Search Results (158)

Search Parameters:
Keywords = polarization reconfiguration

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
13 pages, 2648 KB
Article
Virtual Optical Waveguides for Particle Transport and Sorting
by Liuhao Zhu, Xiaohe Zhang, Xiang Zang, Jun He, Bing Gu and Xi Xie
Photonics 2026, 13(4), 378; https://doi.org/10.3390/photonics13040378 - 16 Apr 2026
Viewed by 254
Abstract
Precise manipulation and directed transport of micro- and nano-particles are cornerstones of emerging lab-on-a-chip technologies. Traditional optofluidic systems that combine optical tweezers with microfluidic channels enable long-range transport. However, they rely on fixed physical boundaries that lack reconfigurability. To bridge this gap, we [...] Read more.
Precise manipulation and directed transport of micro- and nano-particles are cornerstones of emerging lab-on-a-chip technologies. Traditional optofluidic systems that combine optical tweezers with microfluidic channels enable long-range transport. However, they rely on fixed physical boundaries that lack reconfigurability. To bridge this gap, we propose a reconfigurable virtual optical waveguide (VOW) based on a discretized beam-shaping strategy. By superposing two orthogonally polarized shaped beams, we construct interference-free optical channels without physical boundaries. This platform enables programmable transport along complex trajectories, including space-filling Hilbert curves that maximize interaction path length, and shields the transport channel from perturbations induced by surrounding particles. Crucially, the VOW offers multi-dimensional sorting capabilities: (i) it performs precise size-dependent sieving via tunable channel widths, and (ii) it functions as an intrinsic material filter by stably guiding scattering-dominated particles (e.g., gold) while rejecting gradient-dominated dielectric ones. This work establishes a versatile, contactless strategy for adaptive optical logistics and on-chip material purification. Full article
(This article belongs to the Special Issue Advances in Spin-Orbit Coupling of Light)
Show Figures

Figure 1

28 pages, 4609 KB
Review
Reconfigurable Antennas Enabled by Tunable Metasurfaces for Next-Generation Wireless Communications: A Review
by Zahra Hamzavi-Zarghani, Ladislau Matekovits and Wolfgang Bösch
Electronics 2026, 15(8), 1610; https://doi.org/10.3390/electronics15081610 - 13 Apr 2026
Viewed by 514
Abstract
Reconfigurable antennas play a central role in next-generation wireless communication systems by enabling dynamic adaptation of operating frequency, radiation pattern, and polarization. Tunable metasurfaces have emerged as a powerful and compact approach to antenna reconfiguration, allowing electromagnetic wave manipulation through engineered, planar structures [...] Read more.
Reconfigurable antennas play a central role in next-generation wireless communication systems by enabling dynamic adaptation of operating frequency, radiation pattern, and polarization. Tunable metasurfaces have emerged as a powerful and compact approach to antenna reconfiguration, allowing electromagnetic wave manipulation through engineered, planar structures whose properties can be dynamically controlled. By embedding active devices or tunable materials within metasurface unit cells, antenna characteristics can be modified without altering the antenna geometry. This review provides a comprehensive overview of reconfigurable antennas enabled by tunable metasurfaces. We adopt a functionality-based classification that focuses on operating frequency, radiation pattern, polarization, and multifunction reconfiguration. An overview of major tunability technologies, including PIN diodes, varactors, MEMS, graphene and two-dimensional materials, and liquid crystal (LC) or phase-change materials, is first presented. Subsequently, metasurface-based reconfiguration strategies are discussed and compared for each antenna functionality, highlighting design principles, practical trade-offs, and limitations. The review concludes with an assessment of challenges and future research directions relevant to next-generation wireless communications and beyond. Full article
Show Figures

Figure 1

18 pages, 2508 KB
Article
Giant Tunneling Electroresistance and Anisotropic Photoresponse in Sliding Ferroelectric Homojunctions Based on Bilayer Janus MoSSe
by Huxiao Yang and Yuehua Xu
Nanomaterials 2026, 16(6), 370; https://doi.org/10.3390/nano16060370 - 18 Mar 2026
Viewed by 362
Abstract
Interlayer-sliding ferroelectricity in van der Waals bilayers enables ultralow-power switching, but practical devices are often limited by contact/interface scattering and weak coupling between polarization and transport. We propose homophase lateral architectures based on bilayer Janus MoSSe: a 1T/2H/1T ferroelectric tunnel homojunction and an [...] Read more.
Interlayer-sliding ferroelectricity in van der Waals bilayers enables ultralow-power switching, but practical devices are often limited by contact/interface scattering and weak coupling between polarization and transport. We propose homophase lateral architectures based on bilayer Janus MoSSe: a 1T/2H/1T ferroelectric tunnel homojunction and an H-phase lateral p–i–n photodetector (artificially doped electrode). Metallic 1T electrodes largely eliminate contact barriers and maximize polarization-driven tunneling modulation. Using non-equilibrium Green’s function–density functional theory (Perdew–Burke–Ernzerhof approximation, without explicit spin–orbit coupling), we find that AB to BA sliding reduces the current from the nA range to the pA range, with the minimum current of|IOFF|min = 2.83 pA, yielding giant tunneling electroresistance up to 5.3 × 104%. Projected local density of states reveals a non-rigid long-range potential redistribution that reshapes the tunneling barrier and opens high-transmission channels. In the p–i–n photodetector, the response is strongly anisotropic and stacking-dependent: AB reaches photocurrent density Jph ≈ 7.2 µA·mm−2 at 2.6 eV for in-plane light versus ≈ 2.9 µA·mm−2 at 3.5 eV for out-of-plane, and exceeds BA by 1.5–1.8 times due to density of states advantages and Mo-d orbital selection rules. Bilayer Janus MoSSe therefore provides a reconfigurable platform for high-contrast memory and polarization-sensitive photodetection. Full article
(This article belongs to the Special Issue Emerging 2D Materials for Future Nanoelectronics)
Show Figures

Figure 1

16 pages, 10173 KB
Article
A Low-Cost Two-Dimensional Scalable Active Receive Phased Array with 8 Simultaneously Reconfigurable Beams
by Haifu Zhang, Li-Xin Guo, Shubo Dun, Xiaoming Li, Wei Mei, Xiaolong Xu and Dinuo Bu
Micromachines 2026, 17(3), 348; https://doi.org/10.3390/mi17030348 - 12 Mar 2026
Viewed by 342
Abstract
This paper presents a compact multi-beam dual-circularly polarized phased array receiving system operating in the 10.7–12.7 GHz frequency band is designed and implemented, which can generate eight reconfigurable receiving beams with independently configurable polarization modes and scanning directions for each beam. To improve [...] Read more.
This paper presents a compact multi-beam dual-circularly polarized phased array receiving system operating in the 10.7–12.7 GHz frequency band is designed and implemented, which can generate eight reconfigurable receiving beams with independently configurable polarization modes and scanning directions for each beam. To improve the aperture utilization efficiency of the array and reduce the array size, the proposed phased array architecture adopts a “full-aperture multiplexing” beamforming method, where all beams share the same array aperture. For cost-effective phased array architecture with two-dimensional scalability, the array is divided into several identical receiving subarrays, with the control and power supply modules arranged beneath the array aperture. In addition, a heterogeneous integration scheme is introduced to realize high-density integration of various receiving functional chips, which reduces the overall array footprint by approximately 30% while maintaining the basic performance of the system gain-to-noise-temperature ratio (G/T). Meanwhile, different dielectric substrates are adopted to implement multi-level combining networks, optimizing the trade-off between overall efficiency and cost. To verify the feasibility of the proposed architecture, a prototype with a 16 × 16 array configuration is developed and tested. The measured results show that the array gain reduction is no more than 4 dB at a maximum scanning angle of 60°, and the G/T value of all beams in the boresight direction is not less than 0.9 dB/K at 11.7 GHz. The experimental results validate the effectiveness of the proposed multi-beam dual-circularly polarized phased array architecture in terms of engineering implementation and system performance. Full article
Show Figures

Figure 1

35 pages, 20354 KB
Review
Phase Control Mechanisms in Metasurfaces: From Static Approaches to Active and Space–Time Modulation
by Muhammad Haroon, Sun-woong Kim and Dong-You Choi
Sensors 2026, 26(6), 1781; https://doi.org/10.3390/s26061781 - 11 Mar 2026
Cited by 1 | Viewed by 953
Abstract
Metasurfaces provide a compact and powerful means of tailoring electromagnetic wavefronts through spatially varying phase manipulation. This review presents a unified, mechanism-centered perspective on phase control in metasurfaces, tracing their evolution from static designs to actively reconfigurable and space–time-modulated platforms. Beginning with the [...] Read more.
Metasurfaces provide a compact and powerful means of tailoring electromagnetic wavefronts through spatially varying phase manipulation. This review presents a unified, mechanism-centered perspective on phase control in metasurfaces, tracing their evolution from static designs to actively reconfigurable and space–time-modulated platforms. Beginning with the theoretical basis of generalized Snell’s law, phase-control strategies are categorized into resonance-based, PB phase, and propagation-phase mechanisms, with emphasis on their underlying physics, bandwidth, efficiency, and polarization characteristics. These static approaches are then extended to active metasurfaces that enable post-fabrication reconfiguration through liquid-crystal tuning, electro-optic, phase-change materials, and mechanical deformation. Beyond quasi-static tuning, space–time modulation is introduced as a distinct paradigm that exploits temporal phase gradients to achieve frequency conversion, nonreciprocity, and waveform synthesis. By organizing diverse implementations around their physical phase-control mechanisms and experimentally reported performance trends, this review provides practical guidance for selecting metasurface architectures across frequency regimes and application requirements. Full article
(This article belongs to the Section Physical Sensors)
Show Figures

Figure 1

23 pages, 8617 KB
Article
Polarization-Reconfigurable Metasurface Antenna Design for Drone Terminals Based on Characteristic Mode Analysis
by Shiquan Zhang, Hao Yu, Xianqiong Wen and Hongxing Zheng
Micromachines 2026, 17(3), 311; https://doi.org/10.3390/mi17030311 - 28 Feb 2026
Viewed by 435
Abstract
To enhance the anti-jamming performance and operational reliability of drones, this paper presents the design, fabrication, and measurement of a novel polarization-reconfigurable metasurface antenna that meets these demands. The design process is guided systematically by characteristic mode analysis, in which the modal significance [...] Read more.
To enhance the anti-jamming performance and operational reliability of drones, this paper presents the design, fabrication, and measurement of a novel polarization-reconfigurable metasurface antenna that meets these demands. The design process is guided systematically by characteristic mode analysis, in which the modal significance coefficient is used as a key tool to predict resonant frequencies and optimize bandwidth. A major innovation lies in the mechanical rotation mechanism, which enables the antenna to switch between left-hand circular polarization, linear polarization, and right-hand circular polarization, thereby avoiding losses associated with active electronic components. The antenna features a compact geometry of 0.49λ × 0.49λ and delivers strong performance across all polarization states. Impedance bandwidth exceeds 29.9%, average gain ranges from 5.1 to 6.0 dBi, and high polarization purity is achieved with an axial ratio bandwidth > 10% in circular polarization modes and cross-polarization discrimination >23 dB in the linear polarization state. Simulated and measured results are in good agreement, confirming the effectiveness and robustness of the proposed design for modern sub-6 GHz 5G drone terminals. Full article
Show Figures

Figure 1

14 pages, 3153 KB
Article
Hybrid Graphene—VO2 Reconfigurable Terahertz Metamaterial Absorber for Broadband RCS Reduction and High-Performance Sensing
by Kunxuan Su, Yingwen Long and Wenhao Yang
Photonics 2026, 13(2), 205; https://doi.org/10.3390/photonics13020205 - 21 Feb 2026
Viewed by 638
Abstract
A hybrid graphene-VO2 reconfigurable terahertz metamaterial absorber is proposed for broadband radar cross-section (RCS) reduction and high-performance sensing. The designed structure leverages the phase transition property of VO2 and the electrostatic tunability of graphene to achieve dynamic switching between ultra-broadband and [...] Read more.
A hybrid graphene-VO2 reconfigurable terahertz metamaterial absorber is proposed for broadband radar cross-section (RCS) reduction and high-performance sensing. The designed structure leverages the phase transition property of VO2 and the electrostatic tunability of graphene to achieve dynamic switching between ultra-broadband and narrowband absorption states. When VO2 is in the metallic state and graphene is unbiased, the absorber exhibits over 90% absorption across 0.82~3.50 THz, corresponding to a relative bandwidth of 124%. In the narrowband mode, with VO2 in the insulating state and graphene biased (Ef = 1 eV), a sharp absorption peak exceeding 60% is achieved at 1.48 THz. The symmetrical design ensures polarization insensitivity and wide-angle stability. Applications in broadband RCS reduction higher than 10 dB and refractive index sensing with a sensitivity of 24.86 GHz/RIU are demonstrated, surpassing conventional terahertz sensors. This work provides a promising platform for adaptive terahertz stealth and sensing systems. Full article
Show Figures

Figure 1

21 pages, 5796 KB
Article
Analysis and Design of a Hybrid Graphene/Vanadium-Dioxide Terahertz Metasurface with Independently Reconfigurable Reflection Phase and Magnitude
by Eric Amoateng, Ellis Mubarak Sani, Kingsford Sarkodie Obeng Kwakye and Alexandros Pitilakis
Photonics 2026, 13(2), 195; https://doi.org/10.3390/photonics13020195 - 15 Feb 2026
Viewed by 491
Abstract
A reconfigurable THz metasurface (MS) capable of independent reflection amplitude and phase modulation is designed and analyzed. The tunability is achieved in a simple few-layer structure by control over the chemical potential of a graphene monolayer patterned in square patches and over the [...] Read more.
A reconfigurable THz metasurface (MS) capable of independent reflection amplitude and phase modulation is designed and analyzed. The tunability is achieved in a simple few-layer structure by control over the chemical potential of a graphene monolayer patterned in square patches and over the bulk conductivity of an overlying vanadium dioxide (VO2) patch array; these impart control over the reflection phase and magnitude, respectively. To design and analyze the MS unit cell, we employ intuitive equivalent circuit and transmission line modeling, which is validated against full-wave simulations, showing good agreement in the regime of interest, i.e., on the first resonance for normal plane wave incidence. The simulated phase modulation approaches 250°, enabling binary-encoded digital metasurface designs, while the magnitude modulation spans more than 20 dB, from 3 dB almost down to perfect absorption. The flexibility of dynamic phase and amplitude control can unlock the full potential of such THz MS hybrid designs for future wireless communications (6G and beyond) and for sensing applications. Finally, the analytical modeling can be extended to polarization-dependent, anisotropic, or non-local EM responses and/or to include aspects of the multiphysical control mechanisms. Full article
(This article belongs to the Special Issue Photonics Metamaterials: Processing and Applications)
Show Figures

Figure 1

13 pages, 2433 KB
Article
Tunable Chiral Terahertz Wave Absorption and Beam Manipulation Based on Vanadium Dioxide Metasurfaces
by Li Luo, Boyu Chen, Jie Li, Yi Zheng, Jin He, Yuanyuan Lv, Lin Liu, Cheng Chen, Jialuo Ding, Xiang Yan, Junqi Chen, Tian Tian, Zhe Zhao, Zhanyi Lin, Menghan Chen, Lin Liang and Jianquan Yao
Nanomaterials 2026, 16(3), 189; https://doi.org/10.3390/nano16030189 - 30 Jan 2026
Viewed by 487
Abstract
Chiral metasurfaces exhibit enormous potential in optical applications, and their integration with phase-change material vanadium dioxide (VO2) provides a novel pathway for dynamic regulation. In this study, a chiral absorptive metasurface based on VO2 is designed. By tuning the VO [...] Read more.
Chiral metasurfaces exhibit enormous potential in optical applications, and their integration with phase-change material vanadium dioxide (VO2) provides a novel pathway for dynamic regulation. In this study, a chiral absorptive metasurface based on VO2 is designed. By tuning the VO2 conductivity around the operating frequency of 2.81 THz, the circular dichroism (CD) can be continuously adjusted from 0.06 to 0.95, realizing a high-contrast chiral switch. On this basis, the Pancharatnam–Berry (PB) phase is introduced to construct a chirality-dependent phase gradient: when the VO2 conductivity is 200,000 S/m, only the left-handed circularly polarized (LCP) wave is subjected to periodic phase modulation, enabling controllable deflection of the reflected beam, while the right-handed circularly polarized (RCP) wave is selectively absorbed. This “chiral phase encoding” strategy simultaneously achieves absorptive CD tuning and reflective beam shaping on a single metasurface, significantly enhancing the flexible manipulation capability of circular polarization states in the terahertz band. It provides a compact and efficient solution for reconfigurable imaging, unidirectional communication, and integrated photonics systems. Full article
(This article belongs to the Special Issue Nanostructured Materials for Electric Applications)
Show Figures

Figure 1

13 pages, 1278 KB
Article
Four-State Programmable Quasi-BIC Metasurface with Polarization-Divergent Dispersion Rewriting
by Wenbin Wang and Yun Meng
Photonics 2026, 13(2), 105; https://doi.org/10.3390/photonics13020105 - 23 Jan 2026
Viewed by 593
Abstract
A central challenge in reconfigurable photonics based on quasi bound states in the continuum (quasi-BICs) is to move beyond binary switching toward multistate and polarization-aware programmability. Here we propose a dual-phase-change material (PCM) metasurface that enables four-state nonvolatile switching and polarization-divergent dispersion rewriting [...] Read more.
A central challenge in reconfigurable photonics based on quasi bound states in the continuum (quasi-BICs) is to move beyond binary switching toward multistate and polarization-aware programmability. Here we propose a dual-phase-change material (PCM) metasurface that enables four-state nonvolatile switching and polarization-divergent dispersion rewriting within a single unit cell. Two independently switchable PCM layers provide four addressable configurations (0-0, 0-1, 1-0, 1-1) at a fixed geometry, allowing the resonance landscape to be reprogrammed through complex-index rewriting without structural modification. Angle-resolved transmission maps reveal fundamentally different evolution pathways for orthogonal polarizations. For p polarization, the quasi-BIC exhibits strong state sensitivity with dispersion reshaping and multi-branch features near normal incidence; the resonance red-shifts from ~1331 nm to ~1355 nm while the quality factor decreases from ~6.7 × 104 to ~4.0 × 104. In contrast, for s polarization, a single weakly dispersive branch translates coherently across states, producing a much larger shift from ~1635 nm to ~1790 nm while the quality factor increases from ~9.0 × 103 to ~1.8 × 104. The opposite quality-factor trajectories, together with the polarization-contrasting tuning ranges, demonstrate that dual-PCM programming reconfigures polarization-selective radiative coupling rather than imposing a uniform resonance shift. This compact two-bit metasurface platform provides multistate, high-Q control with active dispersion engineering, enabling polarization-multiplexed reconfigurable filters, state-addressable sensors, and other programmable photonic devices. Full article
(This article belongs to the Special Issue Advances in the Propagation and Coherence of Light)
Show Figures

Figure 1

18 pages, 6167 KB
Article
Reconfigurable Millimeter-Wave Generation via Mutually Injected Spin-VCSELs
by Yichuan Xiong, Yu Huang, Pei Zhou, Kuenyao Lau and Nianqiang Li
Photonics 2026, 13(1), 28; https://doi.org/10.3390/photonics13010028 - 29 Dec 2025
Viewed by 364
Abstract
We propose a novel scheme for generating high-frequency millimeter-wave signals by exploiting period-one (P1) dynamics in a mutual injection configuration of two spin-polarized vertical-cavity surface-emitting lasers (spin-VCSELs). The frequency of the generated millimeter-wave signal is jointly determined by the birefringence rate of the [...] Read more.
We propose a novel scheme for generating high-frequency millimeter-wave signals by exploiting period-one (P1) dynamics in a mutual injection configuration of two spin-polarized vertical-cavity surface-emitting lasers (spin-VCSELs). The frequency of the generated millimeter-wave signal is jointly determined by the birefringence rate of the spin-VCSEL and the frequency detuning between the two lasers. By leveraging the complex dynamics of free-running spin-VCSELs, we explore the coupling of three distinct dynamic states: continuous-wave (CW) injected into CW, CW injected into P1 oscillation, and P1 oscillation injected into P1 oscillation. Our results reveal that these interactions not only enhance the tunability and frequency of the millimeter-wave output but also significantly reduce the linewidth, offering substantial advantages for reconfigurable photonic systems. This study demonstrates the remarkable potential of mutually injected spin-VCSELs for generating high-performance, tunable photonic millimeter waves and highlights their promising applications in advanced communication and radar systems. Full article
Show Figures

Figure 1

11 pages, 1986 KB
Article
Laser-Induced Reconfiguration of Magnetic Domain Structure in Iron Garnet Films with Strong In-Plane Anisotropy
by Mikhail A. Stepanov, Nikolai V. Mitetelo, Andrey A. Guskov, Alexey S. Kaminskiy and Alexander P. Pyatakov
Nanomaterials 2025, 15(23), 1830; https://doi.org/10.3390/nano15231830 - 4 Dec 2025
Viewed by 682
Abstract
In this work we demonstrate the laser-driven reconfiguration of stripe domains in a thick bismuth-substituted iron garnet film with the (210) crystallographic orientation exhibiting strong in-plane anisotropy. Under a weak in-plane external magnetic field (H), laser irradiation leads to local “twisting” [...] Read more.
In this work we demonstrate the laser-driven reconfiguration of stripe domains in a thick bismuth-substituted iron garnet film with the (210) crystallographic orientation exhibiting strong in-plane anisotropy. Under a weak in-plane external magnetic field (H), laser irradiation leads to local “twisting” of the magnetic domains; domains with opposite magnetization rotate in different directions. The twisting angle increases linearly with the in-plane magnetic field (H) (above a threshold of approximately 6 Oe) and also changes linearly with the average laser intensity, being fully reversible after the irradiation process. The magnitude of the domain rotation effect does not depend on the light polarization state or its orientation. After optical irradiation, the magnetization distribution in the sample returns to its initial state. It is also observed that moving the focused beam spot along the surface can lead to irreversible modifications in the domain topology in several ways: there is a shift in the dislocations in stripe domain structure (domain “heads”) across the beam transfer direction, expanding the area with a specific magnetization vector orientation, and the stabilization of domain wall positions by their pinning on crystallographic defects. The proposed analytical model based on a local reducing of the effective anisotropy fully describes the rotation type and angle of domains and domain walls, defining their possible trajectories and certain values of the area heating or local anisotropy modulation and the rotation angles. The experimental results and the theoretical model demonstrate a thermal origin of the laser-induced effect in this type of magnetic domain structure. Full article
Show Figures

Figure 1

10 pages, 2300 KB
Article
Universal Logic-in-Memory Gates Using Reconfigurable Silicon Transistors
by Sunhyuk Kim, Nahyeon Kim, Yaeyeon Ko and Doohyeok Lim
Micromachines 2025, 16(12), 1348; https://doi.org/10.3390/mi16121348 - 28 Nov 2025
Viewed by 497
Abstract
This study aims to implement universal logic gates using polarity control within a single silicon transistor structure. For this purpose, a reconfigurable transistor based on a p-i-n structure featuring two polarity gates (PGs) and one control gate was proposed, and its electrical characteristics [...] Read more.
This study aims to implement universal logic gates using polarity control within a single silicon transistor structure. For this purpose, a reconfigurable transistor based on a p-i-n structure featuring two polarity gates (PGs) and one control gate was proposed, and its electrical characteristics and logic-in-memory (LIM) circuit operations were analyzed via two-dimensional technology computer-aided design simulations. The proposed device could be perfectly reconfigured into p-channel or n-channel modes because virtual doping effects could be induced according to the polarity of the PG voltage. Moreover, based on the positive feedback and latch-up phenomena, a steep subthreshold swing of approximately 1 mV/dec and a high ON/OFF current ratio of the order of 1010 were achieved. Building on these characteristics, we successfully verified NAND LIM operation in the p-channel mode and NOR LIM operation in the n-channel mode by connecting two of the proposed devices in parallel. The reconfigurable silicon transistor proposed in this study could perform both NAND and NOR LIM operations while sharing the same device structure and can be expected to play a key role in implementing high-density, low-power LIM systems in the future. Full article
(This article belongs to the Section D1: Semiconductor Devices)
Show Figures

Figure 1

8 pages, 4158 KB
Article
A Wideband Multi-Linear Polarization Reconfigurable Antenna with Artificial Magnetic Conductor
by Shixing Yu, Kaisheng Yang and Yingmeng Zhang
Electronics 2025, 14(21), 4170; https://doi.org/10.3390/electronics14214170 - 25 Oct 2025
Viewed by 617
Abstract
This paper presents a wideband multi-linear polarization reconfigurable antenna featuring five linear polarization states. We use the semi-ellipsoidal dipoles as the main radiators to broaden the operating bandwidth; the states of linear polarizations are switched by controlling the ON/OFF of PIN diodes between [...] Read more.
This paper presents a wideband multi-linear polarization reconfigurable antenna featuring five linear polarization states. We use the semi-ellipsoidal dipoles as the main radiators to broaden the operating bandwidth; the states of linear polarizations are switched by controlling the ON/OFF of PIN diodes between feeding pads and dipoles to excite a specific pair of dipoles. A 7 × 7 AMC array is added below the antenna to obtain a small height of 0.14 λ00 is the free space wavelength at the operating frequency). Prototypes of the designed antenna are fabricated, and experimental results illustrate that the proposed antenna yields an impedance bandwidth of 50% (from 2.25 GHz to 3.75 GHz) for all polarization states, stable radiation patterns, and low cross-polarization within the operating band. In addition, the maximum gain reaches 8.1 dBi. The proposed five linear-polarized switching antenna with wide band and low-profile features can be applied in reconfigurable conformal array antennas, thus flexibly realizing linear polarization reconfiguration of conformal arrays in radar and military platforms. Full article
Show Figures

Figure 1

24 pages, 4193 KB
Article
Reconfigurable Circularly Polarized Phased Array
by Eduardo S. Silveira, Fúlvio F. Oliveira, Bernardo M. Fabiani, Juner M. Vieira, Daniel B. Ferreira and Daniel C. Nascimento
Electronics 2025, 14(21), 4159; https://doi.org/10.3390/electronics14214159 - 24 Oct 2025
Viewed by 2767
Abstract
This paper presents the design, construction, and tests of a polarization-reconfigurable phased array antenna. The proposed array allows the polarization at the main lobe maximum direction to be electronically reconfigured between right-hand (RHCP) and left-hand circular polarization (LHCP). Single-fed microstrip antennas, each with [...] Read more.
This paper presents the design, construction, and tests of a polarization-reconfigurable phased array antenna. The proposed array allows the polarization at the main lobe maximum direction to be electronically reconfigured between right-hand (RHCP) and left-hand circular polarization (LHCP). Single-fed microstrip antennas, each with four tunable varicap diodes, are employed in the phased array to achieve a low axial ratio (AR) at the steering angles. Special attention is given to the microstrip antenna design and varicap modeling, which involves the use of measured data and search algorithms running in an electromagnetic/circuit co-simulation environment. To illustrate the proposed approach, a six-element linear phased array at 2.2 GHz has been built and tested in an anechoic chamber. The experimental results demonstrate an AR below 1 dB in both RHCP and LHCP states over a wide range of steering angles, and even in a multibeam configuration, validating our design method. Full article
(This article belongs to the Section Microwave and Wireless Communications)
Show Figures

Figure 1
