Search Results (6)

Search Parameters:
Keywords = multi-reference frame (MRF)

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
23 pages, 32058 KB
Article
Stern Duct with NACA Foil Section Designed by Resistance and Self-Propulsion Simulation for Japan Bulk Carrier
by Ping-Chen Wu, Tzu-Chi Yeh and Yu-Cheng Wang
Inventions 2025, 10(2), 32; https://doi.org/10.3390/inventions10020032 - 21 Apr 2025
Viewed by 888
Abstract
The objective of the presented work is the stern duct design for the JBC (Japan Bulk Carrier) hull form. Since the original duct only provides a 0.6% resistance reduction, an innovative duct will be proposed to improve the ship resistance and propulsion performance. [...] Read more.
The objective of the presented work is the stern duct design for the JBC (Japan Bulk Carrier) hull form. Since the original duct only provides a 0.6% resistance reduction, an innovative duct will be proposed to improve the ship resistance and propulsion performance. The duct section geometry is based on the NACA (National Advisory Committee for Aeronautics) 4-digit foil series. First, we analyze whether the wake flow field and total resistance of the ship are improved, and then we investigate the self-propulsion performance for the selected ones. The research tool is the CFD (Computational Fluid Dynamics) software OpenFOAM 9 with the viscous free surface flow field modelled by the VOF (Volume of Fluid) method and the SST (Shear Stress Transport) kω turbulence model. The propeller effect is implemented by the MRF (Multi-Reference Frame). Compared to the original duct, two ducts, namely, NACA 7908 and NACA 6.3914, show the best (2.8%) resistance reduction in the bare hull condition. By installing both ducts, the propeller thrust decreases 6 and 5% to reach the self-propulsion point, and the behind-hull efficiency increases 7 and 6%. Both ducts save the energy, i.e., effective horsepower, by 4.3%, and produce obvious flow acceleration, achieving around 10% higher effective wake factor (1 − w). The nominal and propeller wakes are improved as well. Full article
Show Figures

Figure 1

26 pages, 11358 KB
Article
Computational Design of an Energy-Efficient Small Axial-Flow Fan Using Staggered Blades with Winglets
by Mustafa Tutar and Janset Betul Cam
Int. J. Turbomach. Propuls. Power 2025, 10(1), 1; https://doi.org/10.3390/ijtpp10010001 - 9 Jan 2025
Viewed by 3006
Abstract
The present study introduces a conceptual design of a small axial-flow fan. Both individual and combined effects of blade stagger angle and winglet on the performance of the fan design are investigated in design and off-design operating conditions using a computational flow methodology. [...] Read more.
The present study introduces a conceptual design of a small axial-flow fan. Both individual and combined effects of blade stagger angle and winglet on the performance of the fan design are investigated in design and off-design operating conditions using a computational flow methodology. A stepwise solution, in which a proper stagger angle adjustment of a specifically generated blade profile is followed by appending a winglet at the tip of the blade with consideration of different geometrical parameters, is proposed to improve the performance characteristics of the fan. The initial model comparison analysis demonstrates that a three-dimensional, Reynolds-averaged Navier–Stokes (RANS) equation-based renormalization group (RNG) kε turbulence modeling approach coupled with the multiple reference frame (MRF) technique which adapts multi-block topology generation meshing method successfully resolves the rotating flow around the fan. The results suggest that the use of a proper stagger angle with the winglet considerably increases the fan performance and the fan attains the best total efficiency with an additional stagger angle of +10° and a winglet, which has a curvature radius of 6.77 mm and a twist angle of −7° for the investigated dimensioning range. The present study also underlines the effectiveness of passive flow control mechanisms of the stagger angle and winglets for energy-efficient axial-flow fans. Full article
Show Figures

Figure 1

22 pages, 13345 KB
Article
Aerodynamic Investigation on a Coaxial-Rotors Unmanned Aerial Vehicle of Bionic Chinese Parasol Seed
by Wenbiao Gan, Yunpeng Wang, Hongbo Wang and Junjie Zhuang
Biomimetics 2024, 9(7), 403; https://doi.org/10.3390/biomimetics9070403 - 2 Jul 2024
Cited by 1 | Viewed by 2698
Abstract
Aerodynamic investigation of a bionic coaxial-rotors unmanned aerial vehicle (UAV) is performed. According to Chinese parasol seed features and flight requirements, the bionic conceptual design of a coaxial-rotors UAV is described. A solution procedure for the numerical simulation method, based on a multi-reference [...] Read more.
Aerodynamic investigation of a bionic coaxial-rotors unmanned aerial vehicle (UAV) is performed. According to Chinese parasol seed features and flight requirements, the bionic conceptual design of a coaxial-rotors UAV is described. A solution procedure for the numerical simulation method, based on a multi-reference frame (MRF) model, is expressed, and a verification study is presented using the typical case. The aerodynamic design is conducted for airfoil, blade, and coaxial-rotors interference. The aerodynamic performance of the coaxial rotors is investigated by numerical simulation analysis. The rotor/motor integrated experiment verification is conducted to assess the performance of the coaxial-rotors UAV. The results indicate that the UAV has excellent aerodynamic performance and bionic configuration, allowing it to adapt to task requirements. The bionic UAV has a good cruise power load reach of 8.36 kg/kw, and the cruise flying thrust force is not less than 78 N at coaxial-rotor and rotor-balloon distance ratios of 0.39 and 1.12, respectively. It has the “blocks stability phenomenon” formed by the rotor downwash speed decreases and the balloon’s additional negative pressure. The present method and the bionic configuration provide a feasible design and analysis strategy for coaxial-rotors UAVs. Full article
Show Figures

Figure 1

22 pages, 9791 KB
Article
Numerical Analysis and Validation of an Optimized B-Series Marine Propeller Based on NSGA-II Constrained by Cavitation
by Alejandra Vázquez-Santos, Nahum Camacho-Zamora, José Hernández-Hernández, Agustín L. Herrera-May, Lorena del Carmen Santos-Cortes and María Elena Tejeda-del-Cueto
J. Mar. Sci. Eng. 2024, 12(2), 205; https://doi.org/10.3390/jmse12020205 - 23 Jan 2024
Cited by 3 | Viewed by 2602
Abstract
Constantly growing environmental concerns focused on reducing pollution, in addition to rising fuel costs in recent years, have led the maritime industry to develop and implement fuel-saving solutions. Among them is the optimization of marine propeller efficiency, as marine propellers are a crucial [...] Read more.
Constantly growing environmental concerns focused on reducing pollution, in addition to rising fuel costs in recent years, have led the maritime industry to develop and implement fuel-saving solutions. Among them is the optimization of marine propeller efficiency, as marine propellers are a crucial part of ship’s propulsion system. During the initial design stage, selecting the optimal propeller is considered a multi-objective optimization process. This research focused on maximizing propeller open water efficiency, while minimizing engine brake power constrained by thrust and cavitation. Optimization was applied to Wageningen B-series propellers and conducted using the Non-Dominated Sorting Genetic Algorithm II (NSGA-II). The algorithm selected optimum parameters to create the propeller model, which was then evaluated numerically through computational fluid dynamics (CFD) with a multiple reference frame (MRF) and under the SST k-ω turbulence model, to obtain the open water hydrodynamic characteristics. In addition, the cavitation effect was evaluated using the Zwart–Gerber–Belamri cavitation model. The numerical model results were validated through comparison with open water experimental data from the Netherlands Ship Model Basin for the Wageningen B-series propellers. The results showed errors of 3.29% and 2.01% in efficiency under noncavitating and cavitating conditions, respectively. Correct performance of the functions was shown, based on neural networks trained to estimate thrust and torque coefficients instead of polynomials. The proposed optimization process and numerical model are suitable for solving multi-objective optimization problems in the preliminary design of fixed-pitch marine propellers. Full article
(This article belongs to the Section Ocean Engineering)
Show Figures

Figure 1

14 pages, 6782 KB
Article
Aerodynamic Performance Assessment of Distributed Electric Propulsion after the Wing Trailing Edge
by Yao Lei and Xiangzheng Zhao
Appl. Sci. 2024, 14(1), 280; https://doi.org/10.3390/app14010280 - 28 Dec 2023
Cited by 1 | Viewed by 1925
Abstract
Distributed electric propulsion (DEP) with four propellers distributed along the rear edge of the wing (pusher DEP configuration) promote aerodynamic interactions to a higher level. To study the aerodynamic performance of DEP with the rear wing through simulations and experiments, the multi-reference frame [...] Read more.
Distributed electric propulsion (DEP) with four propellers distributed along the rear edge of the wing (pusher DEP configuration) promote aerodynamic interactions to a higher level. To study the aerodynamic performance of DEP with the rear wing through simulations and experiments, the multi-reference frame (MRF) with sliding grid is combined with wind tunnel tests. The obtained results demonstrate that the lift and drag of DEP increase with the angle of attack (AoA) and are related to the relative position of the propellers and wing. The propeller has no significant effect on the lift of the wing, and the lift and the AoA remain linear when the AoA is less than 16°. By contrast, the lift coefficient is much higher than the baseline (isolated wing), and the lift is greatly improved with the increasing drag when the AoA is greater than 16°. This is because the flow around the wing of the pusher configuration remains attached due to the suction of the inflow of the propeller on the trailing edge vortex. In addition, the acceleration effect on the free flow improves the kinetic energy of the airflow, which effectively delays the separation of the airflow in the slipstream region. Full article
(This article belongs to the Special Issue Application of Aerodynamics in Aerospace)
Show Figures

Figure 1

19 pages, 10681 KB
Article
Numerical Simulation Investigation on the Windage Power Loss of a High-Speed Face Gear Drive
by Yu Dai, Feiyue Ma, Xiang Zhu and Jifu Jia
Energies 2019, 12(11), 2093; https://doi.org/10.3390/en12112093 - 31 May 2019
Cited by 18 | Viewed by 3026
Abstract
Reducing the energy consumption and improving the efficiency of high-speed transmission systems are increasingly common goals; the windage power loss is not negligible in these methods. In this work, the multi-reference frame (MRF) and periodic boundary conditions (PBC) based on the computational fluid [...] Read more.
Reducing the energy consumption and improving the efficiency of high-speed transmission systems are increasingly common goals; the windage power loss is not negligible in these methods. In this work, the multi-reference frame (MRF) and periodic boundary conditions (PBC) based on the computational fluid dynamics (CFD) method were adopted to investigate the windage phenomena of a single face gear with and without a shroud, and the impact of the gear speed on the windage power loss was analyzed. Furthermore, the effects on the distribution of static pressure due to the distances between the shroud and the gear body in different directions, including the outer radius direction, the inner radius direction, and the addendum direction were investigated. The results indicate that the gear speed significantly affected the windage loss, as the higher the gear speed was, the greater the windage power loss. Additionally, the shroud could effectively reduce the windage power loss, where the optimal distance from the addendum to the shroud was not the minimum distance; however, for the distances from the shroud to the inner radius and the outer radius, the smaller the distance was, the smaller the windage loss. The results can provide a theoretical basis and technical reference for reducing the windage power loss of various face gear drives. Full article
Show Figures

Figure 1
