Recently, flexible sensors have gained significant attention due to their potential applications in soft robotics and biomimetic intelligent devices. However, the successful production of favorable flexible sensors integrated with high flexibility, sensitivity and excellent environment adaptability toward multiple external stimuli is still an enormous challenge. Herein, a lightweight polymeric porous sponge capable of detecting an external magnetic field and strain excitations is proposed by assembling a sodium alginate/chitosan (SA/CHI) porous sponge with micron carbonyl iron and nanoscale Fe₃O₄ magnetic particles (MPs). Based on the double network structure, the SA/CHI sponge possesses preferable mechanical strength and hydrophilicity, demonstrating its high flexibility and deformability. More importantly, the electrical response of the SA/CHI sponge sensors can display remarkable variation under external magnetic and mechanical stimuli due to their superior magnetic characteristics and electrical conductivity. Meanwhile, their sensing properties can maintain relatively stable recoverability and repeatability towards the periodic excitations and releases. Additionally, a potential mechanism is provided to investigate their stimuli-sensitive behavior. It is highly dependent on the microstructure variations in MPs and conductive multi-walled carbon nanotube (MWCNTs) networks. Due to its exceptional magnetic controllability and appropriate electrical sensitivity, the proposed sensor shows high potential in wearable multi-sensing electronics and intelligent transport devices. Full article

We evaluated the minimum concentration and minimum size within which magnetic particles (MPs) can be detected by modern ultra-sensitive magnetic field sensors (MFS). Calculations showed that magnetite MPs with specific magnetization with characteristic sizes of ≥50 nm and a concentration of C_V~0.1 vol.% can be detected at a distance of l ≤ 0.1 mm using MFS with a magnetic field resolution of S_B ≥ 1 nT. However, at such a close distance it is impossible to non-invasively approach the biological object of study. On the other hand, the same MPs are easily detected at l ≤ 30 mm using supersensitive MFS based on the phenomena of superconductivity (SQUID) or superconductivity and spintronics (combined MFS (CMFS)). These sensors require cryogenic operating temperatures (4–77 K), and S_B~10–100 fT are realized within them. Note that superparamagnetic particles or carbon nanotubes (CNTs) can also be non-invasively detected by SQUID or CMFS sensors, assuming that their concentration in the material is C_V ≥ 0.0000001 vol.%. It is believed that CNTs may contain catalytic iron particles or encapsulated magnetic nanoparticles in nanotubes. Thus, modern supersensitive magnetic field sensors with S_B ≤ 100 fT make it possible to detect MPs in nanoscale, submicron, and micron sizes in biological objects. They can be used for the noninvasive control of organs, implants, prostheses and drug carriers in the necessary parts of the body. Of particular importance is the noninvasive control of CNTs in functional biocompatible nanomaterials, which have good prospects for widespread use in medical practice. Full article

Microscale and nanoscale robots, frequently referred to as future cargo systems for targeted drug delivery, can effectively convert magnetic energy into locomotion. However, navigating and imaging them within a complex colloidal vascular system at a clinical scale is exigent. Hence, a more precise and enhanced hybrid control navigation and imaging system is necessary. Magnetic particle imaging (MPI) has been successfully applied to visualize the ensemble of superparamagnetic nanoparticles (MNPs) with high temporal sensitivity. MPI uses the concept of field-free point (FFP) mechanism in the principal magnetic field. The gradient magnetic field (|∇B|) of MPI scanners can generate sufficient magnetic force in MNPs; hence, it has been recently used to navigate nanosized particles and micron-sized swimmers. In this article, we present a simulation analysis of the optimized navigation of an ensemble of microsized polymer MNP-based drug carriers in blood vessels. Initially, an ideal two-dimensional FFP case is employed for the basic optimization of the FFP position to achieve efficient navigation. Thereafter, a nine-coil electromagnetic actuation simulation system is developed to generate and manipulate the FFP position and |∇B|. Under certain vessel and fluid conditions, the particle trajectories of different ferromagnetic polymer ratios and |∇B| were compared to optimize the FFP position. Full article

In this work, we investigated the processing-microstructure-property relationships for magnetoelectric (ME) particulate composites consisting of hard ferromagnetic CoFe₂O₄ (CFO) particles dispersed in a Nb-doped PbZr_xTi_1-xO₃ (PZT) soft ferroelectric matrix. Several preparation steps, namely PZT powder calcination, PZT-CFO mixture milling and composite sintering were tailored and a range of microstructures was obtained. These included open and closed porosities up to full densification, PZT matrices with decreasing grain size across the submicron range down to the nanoscale and well dispersed CFO particles with bimodal size distributions consisting of submicron and micron sized components with varying weights. All samples could be poled under a fixed DC electric field of 4 kV/mm and the dielectric, piezoelectric and elastic coefficients were obtained and are discussed in relation to the microstructure. Remarkably, materials with nanostructured PZT matrices and open porosity showed piezoelectric charge coefficients comparable with fully dense composites with coarsened microstructure and larger voltage coefficients. Besides, the piezoelectric response of dense materials increased with the size of the CFO particles. This suggests a role of the conductive magnetic inclusions in promoting poling. Magnetoelectric coefficients were obtained and are discussed in relation to densification, piezoelectric matrix microstructure and particle size of the magnetic component. The largest magnetoelectric coefficient α₃₃ of 1.37 mV cm⁻¹ Oe⁻¹ was obtained for submicron sized CFO particles, when closed porosity was reached, even if PZT grain size remained in the nanoscale. Full article
