In this work, we used a label-free biosensor that provides optical readouts to perform continuous detection of human interleukin 8 (IL-8), which is especially overexpressed in certain cancers and, thus, could be an effective biomarker for cancer prognosis estimation and therapy evaluation. For this purpose, we engineered a compact, portable, and easy-to-assemble biosensing module device. It combines a fluidic chip for reagent flow, a biosensing chip for signal transduction, and an optical readout head based on fiber optics in a single module. The biosensing chip is based on independent arrays of resonant nanopillar transducer (RNP) networks. We integrated the biosensing chip with the RNPs facing down in a simple and rapidly fabricated polydimethyl siloxane (PDMS) microfluidic chip, with inlet and outlet channels for the sample flowing through the RNPs. The RNPs were vertically oriented from the backside through an optical fiber mounted on a holder head fabricated ad hoc on polytetrafluoroethylene (PTFE). The optical fiber was connected to a visible spectrometer for optical response analysis and consecutive biomolecule detection. We obtained a sensogram showing anti-IL-8 immobilization and the specific recognition of IL-8. This unique portable and easy-to-handle module can be used for biomolecule detection within minutes and is particularly suitable for in-line sensing of physiological and biomimetic organ-on-a-chip systems. Cancer biomarkers’ continuous monitoring arises as an efficient and non-invasive alternative to classical tools (imaging, immunohistology) for determining clinical prognostic factors and therapeutic responses to anticancer drugs. In addition, the multiplexed layout of the optical transducers and the simplicity of the monolithic sensing module yield potential high-throughput screening of a combination of different biomarkers, which, together with other medical exams (such as imaging and/or patient history), could become a cutting-edge technology for further and more accurate diagnosis and prediction of cancer and similar diseases. Full article

Glancing angle deposition (GLAD) is a unique physical vapor deposition technique to enable wafer-scale production of close-packed nanopillar arrays (NaPAs) made of a wide range of inorganic and organic materials and engineerable structures, offering great potential for advanced optoelectronic applications. By flexibly controlling substrate rotation during GLAD, this technique enables intricate sculpture of nanopillars in vertical/tilted column, helix, zigzag, and square spiral shapes or a combination of these shapes along the vertical growth axis. In particular, NaPAs exhibit unique engineerability in their material/structure-determined optical, electronic, chemical, mechanical, and morphological properties, making them versatile for significant applications in photovoltaics, photodetection, photocatalysis, and advanced displaying. In this review, we provide a comprehensive overview of recent advancements in optoelectronic applications of GLAD-fabricated NaPAs by exploring the relationship between structural features and device functionality. Additionally, we discuss the technical challenges associated with GLAD, such as scalability, material compatibility, and fabrication precision, and address prospects to produce next-generation optoelectronic devices. Full article

The electromagnetic density of states (EM-DOS) plays a crucial role in understanding light–matter interactions, especially at metal–dielectric interfaces. This study explores the impact of interface geometry, material properties, and nanostructures on EM-DOS, with a focus on surface plasmon polaritons (SPPs) and evanescent waves. Using a combination of analytical and numerical methods, the behavior of EM-DOS is analyzed as a function of distance from metal–dielectric interfaces, showing exponential decay with penetration depth. The influence of different metals, including copper, gold, and silver, on EM-DOS is examined. Additionally, the effects of dielectric materials, such as Ti${\mathrm{O}}_2$, PMMA, and ${\mathrm{Al}}_2$${\mathrm{O}}_3$, on the enhancement of electromagnetic field confinement are discussed. The study also investigates the effect of nanostructures, like nanohole and nanopillar arrays, on EM-DOS by calculating effective permittivity and analyzing the interaction of quantum emitters with these structures. Results show that nanopillar arrays enhance EM-DOS more effectively than nanohole arrays, especially in the visible spectrum. The findings provide insights into optimizing plasmonic devices for applications in sensing, quantum technologies, and energy conversion. Full article

Anodized aluminum oxide (AAO) molds were used for the production of large-area and inexpensive superhydrophobic polymer films. A controlled anodization methodology was developed for the fabrication of hierarchical micro–nanoporous (HMN) AAO imprint molds (HMN-AAO), where phosphoric acid was used as both an electrolyte and a widening agent. Heat generated upon repetitive high-voltage (195 V) anodization steps is effectively dissipated by establishing a cooling channel. On the HMN-AAO, within the hemispherical micropores, arrays of hexagonal nanopores are formed. The diameter and depth of the micro- and nanopores are 18/8 and 0.3/1.25 µm, respectively. The gradual removal of micropatterns during etching in both the vertical and horizontal directions is crucial for fabricating HMN-AAO with a high aspect ratio. HMN-AAO rendered polycarbonate (PC) and polymethyl methacrylate (PMMA) films with respective water contact angles (WCAs) of 153° and 151°, respectively. The increase in the WCA is 80% for PC (85°) and 89% for PMMA (80°). On the PC and PMMA films, mechanically robust arrays of nanopillars are observed within the hemispherical micropillars. The micro–nanopillars on these polymer films are mechanically robust and durable. Regular nanoporous AAO molds resulted in only a hydrophobic polymer film (WCA = 113–118°). Collectively, the phosphoric acid-based controlled anodization strategy can be effectively utilized for the manufacturing of HMN-AAO molds and roll-to-roll production of durable superhydrophobic surfaces. Full article

A novel asymmetric all-dielectric metasurface supporting multiple Fano resonances with high quality-factor through the excitation of quasi-bound states in the continuum is theoretically investigated. It is demonstrated that two resonances in the near-infrared wavelength are excited by the symmetry-protected bound state in the continuum, which can be transformed into the electric dipole and the toroidal dipole quasi-BIC resonance with high quality-factor by breaking the symmetry of metasurface. Moreover, the sensing properties based on different liquid refractive indexes are researched theoretically. The results show that the maximum quality-factor of the Fano resonance peak is 8422, and the sensitivity can reach 402 nm/RIU, with a maximum figure of merit of 2400 RIU⁻¹. This research is believed to further promote the development of optical sensing and nonlinear optics. Full article

On-chip multi-dimensional detection systems integrating pixelated polarization and spectral filter arrays are the latest trend in optical detection instruments, showing broad application potential for diagnostic medical imaging and remote sensing. However, thin-film or microstructure-based filter arrays typically have a trade-off between the detection dimension, optical efficiency, and spectral resolution. Here, we demonstrate novel on-chip integrated polarization spectral detection filter arrays consisting of metasurfaces and multilayer films. The metasurfaces with two nanopillars in one supercell are designed to modulate the Jones matrix for polarization selection. The angle of diffraction of the metasurfaces and the optical Fabry–Perot (FP) cavities determine the spectrum’s center wavelength. The polarization spectral filter arrays are placed on top of the CMOS sensor; each array corresponds to one pixel, resulting in high spectral resolution and optical efficiency in the selected polarization state. To verify the methodology, we designed nine-channel polarized spectral filter arrays in a wavelength range of 1350 nm to 1550 nm for transverse electric (TE) linear polarization. The array has a 10 nm balanced spectral resolution and average peak transmission efficiency of over 75%, which is maintained by utilizing lossless dielectric material. The proposed array can be fabricated using overlay e-beam lithography, and the process is CMOS-compatible. The proposed array enables broader applications of in situ on-chip polarization spectral detection with high efficiency and spectral resolution, as well as in vivo imaging systems. Full article

A visible–extended shortwave infrared indium gallium arsenide (InGaAs) focal plane array (FPA) detector is the ideal choice for reducing the size, weight and power (SWaP) of infrared imaging systems, especially in low-light night vision and other fields that require simultaneous visible and near-infrared light detection. However, the lower quantum efficiency in the visible band has limited the extensive application of the visible–extended InGaAs FPA. Recently, a novel optical metasurface has been considered a solution for a high-performance semiconductor photoelectric device due to its highly controllable property of electromagnetic wave manipulation. Broadband Mie resonator arrays, such as nanocones and nanopillars designed with FDTD methods, were integrated on a back-illuminated InGaAs FPA as an AR metasurface. The visible–extended InGaAs detector was fabricated using substrate removal technology. The nanostructures integrated into the Vis-SWIR InGaAs detectors could realize a 10–20% enhanced quantum efficiency and an 18.8% higher FPA response throughout the wavelength range of 500–1700 nm. Compared with the traditional AR coating, nanostructure integration has advantages, such as broadband high responsivity and omnidirection antireflection, as a promising route for future Vis-SWIR InGaAs detectors with higher image quality. Full article

Structural colors based on all-dielectric metasurfaces hold great promise for a wide range of applications, including high-density optical storage, ultra-high-resolution 3D displays, imaging security certification, and so on. However, achieving dynamic tunable structural color with a compact and simple Si platform remains a great challenge. Here, we propose a dynamic tunable structural coloration with polarization-sensitive metasurfaces consisting of arrays of Si elliptical nanopillars, enabling full-colored images to be displayed and switched through the control of the polarization of incident light. A distinct feature of our design is that the color phase is independent of the viewing angle, which is fundamental for real applications. Moreover, we demonstrated that dual and multiple colors can be obtained by varying the angle of either the polarizer or the analyzer. Our scheme provides a simple yet general approach for potential applications in the fields of virtual reality, ultra-high-resolution 3D displays, and high-density information storage. Full article

Diamond nanostructures are mostly produced from bulk diamond (single- or polycrystalline) by using time-consuming and/or costly subtractive manufacturing methods. In this study, we report the bottom-up synthesis of ordered diamond nanopillar arrays by using porous anodic aluminium oxide (AAO). Commercial ultrathin AAO membranes were adopted as the growth template in a straightforward, three-step fabrication process involving chemical vapor deposition (CVD) and the transfer and removal of the alumina foils. Two types of AAO membranes with distinct nominal pore size were employed and transferred onto the nucleation side of CVD diamond sheets. Subsequently, diamond nanopillars were grown directly on these sheets. After removal of the AAO template by chemical etching, ordered arrays of submicron and nanoscale diamond pillars with ~325 nm and ~85 nm diameters were successfully released. Full article

We report on plasmonic sensors based on arrays of metallic bow tie nanoantennas with high sensitivity and an enhanced figure of merit. In the present sensing device, each gold nanoantenna is positioned on the upper surface of a SiO₂ nanopillar that is placed on a quartz substrate. The presence of the nanopillar significantly reduces the coupling of the enhanced electromagnetic field generated at the plasmon resonance to the substrate. The simulated results show that the sensitivity of the device to refractive index sensing is 612 nm/RIU, calculated by the resonance wavelength shift per refractive index unit due to the change in the ambient medium index, while the full width at half maximum is calculated at around 10 nm with a figure of merit of 61. The proposed sensor thus has a great potential for sensing and detection applications. Full article

Infrared detection technology has important applications in laser ranging, imaging, night vision, and other fields. Furthermore, recent studies have proven that hot carriers which are generated by surface plasmon decay can be exploited for photodetection to get beyond semiconductors’ bandgap restriction. In this study, silicon nanopillars (NPs) and gold film at the top and bottom of silicon nanopillars were designed to generate surface plasmon resonance and Fabry–Perot resonance to achieve perfect absorption. The absorption was calculated using the Finite Difference Time Domain (FDTD) method, and factors’ effects on resonance wavelength and absorption were examined. Here we demonstrate how this perfect absorber can be used to achieve near-unity optical absorption using ultrathin plasmonic nanostructures with thicknesses of 15 nm, smaller than the hot electron diffusion length. Further study revealed that the resonance wavelength can be redshifted to the mid-infrared band (e.g., 3.75 μm) by increasing the value of the structure parameters. These results demonstrate a success in the study of polarization insensitivity, detection band adjustable, and efficient perfect absorption infrared photodetectors. Full article

In the present article, the position-controlled and catalytic-free synthesis of vanadium dioxide (VO₂) nanowires (NWs) grown by the chemical vapor deposition (CVD) on nanoimprinted silicon substrates in the form of nanopillar arrays was analyzed. The NW growth on silicon nanopillars with different cross-sectional areas was studied, and it has been shown that the NWs’ height decreases with an increase in their cross-sectional area. The X-ray diffraction technique, scanning electron microscopy, and X-ray photoelectron spectroscopy showed the high quality of the grown VO₂ NWs. A qualitative description of the growth rate of vertical NWs based on the material balance equation is given. The dependence of the growth rate of vertical and horizontal NWs on the precursor concentration in the gas phase and on the growth time was investigated. It was found that the height of vertical VO₂ NWs along the [100] direction exhibited a linear dependence on time and increased with an increase in the precursor concentration. For horizontal VO₂ NWs, the height along the direction [011] varied little with the growth time and precursor concentration. These results suggest that the high-aspect ratio vertical VO₂ NWs formed due to different growth modes of their crystal faces forming the top of the growing VO₂ crystals and their lateral crystal faces related to the difference between the free energies of these crystal faces and implemented experimental conditions. The results obtained permit a better insight into the growth of high-aspect ratio VO₂ NWs and into the formation of large VO₂ NW arrays with a controlled composition and properties. Full article

Surface-enhanced Raman spectroscopy (SERS) can be regarded as a powerful tool for probing chemical molecules by effectively enhancing Raman signals. However, the enhancement factors depend on the SERS template, the probed molecular structures, and the excitation laser wavelength. Herein, we proposed a simple and easily fabricated nanostructured template for SERS and analyzed the wavelength-dependent factors. Three types of golden nanopillar arrays on silicon wafers were designed and manufactured. The SERS signals of the Rhodamine 6G (R6G) molecules were extracted. Three laser sources, a blue 17 mW 458 nm diode laser, a green 20 mW 532 nm laser, and a red 6 mW 633 nm laser, were employed as the excitation laser sources. The 458 nm laser was located far from the resonate spectrum of R6G. The optical intensity distributions for the different SERS templates excited by three laser beams were also simulated. The enhancement factors (EFs) of R6G on the three nanostructured templates were measured and compared. The photoluminescence spectrum of the nanostructured templates and SERS signals of R6G were also measured. In addition, the experimental results concerned optical simulations. The analysis tool that was used was a convolution profile of multiple Lorentzian line shapes with a Gaussian profile. It is helpful to understand the SERS signals when the excitation laser wavelength is located out of the resonance region of molecules. It can also provide a new design approach to fabricate an SERS Template with a nanopillar array for different excitation wavelengths. Full article

In this study, we investigated an absorber based on a center-aligned tandem nanopillar array for ultra-broadband solar energy harvesting theoretically. A high-efficiency, omnidirectional absorber was obtained by introducing the center-aligned tandem nanopillar array embedded in an Al₂O₃ dielectric layer. The multi-coupling modes at different wavelengths were interpreted. The strong absorption can be adjusted by changing the radii and heights of nanopillars. According to the simulation results, the average absorptance of the absorber exceeded 94% in the wavelength range from 300 nm to 2000 nm. In addition, the high-efficiency absorption was insensitive to the incident angle and polarization state. The research not only proposed an absorber which possesses a huge potential value for application areas, such as thermal photovoltaic systems, infrared detection, and isotropic absorption sensors, but also pointed out a new way to design an absorber with high efficiency in an ultrabroad wavelength range. Full article

In this work we present a dual optical and electrochemical sensor based on SiO₂/Si₃N₄ resonant nanopillars covered with an indium tin oxide (ITO) thin film. A 25–30 nm thick ITO layer deposited by magnetron sputtering acts as an electrode when incorporated onto the nanostructured array, without compromising the optical sensing capability of the nanopillars. Bulk sensing performances before and after ITO deposition have been measured and compared in accordance with theoretical calculations. The electrochemical activity has been determined by the ferri/ferrocyanide redox reaction, showing a remarkably higher activity than that of flat thin films of similar ITO nominal thickness, and proving that the nanopillar system covered by ITO presents electrical continuity. A label-free optical biological detection has been performed, where the presence of amyloid-β has been detected through an immunoassay enhanced with gold nanoparticles. Again, the experimental results have been corroborated by theoretical simulations. We have demonstrated that ITO can be a beneficial component for resonant nanopillars sensors by adding potential electrochemical sensing capabilities, without significantly altering their optical properties. We foresee that resonant nanopillars coated with a continuous ITO film could be used for simultaneous optical and electrochemical biosensing, improving the robustness of biomolecular identification. Full article
