In industrial environments, steel plate surface inspection plays a crucial role in quality control. However, vibrations during laser scanning can significantly impact measurement accuracy. While traditional vibration compensation methods rely on complex dynamic modeling, they often face challenges in practical implementation and generalization. This paper introduces a novel point cloud vibration compensation algorithm that combines an improved Gaussian–Laplacian filter with adaptive local feature analysis. The key innovations include (1) an FFT-based vibration factor extraction method that effectively identifies vibration trends, (2) an adaptive windowing strategy that automatically adjusts based on local geometric features, and (3) a weighted compensation mechanism that preserves surface details while reducing vibration noise. The algorithm demonstrated significant improvements in signal-to-noise ratio: 15.78% for simulated data, 6.81% for precision standard parts, and 12.24% for actual industrial measurements. Experimental validation confirms the algorithm’s effectiveness across different conditions. This approach achieved a practical, implementable solution for surface inspection in steel plate surface inspection. Full article

Mechanical vibration in the high-temperature forging production line often causes large forging thermal dimensional measurement error in the detection task, so a vibration point cloud compensation method based on an acceleration sensor is proposed in this study. First, the vibration signal is obtained through the built-in acceleration sensor in the laser camera. After the acceleration of the camera vibration is detected, the displacement of the camera in three directions is solved by secondary integration. Subsequently, the coordinate value of the corresponding point is obtained by the rotation matrix transformation so as to compensate and correct the point cloud deviation caused by the camera vibration. Finally, the forging point cloud is matched using the surface matching algorithm in Halcon. An automatic forging production line for wheel hubs has been built, and the key dimensions of high-temperature forging products have been measured online using the developed method. After the forging point cloud is compensated, the average measurement error of dimensions is reduced from ±0.9 mm to ±0.1 mm, and the standard deviation is reduced from 0.52 mm to 0.056 mm. Using the vibration point cloud compensation method based on the acceleration sensor, as well as using silica aerogel insulation, vibration structural parts, heat insulation and constant temperature, a blue-violet 3D laser camera, and other measures, the dimensional detection accuracy of high-temperature forgings in the forging production line can be improved, and the instability of dimensional detection can be reduced. Full article

An expansion joint is mainly composed of bellows and other components; it is attached on a container shell or pipe to compensate for the additional stress caused by temperature differences and mechanical vibrations. In China, the expansion joint fatigue tests are often used to assess the quality of products. After fatigue tests, convolution pitch will be changed. The amount of change is an important index that can be used to evaluate bellows expansion joints. However, the convolution pitch detection is mainly done manually and randomly by inspection agencies before shipping to the end users. This common practice is not efficient and is often subjective. This paper introduced a novel method for automatically detecting the change of the convolution pitch based on a laser line scanner and data processing technology. The laser line scanner is combined with a precision motorized stage to obtain the point cloud data of the bellows. After denoising and fitting, a peak-finding algorithm is applied to search for the crest of a convolution. The method to find the convolution pitch and the decision that needs to be made to ensure product eligibility are described in detail. A DN500 expansion joint is used as a sample to illustrate the efficiency of the system. The application of the technique intuitively allows a higher precision and relative efficiency in quality inspection of bellows expansion joints. It has also been implemented in the Special Equipment Safety Supervision and Inspection Institute of Jiangsu province with great success. Full article
