This paper presents a new compact and efficient first-order all-pass filter in voltage mode based on a second-generation voltage conveyor, along with two resistors, and a capacitor. This circuit delivers an all-pass response from the low-impedance node and eliminates the need for a voltage buffer in cascading configurations. A thorough non-ideal analysis, accounting for parasitic impedances and the non-ideal gains of the active module, shows negligible effects on the filter performance. Furthermore, a sensitivity analysis with respect to both active and passive components further validates the robustness of the design. The proposed all-pass filter is validated by Cadence PSPICE simulations, utilizing 0.18 µm TSMC CMOS process parameter and ±0.9 V power supply, including Monte Carlo analysis and temperature variations. Additionally, experimental validation is carried out using commercially available IC AD844, showing great consistency between theoretical and experimental results. Resistor-less realization of the proposed filter provides tunability feature. A quadrature sinusoidal oscillator is presented to validate the proposed structure. The introduced circuit provides a simple and effective solution for low-power and compact analog signal processing applications. Full article

The rapid evolution of modern power systems, driven by the large-scale integration of renewable energy sources and the emergence of smart grids, presents new challenges in maintaining grid stability, power quality, and control reliability. As critical interfacing elements, three-phase pulse width modulation (PWM) converters must now ensure resilient and efficient operation under increasingly adverse and dynamic grid conditions. This paper proposes an adaptive neural network-based virtual flux (VF) estimator for sensorless predictive direct power control (PDPC) of PWM converters under nonideal grid voltage conditions. The proposed estimator is realized using an adaptive linear neuron (ADALINE) configured as a quadrature signal generator, offering robustness against grid voltage disturbances such as voltage unbalance, DC offset and harmonic distortion. In parallel, a PDPC scheme based on the extended pq theory is developed to reject active-power oscillations and to maintain near-sinusoidal grid currents under unbalanced conditions. The resulting VF-based PDPC (VF-PDPC) strategy is validated via real-time simulations on the OPAL-RT platform. Comparative analysis confirms that the ADALINE-based estimator surpasses conventional VF estimation techniques. Moreover, the VF-PDPC achieves superior performance over conventional PDPC and extended pq theory-based PDPC strategies, both of which rely on physical voltage sensors, confirming its robustness and effectiveness under non-ideal grid conditions. Full article

This paper introduces a compact analog configuration that concurrently realizes a mixed-mode biquadratic filter and a dual-mode quadrature oscillator (QO) by employing a single differential differencing gain amplifier (DDGA) and all-grounded passive components. The proposed design supports four fundamental operation modes—voltage-mode (VM), current-mode (CM), trans-impedance-mode (TIM), and trans-admittance-mode (TAM)—utilizing the same circuit topology without structural modifications. In filter operation, it offers low-pass, high-pass, band-pass, band-stop, and all-pass responses with orthogonal and electronic pole frequency and quality factor. In oscillator operation, it delivers simultaneous voltage and current quadrature outputs with independent tuning of oscillator frequency and condition. The grounded-component configuration simplifies layout and enhances its suitability for monolithic integration. Numerical simulations in a 0.18-μm CMOS process with ±0.9 V supply confirm theoretical predictions, demonstrating precise gain-phase characteristics, low total harmonic distortion (<7%), modest sensitivity to 5% component variations, and stable operation from −40 °C to 120 °C. These results, combined with the circuit’s low component count and integration suitability, suggest strong potential for future development in low-power IoT devices, adaptive communication front-ends, and integrated biomedical systems. Full article

This paper presents a novel design for precise vertical landing of drones based on the detection of three phase shifts in the range of ±180°. The design has three inputs to which the signal transmitted from an oscillator located at the landing point arrives with different delays. The circuit increases the aerial tracking volume relative to that achieved by detectors with theoretical unambiguous detection ranges of ±90°. The phase shift measurement circuit uses an analog phase detector (mixer), detecting a maximum range of ±90°and a double multiplication of the input signals, in phase and phase-shifted, without the need to fulfill the quadrature condition. The calibration procedure, phase detector curve modeling, and calculation of the input signal phase shift are significantly simplified by the use of an automatic gain control on each branch, dwhich keeps input amplitudes to the analog phase detectors constant. A simple program to determine phase shifts and guidance instructions is proposed, which could be integrated into the same flight control platform, thus avoiding the need to add additional processing components. A prototype has been manufactured in C band to explain the details of the procedure design. The circuit uses commercial circuits and microstrip technology, avoiding the crossing of lines by means of switches, which allows the design topology to be extrapolated to much higher frequencies. Calibration and measurements at 5.3 GHz show a dynamic range greater than 50 dB and a non-ambiguous detection range of ±180°. These specifications would allow one to track the drone during the landing maneuver in an inverted cone formed by a surface with an 11 m radius at 10 m high and the landing point, when 4 cm between RF inputs is considered. The errors of the phase shifts used in the landing maneuver are less than ±3°, which translates into 1.7% losses over the detector theoretical range in the worst case. The circuit has a frequency bandwidth of 4.8 GHz to 5.6 GHz, considering a 3 dB variation in the input power when the AGC is limiting the output signal to 0 dBm at the circuit reference point of each branch. In addition, the evolution of phases in the landing maneuver is shown by means of a small simulation program in which the drone trajectory is inside and outside the tracking range of ±180°. Full article

Quantum squeezing in macroscopic oscillator systems plays a critical role in bridging quantum mechanics with classical-scale phenomena, enabling high-precision measurements and fundamental tests of quantum physics. In this work, we investigate the effect of squeezing on the phonon state in a hybrid macroscopic mechanical system consisting of an ensemble of Rydberg atoms coupled to two macroscopic mechanical oscillators. We notice that the dipole–dipole coupling between atoms and mechanical oscillators can be transferred to the indirectly coupled mechanical interaction, and the nonlinear effective Hamiltonian can be solved to generate a squeezed effect on the mechanical mode. We also discuss the noise effects induced by amplitude and phase fluctuations on the squeezed quadratures of the system. Full article

Phase noise constitutes a pivotal performance parameter in microwave systems, and the evolution of microwave signal sources presents new demands on phase noise analyzers (PNAs) regarding sensitivity and bandwidth. Traditional electronics-based PNAs encounter significant limitations in meeting these advanced requirements. This paper provides an overview of recent progress in photonics-based microwave PNA research. Microwave photonic (MWP) PNAs are categorized into two main types: phase-detection-based and frequency-discrimination-based architectures. MWP phase-detection-based PNAs utilize ultra-short-pulse lasers or optical–electrical oscillators as reference sources to achieve superior sensitivity. On the other hand, MWP frequency-discrimination-based PNAs are further subdivided into photonic-substitution-type PNA and MWP quadrature-frequency-discrimination-based PNA. These systems leverage innovative MWP technologies to enhance overall performance, offering broader bandwidth and higher sensitivity compared to conventional approaches. Finally, the paper addresses the current challenges faced in phase noise measurement technologies and suggests potential future research directions aimed at improving measurement capabilities. Full article

The optimization of computational algorithms is one of the main problems of computational mathematics. This optimization is well demonstrated by the example of the theory of quadrature and cubature formulas. It is known that the numerical integration of definite integrals is of great importance in basic and applied sciences. In this paper we consider the optimization problem of weighted quadrature formulas with derivatives in Sobolev space. Using the extremal function, the square of the norm of the error functional of the considered quadrature formula is calculated. Then, minimizing this norm by coefficients, we obtain a system to find the optimal coefficients of this quadrature formula. The uniqueness of solutions of this system is proved, and an algorithm for solving this system is given. The proposed algorithm is used to obtain the optimal coefficients of the derivative weight quadrature formulas. It should be noted that the optimal weighted quadrature formulas constructed in this work are optimal for the approximate calculation of regular, singular, fractional and strongly oscillating integrals. The constructed optimal quadrature formulas are applied to the approximate solution of linear Fredholm integral equations of the second kind. Finally, the numerical results are compared with the known results of other authors. Full article

This study introduces an electronically tunable resistorless mixed-mode universal filter and dual-mode quadrature oscillator configuration utilizing merely two voltage differencing gain amplifiers and two grounded capacitors. The suggested filter can perform all generic biquadratic filter functions in all four modes: voltage mode, trans-admittance mode, current mode, and trans-impedance mode, while utilizing the same design. The pole frequency and the quality factor can be tuned electronically and orthogonally by means of the transconductances of the voltage differencing gain amplifier. The dual-mode quadrature oscillator featuring both voltage and current outputs can also be obtained from the proposed filter core. It additionally provides separate electronic control of the oscillation condition and frequency. Several PSPICE simulations with the TSMC 0.18 μm CMOS model confirm the feasibility of the proposed configurations. Both proposed circuits were experimentally evaluated using commercially available integrated circuit LM13600s. Both simulation and experimental results have validated the performance of the design. Full article

Gallium Arsenide (GaAs) Schottky technology stands out for its superior performance in terms of conversion loss for terahertz mixers at room temperatures, which establishes it as a dominant solution in receivers for high-data-rate wireless communications. However, Indium Gallium Arsenide (InGaAs) Schottky mixers offer a notable advantage in terms of reduced power requirements due to their lower barrier height, enabling optical pumping with the incorporation of photodiodes acting as photonic local oscillators (LOs). In this study, we present the first comparative analysis of GaAs and InGaAs diode technologies under both electrical and optical pumping, which are also being compared for the first time, particularly in the context of a wireless communication system, transmitting up to 80 Gbps at 0.3 THz using 16-quadrature amplitude modulation (QAM). The terahertz transmitter and the optical receiver’s LO are based on modified uni-traveling-carrier photodiodes (MUTC-PDs) driven by free-running lasers. The investigation covers a total of two mixers, including narrow-band GaAs and InGaAs. The results reveal that, despite InGaAs mixers exhibiting higher conversion loss, the bit error rate (BER) can be as low as that with GaAs. This is attributed to the purity of optically generated LO signals in the receiver. This work positions InGaAs Schottky technology as a compelling candidate for terahertz reception in the context of optical wireless communication systems. Full article

This paper extends the multipoint flux approximation (MPFA-O) method to model coupled pressure and saturation dynamics in subsurface reservoirs with heterogeneous anisotropic permeability and non-K-orthogonal grids. The MPFA method is widely used for reservoir simulation to address the limitations of the two-point flux approximation (TPFA), particularly in scenarios involving full-tensor permeability and strong anisotropy. However, the MPFA-O method is known to suffer from spurious oscillations and numerical instability, especially in high-anisotropy scenarios. Existing stability-enhancing techniques, such as optimal quadrature schemes and flux-splitting methods, mitigate these issues but are computationally expensive and do not always ensure monotonicity or oscillation-free solutions. Building upon prior advancements in the MPFA-O method for pressure equations, this work incorporates the saturation equation to enable the simulation of a coupled multiphase flow in porous media. A unified framework is developed to address stability challenges associated with the tight coupling of pressure and saturation fields while ensuring local conservation and accuracy in the presence of full-tensor permeability. The proposed method introduces stability-enhancing modifications, including a local rotation transformation, to mitigate spurious oscillations and preserve physical principles such as monotonicity and the maximum principle. Numerical experiments on heterogeneous, anisotropic domains with non-K-orthogonal grids validate the robustness and accuracy of the extended MPFA-O method. The results demonstrate improved stability and performance in capturing the complex interactions between pressure and saturation fields, offering a significant advancement in subsurface reservoir modeling. This work provides a reliable and efficient tool for simulating coupled flow and transport processes, with applications in CO₂ storage, hydrogen storage, geothermal energy, and hydrocarbon recovery. Full article

In high-capacity and short-reach applications, double-sideband self-coherent detection (DSB-SCD) has garnered significant attention due to its ability to recover optical fields of DSB signals without requiring a local oscillator. However, DSB-SCD is fundamentally constrained by the non-ideal receiver transfer function, necessitating a guard band between the carrier and signal. While the conventional twin-single-sideband (twin-SSB) modulation scheme addresses this requirement, it incurs substantial implementation complexity. In this paper, we propose a spectrum inversion-based double-sideband (SI-DSB) modulation scheme, where spectral inversion shifts the DSB signal to the high-frequency region, creating a guard band around the zero frequency. After photodetector detection, baseband signal recovery is achieved through subsequent spectral inversion. Compared with the twin-SSB modulation scheme, this approach significantly reduces DSP complexity. The simulation exploration two modulation formats of pulse–amplitude modulation and quadrature-amplitude modulation, demonstrating a comparable system performance between SI-DSB and twin-SSB modulation schemes. We also illustrate the parameter optimization process for the SI-DSB modulation scheme, including carrier-to-signal power ratio and guard band. Furthermore, validation with three FADD receivers further demonstrates the superior performance of the proposed SI-DSB modulation in DSB-SCD systems. Full article

This article is devoted to the investigation of synchronization noise immunity in quadrature chaos shift keying (QCSK) communication systems and its profound impact on system performance. The study focuses on Colpitts and Vilnius chaos oscillators in different synchronization configurations, and the reliability of the system in the particular configuration is assessed using the bit error rate (BER) estimation. The research considers synchronization imbalances and demonstrates their effect on the accuracy of data detection and overall transmission stability. The article proposes an approach for optimal bit detection in the case of imbalanced synchronization and correlated chaotic signals in data transmission. The study practically shows the importance of the proposed decision-making technique, revealing that certain adjustments can significantly enhance system noise resilience. Full article

Simple designs of current-mode quadrature oscillators are presented in this work. The main achievement, with regards to the literature, is the minimization of the required transistor count accomplished by the utilization of a suitable lossless integration stage. The derived post-layout simulation results confirm the validity of the presented concept and show that the resulting structure has attractive characteristics in both frequency and time-domain. Full article

A filter-free, image-reject, sub-harmonic downconverted RoF link is proposed based on a dual-polarization quadrature phase-shift keying (DP–QPSK) modulator. At the remote antenna unit, the receiving radio frequency signal is applied to the upper QPSK modulator to achieve carrier-suppressed single-sideband (CS–SSB) modulation. The local oscillator (LO) is applied to the lower QPSK modulator, achieving sub-harmonic single-sideband (SH–SSB) modulation. The I/Q mixing is realized by exploiting a two-channel photonic microwave phase shifter, which mainly consists of a modulator, two polarization controllers, and two polarizers. The image interference signal can be rejected when combing the I and Q IF signals through a 90° electrical hybrid. Because the scheme is simple and filter-free, it has a good image-reject capability over a large frequency tunable range. Moreover, due to the special SH-SSB modulation, the modulated signals are immune to the chromatic dispersion-introduced power fading effect. Last, the sub-harmonic downconverter can decrease the frequency requirement of the LO signal. Experimental results show that an image rejection ratio (IRR) greater than 50 dB can be achieved when transmitted through a 25 km single-mode fiber (SMF). Simultaneously, under different RF signals and IF signals, the IRR has no periodic power fading, only small fluctuations. Image rejection capability of the scheme for the 50-MBaud 16-QAM wideband vector signal is also verified and the demodulation of the desired IF signal with a good EVM of less than 5% is realized. Full article

Nowadays, M-Quadrature Amplitude Modulation (M-QAM) techniques are widely used to modulate information by bit packets due to their ability to increase transfer rates. These techniques require more power when increasing the modulation index M to avoid interference between symbols. This article proposes a technique that does not suffer from interference between symbols, but instead uses memory elements to store the modulation symbols. In addition, the aim of this paper is to implement a four-dimensional reconfigurable chaotic oscillator that generates 16-Chaotic Phase Shift Keying (16-CPSK) modulation–demodulation carriers. An encryption and modulation transmitter module, a reception module, and a master–slave Hamiltonian synchronization module make up the system. A 16-CPSK modulation scheme implemented in Field Programmable Gate Array (FPGA) and applied to a red-green-blue (RGB) and grayscale image encryption system are the main contributions of this work. Matlab and Vivado were used to verify the modulation–demodulation scheme and synchronization. This proposal achieved excellent correlation coefficients according to various investigations, the lowest being $-15.9\times {10}^{-6}$ and $0.13\times {10}^{-3}$ for RGB and grayscale format images, respectively. The FPGA implementation of the 16-CPSK modulation–demodulation system was carried out using a manufacturer’s card, Xilinx’s Artix-7 AC701 (XC7A200TFBG676-2). Full article
