Hydrogen plasma heating, a unique method for heating and reducing iron ore, is distinguished by its high heat, rapid reduction, and high efficiency, making it a promising technique in the metallurgy field. In this study, a non-transferred arc plasma heating system was used with Ar-H₂ as the working gas and acidic pellets as the raw material. The microstructures and elemental distributions of the slag and iron phases during the reduction process were examined using electron microscopy and energy-dispersive X-ray. The variation patterns of Fe-containing phases in the reduction products were found using X-ray diffraction and full-spectrum fitting refinement. The conversion rate of the oxidized pellets and the deoxidation conversion rate per area were estimated for various gas flow rates and reduction times. A reaction kinetics model was also used to study the reaction controlling step. The results showed that during the reduction process, with an H₂ flow rate of 4.5 L min⁻¹ and a 40 min reduction, the conversion(α) reached 99.89% and the purity of the reduced metallic iron reached 99.9%, achieving the industrial-grade 3N standard. Si and Al in the melt bath generated fayalite (Fe₂SiO₄) and hercynite (FeAl₂O₄) with Fe_xO. The deoxidation conversion rate per unit area was 1.11 g (cm² min)⁻¹. A three-dimensional diffusion-controlled model was used to describe the reduction process, and the mechanism function was 2/3(1 + α)^3/2[(1 + α)^1/3]⁻¹. The values of the reduction reaction rate constant (K) were 12.6 × 10⁻² s⁻¹ and 12.8 × 10⁻² s⁻¹ when the flow rates of H₂ gas were 3 and 4.5 L min⁻¹, respectively. The apparent activation energy was 21.9 kJ mol⁻¹. The empirical equation for the specific reduction rate was calculated as ln r = −2637.5/T − 0.407. Full article

Wear of crushing and grinding equipment components causes frequent maintenance and downtime; therefore, effective repair hardfacing routes are required to extend service life. This study investigates plasma transferred arc (PTA) surfacing of 35L cast steel using a high-chromium Fe–Cr–C powder (PG-S27) and clarifies how the welding current (40–120 A) governs layer geometry, microstructure, phase constitution, hardness, and dry-sliding tribological behavior. All deposits exhibited a dendritic–eutectic structure; increasing current led to dendrite coarsening, wider interdendritic regions, and deeper penetration/dilution. X-ray diffraction indicated an α-Fe matrix with chromium carbide phases (Cr₇C₃/Cr₂₃C₆), while the carbide-related signal decreased with higher current, consistent with enhanced dilution. The coatings showed a strong hardening effect compared with the substrate (~190 HV), reaching ~625–650 HV at 40–80 A and decreasing to ~556–589 HV at 100–120 A. In dry ball-on-flat sliding, the steady-state friction coefficient was nearly unchanged (μ ≈ 0.50–0.55) across all regimes; however, wear resistance depended strongly on current: the lowest wear was achieved at low-to-moderate currents (40–80 A), whereas higher currents (100–120 A) resulted in substantially increased material loss, approaching the substrate level. These results identify 40–80 A as the most favorable current window for obtaining wear-resistant PTA layers from PG-S27 on 35L steel. Full article

To enhance the quality and longevity of valve sealing surfaces, this study fabricated the Stellite 6/TiN composite coatings on F347 austenitic stainless steel. The process involved a plasma transferred arc (PTA) of Stellite 6 coating onto the substrate followed by physical vapor deposition (PVD) of a TiN coating onto the Stellite 6 layer. Mechanical testing revealed that the composite coatings achieved high hardness (~2110 HV), excellent adhesion (critical load Lc2 ~74 N), and superior wear resistance versus uncoated steel and single-layer Stellite 6. At 500 °C, the composite reduced wear volume by 97.2% compared to the uncoated substrate. Wear mechanisms for the Stellite 6 and composite coatings at high temperatures were elucidated, highlighting the role of Stellite 6/TiN composite coatings in enhancing tribological performance. Full article

This paper investigates the applicability of plasma transferred arc (PTA) cladding for extending the service life of biomass shredder tools. The study evaluates the possibility of replacing Hardox 500 steel with a lower-cost structural steel S355J2 whose functional surfaces are modified by PTA cladding. Three commercially available powder fillers were examined: CoCrWNi (PL1), FeCoCrSi (PL2), and NiCrMoFeCuBSi (PL3). The quality and performance of the cladded layers were assessed through hardness measurements, microstructural analysis using SEM and EDX, and tribological testing focused on abrasive and adhesive wear at room temperature. The results showed that the PL1 cladding achieved the highest surface hardness, reaching up to 602 HV0.1, due to the presence of hard carbide phases. In contrast, the PL2 cladding exhibited the best resistance to abrasive wear, demonstrating the lowest mass loss for both as-deposited and machined surfaces. The PL3 cladding showed intermediate performance in terms of wear resistance. Overall, the findings indicate that PTA cladding using an FeCoCrSi-based filler on an S355J2 substrate represents a promising and cost-effective alternative to Hardox 500 for biomass shredder applications. Full article

Transient arcing often occurs as an electric locomotive traverses an electrical sectioning overlap (ESO), deteriorating current collection stability and reducing the durability of the pantograph–catenary (PC) system. In this study, the formation mechanism and electrical evolution characteristics of transient arcing in the ESO region are investigated through theoretical analysis and numerical simulations. First, based on the dynamic motion of the locomotive passing through the ESO, the transient arcing mechanism of the ESO is clarified, and the plasma characteristics of the arc are described. Then, the electromagnetic, airflow, and thermal field interactions within the PC contact gap during arc ignition are analyzed. A Multiphysics coupled PC arc model is developed, incorporating aerodynamic, electromagnetic, and heat transfer effects. Subsequently, finite element meshing and boundary conditions are applied to simulate the transient evolution of the ESO arc. Finally, the transient arcing characteristics of the ESO are analyzed. The results indicate that the current density is highly concentrated at the initial arcing stage and gradually forms an axially symmetric conductive channel (approximately 10⁷ A/m²), which shifts upward as the contact gap increases. Moreover, due to the geometric discontinuity of the ESO, a strong localized electric field develops near the wire edge, leading to arc root migration and reignition. Full article

In this study, simulations and analyses of arc characteristics in EP (positive polarity) and EN (negative polarity) stages (including the arc polarity transition stage) of variable polarity cold metal transition (VP-CMT) during arc additive manufacturing of aluminum alloys are carried out. Temperature field, potential field, and current density distribution of arc plasma at different stages are systematically investigated by establishing a numerical model of arc heat–force coupling in combination with single-layer single-pass additive manufacturing experiments. The results indicate that the arc’s high-temperature zone in EP stage shows the wider distribution range, with enhanced heat transfer efficiency, reaching a surface temperature of up to 11,555.8 K at 2 mm from the substrate. In contrast, the arc during the EN stage demonstrates a more concentrated high-temperature zone, attributed to a more pronounced electromagnetic contraction effect, resulting in reduced heat input and a lower peak substrate temperature in comparison with EP stage. As revealed by analysis of potential and current density distribution, the arc in EP stage shows the “bell-shaped” expansion pattern with widely distributed current density, whereas the EN stage arc displays a “wrapped” contraction pattern with a more concentrated current density. The transition from EN to EP stage exhibits greater arc stability than the reverse transition. Moreover, electrode spacing significantly influences arc characteristics; a reduction in spacing leads to a more focused high-temperature zone and a substantial increase in peak current density. This study elucidates the dynamic variations in heat transfer behavior between the EP and EN stages, offering a theoretical foundation for optimizing process parameters in aluminum alloy arc additive manufacturing. Full article

Plasma Transferred Arc (PTA) cladding is a versatile hardfacing technique that produces dense, metallurgically bonded overlays with excellent wear and corrosion resistance. However, optimizing bead shape is challenging due to complex multi-parameter interactions, an issue not fully addressed in existing studies. The bead morphology, defined by height, width, and penetration depth, remains highly sensitive to process parameters, directly affecting dilution and overall coating quality. In this work, single-pass powder PTA cladding was systematically studied using an orthogonal experimental design to assess the effects of arc current, powder feed rate, welding speed, oscillation width, and oscillation speed. A morphology index was proposed to integrate geometric attributes into a single metric for quality evaluation. Regression analysis and finite element simulations based on a Goldak double-ellipsoid heat source revealed that arc current is the dominant factor, where low-to-moderate values (100–115 A) promote wide–shallow pools and higher morphology index values, while higher currents induce excessive penetration and reduced stability. Multi-parameter coupling further indicated that optimal bead morphology is achieved under low-to-moderate current, a high welding speed, relatively high powder feed rate, wide oscillation width, and moderate oscillation speed. A representative optimal condition (100 A, 105 mm·min⁻¹, 35 g·min⁻¹, 10 mm, 2600 mm·min⁻¹) ensured minimal dilution and stable deposition. This integrative framework of orthogonal design, morphology index evaluation, and thermo-fluid simulation provides practical guidelines for parameter optimization and represents a novel combined approach for PTA bead optimization. Full article

This study explores the development of a novel composite coating system combining the high hardness of WC and thermal conductivity of Cu, employing the plasma transfer arc welding method under ambient conditions. Utilizing an advanced welding approach, the work investigates microstructural evolution and phase formation in a WC-Cu-based coating applied to a mild steel substrate. Emphasis is placed on understanding the solidification behaviour and its influence on defects, microstructural refinement, and carbide formation. The study provides insights into the interactions between coating constituents and the underlying substrate under controlled thermal conditions. These findings demonstrate the potential for producing functionally graded coatings tailored for demanding wear and heat dissipation applications. The approach offers a pathway for enhancing the durability and performance of steel components in extreme service environments. Full article

This study explores how different electrode shapes affect plasma flow in a non-transferred plasma torch. Various cathode geometries—including conical, tapered, flat, and cylindrical—were examined alongside stepped anode designs. A 2D axisymmetric computational model was employed to assess the impact of these shapes on plasma behavior. The results reveal that different cathode designs require varying current levels to maintain a consistent power output. This paper presents the changes in electric conductivity and electric potential for different input currents across the arc formation path (from the cathode tip to the anode beginning) and relating to Ohm’s law. Significant variations in plasma jet velocity and temperature were observed, especially near the cathode tip. The study concludes by evaluating thermal efficiency across geometry configurations. Flat cathodes demonstrated the highest efficiency, while the anode shape had minimal impact. Full article

The resistance to erosion of stainless steel-based plasma transferred arc (PTA)-cladded hardfacings reinforced with ex-situ-synthesized TiC is compared to those reinforced using in-situ-synthesized TiC (formed from TiO₂ and graphite). The PTA cladding was performed under an optimized torch linear velocity of 0.7 m/s and cladding current of 115 A. The microstructure of the cladded overlay was analyzed using scanning electron microscopy (SEM), and the phase composition was determined using X-ray diffraction (XRD). Vickers macrohardness measurements were made at representative areas at the surface of the overlays. An erosive wear test was conducted with impact angles of 30° and 90° and impact velocities of 20, 50, and 80 m/s. The formation of TiC from TiO₂ and graphite started during ball milling and ended during the cladding stage. The final TiC content in the hardfacings was below nominal, which is likely due to carbide segregation occurring during the cladding process. The highest hardness was 2.4 times that of stainless steel, which was observed in the deposit containing 60 vol.% ex-situ-synthesized TiC. Both ex-situ and in-situ TiC reinforcement improved resistance to erosion, providing up to 1.5 times better resistance under the 30° impact angle and up to 6.3 times under the 90° impact angle than that of stainless steel. However, ex-situ TiC showed a slightly larger improvement. At the 30° impact angle, the primary wear mechanism is micro-ploughing, but at the 90° impact angle it is surface fatigue. Both mechanisms appeared at both angles under 80 m/s impact velocity. Full article

Spatters in the powder-based metal additive manufacturing processes influence deposition quality, part surface quality, and internal defects. We developed a novel video analysis method to monitor and count the melted spatter particles of biomedical-grade Co-Cr-Mo-4Ti powder particles in depositing layers using a micro-plasma transferred arc additive manufacturing (M-PTAAM) process. We captured the spatters using a weld-monitoring camera and building datasets of videos and monitored different combinations of M-PTAAM process parameters. We captured videos of the melted spatter particles and counted the melted spatter particles in real time using a Kalman filter. The weld-monitoring camera captured the melted spatter particles and the fumes generated by the evaporated spatter particles. The video processing algorithm was developed in this study to accurately capture melted spatter particles. In images without fumes, nearly all melted spatter particles were successfully detected. Even in images with the presence of fumes, the algorithm maintained a detection accuracy of 90%. The real-time melted spatter count particle exhibited a powder feed rate changing from 30 to 35 g/min and then to 50 g/min. The melted spatter particle count was lowest at a powder feed rate of 30 g/min and increased with the increasing powder feed rate. Full article

In the present work, chemical and ion beam surface treatments were performed in order to modify the electrochemical behavior of industrial austenitic–martensitic steel VNS-5 in 3.5 wt. % NaCl. Immersion for 140 h in a solution containing 0.05 M potassium dichromate and 10% phosphoric acid promotes formation of chromium hydroxides in the outer surface layer. By means of a new type of ion source, based on a high-current pulsed magnetron discharge with injection of electrons from vacuum arc plasma, ion implantation with Ar⁺ and Cr⁺ ions of the VNS-5 steel was performed. It has been found that the ion implantation leads to formation of an Fe- and Cr-bearing oxide layer with advanced passivation ability. Moreover, the ion beam-treated steel exhibits a lower corrosion rate (by ~7.8 times) and higher charge transfer resistance in comparison with an initial (mechanically polished) substrate. Comprehensive electrochemical and XPS analysis has shown that a Cr₂O₃-rich oxide film is able to provide an improved corrosion performance of the steel, while the chromium hydroxides may increase the specific conductivity of the surface layer. A scheme of a charge transfer between the microgalvanic elements was proposed. Full article

This study evaluates the tribological characteristics of quasi-monolithic engine cylinder coatings and piston rings using a custom-built linear reciprocating tribometer. The coatings were deposited on an Al-Si alloy cylinder bore using the Plasma Transfer Wire Arc (PTWA) and Electrolytic Jet Plasma Oxidation (EJPO) processes. The coatings’ tribological performances were investigated in the boundary lubrication regime. The performance of conventional chrome-coated cast iron piston rings was tested and compared to that of EJPO- and PTWA-coated engine cylinder samples that were extracted from a cast Al-Si engine block. Scanning electron microscopy and profilometry were used to compare the evolution of wear and the prevalent wear mechanism. This paper also presents the verification and repeatability analysis of a custom-built tribometer against a standard industry-calibrated tribometer. The wear test results showed that the EJPO coating had 0.05% to 10.35% lower wear rates than its PTWA counterpart throughout a wide range of loading conditions and sliding distances. The variation in the counter-face behavior is likely due to the different surface topographic parameters such as skewness, kurtosis, and porosity. Full article

Laser–arc hybrid welding (LAHW) is an advanced welding technology that integrates both laser and arc heat sources within a single molten pool, achieving synergistic benefits that surpass the sum of their individual contributions. This method enhances the welding speed and depth of the fusion, stabilizes the process, and minimizes welding defects. Numerous studies have investigated the principles, synergistic effects, keyhole dynamics, joint performance, and various factors influencing the parameters of laser–arc hybrid welding. This paper begins with an introduction to the classification of LAHW, followed by a discussion of the characteristics of gas-shielded welding, argon arc welding, and plasma hybrid welding. Subsequently, the welding principles underlying laser–arc hybrid welding will be elucidated. To enhance weld integrity and quality, this paper will analyze keyhole behavior, droplet transfer dynamics, welding quality performance, and the generation and prevention of welding defects that affect laser–arc hybrid welding. Additionally, a detailed analysis of the effects of residual stress on the shape, microstructure, and phase composition of the weld will be provided, along with an exploration of the influences of various welding parameters on post-weld deformation and mechanical properties. Full article

Friction surfacing (FS) is a solid-state process for depositing metallurgically bonded coatings for corrosion and wear protection. It is particularly attractive for depositing coatings in materials that are difficult to fusion deposit. Stellite 6 is one such material, which is widely used as a protective coating on steel structures to combat wear and corrosion. In the current study, Stellite 6 was successfully friction-surfaced on low carbon steel plates without using any preheating. The microstructures and wear behavior of Stellite 6 coatings produced using FS were comparatively investigated with those produced using the plasma transferred arc (PTA) process. The PTA coatings showed a cast microstructure consisting of γ-dendrites and an inter-dendritic carbide network. On the other hand, the FS coatings showed a wrought microstructure with dynamically recrystallized grains and fine, uniformly distributed carbide particles. The FS coatings also showed uniform composition across the coating thickness and were undiluted, while the PTA coatings showed significant dilution as well as strong local variations in chemistry. The FS coatings exhibited a 22% increase in hardness (550 HV) compared to the PTA coatings (450 HV). Pin-on-disc dry sliding wear tests showed that the FS coatings (1.205 mm³) were more wear resistant compared to the PTA coatings (6.005 mm³), highlighting their superior mechanical performance. This study uniquely demonstrates the feasibility of depositing Stellite 6 coatings using FS without the need for preheating or post-deposition heat treatments, while achieving superior microstructural refinement, hardness, and wear resistance compared to conventional PTA coatings. Full article
