Search Results (24)

Validation testing of a liquid-based rheostat confirmed its efficacy in mitigating DC arc faults in photovoltaic systems by exceeding critical resistance and voltage–current thresholds. Experimental characterization of electrode immersion depth, separation, and electrolyte concentration identified zinc-galvanized steel to copper in NaHCO₃ as the optimal configuration, achieving a dynamic range factor of 39.10. Further analysis prioritized high minimum resistance (R_MIN) for arc extinction, favouring stable electrode pairs like copper to brass with a 10 g solute concentration. A unified piecewise resistance model validated arc suppression through a load line analysis, demonstrating non-intersection with the Mayr extinction boundary. These findings support scaling the device to a 5 kW, 250 V_DC rating for electric geysers, utilizing 200 mm × 50 mm electrodes and increased electrolyte volume to ensure operational stability. Full article

Series arc faults on the DC side of photovoltaic (PV) systems are a critical hazard that can trigger system fires. Conventional contact-based detection methods suffer from cumbersome installation and high retrofit cost, whereas existing non-contact approaches mostly rely on megahertz-level high-frequency sampling and therefore require expensive radio-frequency instrumentation or high-performance computing platforms. As a result, it remains difficult to simultaneously achieve strong interference immunity and real-time performance on low-cost embedded devices with limited resources. To address this engineering paradox between high-frequency sampling and constrained computational capability, this paper proposes a fully embedded, non-contact arc fault detection system based on a 12–80 kHz low-frequency sub-band selection strategy. By exploiting the physical characteristic of broadband energy elevation induced by arc faults, the proposed strategy avoids dependence on high-bandwidth hardware. Guided by this strategy, a Moebius-topology coaxial shielded loop antenna is employed as the near-field sensor, while an ultra-simplified passive analog front end is constructed directly by using the on-chip programmable gain amplifier and analog-to-digital converter of the microcontroller unit, enabling efficient signal acquisition and fast Fourier transform processing within the target sub-band. To cope with complex background noise in the low-frequency range, an environment-adaptive baseline mechanism based on exponential moving average and exponential absolute deviation is developed for dynamic decoupling. In addition, a lightweight INT8-quantized multilayer perceptron is introduced as a nonlinear auxiliary module, thereby forming a robust hybrid decision architecture with complementary rule-based and artificial intelligence components. Experimental results show that, under the tested household, laboratory, and PV-site conditions, the proposed system achieved an overall detection rate of 97%, while the remaining 3% mainly corresponded to failed ignition or non-sustained arc attempts rather than persistent false triggering during normal monitoring. Full article

DC fault arcs comprise one of the most serious safety hazards in photovoltaic systems, and their danger far exceeds that of AC arcs. DC arcs lack a natural zero-crossing point, and their burning time can last from several seconds to several minutes, which is sufficient to ignite cable lines and surrounding combustibles, causing fires. To explore the characteristics and mechanism of the ignition of external combustibles by DC fault arcs, this paper, based on the theory of magnetohydrodynamics (MHD), constructed a three-dimensional numerical simulation model of a DC fault arc considering the coupling of electromagnetic, thermal, and flow fields. A DC fault arc experimental platform that can simulate the actual working conditions of photovoltaic systems was built to verify the accuracy of the model. Based on this, by integrating the complex pyrolysis model and the combustion reaction model, and selecting cotton fibers as the typical combustible indicator substances, as stipulated in the UL 1699 standard, a coupled simulation model for the ignition of solid combustibles by direct current fault arcs was established. The numerical simulation of the entire ignition process of the arc was realized, and the coupling mechanism of heat transfer, mass transfer, and chemical reactions during the ignition process was revealed. The research results of this paper fill a research gap in the numerical simulation of arc ignition caused by DC faults in photovoltaic systems, clarify the fire ignition risk patterns of DC fault arcs under different working conditions, and provide important theoretical support and technical references for the formulation of arc fire prevention strategies and the optimized design of fault arc protection devices for photovoltaic systems and other DC power systems. Full article

Arc fault is the dominant cause of fire in photovoltaic (PV) systems, making its accurate identification crucial for PV fire prevention. This study investigates the influence of voltage (200, 300, and 400 V) and current (3, 5, 7, 9, and 11 A) on the DC series arc fault characteristics in PV systems obtained through experimental analysis. The results show that voltage variation has a negligible impact on arc fault behavior, while higher current levels substantially increase noise in the arc fault signals. To effectively mitigate noise, this paper proposes a denoising method that combines an improved moss growth optimization algorithm (IMGO) with improved complete ensemble empirical mode decomposition featuring adaptive noise (ICEEMDAN). It is found that the IMGO-ICEEMDAN denoising algorithm can effectively diminish noise in current signals, broaden characteristic frequency bands, and ameliorate arc feature discernibility. Subsequently, an integrated multi-scale spatiotemporal model is developed to extract arc fault features from the denoised signals. The model employs wide deep convolutional neural networks (WDCNNs) and bidirectional long short-term memory (BiLSTM) networks for parallel feature extraction, supplemented by a cross-attention (CA) module to optimize feature integration. The proposed WDCNN-BiLSTM-CA model ultimately achieves a detection accuracy of 99.89%, demonstrating superior detection performance over conventional methods, such as CNN-GRU and 1DCNN-LSTM models. This work provides a reliable framework for arc fault detection and fire risk reduction in PV systems. Full article

In light of the global energy shortage, the development of renewable energy has become increasingly vital. With China’s commitment to achieving “carbon peak and carbon neutrality,” photovoltaic power generation has emerged as a focal point in new energy development. However, DC arc faults in photovoltaic systems pose significant safety hazards, potentially leading to electrical fires. While new detection technologies for DC arc faults in photovoltaic power generation systems have advanced rapidly, the diversity of international standards—such as UL 1699 B, GB/T 39750, IEC 63027, and CGC/GF 175—limits both the construction of experimental platforms and the universality of detection technologies. Current research often relies on a single standard to establish experimental platforms, resulting in detection methods with limited applicability and an inability to validate technological effectiveness fully. To address this issue, this paper conducts an in-depth study of four international and national standards (IEC 63027; UL 1699 B, GB/T 39750, and CGC/GF 175), focusing on the discrepancies in decoupling methods, impedance parameter settings, and experimental circuit topologies, including series and parallel arc scenarios. Through comprehensive comparative analysis of multiple standards, this study integrates major international and domestic specifications to develop a multi-standard compatible experimental platform. The platform is designed to accommodate diverse topologies and parameter requirements, enabling efficient collection of arc test data and performance evaluation of arc fault detection devices. It also provides a standardized foundation for the performance testing and classification of DC arc circuit breakers in photovoltaic power generation systems. Through a comprehensive multi-standard comparative analysis, we systematically analyze the technical differences in photovoltaic DC arc detection. We construct a multi-standard compatible experimental platform by integrating mainstream international and domestic standards. This platform is designed to accommodate various topological structures and parameter requirements, facilitating the collection of arcing experimental data and assessment of the performance of arc fault detection devices. The findings from this research provide both theoretical and experimental foundations for developing unified technical guidelines for photovoltaic DC arc protection. This will aid in standardizing the development of detection devices and enhancing the electrical safety of photovoltaic systems. Ultimately, this work is significant for promoting the safe utilization of new energy within the framework of the dual carbon goals. Moving forward, it is crucial to enhance the generalization abilities of detection algorithms further and foster the integration of standards and industrial applications. Full article

Arc fault detection in photovoltaic systems is crucial, since it may cause incidents like fires and explosions. So far, most existing methods rely on an arc’s local features and do not characterize arc faults globally, which may lead to detection failure in noisy environments. In this paper, a fundamentally different method is proposed that relies on an arc’s global features instead of local ones. The core idea of the method is that the physical mechanisms of the arc fault signals and the normal signals are so different that they are thought to be generated by two independent sources. Based on this insight, independent component analysis (ICA) is introduced to decompose the photovoltaic system’s DC currents. By using ICA, the DC current signals with an arc fault can be decomposed into two independent signals, while the normal signals without an arc fault cannot be decomposed into two such independent signals. This indicates that arc faults can be detected by using the concept of “independence”. Then, the dynamic time warping algorithm was used to determine the independence level of the ICA outputs so as to realize end-to-end arc fault detection. Experimental results showed that our method has better performance than traditional methods in terms of detection accuracy and robustness against environmental disturbances. Full article

Recurrent catastrophic inverter failures significantly undermine the reliability and economic viability of utility-scale photovoltaic (PV) power plants. This paper presents a comprehensive investigation of severe inverter destruction incidents at the Kopli Solar Power Plant, Estonia, by integrating controlled laboratory simulations with extensive field monitoring. Initially, detailed laboratory experiments were conducted to replicate critical DC-side short-circuit scenarios, particularly focusing on negative DC input terminal faults. The results consistently showed these faults rapidly escalating into multi-phase short-circuits and sustained ground-fault arcs due to inadequate internal protection mechanisms, semiconductor breakdown, and delayed relay response. Subsequently, extensive field-based waveform analyses of multiple inverter failure events captured identical fault signatures, thereby conclusively validating laboratory-identified failure mechanisms. Critical vulnerabilities were explicitly identified, including insufficient isolation relay responsiveness, inadequate semiconductor transient ratings, and ineffective internal insulation leading to prolonged arc conditions. Based on the validated findings, the paper proposes targeted inverter design enhancements—particularly advanced DC-side protective schemes, rapid fault-isolation mechanisms, and improved internal insulation practices. Additionally, robust operational and monitoring guidelines are recommended for industry-wide adoption to proactively mitigate future inverter failures. The presented integrated methodological framework and actionable recommendations significantly contribute toward enhancing inverter reliability standards and operational stability within grid-connected photovoltaic installations. Full article

This study investigates the thermal behavior and ignition dynamics of DC series arcs in a lab-scale photovoltaic (PV) system. The impacts of current magnitude, dynamic current variations, and electrode gap on electrode surface temperatures are analyzed, while ignition characteristics of common electrical materials (PC, PVC, XLPO, PPE, etc.) are investigated by analyzing critical time thresholds during the arc-induced combustion. Results show that electrode surface temperatures rise with increased current or larger electrode gaps, driven by the enhanced DC arc energy release. Dynamic current variations (increasing/decreasing) shift the balance between heat accumulation and dissipation, resulting in the nonlinear temperature evolution. Additionally, the peak temperature of the anode is about 50% higher than that of the cathode due to the electron flow-driven heat transfer and particle collisions. Notably, general electrical materials can be ignited successfully by stable DC arcs. The anode can ignite flame-retardant materials within 3 s, while the cathode takes a relatively long time to ignite, approximately 20 to 30 s. Besides, enlarged electrode gaps can induce a mutual reinforcement between arcs and flames, resulting in further stabilized arcs and intensified flames. This highlights potential elevated fire hazards as the connector gap increases due to the DC arc erosion. Full article

With the rapid growth of photovoltaic power generation systems, fire incidents within the system have progressively increased. The lack of thorough studies on the temperature properties of direct current (DC) arc faults has resulted in an unclear ignition mechanism, significantly increasing the fire risk associated with such faults. Hence, this work presents a proposed experimental scheme for detecting photovoltaic DC series arc faults (SAFs) and the corresponding detection standards. Additionally, the temperature characteristics of the DC arc fault are further analyzed. The magnetohydrodynamic (MHD) arc fault simulation model is developed to investigate the temperature-related aspects of photovoltaic DC arc faults. Finally, our experimental validation confirms the precision of the model in simulating arc temperature. It is verified that the research presented in this paper can provide a good explanation for the rise time of DC arc temperature and the characteristic distribution of arc distance. This study elucidates the impact mechanism of line current, power supply voltage, and arc gap size on arc temperature in a photovoltaic system. Additionally, it proposes an evaluation method for assessing the arc fault ignition risk level. This method is essential for safeguarding against arc fault ignition risk in photovoltaic DC series cells. Full article

The direct current (DC) cable serves as the link for energy output in photovoltaic (PV) systems. Its degradation can cause arcs, which easily lead to fire accidents. Locating arc faults, however, is challenging. To cope with it, this paper proposes an arc location method based on time reversal. The method has been tried to locate system fault. However, its application in the arc fault location of photovoltaic systems is seldom discussed and needs further research. For this purpose, the voltage waveforms of an arc fault collected at one of the cable ends is reversed. This transformation derives a symmetrical arc fault signal. Afterwards, the reversed signal is injected back into the cable to trace the fault location, which is a symmetrical process of the arc fault signal travelling from its origin to the detection point. Utilizing the energy-focusing characteristics of time reversal, the position with the highest energy in the derived waveform corresponds to the actual fault location. To verify the proposed method, a DC arc fault test is performed to obtain the wave characteristics. The Paukert arc model is chosen based on the tested result. A PV system containing a DC cable with an arc fault is simulated with Simulink with the affecting factors, i.e., grounded resistance, cable length, fault location and sampling frequency. The simulated results demonstrate that the localization error is within 5% in the worst case. Full article

This work presents a sensorless brushless DC motor (BLDCM) drive control, optimized for solar photovoltaic (PV)- and battery-fed light electric vehicles (LEVs). A back-electromotive force (EMF) observer integrated with an enhanced quadrature-phase-locked-loop (QPLL) structure is proposed for accurate rotor position estimation, addressing limitations of existing control methods at low speeds and under dynamic conditions. The study replaces the conventional arc-tangent technique with a QPLL-based approach, eliminating low-pass filters to enhance system adaptability and reduce delays. The experimental results demonstrate a significant reduction in commutation error, with a nearly flat value at 0 degrees during steady-state and less than 8 degrees under dynamic conditions. Furthermore, the performance of a modified single-ended primary-inductor converter (SEPIC) for maximum power point tracking (MPPT) in solar-powered LEVs is verified, minimizing current ripple and ensuring smooth motor operation. The system also incorporates a regenerative braking mechanism, extending the vehicle’s range by efficiently recovering kinetic energy through the battery with 30.60% efficiency. The improved performance of the proposed method and system over conventional approaches contributes to the advancement of efficient and sustainable solar-powered BLDC motor-based EV technologies. Full article

The ecofriendly tin selenide (SnSe) is expected to find multiple applications in optoelectronic, photovoltaic, and thermoelectric systems. This work is focused on the thermoelectric properties of thin films. SnSe single crystals exhibit excellent thermoelectric properties, but it is not so in the case of polycrystalline bulk materials. The investigations were motivated by the fact that nanostructuring may lead to an improvement in thermoelectric efficiency, which is evaluated through a dimensionless figure of merit, ZT = S² σ T/λ, where S is the Seebeck coefficient (V/K), σ is the electrical conductivity (S/m), λ is the thermal conductivity (W/mK), and T is the absolute temperature (K). The main objective of this work was to obtain SnSe films via magnetron sputtering of a single target. Instead of common radiofrequency (RF) magnetron sputtering with a high voltage alternating current (AC) power source, a modified direct current (DC) power supply was employed. This technique in the classical version is not suitable for sputtering targets with relatively low thermal and electrical conductivity, such as SnSe. The proposed solution enabled stable sputtering of this target without detrimental cracking and arcing and resulted in high-quality polycrystalline SnSe films with unprecedented high values of ZT equal to 0.5 at a relatively low temperature of 530 K. All parameters included in ZT were measured in one setup, i.e., Linseis Thin Film Analyzer (TFA). The SnSe films were deposited at sputtering powers of 120, 140, and 170 W. They had the same orthorhombic structure, as determined by X-ray diffraction (XRD), but the thickness and microstructure examined by scanning electron microscopy (SEM) were dependent on the sputtering power. It was demonstrated that thermoelectric efficiency improved with increasing sputtering power and stable values were attained after two heating–cooling cycles. This research additionally provides further insights into the DC sputtering process and opens up new possibilities for magnetron sputtering technology. Full article

This paper presents a review of research progress on photovoltaic direct current arc detection based on VOSviewer bibliometric analysis. This study begins by introducing the basic concept and hazards of photovoltaic DC arcing faults, followed by a summary of commonly used arc detection techniques. Utilizing VOSviewer, the relevant literature is subjected to clustering and visualization analysis, offering insights into research hotspots, trends, and interconnections among different fields. Based on the bibliometric analysis method of VOSviewer software, this paper analyzes the articles published in the last 10 years (2014–2023) on photovoltaic DC fault diagnosis. We analyzed the specific characteristics of 2195 articles on arc failures, including year of publication, author, institution, country, references, and keywords. This study reveals the development trend, global cooperation model, basic knowledge, research hotspots, and emerging frontier of PV DC arc. Future research directions and development trends for photovoltaic DC arc detection are proposed which provides valuable references for further studies and applications in this domain. This comprehensive analysis indicates that photovoltaic DC arc detection technology is expected to find broader applications and greater promotion in the future. Full article

With the rapid growth of the photovoltaic industry, fire incidents in photovoltaic systems are becoming increasingly concerning as they pose a serious threat to their normal operation. Research findings indicate that direct current (DC) fault arcs are the primary cause of these fires. DC arcs are characterized by high temperature, intense heat, and short duration, and they lack zero crossing or periodicity features. Detecting DC fault arcs in intricate photovoltaic systems is challenging. Hence, researching DC fault arcs in photovoltaic systems is of crucial significance. This paper discusses the application of mathematical morphology for detecting DC fault arcs. The system utilizes a multi-stage mathematical morphology filter, and experimental results have shown its effective extraction of fault arc features. Subsequently, we propose a method for detecting DC fault arcs in photovoltaic systems using a cyclic neural network, which is well-suited for time series processing tasks. By combining multiple features extracted from experiments, we trained the neural network and achieved high accuracy. This experiment demonstrates that our recurrent neural network (RNN) based scheme for DC fault arc recognition has significant reference value and implications for future research. The ROC curve on the test set approaches 1 from the initial state, and the accuracy on the test set remains at 98.24%, indicating the strong robustness of the proposed model. Full article

The DC arc is the main cause of fire in photovoltaic (PV) systems. This is due to the fact that the DC arc has no zero-crossing point and is prone to stable combustion. Failure to detect it in a timely manner can seriously endanger the PV system. This study analyzes the influences of the series arc and the maximum power point tracking (MPPT) algorithm on the PV output characteristics based on the PV equivalent circuit module. The PV voltage and current variation characteristics are obtained when the series arc occurs. The findings indicate that the input voltage of the converter remains unchanged due to the MPPT algorithm before and after the series arc occurs. Furthermore, the PV faulty string output current will drastically decrease when the series arc fault occurs. On this basis, a series arc detection method based on the current change is proposed, suppressing the combustion of the series arc by increasing the target voltage of the MPPT algorithm. The experimental results show that the proposed method can effectively detect and extinguish the series arc in the PV system within 0.6 s. Compared to the other methods, the proposed method can be integrated into the PV system without additional hardware. Full article
