The uneven load distribution between the planets in planetary gear trains has found multiple solutions including high manufacturing precision, targeted compliance or kinematic mobility of the components of the gear train. This paper presents an experimental investigation of the influence of three different load-equalizing devices on planetary gears’ pin loads in a planetary gear train with three planets. Two of the equalizing devices are designed to increase the radial resilience of the planets, and the third one increases the radial and tangential resilience of the sun gear. Using fast Fourier transform (FFT), the pins’ bending stresses are presented as a function of time and the gear wheels’ rotational frequency. For the experiments, a mechanical closed-loop test rig, designed at the Technical University of Sofia, was used. Full article

To collect the energy generated by rotational motion in the natural environment, a piezoelectric electromagnetic hybrid energy harvester (HEH) based on a planetary gear system is proposed. The harvester combines piezoelectric and electromagnetic effects and is mainly used for collecting low-frequency rotational energy. The HEH has a compact structure and contains four sets of piezoelectric energy harvesters (PEHs) and electromagnetic energy harvesters (EMHs) inside. The working principle of the energy harvester is analyzed, its theoretical model is established, and a simulation analysis is conducted. To verify the effectiveness of the design, an experimental device is constructed. The results indicate that the HEH can generate an average output power of 250 mW under eight magnets and an external excitation frequency of 7 Hz. In actual power supply testing, the HEH can light up 60 LEDs and provide stable power supply for the temperature–humidity meter. Full article

The paper provides an analysis of the energy efficiency of the swing drive system of hydraulic excavators, which integrally includes a hydraulic motor and a planetary reducer. The indicator of the drive’s energy efficiency is determined based on the efficiency of the hydraulic motor and the planetary reducer. The efficiency of the hydraulic motor is defined as a function of the specific flow, pressure, and the number of revolutions of the hydraulic motor. The efficiency of the reducer is determined using structural analysis of planetary gearboxes and the moment method. As an example, the results of a comparative analysis of the energy efficiency of the swing drive of a tracked hydraulic excavator, weighing 16,000 kg and having a bucket volume of 0.6 m³, are presented. From the set of possible generated variant solutions of the drive, obtained through the synthesis process based on the required torque and platform rotation speed, two extreme drive variants were selected for the analysis. In the first configuration, a hydraulic motor characterized by a low specific flow is combined with a three-stage reduction gear featuring a higher overall transmission ratio, whereas the second configuration integrates a high-specific-flow hydraulic motor with a two-stage reduction gear of a lower transmission ratio. The obtained results of the comparative analysis of the drive’s energy efficiency are presented depending on the change in the required torque and the rotational speed of the platform. Full article

This paper introduces an experimental approach to study the distribution of power losses in an oil jet-lubricated planetary gear set, with the aim of increasing the efficiency of these gearboxes. A thermal model is developed to estimate power losses associated with temperature distribution. This model is applied to analyze experimental data collected from a dedicated test setup. Different configurations are studied to progressively validate the thermal network. In this paper, only a configuration composed of a rotating ring gear and a fixed planet carrier is studied. This configuration enables the validation of a thermal network developed from a basic configuration where power loss sources are not numerous. The study reveals that, for this configuration, load-independent power losses are primarily attributed to hydrodynamic losses in the bearings, while the gear windage effects are of second order. The power losses are then compared to those generated by the same planetary gear set but using a rotating planet carrier. The comparison shows that the configuration composed of the rotating ring gear and fixed planet carrier produces less power loss than the other configuration. Full article

Detecting gear rim fatigue cracks using vibration signal analysis is often a challenging task, which typically requires a series of signal processing steps to detect and enhance fault features. This task becomes even harder in helicopter planetary gearboxes due to the complex interactions between different gear sets and the presence of vibration from sources other than the planetary gear set. In this paper, we propose an effectual processing algorithm to isolate and enhance rim crack features and to trend crack growth in planet gears. The algorithm is based on using cepstrum editing (or liftering) of the hunting-tooth synchronous averaged signals (angular domain) to extract harmonics and sidebands of the planet gears and low-pass filtering and minimum entropy deconvolution (MED) to enhance extracted fault features. The algorithm has been successfully applied to a vibration dataset collected from a planet gear rim crack propagation test undertaken in the Helicopter Transmission Test Facility (HTTF) at DSTG Melbourne. In this test, a seeded notch generated by an electric discharge machine (EDM) was used to initiate a fatigue crack that propagated through the gear rim body over 94 load cycles. The proposed algorithm demonstrated a successful isolation of incipient fault features and provided a reliable trending capability to monitor crack progression. Results of a comparative analysis showed that the proposed algorithm outperformed the traditional signal processing approach. Full article

Due to complex environmental factors, the gear transmission systems of wind turbines are continuously affected by large torque load excitation with periodic and random properties. This paper shares the load-sharing and dynamic characteristics of a herringbone planetary gear system applied in a wind turbine. The gear dynamic model is established using a typical lumped parameter method, in which the nonlinear transmission errors of the gear pairs and left and right-side coupling stiffness of the herringbone gears are included. With the help of the blade element momentum theory, the precise calculation of the hub load of the wind turbine, which is the external excitation of the gear system, is implemented, in which the wind shear, tower shadow, turbulent effect, and tip loss correction are taken into consideration. The nonlinear dynamic characteristics of the system are obtained using the Runge-Kutta method and then discussed. The results show that the turbulent effect plays a major role in the impact on the load-sharing characteristics, and a reasonable set of the support stiffness of rotational components can improve the load-sharing characteristics of the system. The purpose of this research is to provide some useful references in numerical modelling and methods for designers and researchers of wind turbine transmission systems. Full article

The feature extraction problem of coupled vibration signals with multiple fault modes of planetary gears has not been solved effectively. At present, kernel principal component analysis (KPCA) is usually used to solve nonlinear feature extraction problems, but the kernel function selection and its blind parameter setting greatly affect the performance of the algorithm. For the optimization of the kernel parameters, it is very urgent to study the theoretical modeling to improve the performance of kernel principal component analysis. Aiming at the deficiency of kernel principal component analysis using the single-kernel function for the nonlinear mapping of feature extraction, a dual-kernel function based on the flexible linear combination of a radial basis kernel function and polynomial kernel function is proposed. In order to increase the scientificity of setting the kernel parameters and the flexible weight coefficient, a mathematical model for dual-kernel parameter optimization was constructed based on a Fisher criterion discriminant analysis. In addition, this paper puts forward a swarm intelligent fusion algorithm to increase this method’s advantages for optimization problems, involving the shuffled frog leaping algorithm combined with particle swarm optimization (SFLA-PSO). The new fusion algorithm was applied to optimize the kernel parameters to improve the performance of KPCA nonlinear mapping. The optimized dual-kernel function KPCA (DKKPCA) was applied to the feature extraction of planetary gear wear damage, and had a good identification effect on the fuzzy damage boundary of the planetary gearbox. The conclusion is that the DKKPCA optimized by the SFLA-PSO swarm intelligent fusion algorithm not only effectively improves the performance of feature extraction, but also enables the adaptive selection of parameters for the dual-kernel function and the adjustment of weights for the basic kernel function through a certain degree of optimization; so, this method has great potential for practical use. Full article

The trend in the global automotive industry is moving towards electric vehicles that do not emit exhaust gases and use eco-friendly fuel. Electric vehicles are more eco-friendly compared to internal combustion engine vehicles, as they emit less carbon dioxide and pollutants. Research and development are actively underway to produce new electric vehicle models in the rapidly growing electric car market. In this study, a 2-speed transmission for electric vehicles, applicable to 300 Nm-class electric cars, has been developed. The 2-speed transmission structure enables efficient energy use and utilizes a planetary gear set and wet multi-plate clutch, which are effective in the power transmission process. The 2-speed transmission developed through the research results of this paper has a compact structure optimized for electric vehicles. The design feasibility of the transmission was verified through performance tests of the prototype, contributing to fuel efficiency improvement and environmental enhancement. Full article

Climate change and air pollution are two significant challenges facing our society and represent a major driver for new developments in the transport sector. As a consequence, automotive manufacturers have focused on the electrification of vehicle propulsion systems and offer a wide range of hybrid and full-electric vehicles in different classes. However, in the world’s most densely populated metropolitan areas, small and lightweight vehicles are key for the mobility of millions. Traditionally these vehicles have provided cost-effective transportation which is difficult to preserve with vehicle electrification. Many of these light vehicles, such as scooters and all-terrain vehicles, use internal combustion engines in combination with a continuously variable rubber belt transmission which provides a simple, comfortable and cost-effective transmission technology but with poor efficiency and high maintenance costs. In this contribution, a novel full hybrid powertrain concept is proposed that offers a similar driving experience to conventional continuously variable transmissions while providing significantly improved performance and fuel economy combined with low system complexity. In its basic configuration, the hybrid powertrain can operate without active actuators and even with mechanical throttle control of the internal combustion engine. This minimalist approach reduces system costs and helps to create a competitive solution for price-sensitive markets. The hybrid system is based on a planetary gear set that combines the internal combustion engine and an electric motor. It is complemented by a centrifugal clutch and one-way clutch, resulting in different operating modes for low and high speeds as well as for electric driving. This paper describes the mechanical design and control approach of the proposed hybrid powertrain layout. In order to evaluate the basic functionalities, a prototype vehicle was built and tested. This contribution shows the integration of the hybrid powertrain concept in a prototype vehicle and proves the fulfilment of all required full hybrid functionalities. Full article

The multi-objective optimization (MOO) of a planetary gearbox is a challenging optimization problem, which includes simultaneous minimization of a number of conflicting objectives including gearbox volume, contact ratio, power loss, etc., and at the same time satisfying a number of complex constraints. This paper addresses this complex problem by proposing a modified hybrid algorithm, named Multi-objective Hybrid Butterfly Optimization and Particle Swarm Optimization Algorithm (HMOBPSO), which integrates PSO and Particle Swarm Optimization (BOA) algorithms with the aim to improve the performance with respect to the considered problem. The proposed approach solves the non-convex Pareto set and provides vital insights for lowering gear weight and efficiency and avoiding early failure. The experimental analysis employs numerical simulations to determine the Pareto optimal solutions to the formulated MOO problem. The results show that the proposed method offers significant improvements in terms of gearbox size, efficiency, and spacing compared to the conventional methods. In addition, an assessment of the optimization performance of the proposed HMOBPSO algorithm has been conducted by comparing it to other established algorithms across several ZDT and DTLZ benchmark problems, where it demonstrated its effectiveness. Full article

To improve the driving comfort of continuously variable transmission (CVT) tractors, the shifting quality of hydrostatic power-split transmission with a standard planetary gear set was optimized. Firstly, the powertrain of the CVT and two shift strategies, direct-shift and bridge-shift, were introduced; then, a dynamic model of tractor shifting was constructed, and the models of key components such as wet clutches and proportional pressure valves were experimentally verified. Finally, the control parameters of the above two shifting strategies were optimized, and the acceleration impact and sliding energy loss caused by them were compared. The results showed the following: the minimum peak acceleration of the bridge-shift method was 0.385807 m/s²; the energy consumption of the bridge-shift method was significantly lower than that of the direct-shift method; the sliding friction work of clutches decreased by 14.92% and 75.84%, respectively, while their power loss decreased by 22.82% and 74.48%, respectively. Full article

This study designed a cam-linked planetary gear system automatic seedling picking mechanism to address unstable operation and issues of high damage to the substrate caused by the picking mechanism of the dryland vegetable seedling transplanter. Through an analysis of the kinematic principle of the structure and the establishment of the kinematic model, computer-aided analysis software was developed using Visual Basic 6.0. Consequently, a set of structural parameter values satisfying the target trajectory was derived employing the human–computer interaction method, and the 3D model was designed. The model was imported into Adams for kinematic simulation, and the seedling picking mechanism’s trajectory during the operation was obtained through simulation. Modal analysis of the model was performed using Ansys, and the first six-order modal vibration patterns and modal frequencies of the seedling picking mechanism were obtained under the simulated working environment. The results confirmed that no resonance occurred during the operation. Comparisons of the seedling picking needle trajectory with the idle test revealed that the theoretical, simulated, and test trajectories were approximately identical. This proved the reliability of the theoretical design of the seedling picking mechanism, the machining of the parts, and the test bench construction. The success rates of seedling picking were 97.66, 96.09, 93.75, and 90.63% at 90, 100, 110, and 120 plants/min, respectively, with rates of substrate damage of 4.43%, 6.73%, 9.57%, and 14.37%, respectively. Thus, the experimental results confirmed that the operating parameters of the cam-linked planetary gear system seedling picking mechanism satisfied the design requirements. Full article

A combined spiral bevel gear and planetary gear set was designed for bucket elevators to reduce the system’s complexity and improve the system’s efficiency. The dynamic model of a combined spiral bevel gear and a 2K-H planetary gear train was developed by using the lumped mass method, where the time-varying mesh stiffness and comprehensive mesh error were introduced. Then, the equations of motion of the system were solved with the Newmark numerical integration method, and the dynamic transmission error and mesh force of the gear pairs were obtained. The influences of different input rotational speeds and power on the dynamic response of the system were analyzed. The dynamic responses of the bearings between the bevel gears, planet carrier, and box were calculated. It was found that the dynamic mesh force gradually decreased with an increase in speed, and it increased with an increase in power. For low-speed and heavy-load transmission systems, the influence of power on the mesh force was more significant. It could also be found that the efficiency of the transmission system composed of a spiral bevel gear and a planetary gear was improved compared with that of the traditional system. Finally, the effectiveness of the dynamic model was validated through a comparison of the test signals. The results of the analysis in this study can be used to guide the design of vibration and noise reduction. Full article

Dynamics models of planetary gear sets (PGSs) are usually established to predict their dynamic behavior and load-sharing characteristics. The accurate modeling of bearing support stiffness is essential to study their dynamics. However, in most of the existing PGS dynamic models, the effect of characteristics coupling the rolling bearing time-varying nonlinear stiffness with the translational property of PGSs on the dynamic responses was completely neglected. To investigate this problem, a refined dynamic model for PGSs is proposed considering the coupled relationship between the radial translation of the rotating components and the time-varying nonlinear support stiffness of the ball bearing. The refined dynamic model simultaneously considers the coupled effect of the time-varying characteristic caused by the orbital motion of the rolling elements and the nonlinear characteristic caused by Hertzian contact between the rolling elements and raceways of the ball bearing. Comparisons between the simulations and experimental results are presented, which indicate that the PGS vibration spectrums yielded by the proposed time-varying nonlinear stiffness model are much closer to the actual scenarios than those of traditional models. The analysis results provide theoretical guidance for fault monitoring and diagnosis of the rolling bearings used in the PGS. Full article

This paper presents a novel wheelchair–exoskeleton hybrid robot that can transform between sitting and walking modes. The lower-limb exoskeleton uses planetary-geared motors to support the hip and knee joints. Meanwhile, the ankle joints are passive. The left and right wheel modules can be retracted to the lower legs of the exoskeleton to prepare for walking or stepping over obstacles. The chair legs are designed to form a stable sitting posture to avoid falling while traveling on smooth surfaces with low energy consumption. Skateboard hub motors are used as the front driving wheels along with the rear caster wheels. The turning radius trajectory as the result of differential driving was observed in several scenarios. For assisting sit-to-stand motion, the desired joint velocities are commanded by the user while the damping of the motors is set. For stand-to-sit motion, the equilibrium of each joint is set to correspond to the standing posture, while stiffness is adjusted on the basis of assistive levels. The joint torques supported by the exoskeleton were recorded during motion, and leg muscle activities were studied via surface electromyography for further improvement. Full article
