With the growing power demand of small electronic devices worldwide, piezoelectric energy harvesting has become a promising solution for low-power energy generation. The primary objective of this study is to experimentally assess the energy harvesting capabilities of a commercially available piezoelectric sensor. The output performance of the piezoelectric harvester is characterized, with particular focus on the generated output voltage and output power, under different resistive loads and various operating conditions, including acceleration amplitude and frequency of mechanical excitation. Full article

Incorporating energy generated from regular human movement into wearable electronics offers a promising alternative to conventional batteries, enabling devices to power themselves by harvesting energy from motion and the surrounding environment. Ambient energy harvesting provides a pathway toward limitless, self-sustaining power and supports the development of cleaner, smarter wearable systems. Among various approaches, integrating hybrid mechanisms into footwear represents a transformative solution for sustainable power generation. In this work, a piezoelectric generator (PEG), an electromagnetic generator (EMG), and a triboelectric generator (TEG) were hybridized within a single architecture to harvest biomechanical energy from walking, jogging, and running. The device incorporates pressure-sensitive Lead Zirconate Titanate (PZT) sheets, a spiral spring with dual neodymium (NdFeB) magnets with wound copper coils, and a nickel foam with polytetrafluoroethylene (PTFE) for triboelectricity operating in contact–separation mode. A dedicated energy-management circuit comprising independent rectification, DC bus energy aggregation, supercapacitor storage, and voltage regulation was implemented to efficiently utilize the harvested energy. The system was optimized through simulation using SOLIDWORKS 2023 and validated experimentally by using LabVIEW-NI myRIO FPGA system and treadmill. The proposed hybrid device achieved an exceptional peak output power of 58 mW and a voltage of 7.4 V, enough to charge low-power wearable devices, significantly surpassing the performance of most reported standalone and hybrid insole energy harvesters. These results demonstrate the effectiveness of multimodal integration in broadening operational bandwidth, increasing energy density, and enhancing compatibility with wearable applications. Piezoelectric, Electromagnetic and Triboelectric Insole Energy Harvesting (PET-IEH) establishes a new benchmark in biomechanical energy harvesting and paves the way for next-generation self-powered and sustainable wearable electronics. Full article

Vibration-based piezoelectric energy harvesting provides a potential power source for low-consumption devices; however, its prediction requires a consistent representation of localized structural properties and experimentally identified modal behavior. This study presents the structural and modal qualification of an analytical electromechanical model for a 6061-T6 aluminum cantilever beam carrying a finite one-sided PZT-5J piezoelectric patch, with unequal beam and patch widths, under base excitation. The specific contribution is the traceable integration of local neutral-axis relocation, spatially varying mass and flexural rigidity, a finite-patch indicator function, $d_{31}$ electromechanical coupling, multimodal projection, and mode-specific reduced-order equations. Two beam lengths, $275$ and $250 \mathrm{m}\mathrm{m}$, were investigated using broadband shaker excitation, accelerometry, and scanning laser vibrometry. The measured first and second bending frequencies were $16.56$ and $110.31 \mathrm{H}\mathrm{z}$ for the $275 \mathrm{m}\mathrm{m}$ beam and $19.14$ and $125.00 \mathrm{H}\mathrm{z}$ for the $250 \mathrm{m}\mathrm{m}$ beam. Experimental damping ratios obtained from the frequency-response functions ranged from $6.54\times {10}^{-3}$ to $1.55\times {10}^{-2}$. The analytical formulation reproduced the increase in modal frequencies produced by reducing the beam length and captured the measured transverse mode-shape trends. Experimentally identified frequencies, base accelerations, and damping ratios were subsequently introduced into the reduced model to obtain experimentally parameterized model outputs. The largest calculated peak voltage and estimated average electrical power were $155.99 \mathrm{m}\mathrm{V}$ and $1.22 \mathsf{\mu }\mathrm{W}$, respectively, for the first mode of the $275 \mathrm{m}\mathrm{m}$ beam across a reference $10 \mathrm{k}\mathsf{\Omega }$ resistive load. The reported qualification is restricted to the structural and modal response of the two tested configurations; the electrical quantities are calculated outputs rather than independent electrical measurements. Full article

Piezoelectric energy harvesters, characterised by design simplicity, robustness, high energy density and conversion efficiency, as well as scalability, are a viable choice for transducing ubiquitous kinetic energy in a reliable and stable electrical energy source aimed at powering IoT and other prospective applications of autonomous sensors. The performances of this class of harvesting devices can be considerably enhanced by optimising their design configurations. An overview of several optimised piezoelectric harvesters’ designs, with the respective modelling and experimental validation procedures, is provided in this work. In this regard, special attention is dedicated to innovative topologies of the considered devices, as well as to excitation mechanisms leading to considerably ameliorated output power levels. Possible applications in wearables for biomedical applications, structural health monitoring in aircraft, open-field applications (either for environmental monitoring of river flows or rainfall-actuated devices), as well as in automobile tyre pressure monitoring, are given as elaborated examples of conceivable sensing nodes. A basic overview of the aspects related to the conforming power management electronics and an outlook on future research directions are also given. Full article

This study investigates active geometric modulation in a variable-length pendulum energy harvester combining radial electromagnetic, rotational electromagnetic, and piezoelectric transduction. A reciprocal seven-state electromechanical model is formulated and analysed using phase-aligned continuation, transverse Floquet stability, Lyapunov diagnostics, physical load variation, and paired control-on/control-off energy accounting. A minimal threshold-based shift of the radial spring equilibrium serves to reveal the branch-support mechanism rather than to provide a final control strategy. The results show that an established finite-amplitude branch may persist below the local instability boundary of the inactive response, while piezoelectric loading can modify this boundary through electromechanical back-action. All three transduction channels contribute to gross electrical output, and physical load matching increases that output. Nevertheless, the continuous modulation remains energetically unfavourable after actuator, power-conditioning, and auxiliary demands are included and does not robustly retain the branch under the tested nonstationary excitations. The results therefore define requirements for phase-aware, adaptive, latching, or regenerative implementations with substantially lower actuation work. Full article

This study presents a full polymer piezoelectric flextensional energy harvester (FPPFEH) comprising a single-layer poly(vinylidene fluoride) (PVDF) film bonded to a 3D-printed polylactic acid (PLA) flextensional frame. For an arm inclination angle of $\theta =10°$, the free-body model gives a theoretical geometric force-amplification factor of $M_{\mathrm{F}}=\cot \theta \approx 5.67$; this value represents an ideal upper bound and was not independently validated by local force or strain measurements. During assembly, the film was tensioned only to remove visible slack and maintain a flat configuration. No intentional pretension was applied, and any residual tension was not measured. Off-resonance force-controlled tests showed that the generated voltage was approximately proportional to the dynamic input force and nearly independent of frequency after accounting for attenuation caused by the finite measurement-input impedance. The ideal quasi-static model overpredicted the absolute voltage by a nearly constant factor across the tested force range. This offset is consistent with a lumped reduction associated with frame compliance and the in-plane anisotropy of the PVDF film, neither of which was independently measured. At $30\mathrm{Hz}$ and $12.32{\mathrm{N}}_{\mathrm{rms}}$, the rectified output charged a $6600\mathsf{\mu }\mathrm{F}$ supercapacitor to $2.10\mathrm{V}$ in $14\min$, corresponding to $14.55\mathrm{mJ}$ of stored energy. Under base-acceleration excitation from $0.05$ g to 1 g, the voltage peak occurred between $112.88$ and $116.49\mathrm{Hz}$, close to the electrical anti-resonance near $114\mathrm{Hz}$, and reached $12.11{\mathrm{V}}_{\mathrm{peak}}$ at 1 g. Near resonance, the highest measured power among the tested resistive loads occurred between 150 and $200\mathrm{k}\Omega$; however, the exact optimal resistance could not be resolved from the four tested loads. These results demonstrate off-resonance force-driven energy storage and resonance-mode vibration energy harvesting within the tested conditions. Full article

This paper proposes a sensorless current estimation method for piezoelectric energy harvesting (PEH) systems using a first-order Takagi–Sugeno fuzzy system. Unlike invasive current sensing, the proposed estimator uses only non-invasive measurements: output voltage $V_O$, its derivative ${\dot{V}}_O$, and load resistance $R_L$. The fuzzy rules are initialized directly from the physical equivalent circuit parameters and trained via the ANFIS on a large-scale dataset (78 million samples). The proposed model achieves a mean coefficient of determination $R^2=0.9999$ (95% CI: [0.99989, 0.99991]), root mean square error $\mathrm{RMSE}=3.12\times {10}^{-8}$ A, mean absolute percentage error MAPE = 2.51% (95% CI: [1.98, 3.04]%), and fitness FIT = 98.98%—outperforming multiple linear regression $(R^2=0.9738$ and MAPE = 116.25%) and a shallow neural network with 211 parameters $(R^2=0.9991$ and MAPE = 13.85%) despite having only 170 trainable parameters. Unlike black-box neural networks, the fuzzy model provides interpretable rules whose consequent parameters map directly to physical quantities (effective capacitance $C_p^{\left(\mathrm{eff}\right)}$ and leakage conductance $1/R_p^{\left(\mathrm{eff}\right)}$). The low computational footprint (170 parameters, <5 μs inference, and ≈1.4 kB of memory) makes it suitable for real-time deployment on low-power microcontrollers. These results demonstrate the viability of the proposed approach under controlled laboratory conditions for the single, series, and parallel PEH configurations considered. This work establishes that physically informed fuzzy modeling is a viable, interpretable, and efficient alternative to deep learning for sensorless monitoring in low-power energy harvesting systems. Full article

This paper develops a reduced-order electromechanical model for piezoelectric energy harvesting from a beam traversed by a moving mass. The beam is described by the Euler–Bernoulli theory, and the coupled equations of motion are derived through modal expansion combined with the linear piezoelectric constitutive relations. Unlike most existing formulations, the model accounts for non-uniform transit by including moving-mass acceleration, accommodates an arbitrary number of piezoelectric patches distributed along the span, and incorporates von Kármán strain–displacement relations. So, moderately large deflections and mid-plane stretching as well as various boundary conditions may be investigated within the same framework. The resulting coupled nonlinear ordinary differential equations are integrated in time using a numerical solver. On the other hand, predictions of midpoint deflection, output voltage, and harvested power are validated against the COMSOL Multiphysics Finite element model. The experimental setup has been established, and a dedicated laboratory experiment provides additional verification under controlled conditions. Parametric analyses investigating the individual and combined effects of the mass ratio, velocity ratio, acceleration profile, patch length, patch position, number of patches, and external load resistance are elaborated. Distributed multi-patch configurations are shown to recover more energy than a single-centered patch once higher modes contribute appreciably to the response. Design charts relating the governing parameters to the harvested power are constructed for each set of support conditions. These results are intended to assist the preliminary sizing and placement of piezoelectric transducers on some practical energy harvesting applications. Full article

This article reviews the reactive magnetron sputtering of piezoelectric Aluminium Nitride (AlN) thin films, with a focus on process parameter optimisation and system-level deposition challenges. AlN is a leading material for MEMS and RF applications owing to its c-axis (002) orientation, high acoustic velocity, wide bandgap (∼6.2 eV), and CMOS compatibility. We review the influence of sputtering power, nitrogen flow ratio, substrate temperature, and target-to-substrate distance on crystallographic quality and document practical hardware challenges, including vacuum leakage, grounding faults, target erosion, and mass flow controller drift, that critically affect reproducibility but are systematically underreported in the literature. A perspective is provided on emerging application domains where optimised AlN films address current performance gaps, including next-generation RF/telecom systems towards 6G and Future Networks, harsh environment sensing and actuation, biomedical ultrasound, and IoT energy harvesting. The complementarity between AlN and Silicon Carbide (SiC) is discussed for high-temperature, high-power, and radiation-hard MEMS, where AlN/SiC heterostructures combine the piezoelectric activity of AlN with the mechanical and chemical robustness of SiC. It also incorporates a discussion of dopant- and heteroepitaxy-based AlN engineering, AlN deposition on a wider range of substrates, the role of seed and electrode underlayers, and pulsed-DC sputtering as a third power supply mode alongside RF and conventional DC. Full article

Pyropiezoelectric energy harvesting has the potential to utilize both environmental vibrations and time-dependent temperature changes to increase the amount of energy harvested compared to harvesting from only one of the two sources. So far, the investigation of such hybrid energy harvesting approaches has mainly been experimental. This makes it difficult to distinguish between their individual physical effects and complicates the optimization of such harvesters. This work presents a numerical framework for solving transient coupled pyropiezoelectric equations using the finite element method. The numerical method can be applied to simulate hybrid energy harvesters by taking into account external electrical circuits. The numerical simulations enable a targeted analysis of the contributions of mechanical, electrical and thermal effects to the harvested energy. This is illustrated by various numerical examples, such as a simple piezoelectric cuboid, a unimorph, a bimorph and a bimetallic beam with a piezoelectric patch. These are subjected to oscillating deformations and/or temperature changes. The simulations calculate the harvested energy resulting from the individual physical effects, depending on the excitation frequency, the external resistance, and the geometric configuration of the harvester. For a bimetallic beam with a piezoelectric patch, which is used as a low frequency hybrid energy harvester, a geometric optimization based on the simulation results showed a possible increase in the harvested energy of up to 386% under idealized circuit conditions compared to the initial design from the literature. Full article

Multistable energy harvesters have attracted considerable attention due to their shallow potential wells, which facilitate low-energy inter-well oscillations. Although bistable or tristable configurations can be realized using combined magnets or springs, two critical challenges remain: (i) the difficulty in obtaining a higher number of stable equilibrium points and (ii) the inability to arbitrarily prescribe the coordinates of these equilibrium points. To address these issues, this paper proposes a piezoelectric cantilever beam-based multistable energy harvester that allows programmable specification of both the number and the positions of equilibrium points. As demonstrations, a tristable and a pentastable energy harvester with user-defined equilibrium coordinates are designed, and their energy harvesting performances are systematically investigated. Simulation and experimental results show that under an excitation acceleration of 0.1 g, both harvesters can only perform intra-well motion, exhibiting softening nonlinearity. When the excitation acceleration increases to 0.2 g, the pentastable harvester successfully overcomes the maximum potential barrier to achieve inter-well oscillation, displaying hardening nonlinearity and significantly broadening the operational bandwidth, while the tristable harvester remains confined to intra-well motion. At an excitation acceleration of 0.4 g, both harvesters can achieve inter-well oscillation, but the pentastable harvester possesses a wider operational bandwidth and a lower starting frequency for energy harvesting. The proposed method enables the design of multistable vibration energy harvesters without increasing structural complexity with the number of equilibrium points, which is of great significance for optimizing multistable vibration energy harvesters. Full article

Vibration energy technology holds promise for self-powered miniature wireless sensor devices in underground coal mines. This study proposes a magnetically coupled bistable composite-beam wind energy harvester (BCBWEH) to enhance the response threshold for harvesting weak ambient wind energy. A nonlinear magnetic model based on magnetic dipoles is established, and the system’s dynamic equations are formulated using the lumped parameter method. Numerical simulations analyze the effect of magnetic spacing on static bifurcation, and discuss the influences of initial static position, wind excitation, and magnetic moment on the system’s dynamic behavior; experimental results validate the accuracy of the numerical predictions. By adjusting the magnetic spacing under the same level of excitation, the system’s motion can transition from single-well oscillation to efficient inter-well vibration. When the initial position lies closer to the shallower potential well, relatively small wind excitation can trigger large-amplitude inter-well vibrations, thereby increasing output power. This study offers guidance for optimizing structural configurations and tuning design parameters of piezoelectric energy harvesters based on composite-beam architectures. Full article

Piezoelectric energy harvesters (PEHs) have emerged as a promising solution for self-powered small-scale electronic systems; however, their narrow operational bandwidth limits performance under varying excitation conditions commonly found in ambient environments. To address this limitation, this study proposes a passive multi-chamber proof-mass design containing internal free-moving masses to enhance the frequency bandwidth of a PEH through nonlinear dynamics. Multiple proof-mass models were designed and experimentally evaluated using tungsten and Teflon spherical movable masses under 0.5 g and 1 g excitation levels. Design alterations include varying the number of chambers, which in essence reduces the maximum lateral displacement of the movable mass. Baseline characterization was first conducted using empty proof-mass configurations, followed by fixed-mass and free-mass testing to isolate the effects of dynamic mass repositioning. The results demonstrate that baseline and fixed-mass configurations remained limited to bandwidths in the 5–8 Hz range. In contrast, free-mass configurations produced significant bandwidth enhancement across all models. The largest bandwidth increase consisted of a multiple-chamber proof-mass design, which resulted in a bandwidth of 72 Hz using tungsten rolling spheres at 1 g excitation, corresponding to a 1400% increase relative to the baseline conditions. Full article

Piezoelectric cantilever beams are among the most popular vibration energy harvesting devices. Maximization of the spatial distribution of axial strain along this beam (objective function) increases harvesting efficiency. In vibro-impact systems, mechanical contact can excite higher-order vibration modes, making the second eigenfrequency particularly relevant for energy harvesting under such nonlinear operating conditions. Therefore, the harvester geometry should be designed to maximize the harvested energy associated with this mode. In many practical applications, cantilever-based harvesters are subjected to complex and broadband excitation conditions, where multiple vibration modes, including the second eigenfrequency, contribute to the overall response. Therefore, optimization at the second eigenfrequency is essential for improving energy harvesting performance under realistic operating conditions. In this study, to maximize axial strain, a thickness shape optimal design is proposed, and a finite element-based optimization scheme is constructed to maximize harvesting efficiency. Optimization is performed subject to a fixed second eigenfrequency of the cantilever beam, using the eigenmode equation as the state equation in the optimization procedure. The optimized shape for maximal strain integral at the second bending resonance is determined. Experimental results validate the findings of the optimization, showing an increase in strain for the optimized-shaped beam compared to a uniform-thickness beam with the same eigenfrequency. It should be noted that experimental validation is subject to certain limitations, including manufacturing precision and environmental influences. The manufacturing of specimens can only be achieved within a limited precision, resulting in deviations from the ideal optimized geometry. Additionally, the experimental environment may influence the measured response, and simplified boundary conditions can introduce discrepancies between numerical and experimental results. Full article

To exploit ultra-low power logic and architectural design techniques for bio-sensors in the human body, wireless ultrasonic techniques have emerged as a strong candidate for intra-body power transmission, thanks to lower medium attenuation and higher permitted safe intensity levels. When sub-100 $\mathsf{\mu }$m dimensions are considered for the bio-sensor, most devices struggle to guarantee a suitable voltage and power for digital electronics due to additional scaling requirements. This study investigates three alternative piezoelectric micromachined ultrasonic transducers in aluminum nitride doped with scandium, as reported in the literature, operating in the range 1–10 MHz. Their respective advantages and limitations with regard to energy harvesting and signal transmission performance are analyzed. It is shown that devices with footprints of less than 100 × 100 $\mathsf{\mu }$m² can achieve voltage outputs of over 150 mV and average power greater than 100 nW. Full article
