Bound states in the continuum (BICs) can be transformed into quasi-bound states (quasi-BICs) via intentional symmetry breaking, thereby enabling ultrahigh-Q resonances critical for refractometric sensing applications. To advance detection capabilities for organic analytes, we proposed an all-dielectric metasurface monolithically integrated within a microfluidic channel. Mirror symmetry was intentionally disrupted through a cylindrical perturbation applied to one of two identical elliptical resonators, which excited a quasi-BIC mode at 1.9591 THz with a numerically validated Q-factor of 1959. This resonance manifested an absorption peak approaching unity, featuring a full-width at half-maximum (FWHM) of merely 1 GHz. Multipolar decomposition revealed that the mode originated from a synergistic electric-quadrupole (EQ)–magnetic-dipole (MD) pair, wherein the EQ contribution exceeded the MD counterpart by 20%. Capitalizing on this high-Q resonance, the sensor attained a sensitivity of 240 GHz per refractive-index unit (GHz RIU⁻¹) and a figure of merit (FOM = S/FWHM) of 240, while demonstrating robust performance against fabrication tolerances spanning −4% to +4%. Additionally, we verified that oblique-incidence illumination could activate a quasi-BIC within the identical spectral band, circumventing the need for structural asymmetry and thus expanding operational versatility. Benefiting from its geometric simplicity and competitive performance, this architecture exhibited substantial potential for on-chip sensing of organic compounds. Full article

This study reports the experimental validation of several designs of photon sieves with focusing capabilities. These permeable optical elements were implemented with a spatial light modulator working in pure-amplitude mode. The focal region was scanned using a traveling stage, holding a camera. Using this experimental setup, we characterized the focal region of the photon sieves and determined some parameters of interest, such as the depth of focus and the transverse extent of the focal region. These parameters and their evolution were measured and analyzed to compare the optical performance of different designs. Moreover, the permeability of the mask was also evaluated and is included in the discussion. When the photon sieve is intended to be used as an optical element for the monitoring of running fluids, one of the designs studied, labeled the Ring-by-Ring method, behaves in a quite balanced manner and thus has become the preferred choice. Through simulations for a refractometric sensor, we obtained the Figure of Merit of the Ring-by-Ring mask, which reached a maximum value of 7860 RIU⁻¹, which is competitive with plasmonic sensing devices. Full article

Magneto-optic surface plasmon resonances (MOSPRs) rely on the interaction of magnetic fields with surface plasmon polaritons (SPP) to modulate plasmonic bands with magnetic fields and enhance magneto-optical activity. In the present work, a study on the magnetoplasmonic behavior of Ag/Fe bilayers is carried out by VIS-NIR spectroscopy and backed with SQUID measurements, determining the thickness-dependent magnetization of thin-film samples. The MOSPR sensing properties of Ag/Fe planar bilayers are simulated using Berreman’s matrix formalism, from which an optimized structure composed of 15 nm of Ag and 12.5 nm of Fe is obtained. The selected structure is fabricated and characterized for refractive index (RI) sensitivity, reaching 4946 RIU⁻¹ and returning an effective enhancement of refractometric sensitivity after magneto-optical modulation. A new optimized and cobalt-free magnetoplasmonic Ag/Fe bilayer structure is studied, fabricated, and characterized for the first time towards refractometric sensing, to the best of our knowledge. This configuration exhibits potential for enhancing refractometric sensitivity via magneto-optical modulation, thus paving the way towards a simpler, more accessible, and safe type of RI sensor with potential applications in chemical sensors and biosensors. Full article

A novel application of microresonators for refractometric sensing in aqueous media is presented. To carry out this approach, microspheres of different materials and sizes were fabricated and doped with Nd³⁺ ions. Under 532 nm excitation, the microspheres presented typical NIR Nd³⁺ emission bands with superimposed sharp peaks, related to the Whispering Gallery Modes (WGMs), due to the geometry of the microspheres. When the microspheres were submerged in water with increasing concentrations of glycerol, spectral shifts for the WGMs were observed as a function of the glycerol concentration. These spectral shifts were studied and calibrated for three different microspheres and validated with the theoretical shifts, obtained by solving the Helmholtz equations for the electromagnetic field, considering the geometry of the system, and also by calculating the extinction cross-section. WGM shifts strongly depend on the diameter of the microspheres and their refractive index (RI) difference compared with the external medium, and are greater for decreasing values of the diameter and lower values of RI difference. Experimental sensitivities ranging from 2.18 to 113.36 nm/RIU (refractive index unit) were obtained for different microspheres. Furthermore, reproducibility measurements were carried out, leading to a repeatability of 2.3 pm and a limit of detection of 5 × 10⁻⁴ RIU. The proposed sensors, taking advantage of confocal microscopy for excitation and detection, offer a robust, reliable, and contactless alternative for environmental water analysis. Full article

Label-free sensing is a promising approach for point-of-care testing devices. Among optical transducers, photonic crystal slabs (PCSs) have positioned themselves as an inexpensive yet versatile platform for label-free biosensing. A spectral resonance shift is observed upon biomolecular binding to the functionalized surface. Commonly, a PCS is read out by a spectrometer. Alternatively, the spectral shift may be translated into an intensity change by tailoring the system response. Intensity-based camera setups (IBCS) are of interest as they mitigate the need for postprocessing, enable spatial sampling, and have moderate hardware requirements. However, they exhibit modest performance compared with spectrometric approaches. Here, we show an increase of the sensitivity and limit of detection (LOD) of an IBCS by employing a sharp-edged cut-off filter to optimize the system response. We report an increase of the LOD from (7.1 ± 1.3) × 10⁻⁴ RIU to (3.2 ± 0.7) × 10⁻⁵ RIU. We discuss the influence of the region of interest (ROI) size on the achievable LOD. We fabricated a biochip by combining a microfluidic and a PCS and demonstrated autonomous transport. We analyzed the performance via refractive index steps and the biosensing ability via diluted glutathione S-transferase (GST) antibodies (1:250). In addition, we illustrate the speed of detection and demonstrate the advantage of the additional spatial information by detecting streptavidin (2.9 µg/mL). Finally, we present the detection of immunoglobulin G (IgG) from whole blood as a possible basis for point-of-care devices. Full article

Metaphotonic devices, which enable light manipulation at a subwavelength scale and enhance light–matter interactions, have been emerging as a critical pillar in biosensing. Researchers have been attracted to metaphotonic biosensors, as they solve the limitations of the existing bioanalytical techniques, including the sensitivity, selectivity, and detection limit. Here, we briefly introduce types of metasurfaces utilized in various metaphotonic biomolecular sensing domains such as refractometry, surface-enhanced fluorescence, vibrational spectroscopy, and chiral sensing. Further, we list the prevalent working mechanisms of those metaphotonic bio-detection schemes. Furthermore, we summarize the recent progress in chip integration for metaphotonic biosensing to enable innovative point-of-care devices in healthcare. Finally, we discuss the impediments in metaphotonic biosensing, such as its cost effectiveness and treatment for intricate biospecimens, and present a prospect for potential directions for materializing these device strategies, significantly influencing clinical diagnostics in health and safety. Full article

Process Analytical Technology (PAT) has been increasingly used in the pharmaceutical industry to monitor essential parameters in real-time during pharmaceutical processes. The concentration of Active Pharmaceutical Ingredients (APIs), such as paracetamol, is one of these parameters, and controlling its variations allows for optimization of the production process. In this study, a refractometric sensor, implemented by an interrogation system based on an Erbium-Doped Fiber Ring Cavity (EDFRC), was presented and experimentally demonstrated. The Cavity Ring proposed included a 1 × 3 coupler. One port of the coupler was used to increase the optical power of the system through a Fiber Bragg Grating (FBG), and the other two ports were used as sensing head and reference. The sensor detected variations of paracetamol concentration with a sensitivity of [(−1.00 ± 0.05) × 10⁻³] nW/(g/kg) and a resolution of 5.53 g/kg. The results demonstrate the potential of this technology as a possible non-invasive PAT tool. Full article

The design of a refractometric sensing system for liquids analysis with a sensor and the scheme for its intensity interrogation combined on a single photonic integrated circuit (PIC) is proposed. A racetrack microring resonator with a channel for the analyzed liquid formed on the top is used as a sensor, and another microring resonator with a lower Q-factor is utilized to detect the change in the resonant wavelength of the sensor. As a measurement result, the optical power at its drop port is detected in comparison with the sum of the powers at the through and drop ports. Simulations showed the possibility of registering a change in the analyte refractive index with a sensitivity of 110 nm per refractive index unit. The proposed scheme was analyzed with a broadband source, as well as a source based on an optoelectronic oscillator using an optical phase modulator. The second case showed the fundamental possibility of implementing an intensity interrogator on a PIC using an external typical single-mode laser as a source. Meanwhile, additional simulations demonstrated an increased system sensitivity compared to the conventional interrogation scheme with a broadband or tunable light source. The proposed approach provides the opportunity to increase the integration level of a sensing device, significantly reducing its cost, power consumption, and dimensions. Full article

We present a theoretical analysis of the refractometric sensitivity of a spherical microresonator coated with a porous sensing layer performed for different whispering gallery modes. The effective refractive index of the modes is also calculated. The calculations are also made for a system which has an additional high-refractive index layer sandwiched between the microsphere and the porous sensing layer. The results of the calculation are discussed in regards to the applicability of the studied systems for gas sensor construction. Full article

A new sensing platform based on long-period fiber gratings (LPFGs) for direct, fast, and selective detection of human immunoglobulin G (IgG; Mw = 150 KDa) was developed and characterized. The transducer’s high selectivity is based on the specific interaction of a molecularly imprinted polymer (MIPs) design for IgG detection. The sensing scheme is based on differential refractometric measurements, including a correction system based on a non-imprinted polymer (NIP)-coated LPFG, allowing reliable and more sensitive measurements, improving the rejection of false positives in around 30%. The molecular imprinted binding sites were performed on the surface of a LPFG with a sensitivity of about 130 nm/RIU and a FOM of 16 RIU⁻¹. The low-cost and easy to build device was tested in a working range from 1 to 100 nmol/L, revealing a limit of detection (LOD) and a sensitivity of 0.25 nmol/L (0.037 µg/mL) and 0.057 nm.L/nmol, respectively. The sensor also successfully differentiates the target analyte from the other abundant elements that are present in the human blood plasma. Full article

High-contrast gratings (HCG) are an excellent candidate for label-free detection of various kinds of biomarkers because they exhibit sharp and sensitive optical resonances. In this work, we experimentally show the performance of pedestal HCG (PHCG), which is significantly enhanced in comparison with that of conventional HCG. PCHGs were found to provide a 11.2% improvement in bulk refractive index sensitivity, from 482 nm/RIU for the conventional design to 536 nm/RIU. The observed resonance was narrower, resulting in a higher Q-factor and figure of merit. By depositing Al${}_2$O${}_3$, HfO${}_2$, and TiO${}_2$ of different thicknesses as model analyte layers, surface sensitivity values were estimated to be 10.5% better for PHCG. To evaluate the operation of the sensor in solution, avidin was employed as a model analyte. For avidin detection, the surface of the HCG was first silanized and subsequently functionalized with biotin, which is well known for its ability to bind selectively to avidin. A consistent red shift was observed with the addition of each of the functional layers, and the analysis of the spectral shift for various concentrations of avidin made it possible to calculate the limit of detection (LoD) and limit of quantification (LoQ) for the structures. PHCG showed a LoD of 2.1 ng/mL and LoQ of 85 ng/mL, significantly better than the values 3.2 ng/mL and 213 ng/mL respectively, obtained with the conventional HCG. These results demonstrate that the proposed PHCG have great potential for biosensing applications, particularly for detecting and quantifying low analyte concentrations. Full article

This paper reports on the refractometric detection of water-adulterated milk using an optical fiber sensor whose principle of operation is based on multimode interference (MMI). The device is manufactured in a simple way by splicing a segment of coreless multimode fiber (NC-MMF) between two single-mode fibers (SMFs); neither functionalization nor deposition of a sensing material is required. MMI takes place in the NC-MMF and, when fed with a broadband spectrum, a transmission peak appears at the output of the MMI device due to its inherent filter-like response, whose position depends on the effective refractive index (RI) of the medium surrounding the NC-MMF. Therefore, when the sensor is immersed in different milk–water mixtures, the peak wavelength shifts according to the RI of the mixture. In this way, adulterated milk can be detected from the wavelength shift of the transmission peak. The system was tested with two commercial brands of milk, and adulterations were clearly distinguished in both cases. In the range of interest, from no dilution up to 50% dilution, the sensor exhibits a linear response with a sensitivity of −0.04251 and −0.03291 nm/%, respectively, for the two samples tested. The measurement protocol is repeatable and allows for locating the peak wavelength within <0.34 nm over several repetitions using different samples with the same concentration. A thermal sensitivity of 0.85 nm/°C was obtained, which suggests that the temperature needs to be maintained as fixed during the measurements. The approach presented can be extended to other scenarios as a quality control tool in beverages for human consumption, showing the advantages of simple construction, high sensitivity, and the potential for real-time monitoring. Full article

Optical sensors based on surface plasmon resonance (SPR) have made great strides in the detection of various chemical and biological analytes. A surface plasmon is a bound, non-radiative evanescent wave generated as resonant electrons on a metal–dielectric surface to absorb energy from an incident light. As analytes bind to a functionalized metal substrate, the refractometric response generated can be used for quantitation with great selectivity, sensitivity, and capacity for label-free real-time analysis. Polymer nanobrushes are ideal recognition elements because of their greater surface area and their wide range of functional versatility. Here, we introduce a simple “grafting-from” method to covalently attach nanometer-thick polymer chains on a gold surface. Nanografting on gold-coated BK-7 glass was performed in two steps: (1) self-assembly of organosulfur compounds; and (2) RAFT-mediated radiation-induced graft polymerization (RAFT-RIGP) of polyglycidyl methacrylate (PGMA). Surface modification was monitored and verified using FTIR and SPR. Layer-by-layer thickness calculated based on Winspall 3.02 simulation fitted with experimental SPR curves showed successful self-assembly of 1-dodecanethiol (DDT) monolayer with thickness measuring 1.4 nm. These alkane chains of DDT served as the graft initiation sites for RAFT-RIGP. Nanografting was controlled by adjusting the absorbed dose in the presence of chain transfer agent, 4-cyano-4-(phenylcarbonothioylthio)pentanoic acid. The molecular weight of grafted polymers measuring 2.8 and 4.3 kDa corresponded to a thickness increase of 3.6 and 7.9 nm, respectively. These stable nanografted gold substrates may be further functionalized for sensing applications. Full article

A multipurpose plasmonic sensor design based on a metal-insulator-metal (MIM) waveguide is numerically investigated in this paper. The proposed design can be instantaneously employed for biosensing and temperature sensing applications. The sensor consists of two simple resonant cavities having a square and circular shape, with the side coupled to an MIM bus waveguide. For biosensing operation, the analytes can be injected into the square cavity while a thermo-optic polymer is deposited in the circular cavity, which provides a shift in resonance wavelength according to the variation in ambient temperature. Both sensing processes work independently. Each cavity provides a resonance dip at a distinct position in the transmission spectrum of the sensor, which does not obscure the analysis process. Such a simple configuration embedded in the single-chip can potentially provide a sensitivity of 700 nm/RIU and −0.35 nm/°C for biosensing and temperature sensing, respectively. Furthermore, the figure of merit (FOM) for the biosensing module and temperature sensing module is around 21.9 and 0.008, respectively. FOM is the ratio between the sensitivity of the device and width of the resonance dip. We suppose that the suggested sensor design can be valuable in twofold ways: (i) in the scenarios where the testing of the biological analytes should be conducted in a controlled temperature environment and (ii) for reducing the influence on ambient temperature fluctuations on refractometric measurements in real-time mode. Full article

This work introduces a method specially developed to produce a biorecognition element based on modified Stöber silica nanoparticles by the covalent immobilization of the human IgG. The sensing structure is based on long period fiber gratings (LPFG), specially developed to allow the interaction of the electromagnetic wave with the target analytes through its evanescent field. The surface was modified by the immobilization of the IgG-modified nanoparticles serving has recognition elements for specific target molecules. The resulting configuration was tested in the presence of anti-human IgG, recording the refractometric response of the modified LPFG in contact with different amounts of analyte. The selectivity of the sensor was also assessed. Full article
