TA1 titanium bipolar plates for hydrogen fuel cells are prone to plastic instability phenomena such as wrinkling during the stamping process, which adversely affects the forming quality. This study applies an ultrasonic-vibration energy field, aligned with the direction of stretching, in a plate diagonal tensile testing scenario based on the Blaha effect. The impact of varying thicknesses and vibration amplitudes on the anti-wrinkling performance of TA1 titanium sheets is investigated. Through a combined analysis of load–displacement curves and wrinkle height measurements using a super-depth-of-field microscope, by examining the forming load, the onset of wrinkling, and the wrinkle height at buckling locations, this study explores the deformation behavior of the thin sheet and the wrinkle suppression mechanism under the coupled effects of the ultrasonic-vibration field and scale. The results show that as the thickness decreases, the anti-wrinkling ability of the TA1 titanium sheet diminishes. The ultrasonic-vibration energy field reduces the yield stress and flow stress of the material, promoting wrinkling during the elastic deformation stage. Moreover, the 0.075 mm thick TA1 titanium sheet experiences local secondary wrinkling during the plastic deformation stage. Additionally, the ultrasonic-vibration energy field effectively reduces the forming load of the sheet and suppresses wrinkling within a certain range of amplitudes. These findings provide experimental evidence for the ultrasonic-vibration-assisted stamping process of titanium bipolar plates. Full article

This study investigates the mixed-mode I/II fracture behavior of O-notched diagonally loaded square plate (DLSP) samples containing an edge crack within the O-notch. This investigation aims to explore the combined effects of loading rate and mode mixity on the fracture properties of steel 304L, utilizing DLSP samples. The DLSP samples, made from strain-hardening steel 304L, were tested at three different loading rates: 1, 50, and 400 mm/min, covering five mode mixities from pure mode I to pure mode II. Additionally, tensile tests were performed on dumbbell-shaped specimens at the same loading rates to examine their influence on the material’s mechanical properties. The findings revealed that stress and strain diagrams derived from the dumbbell-shaped samples were largely independent of the tested loading rates (i.e., 1–400 mm/min). Furthermore, experimental results from DLSP samples showed no significant impact of the loading rates on the maximum load values, but did indicate an increase in the ultimate displacement. In contrast to the loading rate, mode mixity exhibited a notable effect on the fracture behavior of DLSP samples. Ultimately, it was observed that the loading rate had an insignificant effect on the fracture path or trajectory of the tested DLSP samples. Full article

The connection between the leg members and diagonal members of the urban transmission line tower is mostly in the form of single-limb connection. This paper puts forward a new connection form of pipe double-limb double-plate connection joint, which is based on the model of key joints in an urban narrow base tower structure. The traditional pipe single-limb single-plate and new pipe double-limb double-plate joint are analyzed and studied from three aspects of theory, numerical simulation and experimental study. Through finite element analysis, it is obtained that the section stress of angle steel under eccentric load is 2.05 times of that under axial load, which is basically consistent with the 2.5 times of the theoretical calculation. This shows that the stress of the angle steel in the pipe double-limb double-plate joint is greatly reduced as the axial stress component, which can ensure the safety of the angle steel. Based on the theoretical analysis of the tensile force of two kinds of joints, through the test research and corresponding numerical simulation of pipe single-limb single-plate and pipe double-limb double-plate joints, under the same load, compared with pipe single-limb single-plate joints, the pipe double-limb double-plate joints designed in this paper can greatly reduce the stress of connection plates and members, and compared with the existing joint forms, the bending stress of joint plates can be reduced by about four times, which greatly improves the bearing capacity of the joint. The research on the pipe double-limb double-plate connection joint will provide the basis for the design of new connection joints of narrow base towers in urban areas. Full article

To investigate the residual shear capacity of post-fire bolted side-plated (BSP) reinforced concrete (RC) beams with different depths of steel plate and types of anchor adhesive, i.e., magnesium oxychloride cement (MOC) and HIT-RE500, a control beam and five BSP beams were fabricated, of which two were exposed to fire in accordance with ISO834 temperature curve. Four-point bending shear tests were conducted to investigate the influence of elevated temperature on the failure mode, cracking load, shear capacity, stiffness, ductility and strain development, etc. The shear capacities of RC beams were found to be improved significantly by using the BSP technique. However, the stiffness of BSP beams was seriously degraded after exposed to fire, but the reduction in shear capacity was negligible, whereas the ductility and the strain of longitudinal reinforcement were obviously increased. Thus, the failure-mode was changed from shear failure to flexural failure. Regarding the adhesive mortar used for bolt anchorage, magnesium oxychloride cement (MOC) achieved higher shear capacity and better ductility but lower stiffness for BSP beams compared with HIT-RE500. Additionally, increasing the depth of bolted steel plates effectively improved the shear performance of BSP beams. In the tests, uneven relative slips were observed on the plate-RC interface due to the shear deformation of bolt shafts and the plates’ tensile principal stress perpendicular to the main diagonal crack, which proved the deformation lag of the bolted steel plates with respect to the RC beam. The outcomes of this study provide a better understanding on the shear performance of BSP beams at room temperatures and at fire conditions. Full article
