Search Results (1,378)

The paper explores the application of heat pipes in thermal management for efficient heat dissipation, particularly in electrical equipment with high heat loads. Heat pipes are devices that transfer heat with high efficiency through the phase transition of the working medium (e.g., water, alcohol, ammonia) between the evaporator and the condenser, while they have no moving parts and are distinguished by their simplicity of construction. Different types of heat pipes—gravity, capillary, and closed loop (thermosiphon loop)—are suitable according to specific applications and requirements for the working position, temperature range, and condensate return transport. An example of an effective application is the removal of heat from the internal winding of a static energy converter transformer, where the use of a gravity heat pipe has enabled effective cooling even through epoxy insulation and kept the winding temperature below 80 °C. Other applications include the cooling of mounting plates, power transistors, and airtight cooling of electrical enclosures with the ability to dissipate lost thermal power in the order of 102 to 103 W. A significant advantage of heat pipes is also the ability to dust-tightly seal equipment and prevent the build-up of dirt, thereby increasing the reliability of the electronics. In the field of environmental technology, systems have been designed to reduce the radiant power of fireplace inserts by up to 40%, or to divert their heat output of up to about 3 kW into hot water storage tanks, thus optimising the use of the heat produced and preventing overheating of the living space. The use of nanoparticles in the working substances (e.g., Al₂O₃ in water) makes it possible to intensify the boiling process and thus increase the heat transfer intensity by up to 30% compared to pure water. The results of the presented research confirm the versatility and high efficiency of the use of heat pipes for modern cooling requirements in electronics and environmental engineering. Full article

A radiation-hardened RCC (Ring Choke Converter) isolated power supply design is proposed, which provides an innovative solution to the challenge of providing stable power to the PWM controller in DC-DC converters under nuclear radiation environments. By optimizing circuit architecture and component selection, and incorporating transformer isolation and dynamic parameter compensation technology, the RCC maintains an 8.9 V output voltage after exposure to neutron irradiation of 3 × 10¹³ n/cm², significantly outperforming conventional designs with a failure threshold of 1 × 10¹³ n/cm². For the first time, the degradation mechanisms of VDMOS devices under neutron irradiation during switching operations are systematically revealed: a 32–36% reduction in threshold voltage (with the main power transistor dropping from 5 V to 3.4 V) and an increase in on-resistance. Based on these findings, a selection criterion for power transistors is established, enabling the power supply to achieve a 2 W output in extreme environments such as nuclear power plant monitoring and satellite systems. The results provide a comprehensive solution for radiation-hardened power electronics systems, covering device characteristic analysis to circuit optimization, with significant engineering application value. Full article

This paper presents a novel open-loop modulation and control strategy for bidirectional, multi-source/load parallel AC-link power converters. While these converters offer advantages such as high-frequency operation and flexible power conversion capabilities, their application to complex systems such as nanogrids presents significant control challenges. Traditional control methods often struggle to efficiently manage power flow and charging/discharging processes, especially when dealing with multiple sources and loads of varying characteristics. To address these issues, this paper proposes a new control strategy that enables intelligent source and load selection while maintaining fast charging and discharging times. Simulation results demonstrate the effectiveness of the proposed approach. This research contributes to advancing the state-of-the-art in power electronics by providing a foundation for improved control of complex power conversion systems for renewable energy applications. Full article

Plant microbial fuel cells (PMFCs) represent an eco-friendly solution for generating clean energy by converting biological processes into electricity. This work presents the first integration of tin sulfide (SnS)-coated 304 stainless steel (SS304) electrodes into Aloe vera-based PMFCs for enhanced energy harvesting. SnS thin films were obtained via chemical bath deposition and screen printing, followed by thermal treatment. X-ray diffraction (XRD) revealed a crystal size of 15 nm, while scanning electron microscopy (SEM) confirmed film thicknesses ranging from 3 to 13.75 µm. Over a 17-week period, SnS-coated SS304 electrodes demonstrated stable performance, with open circuit voltages of 0.6–0.7 V and current densities between 30 and 92 mA/m², significantly improving power generation compared to uncoated electrodes. Polarization analysis indicated an internal resistance of 150 Ω and a power output of 5.8 mW/m². Notably, the system successfully charged a 15 F supercapacitor with 8.8 J of stored energy, demonstrating a practical proof-of-concept for powering low-power IoT devices and advancing PMFC applications beyond power generation. Microbial biofilm formation, observed via SEM, contributed to enhanced electron transfer and system stability. These findings highlight the potential of PMFCs as a scalable, cost-effective, and sustainable energy solution suitable for industrial and commercial applications, contributing to the transition toward greener energy systems. These incremental advances demonstrate the potential of combining low-cost electrode materials and energy storage systems for future scalable and sustainable bioenergy solutions. Full article

For power electronic transformer (PET) based Modular Multilevel DC-Link Based T-type Converters (MMDTC) with Double Active Bridges (DABs) (namely DABs-based MMDTC-PET), the sub-module capacitor voltages exhibit relatively large ripples. To reduce the voltage ripple of sub-module capacitors, this paper proposes a novel MMDTC-PET structure that utilizes the Three-Port Active Bridges (TABs) to replace the DABs as the isolation stage (TABs-based MMDTC-PET). When the two full bridges of the TAB on the primary side adopt identical phase-shift modulation, the two sub-module capacitors within the upper and lower arms form a parallel connection. This configuration endows the sub-module capacitors with switched-capacitor characteristics, suppressing voltage ripple in the sub-module capacitors and enabling power ripple flow to the secondary side. Meanwhile, by leveraging the characteristic that the AC power components of the upper and lower arm sub-modules have equal amplitudes but opposite phases, these AC power components are mutually canceled on the secondary side of the TAB. Simulation and experimental results verify the effectiveness of the proposed scheme. Full article

With the increasing demands of the grid on power electronic converters, active neutral-point-clamped (ANPC) converters have been widely adopted due to their flexible modulation strategies and wide-range power regulation capabilities. To address grid-integration testing requirements for ANPC converters, this paper comparatively studies three electromagnetic transient (EMT) modeling approaches: switch-state prediction method (SPM), associated discrete circuit (ADC), and time-averaged method (TAM). Steady-state and transient simulations reveal that the SPM model achieves the highest accuracy (error ≤ 0.018%), while the TAM-based switching function model optimizes the efficiency–accuracy trade-off with 6.4× speedup versus traditional methods and acceptable error (≤2.62%). Consequently, the TAM model is implemented in a real-time hardware-in-the-loop (HIL) platform. Validation under symmetrical/asymmetrical grid faults confirms both the model’s efficacy and the controller’s robust fault ride-through capability. Full article

In the event of power outages caused by natural disasters, accidents, or other emergencies, outdoor emergency lighting systems play a critical role in providing illumination to maintain spatial orientation, facilitate evacuation procedures, and help individuals avoid hazardous areas or locate safe shelters. Compared to traditional lighting technologies, LED-based outdoor emergency lighting offers several advantages, including compact size, long operational lifespan, low energy consumption, high safety, resistance to breakage, and the absence of chemical residue or pollution. These characteristics align with contemporary trends in environmental sustainability and energy efficiency. This study proposes a novel LED driver circuit architecture for outdoor emergency lighting applications. The primary circuit topology is based on an improved buck-boost converter integrated with a flyback converter, forming a hybrid buck-boost-flyback configuration. The proposed circuit is capable of recycling the energy stored in the transformer’s leakage inductance, thereby enhancing overall power conversion efficiency. A 12 W (20 V/0.6 A) prototype LED driver circuit was designed and implemented to validate the performance of the proposed system. Experimental measurements, including waveform analysis and efficiency evaluation, demonstrate that the driver circuit achieves a high efficiency exceeding 91%. These results confirm the practical feasibility and effectiveness of the proposed electronic driver for LED-based outdoor emergency lighting applications. Full article

Intrinsically stretchable polymer ionic conductors (PICs) hold significant application prospects in fields such as flexible sensors, energy storage devices, and wearable electronic devices, serving as promising solutions to prevent mechanical failure in flexible electronics. However, the development of PICs is hindered by an inherent trade-off between mechanical robust and electrical properties. Cellulose, renowned for its high mechanical strength, tunable chemical groups, abundant resources, excellent biocompatibility, and remarkable recyclability and biodegradability, offers a powerful strategy to decouple and enhance mechanical and electrical properties. This review presents recent advances in cellulose-based polymer ionic conductors (CPICs), which exhibit exceptional design versatility for flexible electrodes and strain sensors. We systematically discuss optimization strategies to improve their mechanical properties, electrical conductivity, and environmental stability while analyzing the key factors such as sensitivity, gauge factor, strain range, response time, and cyclic stability, where strain sensing refers to a technique that converts tiny deformations (i.e., strain) of materials or structures under external forces into measurable physical signals (e.g., electrical signals) for real-time monitoring of their deformation degree or stress state. Full article

With the development of embedded electronic devices, energy consumption has become a significant design issue in modern systems-on-a-chip. Conventional SRAMs cannot maintain data after powering turned off, limiting their use in applications such as battery-powered smartphone devices that require non-volatility and no leakage current. RRAM devices are recently used extensively in applications such as self-charging wireless sensor networks and storage elements, owing to their intrinsic non-volatility and multi-bit capabilities, making them a potential candidate for mitigating the von Neumann bottleneck. We propose a new RRAM-based hybrid memristor model incorporated with a permanent magnet. The proposed design (1T2R) was simulated in Cadence Virtuoso with a 1.5 V power supply, and the finite-element approach was adopted to simulate magnetization. This model can retain the data after the power is off and provides fast power on/off transitions. It is possible to charge a smartphone battery without an external power source by utilizing a portable charger that uses magnetic induction to convert mechanical energy into electrical energy. In an embedded smartphone self-charging device this addresses eco-friendly concerns and lowers environmental effects. It would lead to the development of magnetic field-assisted embedded portable electronic devices and open the door to new types of energy harvesting for RRAM devices. Our proposed design and simulation results reveal that, under usual conditions, the magnet-based device provide a high voltage to charge a smartphone battery. Full article

This article investigates the zonotope-based state estimation for boost converter system with Markov jump process. DC-DC boost converters are pivotal in modern power electronics, enabling renewable energy integration, electric vehicle charging, and microgrid operations by elevating low input voltages from sources like photovoltaics to stable high outputs. However, their nonlinear dynamics and sensitivity to uncertainties/disturbances degrade control precision, driving research into robust state estimation. To address these challenges, the boost converter is modeled as a Markov jump system to characterize stochastic switching, with time delays, disturbances, and noises integrated for a generalized discrete-time model. An adaptive event-triggered mechanism is adopted to administrate the data transmission to conserve communication resources. A zonotopic set-membership estimation design is proposed, which involves designing an observer for the augmented system to ensure $H_{\infty }$ performance and developing an algorithm to construct zonotopes that enclose all system states. Finally, numerical simulations are performed to verify the effectiveness of the proposed approach. Full article

Modern utility systems are being heavily strained by rising energy consumption and dynamic load variations, which have an impact on the quality and reliability of the supply. Harmonic injection and reactive power imbalance are caused by the widespread divergence. Power quality (PQ) issues are mostly caused by renewable energy powered by power electronic converters that are integrated into the utility grid, despite the fact that a range of industries require high-quality power to function properly at all times. Several solutions have been created, but continuing efforts and newly improved solutions are needed to solve these problems by operating according to various international standards. Distributed Static Compensator (DSTATCOM) was created in the proposed model to enhance PQ in a standard bus system. A standard bus system using the DSTATCOM model was initially developed. A real-time dataset was gathered while applying various PQ disturbance conditions. A deep learning controller was created using this generated dataset, which examined the bus voltages to generate the DSTATCOM pulse signal. Two case studies, the IEEE 13 bus and the IEEE 33 bus system, were used to analyze the proposed work. Performance of the proposed deep learning controller was verified in various situations, including interruption, swell, harmonics, and sag. The outcome of THD in the IEEE 13 bus is 0.09% at the sag period, 0.08% at the swell period, 0.01% at the interruption period, and in the IEEE 33 bus was 1.99% at the sag period, 0.44% at the swell period, and 0.01% at the interruption period. Also, the effectiveness of the proposed deep learning controller was examined and contrasted with current methods like K-Nearest Neighbor (KNN) and Feed Forward Neural Network (FFNN). The validated results show that the suggested method provides an efficient mitigation mechanism, making it suitable for all cases involving PQ issues. Full article

We present a single-slab metasurface that converts a normally incidental linearly polarized wave into either right- or left-handed circular polarization (RHCP/LHCP) through a simple ${90}^{\circ }$ mechanical rotation. Each unit cell comprises two L-shaped metallic resonators placed on the opposite faces of a low-permittivity substrate. Operating in transmission mode, the linear-to-circular (LTC) converter does not require any active electronic components. The geometry is optimized by using full-wave simulations to maximize the conversion up to 26% relative bandwidth with polarization conversion efficiency up to 65%, and insertion loss below 1.3 dB. Power balance analysis confirms low-loss, impedance-matched behavior. A scaled prototype fabricated from AWG-25 steel wires validates the model: experimental measurements closely reproduce the simulated bandwidth and demonstrate robust handedness switching. Because the resonance frequency depends primarily on resonator length and unit-cell pitch and thickness, the design can be retuned across the microwave spectrum through straightforward geometrical scaling. These results suggest that mechanical rotation could provide a simple and reliable alternative to electronic tuning in reconfigurable circular polarizers. Full article

This paper presents an integrated approach for optimizing the performance of a 36-pulses converter system by using artificial intelligence (AI) techniques to be included in a Supervisory Control and Data Acquisition (SCADA) environment. The focus of the proposal is on enhancing harmonic reduction through intelligent adjustment of switching angles and coordinated control of the reinjection transformer included in the power converter topology. A key component of the proposed methodology involves a simulation-based process to determine optimal firing angles (${\mathit{\alpha }}_1$, ${\mathit{\alpha }}_2$, and ${\mathit{\alpha }}_3$), based on Selective Harmonic Elimination (SHE) theory, that minimize Total Harmonic Distortion (THD). Using MATLAB with Simulink and PLECS models, a parametric sweep of the firing angles, generating a comprehensive dataset of THD outcomes. This dataset, consisting of THD evaluations across fine-grained angle variations, serves as the training foundation for supervised machine learning models—specifically, neural network regressors—that approximate the nonlinear mapping between firing angles and harmonic distortion. These predictive models are then employed as surrogates to estimate THD rapidly and guide the selection of optimal switching angles in real time without requiring iterative numerical solvers. Optimization heuristics and predictive models are then deployed to dynamically adapt system parameters in real time under varying load conditions. The proposed method demonstrates significant improvements in power quality and operational reliability, highlighting the potential of AI-assisted SCADA systems in advanced power electronics applications. Implementation results performed on a 36-pulses voltage source converter prototype are included to illustrate the appropriateness of the proposal. Full article

Traditional methods for evaluating power electronic converter efficiency heavily rely on simulations and often lack theoretical support, which can lead to inaccuracies and limit effective design optimization. To address these shortcomings, this paper proposes a modal segment integration method based on a device loss model. The analysis begins with the operating principles of the proposed circuit topology. A detailed power loss model is then established and applied to representative operating modes. Using the modal segment integration method, the total loss over a full operating cycle is calculated. Theoretical analysis estimates the system efficiency exceeds 98%. To validate the proposed method, a 1 kW experimental prototype with a 400 V DC output is built. The results show that the maximum error between the theoretical and experimental efficiency is less than 0.4%. This method offers a reliable theoretical basis for efficiency evaluation of three-level converter topologies and supports the structural design and performance optimization of power electronic systems. Full article

This paper presents a proportional–integral (PI) control-based charging strategy that introduces a ripple component into the constant-current (CC) charging profile to regulate battery temperature and improve long-term performance. The proposed method is implemented within an on-board charger (OBC), where the ripple amplitude is adaptively adjusted based on battery temperature and internal resistance. While most prior studies focus on electrochemical characteristics, this work highlights the importance of analyzing current profiles from a power electronics and converter control perspective. The ripple magnitude is controlled in real time through gain tuning of the PI current controller, allowing temperature-aware charging. To validate the proposed method, experiments were conducted using a 11 kW OBC system and 70 Ah lithium-ion battery to examine the correlation between ripple amplitude and battery temperature rise, as well as its impact on internal resistance. The control strategy was evaluated under various thermal conditions and shown to be effective in mitigating temperature-related degradation through ripple-based modulation. Full article
