Search Results (171)

Efficient energy harvesting from open-channel flows offers a sustainable solution for powering distributed sensing systems in water infrastructure. This study investigates a piezoelectric wake-excited membrane vortex-induced vibration (VIV) energy harvester through a combined numerical and mechanical approach. The device features an upstream cylindrical bluff body that generates a periodic vortex street, exciting a downstream flexible membrane equipped with surface-mounted piezoelectric patches. A one-way coupled CFD–FEM framework implemented in ANSYS was employed to assess the effects of membrane length, material stiffness, and flow conditions on hydrodynamic loading, structural deformation, and deformation power. Results show that membrane length mainly affects oscillation amplitude and force levels, whereas material stiffness has a stronger influence on membrane deformation and RMS mechanical power. Among the investigated materials, low-stiffness polyethylene yields the highest deformation power, while none of the analysed configurations reaches a full lock-in condition within the explored parameter range. Complementary mechanical analysis revealed that the stiffness of commercial piezoelectric patches significantly reduces local strain, thereby constraining the practically harvestable energy in the present baseline configuration. Spectral power density analysis identified the dominant shedding frequency and its harmonics, confirming that the flow response is governed by a coherent periodic excitation. These findings highlight key design trade-offs in wake-excited membrane harvesters and provide useful guidance for the future optimisation of self-powered hydraulic monitoring systems. Full article

This study investigates the dynamic behavior and structural optimization of hydraulic water well drilling rig masts through a comparative finite element analysis (FEA) of metallic and composite configurations. The reference model, manufactured from structural steel (S355J2/E315), was compared with two optimized lightweight alternatives made of carbon fiber reinforced polymer (CFRP) and glass fiber reinforced polymer (GFRP) laminates. Simulations were performed in MSC Visual Nastran using identical geometric and loading conditions, including the critical dynamic event of drill string pull-out. The results demonstrate that substituting steel with composite materials significantly decreases the overall mass by up to 55%, while increasing the first natural frequency by 20–25% and reducing dynamic stress amplification by approximately 15–20%. Furthermore, the maximum tip displacement of the mast was reduced by 35–45% for the composite variants, indicating improved stiffness and vibration damping capability. These findings confirm that polymer composite structures offer superior dynamic performance, lower inertial loads, and enhanced operational safety, providing a viable route for next-generation lightweight drilling rig designs integrating advanced macromolecular materials. Full article

Brake-by-wire systems eliminate the mechanical linkage between the brake pedal and wheel actuators, resulting in the loss of the natural and familiar braking feel perceived by the driver. To address this issue, this study proposes an active brake pedal simulator based on a linear motor and springs, aiming to simulate the adaptive pedal feel and ensure safety performance. Firstly, this paper established a structural model of the pedal simulator and designed a force compensation strategy to reproduce the target pedal characteristic curve of the traditional hydraulic braking system. Subsequently, the system was verified through Adams simulation and real vehicle experiments under slow, normal, and emergency braking conditions. The experimental results show that the initial design exhibited a relatively “soft” pedal feel, with a brake feel index score of 62.31. By optimizing the spring stiffness and feedback force composition, the brake feel index score was significantly improved to 92.21. The optimized pedal simulator is capable of achieving precise pedal force tracking and adaptive adjustment of pedal feel, and still providing basic and reliable pedal force feedback, even in the event of motor failure. Therefore, the designed pedal simulator provides a practical and effective solution for improving the pedal feel of the brake-by-wire system, demonstrating strong application potential. Full article

Twin shield tunneling in river-crossing soft soils faces increased risks like face instability, largely due to unclear mechanisms linking water level fluctuations to ground settlement. To address this issue, a 3D fluid–solid-coupled FLAC3D model is developed based on the Zhanqiaogang section of Hangzhou Metro Line 15. Specifically, the model simulates four hydrological conditions: low water, normal water level, high water level, and flood level. It examines their effects on ground settlement, stress distribution, and pore water pressure during twin-tunnel excavation. The results indicate that the maximum ground surface settlement on the left alignment under flood-level conditions increased by 41.58% compared with that under normal water levels. On the right alignment, surface settlement increased from 6.54 mm under normal water levels to 8.54 mm under flood conditions, representing a 30.6% increase. A sensitivity analysis is also conducted on pore water pressure, soil internal friction angle, and support stiffness. Results show that ground settlement increases with rising river levels, mainly due to elevated pore pressure reducing soil strength. Sensitivity analysis confirms pore pressure as the key factor influencing deformation. Numerical results align well with field data, highlighting the critical role of hydraulic boundaries. Based on these results, control measures are proposed to provide practical guidance for mitigating settlement in similar river-crossing tunnel projects. Full article

Brake pedals and wheel braking units are mechanically decoupled in brake-by-wire systems. This causes the driver to lose the familiar pedal feel. To address this issue, this paper designed an active braking pedal simulator based on the long-travel Halbach-array linear motor. Firstly, this paper conducted both qualitative and quantitative analyses on the pedal characteristics of a traditional hydraulic braking system and used them as a reference. A dual-coil independent control strategy was designed in order to overcome the thrust instability at the junction of the Halbach-array magnetic field. This enables the linear motor to achieve smooth and continuous thrust output throughout the entire travel range. Secondly, this paper also designed a “linear motor + spring” solution to reduce energy consumption and peak motor thrust. By conducting a quantitative analysis of the relationship between the spring stiffness, motor work and peak thrust, the spring stiffness was optimized. The results show that when the spring stiffness is 3.73 N/mm, the motor work can be reduced to 5.92 Joules while significantly reducing the peak thrust. Finally, this paper also established a testing platform. It was used to verify the performance of the proposed pedal simulator under low-intensity, medium-intensity, and high-intensity braking conditions as well as an anti-lock braking system intervention. The testing results show that the pedal simulator can actively adjust the pedal characteristics according to the braking intensity, and it can provide clear vibration feedback during the anti-lock braking system intervention. Therefore, the proposed pedal simulator effectively simulates the pedal feel of hydraulic braking systems while improving energy efficiency and operational stability. It provides a feasible solution for enhancing the driver–vehicle interaction and the driving comfort of brake-by-wire systems. Full article

To address the limited capability of conventional hydro-pneumatic suspensions in coordinated damping–stiffness regulation, this paper proposes a new semi-active hydro-pneumatic suspension (SAHPS) system based on a dual-valve shock absorber. A damping valve architecture composed of a spring check valve–solenoid proportional valve–spring check valve is arranged between the rod and rodless chambers of the hydraulic cylinder, enabling coordinated adjustment of suspension damping and equivalent stiffness. Furthermore, a genetic algorithm optimization with model predictive control (GA-MPC) is designed to enhance the overall dynamic performance of the suspension while effectively reducing the operating frequency of the solenoid proportional valve. Finally, AMESim–Simulink co-simulations and hardware-in-the-loop (HIL) experiments are conducted under bumpy road excitation and Class C random road conditions. Under Class C random road conditions, compared with passive hydro-pneumatic suspension and semi-active suspension with conventional MPC, the proposed method achieves maximum reductions of 11%, 25%, and 12.9% in the root mean square values of body acceleration, suspension working space, and dynamic tire load, respectively. The discrepancies between experimental and simulation results remain below 7%, confirming the effectiveness of the proposed system and control strategy. This study provides a new technical guidance for low-frequency vibration suppression in vehicle suspension systems. Full article

A hybrid quill shaft for a multifunctional machine tool centre combines a conventional steel body with a wound composite insert that significantly enhances structural stiffness and dynamic properties. This paper presents a methodologically rigorous approach to the design and validation of a hybrid quill shaft, encompassing material optimisation through the NSGA-II evolutionary algorithm, experimental modal analysis, and verification of the influence of an active pre-tensioning anchor system on the compensation of elastic deformations. A finite element model was coupled with an optimisation tool evaluating eight fibre types across 786 iterations. Results unequivocally demonstrated the superiority of M55J fibre with ±88° orientation as the optimal compromise between stiffness (13.2% reduction in deflection), weight (3% reduction), and cost (4.2% cost increase). Composite safety was ensured through the three-dimensional Tsai-Wu strength criterion applied as a constraint. Experimental validation on an assembly with a hydraulic pre-tensioning system demonstrated symmetrical quill shaft behaviour (±0.07 mm/m) and agreement with finite element analysis (9.5% deviation). Numerical modal analysis revealed a pronounced decrease in natural frequencies with increasing overhang (from 308 Hz to 58 Hz). The resulting design incorporating M55J fibres, 2345 mm length, and epoxy resin in a 60:40 fibre-to-matrix ratio represents a practically implementable solution for enhanced precision and productivity in modern machine tool centres. Full article

Legged robots inspired by animal locomotion require actuators with high power density, fast response, and robust force control, yet traditional valve-controlled hydraulic systems suffer from substantial energy losses and weak regeneration performance. Motivated by role allocation across gait phases in animal legs, where in-air positioning requires far less actuation effort than ground contact support and force modulation, this work proposes a novel gas–oil hybrid servo actuator, denoted GOhsa, for quadruped knee joints. GOhsa utilizes pre-charged high-pressure gas to pressurize hydraulic oil, converting the conventional dual-chamber pressure servo control into a single-chamber configuration while preserving the original piston stroke. This architecture enables bidirectional position–force control, enhances energy regeneration applicability, and improves operational efficiency. Theoretical modeling is conducted to analyze hydraulic stiffness and frequency-response characteristics, and a linearization-based force controller with dynamic compensation is developed to handle system nonlinearities. Experimental validation on a single-leg platform demonstrates significant energy-saving performance: under no-load conditions (simulating the swing phase), GOhsa achieves a maximum power reduction of 79.1%, with average reductions of 15.2% and 11.5% at inflation pressures of 3 MPa and 4 MPa, respectively. Under loaded conditions (simulating the stance phase), the maximum reduction reaches 28.0%, with average savings of 10.0% and 9.8%. Tracking accuracy is comparable to traditional actuators, with reduced maximum errors (13.7 mm/16.5 mm at 3 MPa; 15.0 mm/17.8 mm at 4 MPa) relative to the 16.6 mm and 18.1 mm errors of the conventional system, confirming improved motion stability under load. These results verify that GOhsa provides high control performance with markedly enhanced energy efficiency. Full article

The coupling mechanism involving high-pressure seepage and soil degradation regarding the face stability in water-rich silty sand environment remains to be comprehensively elucidated. This paper employs 3D fluid–solid coupling simulations to investigate these interactions taking the Jingu-Haihe Tunnel as a case study, and the dry and saturated hydraulic environments alongside three softening scenarios are set. Results indicate that hydro-mechanical coupling significantly compromises face stability, elevating the limit support pressure from 140 kPa in dry mechanical state to 231 kPa. The failure mechanism transitions from localized “horn-like” shear bands in dry states to global quasi-symmetric “bulb-like” visco-plastic diffusion in saturated seepage field scenarios. Softening effects cause stress-dependent stiffness degradation, increasing the deformation rate by 53.8% under low support pressure, and inducing uneven deformation where the crown displacement increases by 32.8 times, exceeding the 11.8-fold increase at the center as the support pressure drops from 600 kPa to 100 kPa. Moreover, the fluid–solid coupling effect amplifies the stratum’s sensitivity to shear strength parameters by up to 26 times at the face center compared to the dry condition. These findings may offer theoretical insights for optimizing support pressure determination in deep-buried saturated excavations. Full article

To address the technical challenge where traditional high-pressure, large-flow emulsion pump stations cannot adapt to the drastic flow rate changes in hydraulic supports due to the fixed displacement of their quantitative pumps—leading to frequent system unloading, severe impacts, and damage—this study proposes an intelligent flow control method based on the digital flow distribution principle for actively perceiving and matching support demands. Building on this method, a compact, electro-hydraulically separated prototype with stepless flow regulation was developed. The system integrates high-speed switching solenoid valves, a piston push rod, a plunger pump, sensors, and a controller. By monitoring piston position in real time, the controller employs an optimized combined regulation strategy that integrates adjustable duty cycles across single, dual, and multiple cycles. This dynamically adjusts the switching timing of the pilot solenoid valve, thereby precisely controlling the closure of the inlet valve. As a result, part of the fluid can return to the suction line during the compression phase, fundamentally achieving accurate and smooth matching between the pump output flow and support demand, while significantly reducing system fluctuations and impacts. This research adopts a combined approach of co-simulation and experimental validation to deeply investigate the dynamic coupling relationship between the piston’s extreme position and delayed valve closure. It further establishes a comprehensive dynamic coupling model covering the response of the pilot valve, actuator motion, and backflow control characteristics. By analyzing key parameters such as reset spring stiffness, piston cylinder diameter, and actuator load, the system reliability is optimized. Evaluation of the backflow strategy and delay phase verifies the effectiveness of the multi-mode composite regulation strategy based on digital displacement pump technology, which extends the effective flow range of the pump to 20–100% of its rated flow. Experimental results show that the system achieves a flow regulation range of 83% under load and 57% without load, with energy efficiency improved by 15–20% due to a significant reduction in overflow losses. Compared with traditional unloading methods, this approach demonstrates markedly higher control precision and stability, with substantial reductions in both flow root mean square error (53.4 L/min vs. 357.2 L/min) and fluctuation amplitude (±3.5 L/min vs. ±12.8 L/min). The system can intelligently respond to support conditions, providing high pressure with small flow during the lowering stage and low pressure with large flow during the lifting stage, effectively achieving on-demand and precise supply of dynamic flow and pressure. The proposed “demand feedforward–flow coordination” control architecture, the innovative electro-hydraulically separated structure, and the multi-cycle optimized regulation strategy collectively provide a practical and feasible solution for upgrading the fluid supply system in fully mechanized mining faces toward fast response, high energy efficiency, and intelligent operation. Full article

The mechanical response of geomembranes in hydraulic structures is strongly influenced by temperature variations, which alter both material stiffness and interface shear strength behavior. This study develops a non-linear, temperature-dependent tensile behavior constitutive model for a polyvinyl chloride (PVC) geomembrane and evaluates its implications for the stability of geomembrane-lined reservoir slopes. The empirical relationship was calibrated using tensile tests reported in literature for temperatures between 10 °C and 60 °C, reproducing the observed non-linear softening and modulus reduction with increasing temperature. A classical thermal dilation formulation was incorporated to simulate cyclic thermal expansion and contraction. The constitutive and thermal formulations were implemented in FLAC2D and applied to a 2H:1V covered geomembrane slope representative of dam lining systems. The results show that temperature-induced softening significantly increases tensile strain within the geomembrane. The model also shows that the lower surface interface friction angle of the geomembrane plays a significant role in the slope stability. Thermal cycle analysis demonstrates the accumulation of efforts resulting from the fatigue of the geomembrane. The proposed model provides a practical framework for incorporating thermo-mechanical coupling in design analyses and highlights the necessity of accounting for realistic thermal conditions in assessing the long-term stability of geomembrane-lined reservoirs. Full article

An explicit coupled two-dimensional (2D) hydromechanical model (HMM) that can simulate discontinuous features in the foundation, as well as the effects of grout curtains and drainage systems, is employed to evaluate the influence of key parameters such as dam height, foundation behaviour, joint patterns, joint stiffness and strength, hydraulic apertures, and grout curtain permeability. A parametric sensitive study using four gravity dams, and a real case study of an operating dam are presented. The results presented show that dam height influences the relationship between water level in the reservoir and drain discharges, with higher dams showing more pronounced curved nonlinearity. The strength properties of the concrete–rock interface are also shown to have a meaningful influence on the HM response, especially for an elastic foundation and for higher dams, showing the need to properly characterize this interface through in situ testing. The joint aperture at nominal zero stress is shown to be the parameter with the most significant effect on the HM response. The results also show that a progressive degradation scenario of the concrete–rock interface or of the grout curtain permeability is easier to identify through the hydraulic measurements than in the mechanical displacement field. Full article

Limb amputations are a growing global challenge. Electrically powered prosthetic hands are heavy, expensive, and battery dependent. Body-powered prostheses offer a simpler and lighter alternative; however, existing designs require high body forces to operate, exhibit poor aesthetics, and have limited dexterity. This study aims to present a design of a hydraulically actuated soft bending finger with a simple and scalable manufacturing process. This is then realised into a five-fingered body-powered prosthetic hand that is lightweight, comfortable, and representative of a human hand. The actuator was formed from two silicone materials of different stiffness (Stiff Smooth-Sil 950 and flexible Ecoflex 00-30) and reinforced with double-helix fibres to generate bending under internal hydraulic pressure. A shoulder-mounted hydraulic system has been designed to convert scapular elevation and protraction into actuator pressure. Finite element analysis and physical tests were performed to examine the bending and blocking force performance of the actuators. The physical actuators achieved bending angles up to 230 degrees at 60 kPa and blocking forces of 5.9 N at 100 kPa. The prosthetic system was able to grasp and hold a 320-g water bottle. The results demonstrate a soft actuator design that provides simple and scalable manufacturing and shows how these actuators can be incorporated into a body-powered prosthesis. This study provides a preliminary demonstration of the feasibility of human-powered prosthetics and necessitates continued research. This work makes progress towards an affordable and functional body-powered prosthetic hand that can improve the lives of transradial amputees. Full article

This study addresses the stability and deformation control of the Xiling auxiliary shaft in the Sanshandao Gold Mine during excavation, under the complex geological conditions of high in situ stress, high pore pressure, and elevated geothermal gradients. A thermal–hydraulic–mechanical (THM) coupling numerical model is developed to investigate the stress distribution, deformation mechanisms, and long-term stability of the surrounding rock under multi-physical interactions. Meanwhile, the influence of excavation rate on rock stability is analyzed. The results indicate that excavation induces significant stress redistribution, with stress concentrations in high-elastic-modulus strata, where the maximum compressive and tensile stresses reach 15.9 MPa and 14.1 MPa, respectively. The maximum displacement occurs in low-stiffness rock layers (around 1400 m depth), with a total magnitude of 1139 mm, primarily resulting from unloading relaxation, pore pressure reduction, and thermal contraction. Excavation rate strongly affects the temporal evolution of deformation: faster excavation leads to greater instantaneous displacements, whereas slower excavation suppresses displacement due to the sustained influence of thermal contraction. Based on these findings, particular attention should be paid to the low-stiffness strata near 1400 m depth during the construction of the Xiling auxiliary shaft. A combined support system consisting of high-prestress rock bolts, lining, and grouting is recommended for deformation-concentrated zones, while excavation rates should be optimized to balance efficiency and safety. Furthermore, long-term monitoring of temperature, pore pressure, and displacement is essential to achieve dynamic risk control. These results provide valuable theoretical and engineering insights for the safe construction and stability management of deep mine shafts. Full article

Seepage-induced internal erosion occurs when the hydraulic forces are sufficient to detach fine particles and transport them out of the structure, leading to notable changes in soil characteristics such as particle size distribution, pore size distribution, and pore structure, which will, in turn, have significant influences on the mechanical properties of soil. In this study, three approaches were utilized to model the erosion-induced loss of fine particles, i.e., deleting fine particles randomly (RM), by contact force (CF), and by coordination number (CN) using the discrete element method (DEM). The impact of each fine particle removal mode on both micro- and macro-mechanical soil properties, including peak strength, dilation, critical state characteristics, average particle coordination number, and contact force distribution, is comprehensively analyzed and compared. The results demonstrate that residual strength was insensitive to removal method, whereas at 10% fines loss, peak strength decreased by up to 17% and the secant stiffness E₅₀ decreased by nearly 48%. This work provides a foundation for simulating the internal erosion of gap-graded soils. Full article
