposites, etc. Secondly, the design concept of the helmet liner structure is discussed, including the use of a multi-layer structure, the addition of geometric irregular bubbles to enhance the energy absorption effect, and the introduction of new manufacturing processes, such as additive manufacturing technology, to realize the preparation of complex structures. Then, the application of biomimetic structures to helmet liner design is analyzed, such as the design of helmet liner structures with more energy absorption properties based on biological tissue structures. On this basis, we propose extending the concept of bionic structural design to the fusion of plant stalks and animal skeletal structures, and combining additive manufacturing technology to significantly reduce energy loss during elastic yield energy absorption, thus developing a reusable helmet that provides a research direction for future helmet liner materials and structural applications. Full article

In this study, to discuss the influence of concussion risk from the long-term use of American football helmets on collegiate teams, accident cases during the game are replicated based on game videos by simulations using whole-body numerical models and helmeted finite element human head models. The concussion risks caused by collisions were estimated using the mechanical parameters inside the skull obtained from finite element analyses. In the analyses, the different material properties of helmets identified by free-fall experiments using headform impactor-embedded helmets were used to represent brand-new and long-term-use helmets. After analyzing the five cases, it was observed that wearing a new helmet instead of a long-term-use one resulted in a reduction in the risk of concussion by 1 to 44%. More energy is attenuated by the deformation of the liners of the brand-new helmet, so the energy transferred to the head is smaller than that when wearing the long-term-use helmet. Thus, the long-term use of the helmet reduces its ability to protect the head. Full article

Chronic health risks associated with firefighting continue to be documented and studied, however, the complexity of occupational exposures and the relationship between occupational exposure and contaminated personal protective equipment (PPE) remains unknown. Recent work has revealed that common PPE cleaning practices, which are becoming increasingly more common in the fire service, are not effective in removing certain contaminants, such as polycyclic aromatic hydrocarbons (PAHs), from PPE. To better understand the relationship between contaminated firefighter PPE and potential exposure to PAHs, and to gain further understanding of the efficacy of cleaning practices, we used a standardized fire exposure simulator that created repeatable conditions and measured PPE surface contamination levels via wipe sampling and filters attached to firefighter gear worn by standing mannequins. This study examined the effects of repeated (40 cycles) PPE cleaning (laundering and on-scene preliminary exposure reduction (PER) techniques) and repeated exposures on PAH concentration on different surfaces. Further exploration included examination of contamination breakthrough of turnout jackets (comparing outer shell and interior liner) and evaluation of off-gassing PAHs from used gear after different cleaning treatments. When compared by jacket closure type (zipper and hook and dee), total PAH concentration wiped from gear after exposure and cleanings showed no significant differences. Regression analysis indicated that there was no effect of repeated exposures on PAH contamination levels (all sampling sites combined; before fire 10, 20, and 40; after fire 1, 10, 20, and 40; p-value > 0.05). Both laundering and on-scene PER significantly reduced contamination levels on the exterior pants and helmets and were effective at reducing PAH contamination. The jacket outer shell had significantly higher PAH contamination than the jacket liner. Both laundering and wet soap PER methods (post-fire) are effective in reducing surface contamination and appear to prevent accumulation of contamination after repeated exposures. Semi-volatile PAHs deep within the fibers of bulky PPE are not effectively reduced via PER or machine laundering, therefore, permitting continued off-gassing of these compounds. Further research is needed to identify the most effective laundering methods for firefighter turnout gear that considers the broad spectrum of common contaminants. Full article

A helmet is the main protective equipment for a child pillion passenger. A safe helmet must be able to mitigate head and brain injuries resulting from high head impact loading. A lightweight helmet is preferable, especially for children. This paper proposed to study the effect of materials, liner thickness, and friction at the head–helmet interface on linear and rotational accelerations using reduced-order modelling. A child head–helmet finite element model was developed and validated against an experiment. Finite element simulations were conducted to generate training data for the establishment of reduced-order models which were subsequently used to predict the linear and rotational accelerations for various helmet parameters. The prediction could be performed in a very short time compared to its corresponding finite element simulation. The use of aluminium foam enhanced mitigation of the linear and rotational accelerations as well as weight reduction. This study also revealed that the head–helmet friction coefficient had a strong effect on the rotational acceleration, while the liner thickness predominantly affected the linear acceleration. However, the liner thickness had less influence on the rotational acceleration when the head–helmet friction was low. The risk of brain concussion as well as diffusional injury could be reduced by enabling low friction at head–helmet surface. Full article

Vinyl nitrile foams are polymeric closed-cell foam commonly used for energy absorption in helmets. However, their impact behavior has never been described in isolation. This study aims to characterize the strain rate dependent behavior of three VN foams in compression and combined compression and shear. Vinyl nitrile samples of density 97.5, 125, and 183 kg/m³ were submitted to quasi-static compression (0.01 s⁻¹) and impacts in compression and combined compression and shear (loading direction of 45°). For impacts, a drop test rig was used, and a method was developed to account for strain rate variation during impactor deceleration. Young’s modulus and stress at plateau were correlated with foam density in both compression and combined loading. Vinyl nitrile foams were strain rate dependent: The absorbed energy at the onset of densification was two to four times higher at 100 s⁻¹ than at 0.01 s⁻¹. In combined loading, the compressive stress at yield was reduced by 43% at a high strain rate. Compared to expanded polypropylene, vinyl nitrile foams transmitted less stress at the onset of densification for equivalent absorbed energy and presented a larger ratio between the compression and shear stresses in combined loading (0.37 at yield). This larger ratio between the compression and shear stresses might explain why vinyl nitrile helmet liners are thought to be better at reducing head rotational acceleration than expanded polypropylene helmet liners. Full article

Cork is a sustainable material with remarkable properties. In addition to its main application as wine stoppers, it has also been employed as a sound and thermal insulator in facades, building roofs, aeronautical applications, and, more recently, in impact energy absorption systems. In its natural form, cork is mainly used in wine stopper manufacturing, but for other applications, cork compounds are usually employed, which makes it possible to manufacture complex geometries with nearly isotropic behavior. In this work, an attempt was made to merge the desirable properties of two different cork materials (agglomerated and expanded black) into cork composite sandwich structures. These structures were tested according to impact conditions typically experienced by energy-absorbing liners used in personal safety devices. Additionally, the performance dependency on the working temperature was analyzed. The sole black, expanded cork (EC159) and agglomerated cork (AC199A and AC216) were tested in 500 J impacts. It was found that black cork was characterized by superior thermal stability, while expanded cork allowed absorbing high energies. In the second stage, the composites consisting of both tested materials were tested in 100 J impact scenarios. The combination of two materials of different properties enabled reduction of the peak force exerted on a helmet user’s head during the impact by about 10% compared to agglomerated specimens. Additionally, it was proved that there was no influence of the glue used to join different cork types. Full article

Cellular materials have been used in many applications such as insulation, packaging, and protective gear. Expanded polystyrene has been widely used as energy-absorbing liner in helmets due to its excellent cost-benefit relation. This synthetic material can absorb reasonable amounts of energy via permanent deformation. However, in real-world accidents, helmets may be subjected to multi-impact scenarios. Additionally, oil-derived plastic is presently a major source of societal concern regarding pollution and waste. As a sustainable alternative, cork is a natural cellular material with great crashworthiness properties and it has the remarkable capacity to recover after compression, due to its viscoelastic behavior, which is a desired characteristic in multi-impact applications. Therefore, the main goal is to analyze the applicability of agglomerated cork as padding material in safety helmets. First, a finite element model of a motorcycle helmet available on the market was developed to assess its safety performance and to establish a direct comparison between expanded polystyrene and cork agglomerates as liners. Secondly, a new helmet model with a generic geometry was developed to assess the applicability of agglomerated cork as liner for different types of helmets, based on the head injury risk predictions by the finite element head model, YEt Another Head Model (YEAHM), developed by the authors. Several versions of helmet liners were created by varying its thickness and removing sections of material. In other words, this generic helmet was optimized by carrying out a parametric study, and by comparing its performance under double impacts. The results from these tests indicate that agglomerated cork liners are an excellent alternative to the synthetic ones. Thus, agglomerated cork can be employed in protective gear, improving its overall performance and capacity to withstand multi-impacts. Full article
