Search Results (55)

This study explores the application of 3D printing as a strategic tool in engineering education and robotics development. An embedded control system for a 3D-printed MK2 manipulator is implemented, including an Arduino microcontroller, servo motors, an analog joystick interface, and an LCD, with software developed in Arduino IDE. The design uses PLA material and a modular architecture for flexibility and extensibility. The platform is applied in laboratory training to develop algorithmic thinking and engineering creativity, demonstrating the potential of 3D printing as an integrated educational and engineering tool. Full article

Mouthguards are recommended for all sports that may cause injuries to the head and oral cavity. Custom mouthguards, made conventionally in the thermoforming process from ethylene vinyl acetate (EVA), face challenges with thinning at the incisor area during the process. In contrast, additive manufacturing (AM) processes enable the precise reproduction of the dimensions specified in a computer-aided design (CAD) model. The potential use of filament extrusion materials in the fabrication of custom mouthguards has not yet been explored in comparative studies. Our research aimed to compare five commercially available filaments for the material extrusion (MEX) also known as fused deposition modelling (FDM) of custom mouthguards using a desktop 3D printer. Samples made using Copper 3D PLActive, Spectrum Medical ABS, Braskem Bio EVA, DSM Arnitel ID 2045, and NinjaFlex were compared to EVA Erkoflex, which served as a control sample. The samples underwent tests for ultimate tensile strength (UTS), split Hopkinson pressure bar (SHPB) performance, drop-ball impact, abrasion resistance, absorption, and solubility. The results showed that Copper 3D PLActive and Spectrum Medical ABS had the highest tensile strength. DSM Arnitel ID 2045 had the highest dynamic property performance, measured with the SHPB and drop-ball tests. On the other hand, NinjaFlex exhibited the lowest abrasion resistance and the highest absorption and solubility. DSM Arnitel ID 2045’s absorption and solubility levels were comparable to those of EVA, but had significantly lower abrasion resistance. Ultimately, DSM Arnitel ID 2045 is recommended as the best filament for 3D-printing mouthguards. The properties of this biocompatible material ensure high-impact energy absorption while maintaining low fluid sorption and solubility, supporting its safe intra-oral application for mouthguard fabrication. However, its low abrasion resistance indicated that mouthguards made from this material may need to be replaced more frequently. Full article

This study presents the results of optimizing FDM 3D printing parameters (layer height deposited in one pass—L_h and filling density—I_d) to enhance the mechanical performance of three-point bending specimens made from PETG and recycled PETG (rPETG). The objectives of the study are to investigate the influence of variable parameters (L_h and I_d) on the three-point bending behavior of additively manufactured specimens by thermoplastic extrusion of PETG and rPETG. It is also aims to optimize the manufacturing parameters to maximize mechanical performance, but also to evaluate the potential of using rPETG in mechanical engineering applications. The materials analyzed in this study are PETG and recycled PETG (rPETG), in the context of promoting the concept of circular economy. Using the QIDI Q1 Pro 3D printer, and the variable parameters of FDM, L_h = (0.10; 0.15; 0.20) mm and I_d = (50; 75; 100)%, 90 three-point bending specimens (45 from PETG and 45 from rPETG) were additively manufactured. To determine the mechanical strength characteristics under three-point bending stress, all 90 additively manufactured specimens were tested in three-point bending using a Barrus White 20 kN universal testing machine. The maximum bending stress is influenced by the two considered variable parameters of FDM (L_h and I_d), the parameter with the greater impact being I_d. Comparing the results of the maximum bending stresses of the additively manufactured specimens made of PETG and rPETG using the optimal parameters, it was found that the maximum bending stresses are higher in the case of the rPETG specimens, which highlights the potential of using recycled plastics in mechanical engineering applications. Full article

Background/Objectives: Hyaluronic acid (HA) is a natural substance in the human body with anti-inflammatory and healing properties that help repair bone by supporting cell growth, blood vessel formation, and tissue structure. A common complication after minimally invasive surgery is delayed bone healing in osteotomies. HA may offer a useful treatment to support faster recovery. Methods: This systematic review followed PRISMA guidelines and was pre-registered in PROSPERO (ID: CRD420250654929). Searches were conducted in PubMed, EbscoHost, Web of Science, and Scopus up to 25 January 2025. Studies from the last five years on HA and bone healing were included. The main outcomes were faster bone repair and improved regeneration. Study quality was assessed using the OCEBM, ROBINS-I, and GRADE tools. Results: Out of 96 studies, 9 met the inclusion criteria. HA, especially when combined with other materials or stem cells, helped bone repair by supporting new bone formation. Materials like 3D-printed scaffolds, hydrogels, and meshes showed good results in bone healing. However, differences in the study design made direct comparison difficult. Conclusions: Hyaluronic acid shows promise for bone repair, especially in combination with other materials. More standardized clinical trials are needed to confirm its effectiveness and define how best to use it in minimally invasive surgeries. Full article

Freeform carbon fibres were 3D-printed from CH₃OH:H₂O mixtures using hyperbaric-pressure laser chemical vapour deposition (HP-LCVD). The experiment overlapped a region of known diamond growth, with the objective of depositing diamond-like carbon without the use of plasmas or hot filaments. A high-pressure regime was investigated for the first time through the precursor’s critical point. Seventy-two C-fibres were grown from 13 different CH₃OH:H₂O mixtures at total pressures between 7.8 and 180 bar. Maximum steady-state axial growth rates of 14 µm/s were observed. Growth near the critical point was suppressed, ostensibly due to thermal diffusion and selective etching. In addition to nanostructured graphite, various carbon allotropes were synthesised at/within the outer surface of the fibres, including diamond-like carbon, graphite polyhedral crystal, and tubular graphite cones. Several allotropes were oversized compared to structures previously reported. Raman spectral pressure–temperature (P-T) maps and a pictorial P-T phase diagram were compiled over a broad range of process conditions. Trends in the Raman I_D/I_G and I_2D/I_G intensity ratios were observed and regions of optimal growth for specific allotropes were identified. It is intended that this work provide a basis for others in optimising the growth of specific carbon allotropes from methanol using HP-LCVD and similar CVD processes. Full article

This study investigates the complex relationships between process parameters and material properties in FDM-based 3D-printed biocomposites using explainable AI techniques. We examine the effects of key parameters, including biochar content (BC), layer thickness (LT), raster angle (RA), infill pattern (IP), and infill density (ID), on the tensile, flexural, and impact strengths of FDM-printed pure PLA and biochar-reinforced PLA composites. Mechanical testing was used to measure the ultimate tensile strength (UTS), flexural strength (FS), and impact strength (IS) of the 3D-printed samples. The extreme gradient boosting (XGB) algorithm was used to build a predictive model based on the data collected from mechanical testing. Shapley Additive Explanations (SHAP), Local Interpretable Model-Agnostic Explanations (LIME), and Partial Dependence Plot (PDP) techniques were implemented to understand the effects of the interactions of key parameters on mechanical properties such as UTS, FS, and IS. Prediction by XGB was accurate for UTS, FS, and IS, with R-squared values of 0.96, 0.95, and 0.85, respectively. The explanation showed that infill density has the most significant influence on UTS and FS, with SHAP values of +2.75 and +5.8, respectively. BC has the most significant influence on IS, with a SHAP value of +2.69. PDP reveals that using 0.3 mm LT and 30° RA enhances mechanical properties. This study contributes to the field of the application of artificial intelligence in additive manufacturing. A novel approach is presented in which machine learning and XAI techniques such as SHAP, LIME, and PDP are combined and used not only for optimization but also to provide valuable insights about the interaction of the process parameters with mechanical properties. Full article

Image watermarking often involves the use of handheld devices under non-structured conditions for authentication purposes, particularly in the print-cam process where smartphone cameras are used to capture watermarked printed images. However, these images frequently suffer from perspective distortions, making them unsuitable for automated information detection. To address this issue, Cam-Unet, an end-to-end neural network architecture, is presented to predict the mapping from distorted images to rectified ones, specifically tailored for print-cam challenges applied to ID images. Given the limited availability of large-scale real datasets containing ground truth distortions, we created an extensive synthetic dataset by subjecting undistorted images to print-cam attacks. The proposed network is trained on this dataset, using various data augmentation techniques to improve its generalization capabilities. Accordingly, this paper presents an image watermarking system for the print-cam process. The approach combines Fourier transform-based watermarking with Cam-Unet as perspective distortion correction. Results show that the proposed method outperforms existing watermarking approaches typically employed to counter print-cam attacks and achieves an optimal balance between efficiency and cost-effectiveness. Full article

In this study, Silicon Carbide (SiC) nanoparticle-based serigraphic printing inks were formulated to fabricate highly sensitive and wide temperature range printed thermistors. Inter-digitated electrodes (IDEs) were screen printed onto Kapton^® substrate using commercially avaiable silver ink. Thermistor inks with different weight ratios of SiC nanoparticles were printed atop the IDE structures to form fully printed thermistors. The thermistors were tested over a wide temperature range form 25 °C to 170 °C, exhibiting excellent repeatability and stability over 15 h of continuous operation. Optimal device performance was achieved with 30 wt.% SiC-polyimide ink. We report highly sensitive devices with a TCR of −0.556%/°C, a thermal coefficient of 502 K ($\beta$-index) and an activation energy of $0.08$ eV. Further, the thermistor demonstrates an accuracy of ±1.35 °C, which is well within the range offered by commercially available high sensitivity thermistors. SiC thermistors exhibit a small 6.5% drift due to changes in relative humidity between 10 and 90%RH and a 4.2% drift in baseline resistance after 100 cycles of aggressive bend testing at a 40° angle. The use of commercially available low-cost materials, simplicity of design and fabrication techniques coupled with the chemical inertness of the Kapton^® substrate and SiC nanoparticles paves the way to use all-printed SiC thermistors towards a wide range of applications where temperature monitoring is vital for optimal system performance. Full article

Flexible electronics, also referred to as printable electronics, represent an interesting technology for implementing electronic circuits via depositing electronic devices onto flexible substrates, boosting their possible applications. Among all flexible electronics, interdigitated electrodes (IDEs) are currently being used for different sensor applications since they offer significant benefits beyond their functionality as capacitors, like the generation of high output voltage, fewer fabrication steps, convenience of application of sensitive coatings, material imaging capability and a potential of spectroscopy measurements via electrical excitation frequency variation. This review examines the role of IDEs in printed and flexible electronics since they are progressively being incorporated into a myriad of applications, envisaging that the growth pattern will continue in the next generations of flexible circuits to come. Full article

Given the current maturity of printed technologies, Organic Thin-Film Transistors (OTFT) still show high initial variability, which can be beneficial for its exploitation in security applications. In this work, the process-related variability and aging of commercial OTFTs have been characterized to evaluate the feasibility of OTFTs-based Physical Unclonable Functions (PUFs) implementation. For our devices, I_D-based PUFs show good uniformity and uniqueness. However, PUFs’ reliability could be compromised because of the observed transient and aging effects in the OTFTs, which could hinder the reproducibility of the generated fingerprints. A systematic study of the aging of OTFTs has been performed to evaluate the PUFs’ reliability. Our results suggest that the observed transient and aging effects could be mitigated so that the OTFTs-based PUFs’ reliability could be improved. Full article

This paper reports a high-performance humidity sensor made using a novel cellulose nanofiber (CNF)–silver nanoparticle (AgNP) sensing material. The interdigital electrode pattern was printed via reverse-offset printing using Ag nano-ink, and the sensing layer on the printed interdigitated electrode (IDE) was formed by depositing the CNF-AgNP composite via inkjet printing. The structure and morphology of the CNF-AgNP layer are characterized using ultraviolet–visible spectroscopy, an X-ray diffractometer, field emission scanning electron microscopy, energy-dispersive X-ray analysis, and transmission electron microscopy. The humidity-sensing performance of the prepared sensors is evaluated by measuring the impedance changes under the relative humidity variation between 10 and 90% relative humidity. The CNF-AgNP sensor exhibited very sensitive and fast humidity-sensing responses compared to the CNF sensor. The electrode distance effect and the response and recovery times are investigated. The enhanced humidity-sensing performance is reflected in the increased conductivity of the Ag nanoparticles and the adsorption of free water molecules associated with the porous characteristics of the CNF layer. The CNF-AgNP composite enables the development of highly sensitive, fast-responding, reproducible, flexible, and inexpensive humidity sensors. Full article

The performance, stability, and lifespan of lithium-ion batteries are influenced by variations in the flow of lithium ions with temperature. In electric vehicles, coolants are generally used to maintain the optimal temperature of the battery, leading to an increasing demand for temperature and humidity sensors that can prevent leakage and short circuits. In this study, humidity and temperature sensors were fabricated on a pouch film of a pouch-type battery. IDE electrodes were screen-printed on the pouch film and humidity- and temperature-sensing materials were printed using a dispenser process. Changes in the capacitance of the printed Ag-CNF film were used for humidity sensing, while changes in the resistance of the printed PEDOT:PSS film were used for temperature sensing. The two sensors were integrated into a single electrode for performance evaluation. The integrated sensor exhibited a response of ΔR ≈ 0.14 to temperature variations from 20 °C to 100 °C with 20% RH humidity as a reference, and a response of ΔC ≈ 2.8 to relative humidity changes from 20% RH to 80% RH at 20 °C. The fabricated integrated sensor is expected to contribute to efficient temperature and humidity monitoring applications in various pouch-type lithium-ion batteries. Full article

Traditional printed electronics processes have recently been utilized within 3D-printed structures where components and interconnects are introduced during manufacturing disruptions. The dielectric performance of 3D-printed materials has a low-resolution problem, and many technologies have been proposed for direct printing on a 3D curved surface or structure. This paper reports a humidity sensor fabricated with a 3D-printed electrode and cellulose nanofibers on a curved surface. The electrode part of an interdigital electrode (IDE) sensor is printed on a flat glass substrate and a 3D-curved glass substrate using a double blanket reverse offset. Subsequently, a cellulose nanofiber emulsion is coated onto the IDE pattern as a sensing layer with a dispenser. The electrical impedance of the sensor is measured with the relative humidity (RH) changes between 10% and 90% RH. The sensor demonstrates a high repeatability and sensitivity, even on a 3D curved substrate. This technology provides a promising method to integrate humidity sensors and 3D deformable surfaces. Full article

The cartilaginous nasal septum is integral to the overall structure of the nose. Developing our an-atomic understanding of the septum will improve the planning and techniques of septal surgeries. While the basic dimensions of the septum have previously been described, the average shape in the sagittal plane has yet to be established. Furthermore, determining the average shape allows for the creation of a mean three-dimensional (3D) septum model. To better understand the average septal shape, we dissected septums from 40 fresh human cadavers. Thickness was measured across pre-defined points on each specimen. Image processing in Photoshop was used to superimpose lateral photographs of the septums to determine the average shape. The average shape was then combined with thickness data to develop a 3D model. This model may be utilized in finite elemental analyses, creating theoretical results about septal properties that are more translatable to real-world clinical practice. Our 3D septum also has numerous applications for 3D printing. Realistic models can be created for educational or surgical planning purposes. In the future, our model could also serve as the basis for 3D-printed scaffolds to aid in tissue regeneration to reconstruct septal defects. The model can be viewed at the NIH 3D model repository (3DPX ID: 020598, Title: 3D Nasal Septum). Full article

This study presents graphene inks produced through the liquid-phase exfoliation of graphene flakes in water using optimized concentrations of dispersants (gelatin, triton X-100, and tween-20). The study explores and compares the effectiveness of the three different dispersants in creating stable and conductive inks. These inks can be printed onto polyethylene terephthalate (PET) substrates using an aerosol jet printer. The investigation aims to identify the most suitable dispersant to formulate a high-quality graphene ink for potential applications in printed electronics, particularly in developing chemiresistive sensors for IoT applications. Our findings indicate that triton X-100 is the most effective dispersant for formulating graphene ink (GTr), which demonstrated electrical conductivity (4.5 S·cm⁻¹), a high nanofiller concentration of graphene flakes (12.2%) with a size smaller than 200 nm (<200 nm), a low dispersant-to-graphene ratio (5%), good quality as measured by Raman spectroscopy (I_D/I_G ≈ 0.27), and good wettability (θ ≈ 42°) over PET. The GTr’s ecological benefits, combined with its excellent printability and good conductivity, make it an ideal candidate for manufacturing chemiresistive sensors that can be used for Internet of Things (IoT) healthcare and environmental applications. Full article
