High production costs and extended development timelines pose significant challenges to the manufacturing of bearingless permanent magnet synchronous motors (BPMSMs). Moreover, uncertainties regarding the motor’s ability to generate suspension and torque often persist even after prototyping, primarily due to the limitations of lumped parameter models in capturing the system’s complex dynamics. Since this technology is not yet fully consolidated, there is a clear need for a solution that enables the effective evaluation of BPMSMs prior to physical production. To address this, a reduced-order model (ROM) was developed for BPMSMs with combined windings, capturing the cross-coupling effects associated with rotor eccentricity, magnetic saturation, and topological complexity. The model was constructed using the parametric interpolation method (PIM), enabling efficient and accurate representations of nonlinear electromechanical behavior as ferromagnetic materials and spatial harmonics are addressed through finite element modeling. Additionally, hardware-in-the-loop (HIL) techniques were used for gain tuning, and active disturbance rejection control (ADRC) was applied to enhance performance. This combined approach offers a comprehensive solution for the design and control of BPMSMs. Full article

In this paper, an optimal transient control (OTC) scheme is proposed to improve the transient stability of the grid-forming (GFM) wind farm (WF) based on the transient stability of the WTs. The converter’s current operating safety range is considered to quantify the maximum KES capabilities of the WTs. At the WF control level, the global transient voltage control problem is solved by optimizing the output reactive power of different WTs of the WF. At the WT control level, the transient stability of WT is improved by regulating the output power and weak magnetic current. The simulation results in MATLAB/Simulink show that the proposed control scheme can more efficiently improve the transient stability of WT by suppressing the DC bus voltage fluctuations and enhancing the voltage support capability of WT compared with the traditional control schemes. Full article

This paper proposes a sensorless field-oriented control (FOC) strategy for permanent magnet synchronous motors (PMSMs), focusing on rotor flux position estimation based on back-electromotive force (back-EMF) signals. The limitations of conventional phase-locked loop (PLL) techniques for rotor flux position estimation along the motor shaft are analyzed, and an enhanced PLL structure is developed to address these deficiencies.In electric vehicle traction applications, precise flux position estimation alone is insufficient; accurate generation of d–q-axis current commands is equally critical. To address this need, a zero-pole-free PI regulator is designed within the PLL module, enabling more accurate flux estimation. Additionally, a gradient-based self-tuning algorithm is employed to identify system parameters, particularly the stator inductance, enabling the controller to optimize current command generation.Comprehensive system-level simulations have been conducted to validate the effectiveness of the proposed sensorless control scheme. Comparative studies demonstrate that the proposed method significantly improves feasibility and robustness for practical PMSM drive applications. Full article

To optimize the modulated vibration generated by the integer-slot interior permanent magnet synchronous motor (IPMSM), a stepwise segmented skewed pole method was proposed, using an 8-pole 48-slot IPMSM as an example. First, the vibration characteristics of the motor were studied, and the theoretical mechanisms of the magnetic field modulation effect and radial force modulation effect were explained. The study showed that high-order radial forces can excite larger low-order vibrations under the influence of radial force modulation. Then, in response to the axial spacing in the linear skewed pole structure when canceling the 48th-order radial force, a stepwise skewed pole structure was proposed. The suppression mechanism of this skewed pole structure on the motor’s modulated vibration was analyzed, and the optimization effect of different segment numbers on the motor’s vibration acceleration at $12f_e$ was discussed. Finally, models for the motor’s magnetic field, structural field, and acoustic field before and after skewing were established, and simulations were conducted to compare the magnitudes of the radial forces at each order and their vibration noise performance. The results showed that after stepwise skewed pole optimization, the radial force that excites the modulated vibration was reduced by 68%, the maximum vibration acceleration on the casing surface was reduced by 84%, and the overall noise was reduced by 7.491 dB, effectively suppressing electromagnetic vibration noise. Full article

A PCB stator axial flux permanent magnet (AFPM) motor is presented that overcomes the manufacturing challenges associated with the complex geometry of conventional stators by employing a PCB substrate. Traditionally, AFPM motors are produced by winding coils around the stator teeth, a process that requires specialized winding machinery and is both labor intensive and time consuming, ultimately incurring considerable manufacturing costs and delays. In contrast, PCB substrates offer significant advantages in manufacturability and mass production, effectively resolving these issues. Furthermore, the primary material used in PCB substrates, FR-4, exhibits a permeability similar to that of air, resulting in negligible electromagnetic cogging torque. Cogging torque arises from the attraction between permanent magnets and stator teeth, creating forces that interfere with motor rotation and generate unwanted vibration, noise, and potential mechanical collisions between the rotor and stator. In the PCB stator design, the conventional PCB circuit pattern is replaced by the motor’s coil configuration, and the absence of stator teeth eliminates these interference issues. Consequently, a slotless motor configuration with minimal vibration and noise is achieved. The PCB AFPM motor has been applied to a vehicle-mounted electric water pump (EWP), where mass production and space efficiency are critical. In an EWP, which integrates the impeller with the motor, it is essential that vibrations are minimized since excessive vibration could compromise impeller operation and, due to fluid resistance, require high power input. Moreover, the AFPM configuration facilitates higher torque generation compared to a conventional radial flux permanent magnet synchronous motor (RFPM). In a slotless AFPM motor, the absence of stator teeth prevents core flux saturation, thereby further enhancing torque performance. AC losses occur in the conductors as a result of the magnetic flux produced by the permanent magnets, and similar losses arise within the PCB circuits. Therefore, an optimized PCB circuit design is essential to reduce these losses. The Constant Trace Conductor (CTC) PCB circuit design process is proposed as a viable solution to mitigate AC losses. A 3D finite element analysis (3D FEA) model was developed, analyzed, fabricated, and validated to verify the proposed solution. Full article

This paper proposes a vibration reduction method for fractional slot concentrated winding (FSCW) permanent magnet synchronous motors (PMSMs) by applying a four-layer winding configuration. The radial electromagnetic force (REF), particularly its low space-harmonics, causes significant vibration in PMSMs. These low-order REF components are influenced by sub-harmonics in the airgap magnetic flux density (MFD), which occur at frequencies lower than the fundamental component generated by the armature magnetomotive force (MMF) in FSCW PMSMs. To mitigate these sub-harmonics in the MFD, the four-layer winding is applied to the FSCW PMSM. As a result, the overall vibration of the motor is reduced. To verify the effectiveness of the four-layer winding, both electrical and mechanical characteristics are compared among motors with conventional one-, two-, and, proposed, four-layer windings. Finally, the three motors are fabricated and tested, and their vibration levels are experimentally evaluated. Full article

This article proposes an innovative joint vibration suppression method for six-axis collaborative robots. A permanent magnet synchronous motor (PMSM) and harmonic reducer are considered as a whole system in the design. A novel active disturbance rejection control (ADRC) scheme has been implemented by applying vibration suppression measures to the low-speed end of joint reducers. The mechanism of vibration generated by robot joints was analyzed. A vibration model for harmonic reducers was built. A new extended state observer model was designed to analyze the position disturbance data of two encoders in robot joints. Vibration signals were extracted and input into the ADRC algorithm to suppress joint vibration. A six-axis robot experimental platform was built and used to explore the changes in robot vibration trajectories under different speed conditions by applying the ADRC algorithm. The experimental results clearly show that the fluctuation amplitude of the trajectory of the robot has been reduced. The experimental results clearly show that by applying the new vibration suppression algorithm, the amplitude, vibration velocity, and acceleration of the robot at low speed have decreased $0.533$ mm, $10.12$ mm/s, and $0.49$ mm/s², respectively, and at the same time, the velocity stability of the PMSM has been improved. This article accurately evaluates the vibration suppression performance of the ADRC algorithm at different speeds of robots, effectively suppressing the vibration of robot joints. Full article

Thanks to the magnetic field modulation effect, the magnetic field modulation motor (MFMM) significantly improves torque density and magnetic field harmonic utilization by breaking the constraints of traditional motor excitation and armature pole number matching. This advantage enhances its development potential in fields such as new energy vehicles, aerospace, power generation, and the military. This article first starts with the basic principle of magnetic field modulation, and adopts the excitation unit position classification method to systematically summarize the evolution laws of major MFMM topology structures such as the permanent magnet synchronous motor, switch magnetic flux motor, and flux reversal motor in recent years. It also analyzes the research progress of key performance such as the torque characteristics and power factor of these motors. Research has pointed out that the MFMM still faces core challenges such as high torque ripple, complex structure, low power factor, and multiple losses. Based on a review of the main achievements in the field, the future development direction of MFMMs is proposed to promote its development in the fields of precision drive and efficient energy conversion. Full article

On the basis of the space voltage vector pulse width modulation (SVPWM) technique, the random pulse width modulation (RPWM) technique, which can reduce harmonics, is investigated based on the vector control system of permanent magnet synchronous motor (PMSM) to address the problem of generating a large number of high-amplitude harmonics at the carrier frequency and its multiplier frequency. Firstly, the root causes of the large number of high-amplitude harmonics at the carrier frequency and its multiplier frequency are analyzed in depth, and the RPWM technique is explained in detail on how to reduce the amplitude of these harmonics effectively. Secondly, to address the problem of insufficient random performance in the traditional RPWM technique, an innovative optimization scheme is proposed, i.e., the introduction of a two-state Markov chain and, based on the immune algorithm for transition probability and random gain, the optimization of two key parameters. Ultimately, through experimental verification, the proposed method significantly improves the spectral distribution of the current waveform compared with the traditional RPWM, which makes the distribution more uniform and effectively reduces the high-amplitude harmonics concentrated near the carrier frequency and its octave frequency, thus enhancing the overall performance of the system. Full article

This paper introduces an enhanced approach for optimizing the flux-weakening performance of a non-salient permanent magnet synchronous machine (PMSM), by incorporating the maximum torque per voltage (MTPV) region into a conventional voltage magnitude feedback control strategy. The MTPV control strategy is initially optimized for steady-state performance by incorporating the effect of resistance, which plays a crucial role in small power motors. To maintain stability and good dynamics in the flux-weakening region, a current command feedback MTPV controller is utilized, as opposed to a voltage command feedback approach. Additionally, to address stability concerns in the MTPV region, a feedback type proportional-integral (PI) MTPV controller is designed and implemented. The stability in both the over-modulation and various flux-weakening regions is further enhanced using a voltage vector modifier (VVM). Therefore, the proposed feedback-based flux-weakening control enhances system steady-state performance, dynamic response, and stability across both linear and over modulation regions under various flux-weakening conditions, making it suitable for general-purpose applications. The effectiveness of the proposed method is validated through experimental results. Full article

Currently, electric machines predominantly rely on costly rare-earth NdFeB magnets, which pose both economic and environmental challenges due to rising demand. This research explores recent advancements in machine topologies and magnetic materials to identify and assess promising solutions to this issue. The study investigates two alternative machine topologies to the conventional permanent magnet synchronous machine (PMSM): the permanent magnet-assisted synchronous reluctance machine (PMaSynRM), which reduces magnet usage, and the wound-field synchronous machine (WFSM), which eliminates magnets entirely. Additionally, the potential of ferrite and recycled NdFeB magnets as substitutes for primary NdFeB magnets is evaluated. Through detailed simulations, the study compares the performance and cost-effectiveness of these solutions against a reference permanent magnet synchronous machine (PMSM). Given their promising performance characteristics and potential to reduce or eliminate the use of rare-earth materials in next-generation electric machines, it is recommended that future research should focus on novel topologies like hybrid-excitation, axial-flux, and switched reluctance machines with an emphasis on manufacturability and also novel magnetic materials such as FeN and MnBi that are currently seeing synthesis challenges. Full article

In the control system of a permanent magnet synchronous motor (PMSM) driven by an inverter, the conventional space vector pulse width modulation (SVPWM) strategy introduces high-frequency current harmonics at the switching frequency and its multiples, resulting in significant high-frequency vibrations during motor operation. To address this issue, a dual-random SVPWM strategy is proposed in this paper, which combines a random switching frequency and random zero-vector to spread the spectrum of high-frequency current harmonics. This approach effectively disperses the high-frequency harmonics concentrated at the switching frequency and its multiples, thereby significantly reducing the motor’s high-frequency vibrations. Furthermore, to overcome the limitations of the traditional linear congruential method in generating random numbers, the Beta distribution is introduced and improved in this study. The particle swarm optimization (PSO) algorithm is employed to optimize the shape parameters of the Beta distribution, to achieve the optimal random number performance. Finally, experimental validation is conducted under various speed conditions. Compared with the conventional SVPWM strategy, the results demonstrate that the proposed dual-random SVPWM strategy exhibits superior suppression of both high-frequency harmonics and high-frequency vibrations. Full article

This paper focuses on the application of digital twins in the field of electric motor fault diagnosis. Firstly, it explains the origin, concept, key technology and application areas of digital twins, compares and analyzes the advantages and disadvantages of digital twin technology and traditional methods in the application of electric motor fault diagnosis, discusses in depth the key technology of digital twins in electric motor fault diagnosis, including data acquisition and processing, digital modeling, data analysis and mining, visualization technology, etc., and enumerates digital twin application examples in the fields of induction motors, permanent magnet synchronous motors, wind turbines and other motor fields. A concept of multi-phase synchronous generator fault diagnosis based on digital twins is given, and challenges and future development directions are discussed. Full article

This article presents the simulation results of synchronization of a permanent magnet synchronous generator (PMSG) dedicated for a hydroelectric plant without power converter devices. The proposed machine design allows to connect a generator to the grid in two different ways. With the first method, the machine is connected to the grid in a similar way as in the case of an electrically excited synchronous generator. The second method is a direct line-start process based on asynchronous torque—similar to asynchronous motor start. Both methods can be used alternately. The advantages of the presented design are elimination of converter devices for starting the PMSG, possibility of use in small and medium hydroelectric power plants, operation with a high efficiency and high power factor in a wide range of generated power, and smaller dimensions in comparison to the generators currently used. The described rotor design allows for the elimination of capacitor batteries for compensation of reactive power drawn by induction generators commonly used in small hydroelectric plants. In addition, due to the high efficiency of the PMSG, high power factor, and appropriately selected design, the starting current during synchronization is smaller than in the case of an induction generator, which means that the structural elements wear out more slowly, and thus, the generator’s service life is increased. In this work, it is shown that PMSG with a rotor cage should have permanent magnets with an increased temperature class in order to avoid demagnetization of the magnets during asynchronous start-up. In addition, manufacturers of such generators should provide the number of start-up cycles from cold and warm states in order to avoid shortening the service life of the machine. The main objective of the article is to present the methods of synchronizing a generator of such a design (a rotor with permanent magnets and a starting cage) and their consequences on the behavior of the machine. The presented design allows synchronization of the generator with the network in two ways. The first method enables synchronization of the generator with the power system by asynchronous start-up, i.e., obtaining a starting torque exceeding the braking torque from the magnets. The second method of synchronization is similar to the method used in electromagnetically excited generators, i.e., before connecting, the rotor is accelerated to synchronous speed by means of a water turbine, and then, the machine is connected to the grid by switching on the circuit breaker. This paper presents electromagnetic phenomena occurring in both cases of synchronization and describes the influence of magnet temperature on physical quantities. Full article

Recent advancements in neural networks (NNs) have underscored their potential for deployment in domains that demand computationally intensive operations, including applications on resource-constrained edge devices. This study investigates the integration of a compact neural network, TinyFC, within the Field-Oriented Control (FOC) framework of a Permanent Magnet Synchronous Motor (PMSM). While proportional–integral (PI) controllers remain a widely adopted choice for FOC due to their simplicity, their performance can degrade significantly under high-frequency speed transitions, where nonlinear dynamics introduce notable inaccuracies. The TinyFC model complements the PI controller by learning the intrinsic dependencies within the control loops and generating corrective signals to alleviate these inaccuracies. To ensure practical implementation, TinyFC underwent extensive optimization procedures, incorporating advanced techniques such as hyperparameter tuning, pruning, and 8-bit quantization. These measures successfully reduced the model’s computational overhead while preserving predictive accuracy. Simulation results demonstrated that embedding TinyFC within the FOC framework substantially reduced overshoot, with the pruned TinyFC entirely eliminating overshoot when integrated into the speed control unit. These findings highlight the feasibility of employing lightweight neural networks for real-time motor control applications, establishing a foundation for more efficient and precise control strategies in edge automotive and industrial systems. Full article
