Search Results (49)

This paper presents an experimental study of a novel automated manufacturing process that integrates cold embossing to add complex features, such as micro-Fresnel lens designs, onto a 3D-printed ABS polymer component. The research demonstrates that precise control over process parameters, including embossing time (E_t) and velocity (E_v), is critical for successful feature replication. Gloss analysis confirmed that surface softening as a crucial prerequisite for embossing was successfully achieved using a vapour smoothing (VS) chamber that was developed and optimised for the process. High-speed automation using a 6-axis KUKA robot allowed 48 embosses to be completed in just over one minute, highlighting its efficiency over conventional hot embossing (HE) methods. Results showed that an E_t (0.01 s) prevented feature replication as there was insufficient time to allow for polymer flow, while an optimal E_t (0.1 s) produced high-quality embosses across all test segments. Additionally, this study identified that while insufficient cycle times hinder polymer flow, extended durations can lead to surface hardening, prohibiting replication. These findings pave the way for integrating Diffractive Optical Elements into 3D-printed parts, potentially enhancing precision, functionality, and productivity beyond the capabilities of standard 3D-printing processes. Full article

Poly(butylene adipate-co-terephthalate) (PBAT) is a promising degradable polymer for replacing non-degradable traditional plastics to mitigate pollution. However, its low softening temperature and poor hardness impede its application. Herein, PBAT and stereocomplex polylactide (sc-PLA) blends were fabricated through a melt-blending process to balance the heat resistance and mechanical strength of PBAT in this research. The effects of the PLA content and hot embossing temperature on the blend properties were comprehensively investigated. The results demonstrate that the sc-crystal content in the PBAT/sc-PLA blend increased by 493% as the PLA content rose from 10% to 30%. The blend with 15% PLLA and 15% PDLA, hot embossed at 190 °C, exhibited the highest sc-PLA crystallinity of 23.3% and the largest fraction of sc-crystallites at 66%, leading to the optimal comprehensive performance. Its Vicat softening temperature (VST) reached 92.2 °C, and a nonlinear increase trend in accordance with the power-law model between VST and the mass ratio of sc-crystal was obtained. Compared with the mechanical properties of neat PBAT, a maximum tensile yield stress of 9.7 MPa and a Young’s modulus of 82.5 MPa were achieved and improved approximately by 107% and 361%, respectively. This research offers an effective strategy for synergistically enhancing the heat resistance and mechanical strength of PBAT. Full article

The organ-on-a-chip (OoC) technology holds significant promise for biosensors and personalized medicine by enabling the creation of miniature, patient-specific models of human organs. This review studies the recent advancements in the application of polydimethylsiloxane (PDMS) microfluidics for OoC purposes. It underscores the main fabrication technologies of PDMS microfluidic systems, such as photolithography, injection molding, hot embossing, and 3D printing. The review also highlights the crucial role of integrated biosensors within OoC platforms. These electrochemical, electrical, and optical sensors, integrated within the microfluidic environment, provide valuable insights into cellular behavior and drug response. Furthermore, the review explores the exciting potential of PDMS-based OoC technology for personalized medicine. OoC devices can forecast drug effectiveness and tailor therapeutic strategies for patients by incorporating patient-derived cells and replicating individual physiological variations, helping the healing process and accelerating recovery. This personalized approach can revolutionize healthcare by offering more precise and efficient treatment options. Understanding OoC fabrication and its applications in biosensors and personalized medicine can play a pivotal role in future implementations of multifunctional OoC biosensors. Full article

The development of hydrophobicity on polymer surfaces in mass production is one of the most critical challenges in the plastic industry. This paper deals with a novel combined hot embossing process in which femtosecond laser ablation is utilized to texture the embossing stamps. By controlling the process temperature and axial forces, the laser textures were transferred to polymer surfaces, successfully resulting in hydrophobicity. Four different polymers, including ABS, PP, PA, and PC, along with two different laser textures, namely ball and pyramid, were tested. The laser and hot embossing parameters under which the textures were transferred to the polymers are introduced. The critical micro- and nano-features of the transferred textures that resulted in high hydrophobic contact angles are also discussed. The results indicate that PP and ABS have higher contact angles, respectively, while under the given parameters, PA and PC did not exhibit hydrophobic surfaces. Full article

The roller-to-plate (R2P) hot-embossing process is an effective, low-cost method for producing high-quality micro-/nano-optical components. In the field of night vision applications, the fabrication of chalcogenide glass microstructures is emerging as a promising alternative to traditional infrared glass. This trend is driven by the potential of chalcogenide glass to surpass conventional materials in terms of performance. However, the development of R2P hot embossing faces challenges, such as the high cost of curved mold manufacturing, the reliance on roll-to-roll processes for nano hot embossing, the limitations of plastic materials, and the unclear viscoelastic properties of infrared glass. In this study, a novel R2P hot-embossing process was developed to fabricate flat chalcogenide glass structures. The key parameters, such as roller temperature, speed, and embossing pressure, were investigated to understand their impact on the glass-filling performance. The deformation mechanism of the glass microstructures was also analyzed. The experimental results show that the R2P hot-embossing method offers excellent reproducibility, achieving a maximum filling rate of 96% and an average roughness deviation of 8.36 nm. The increase in the roller temperature and embossing force increased the filling height of the glass microstructure arrays, while an increase in the roller speed decreased the filling height. Different embossing methods, including variations in speed, temperature, and force, are summarized to analyze the structural changes during embossing. This study provides a foundation and a basis for future research on the roller-to-plate hot embossing process. Full article

Hot embossing is a manufacturing technique used to create microchannels on polymer substrates. In recent years, microchannel fabrication technology based on hot embossing has attracted considerable attention due to its convenience and low cost. A new evaluation method of microchannels, as well as an approach to obtaining optimal hot embossing conditions based on the Taguchi method, is proposed in this paper to fabricate precise microchannels for a flexible proton-exchange membrane fuel cell (PEMFC). Our self-made hot embossing system can be used to fabricate assorted types of micro-channel structures on polymer substrates according to various applications, whose bottom width, top width, height and cross-sectional area vary in the aims of different situations. In order to obtain a high effective filling ratio, a new evaluation method is presented based on the four parameters of channel structures, and the Taguchi method is utilized to arrange three main factors (temperature, force and time) affecting the hot embossing in orthogonal arrays, quickly finding the optimal condition for the embossing process. The evaluation method for microchannels proposed in this paper, compared to traditional evaluation methods, incorporates the area factor, providing a more comprehensive assessment of the fabrication completeness of the microchannels. Additionally, it allows for the quick and simple identification of optimal conditions. The experimental results indicate that after determining the optimal embossing temperature, pressure and time using the Taguchi method, the effective filling rate remains above 95%, thereby enhancing the power density. Through variance analysis, it was found that temperature is the most significant factor affecting the hot embossing of microchannels. The high filling rate makes the process suitable for PEMFCs. The results demonstrate that under optimized process conditions, a self-made hot embossing system can effectively fabricate columnar structure microchannels for PEMFCs. Full article

This study aims to establish and optimize a process for the fabrication of 3D microstructures of the biocompatible polymer Parylene C using hot embossing techniques. The different process parameters such as embossing temperature, embossing force, demolding temperature and speed, and the usage of a release agent were optimized, utilizing adhesive micropillars as a use case. To enhance compatibility with conventional semiconductor fabrication techniques, hot embossing of Parylene C was adapted from conventional stainless steel substrates to silicon chip platforms. Furthermore, this adaptation included an investigation of the effects of the hot embossing process on metal layers embedded in the Parylene C, ensuring compatibility with the ultra-thin Parylene printed circuit board (PCB) demonstrated previously. To evaluate the produced microstructures, a combination of characterization methods was employed, including light microscopy (LM) and scanning electron microscopy (SEM), X-ray diffraction (XRD), X-ray photoelectron spectroscopy (XPS), and Fourier-transform infrared spectroscopy (FTIR). These methods provided comprehensive insights into the morphological, chemical, and structural properties of the embossed Parylene C. Considering the improved results compared to existing patterning techniques for Parylene C like plasma etching or laser ablation, the developed hot embossing approach yields a superior structural integrity, characterized by increased feature resolution and enhanced sidewall smoothness. These advancements render the method particularly suitable for diverse applications, including but not limited to, sensor optical components, adhesive interfaces for medical wearables, and microfluidic systems. Full article

A novel non-isothermal glass hot embossing system utilizes a silicon mold core coated with a three-dimensional carbide-bonded graphene (CBG) coating, which acts as a thin-film resistance heater. The temperature of the system significantly influences the electrical conductivity properties of silicon with a CBG coating. Through simulations and experiments, it has been established that the electrical conductivity of silicon with a CBG coating gradually increases at lower temperatures and rapidly rises as the temperature further increases. The CBG coating predominantly affects electrical conductivity until 400 °C, after which silicon becomes the dominant factor. Furthermore, the dimensions of CBG-coated silicon and the reduction of CBG coating also affect the rate and outcome of conductivity changes. These findings provide valuable insights for detecting CBG-coated silicon during the embossing process, improving efficiency, and predicting the mold core’s service life, thus enhancing the accuracy of optical lens production. Full article

The filling efficiency during the hot embossing process at micro scale is essential for micro-component replication. The presence of the unfilled area is often due to the inadequate behavior law applied to the embossed materials. This research consists of the identification of viscoplastic law (two-layer viscoplastic model) of polymers and the optimization of processing parameters. Mechanical tests have been performed for two polymers at 20 °C and 30 °C above their glass transition temperature. The viscoplastic parameters are characterized based on stress–strain curves from the compression tests. The influences of imposed displacement, temperature, and friction on mold filling are investigated. The processing parameters are optimized to achieving the complete filling of micro cavities. The replication of a micro-structured cavity has been effectuated using this process and the experimental observations validate the results in the simulation, which confirms the efficiency of the proposed numerical approach. Full article

Given the growing importance of lab-on-a-chip in a number of fields, such as medical diagnosis or environmental analysis, the fact that the current fabrication process relies mainly on oil-based polymers raises an ecological concern. As an eco-responsible alternative, we presented, in this article, a manufacturing process for microfluidic devices from chitosan, a bio-sourced, biodegradable, and biocompatible polysaccharide. From chitosan powder, we produced thick and rigid films. To prevent their dissolution and reduce their swelling when in contact with aqueous solutions, we investigated a film neutralization step and characterized the mechanical and physical properties of the resulting films. On these neutralized chitosan films, we compared two micropatterning methods, i.e., hot embossing and mechanical micro-drilling, based on the resolution of microchannels from 100 µm to 1000 µm wide. Then, chitosan films with micro-drilled channels were bonded using a biocompatible dry photoresist on a glass slide or another neutralized chitosan film. Thanks to this protocol, the first functional chitosan microfluidic devices were prepared. While some steps of the fabrication process remain to be improved, these preliminary results pave the way toward a sustainable fabrication of lab-on-a-chip. Full article

Freestanding, flexible and open through-hole polymeric micro- and nanostructured membranes were successfully fabricated over large areas (>16 cm²) via solvent removal of sacrificial scaffolds filled with polymer resin by spontaneous capillary flow. Most of the polymeric membranes were obtained through a rapid UV curing processes via cationic or free radical UV polymerisation. Free standing microstructured membranes were fabricated across a range of curable polymer materials, including: EBECRYL3708 (radical UV polymerisation), CUVR1534 (cationic UV polymerisation) UV lacquer, fluorinated perfluoropolyether urethane methacrylate UV resin (MD700), optical adhesive UV resin with high refractive index (NOA84) and medical adhesive UV resin (1161-M). The present method was also extended to make a thermal set polydimethylsiloxane (PDMS) membranes. The pore sizes for the as-fabricated membranes ranged from 100 µm down to 200 nm and membrane thickness could be varied from 100 µm down to 10 µm. Aspect ratios as high as 16.7 were achieved for the 100 µm thick membranes for pore diameters of approximately 6 µm. Wide-area and uniform, open through-hole 30 µm thick membranes with 15 µm pore size were fabricated over 44 × 44 mm² areas. As an application example, arrays of Au nanodots and Pd nanodots, as small as 130 nm, were deposited on Si substrates using a nanoaperture polymer through-hole membrane as a stencil. Full article

In this paper, a high-precision, low-cost, batch processing nanoimprint method is proposed to process a spherical microlens array (MLA). The nanoimprint mold with high surface precision and low surface roughness was fabricated by single-point diamond turning. The anti-sticking treatment of the mold was carried out by perfluorooctyl phosphoric acid (PFOPA) liquid deposition. Through the orthogonal experiment of hot embossing with the treated mold and subsequent inductively coupled plasma (ICP) etching, the microstructure of MLA was transferred to the silicon substrate, with a root mean square error of 17.7 nm and a roughness of 12.1 nm Sa. The average fitted radius of the microlens array units is 406.145 µm, which is 1.54% different from the design radius. Full article

In this study, the unconventional microfabrication method by the combined processes of the chemical soft stamping technique with the thermal uplifting technique to fabricate metal nanoarrays on a glass plate is proposed and their feasibility verified. The gold micro-ring arrays on a quartz glass plate are realized by utilizing a chemical template with the thermal uplifting method. Their optical properties are studied experimentally. First, a plastic mold is made of a Biaxially Oriented Polyethylene Terephthalate (BOPET) via the hot embossing method. Then, the Methanal micropatterns are transferred onto an etched surface of a substrate via a soft stamping process with a BOPET mold. The gold thin film is coated onto the methanol patterned glass plate via the Ar+ sputter coating process. Finally, the metallic micro-ring structures are aggregated on a glass plate via the thermal uplifting technique. The LSPR optical properties as the extinction spectrums of the gold micro-ring structure arrays are investigated experimentally. It is confirmed that this method was able to fabricate plasmonic micro-ring arrays with low cost and high throughput. Full article

This paper aims to present a novel rapid hot embossing approach and to study filling capacity of optical glass in the hot embossing process. Firstly, a novel rapid hot embossing device is developed, which consists of a rapid heating module and a precision loading module. Particularly, the rapid heating module allows a maximum temperature of 800 °C and a heating rate of 300 °C/min, with decent temperature control accuracy and uniform temperature distribution. In hot embossing process, by incompletely filling the microhole of silicon carbide mold, a microlens would be formed on the surface of glass disc, and the filling capacity of glass is quantified by the maximum height of the microlens. The tailor-made hot embossing device was exploited to conduct a series of experiments for evaluating effects of process parameters on the filling capacity of N-BK7 glass. Experimental results indicate that the filling capacity of glass could be enhanced by increasing the embossing force, the embossing temperature, the soaking time but decreasing the annealing rate. Furthermore, compared to soaking time and annealing rate, embossing force and embossing temperature have more significant influence on the filling capacity of N-BK7 glass. Therefore, the novel rapid hot embossing is a practical and promising technology for fabricating microstructures on glass materials with high softening points. Full article

This work aims at developing polymer surfaces with enhanced hydrophobicity by controlling both the surface chemistry and the surface structure. As a first step, a chemical surface modification is achieved by the incorporation of a synthetized tailored fluorinated copolymer, named POISE-a (Polymer prOcessing Interface StabilizEr), in a commercial polystyrene matrix. Then, a complementary physical approach based on micro-structuration of a polymer surface is used. Polystyrene films containing various contents of POISE-a were elaborated by a solvent casting method. The structuration of the films was conducted by replicating a texture from a nickel insert using a hot-embossing technique with optimized processing conditions. The beneficial effect of POISE-a on both the wettability properties and the replication efficiency was evaluated by the water/polymer static contact angle and the quantification of the replication rate, respectively. The use of this tailored additive, even at low percentages (i.e., 1 wt.%), associated with the structuration of the PS surface, improves both the hydrophobicity of polystyrene and the robustness of the replication process. Full article
