Search Results (36)

Nowadays, underwater activities are becoming more and more important. As the number of underwater sensing devices grows rapidly, the amount of bandwidth needed also increases very quickly. Apart from underwater communication, direct communication across the water–air interface is also highly desirable. Air-to-water wireless transmission is crucial for sending control information or instructions from unmanned aerial vehicles (UAVs) or ground stations above the sea surface to autonomous underwater vehicles (AUVs). On the other hand, water-to-air wireless transmission is also required to transmit real-time information from AUVs or underwater sensor nodes to UAVs above the water surface. Previously, we successfully demonstrated a water-to-air optical camera-based OWC system, which is also known as optical camera communication (OCC). However, the reverse transmission (i.e., air-to-water) using OCC has not been analyzed. It is worth noting that in the water-to-air OCC system, since the camera is located in the air, the image of the light source is magnified due to diffraction. Hence, the pixel-per-symbol (PPS) decoding of the OCC pattern is easier. In the proposed air-to-water OCC system reported here, since the camera is located in the water, the image of the light source in the air will be diminished in size due to diffraction. Hence, the PPS decoding of the OCC pattern becomes more difficult. In this work, we propose and experimentally demonstrate a wide field-of-view (FOV) air-to-water OCC system using CUDA Deep-Neural-Network Long-Short-Term-Memory (CuDNNLSTM). Due to water turbulence and air turbulence affecting the AUV and UAV, a precise line-of-sight (LOS) between the AUV and the UAV is difficult to achieve. OCC can provide wide FOV without the need for precise optical alignment. Results revealed that the proposed air-to-water OCC system can support a transmission rate of 7.2 kbit/s through a still water surface, and 6.6 kbit/s through a wavy water surface; this satisfies the hard-decision forward error correction (HD-FEC) bit-error-rate (BER). Full article

The generation of digital aerial photogrammetry products using unmanned aerial vehicle-digital aerial photogrammetry (UAV-DAP) has become an essential task due to the increasing use of UAVs in the world of geomatics, thanks to their low cost and spatial resolution. Therefore, it is relevant to explore the performance of new digital cameras equipped in UAVs using electronic rolling shutters instead of ideal mechanical or global shutter cameras to achieve accurate and reliable photogrammetric products, if possible, while minimizing workload, especially for their application in projects that require a high level of detail. In this paper, we analyse performance using oblique images along the perimeter (3D perimeter) on a flat area, i.e., with slopes of less than 3%. The area was photogrammetrically surveyed with a DJI (Dà-Jiāng Innovations) Inspire 2 multirotor UAV equipped with a Zenmuse X5S rolling shutter camera. The photogrammetric survey was accompanied by a Global Navigation Satellite System (GNSS) survey, in which dual frequency receivers were used to determine the ground control points (GCPs) and checkpoints (CPs). The study analysed different scenarios, including the combination of forward and transversal strips and oblique images. After examining the ideal scenario with the least root mean square error (RMSE), six different combinations were analysed to find the best location for the GCPs. The most significant results indicate that the optimal calibration of the camera is obtained in scenarios including oblique images, which outperform the rest of the scenarios for achieving the lowest RMSE (2.5x the GSD in Z and 3.0x the GSD in XYZ) with optimum GCPs layout; with non-ideal GCPs layout, unacceptable errors can be achieved (11.4x the GSD in XYZ), even with ideal block geometry. The UAV-DAP rolling shutter effect can only be minimised in the scenario that uses oblique images and GCPs at the edges of the overlapping zones and the perimeter. Full article

This study proposes a biometric authentication method using infrared (IR)-based periocular images captured in virtual reality (VR) environments with head-mounted displays (HMDs). The widespread application of VR technology highlights the growing need for robust user authentication in immersive environments. To address this, the study introduces a novel periocular biometric authentication system optimized for HMD usage. Ensuring reliable authentication in VR environments necessitates overcoming significant challenges, including flicker noise and infrared reflection. Flicker noise, caused by alternating current (AC)-powered lighting, produces banding artifacts in images captured by rolling-shutter cameras, obstructing biometric feature extraction. Additionally, IR reflection generates strong light glare on the iris surface, degrading image quality and negatively impacting the model’s generalization performance and authentication accuracy. This study utilized the AffectiVR dataset, which includes noisy images, to address these challenges. In the preprocessing phase, iris reflections were removed, reducing the Equal Error Rate (EER) from 6.73% to 5.52%. Furthermore, incorporating a Squeeze-and-Excitation (SE) block to mitigate flicker noise and enhance model robustness resulted in a final EER of 6.39%. Although the SE block slightly increased the EER, it significantly improved the model’s ability to suppress noise and focus on critical periocular features, ensuring enhanced robustness in challenging VR environments. Heatmap analysis revealed that the proposed model effectively utilized periocular features, such as the skin around the eyes and eye contours, compared to prior approaches. This study establishes a crucial groundwork for advancing robust biometric authentication systems capable of overcoming noise challenges in next-generation immersive platforms. Full article

Display field communication (DFC) is an emerging technology that enables seamless communication between electronic displays and cameras. It utilizes the frequency-domain characteristics of image frames to embed and transmit data, which are then decoded and interpreted by a camera. DFC offers a novel solution for screen-to-camera data communication, leveraging existing displays and camera infrastructures. This makes it a cost-effective and easily deployable solution. DFC can be applied in various fields, including secure data transfer, mobile payments, and interactive advertising, where data can be exchanged by simply pointing a camera at a screen. This article provides a comprehensive survey of DFC, highlighting significant milestones achieved in recent years and discussing future challenges in establishing a fully functional DFC system. We begin by introducing the broader topic of screen–camera communication (SCC), classifying it into visible and hidden SCC. DFC, a type of spectral-domain hidden SCC, is then explored in detail. Various DFC variants are introduced, with a focus on the physical layer. Finally, we present promising experimental results from our lab and outline further research directions and challenges. Full article

Most of Optical Camera Communication (OCC) systems benefit from the rolling shutter mechanism of Complementary Metal-Oxide Semiconductor (CMOS) cameras to record the brightness evolution of the Light-Emitting Diode (LED) through dark and bright strips within images. While this technique enhances the maximum achievable data rate, the main difficulty lies in the demodulation of the signal extracted from images, subject to blooming effect. Thus, two main approaches were proposed to deal with this issue, using adaptive thresholds whose value evolves according to amplitude changes or detecting signal variations with the first-order derivative. As the second method is more robust, a new demodulation method based on the detection of the zeros of the first-order derivative of the extracted signal was proposed in this paper. Obtained results clearly show an improvement in the extracted signal demodulation compared to other methods, achieving a raw Bit Error Rate (BER) of 10⁻³ around 50 cm in a Line-Of-Sight scenario, and increasing the maximum communication distance by 43.5%, reaching 330 cm in the case of a Non-Line-Of-Sight transmission. Full article

Nowadays, a variety of underwater activities, such as underwater surveillance, marine monitoring, etc., are becoming crucial worldwide. Underwater sensors and autonomous underwater vehicles (AUVs) are widely adopted for underwater exploration. Underwater communication via radio frequency (RF) or acoustic wave suffers high transmission loss and limited bandwidth. In this work, we present and demonstrate a rolling shutter (RS)-based underwater optical camera communication (UWOCC) system utilizing a long short-term memory neural network (LSTM-NN) with side glow optical fiber (SGOF). SGOF is made of poly-methyl methacrylate (PMMA) SGOF. It is lightweight and flexibly bendable. Most importantly, SGOF is water resistant; hence, it can be installed in an underwater environment to provide 360° “omni-directional” uniform radial light emission around its circumference. This large FOV can fascinate the optical detection in underwater turbulent environments. The proposed LSTM-NN has the time-memorizing characteristics to enhance UWOCC signal decoding. The proposed LSTM-NN is also compared with other decoding methods in the literature, such as the PPB-NN. The experimental results demonstrated that the proposed LSTM-NN outperforms the PPB-NN in the UWOCC system. A data rate of 2.7 kbit/s can be achieved in UWOCC, satisfying the pre-forward error correction (FEC) condition (i.e., bit error rate, BER ≤ 3.8 × 10⁻³). We also found that thin fiber also allows performing spatial multiplexing to enhance transmission capacity. Full article

We explore the use of smartphones to decode data transmitted from LEDs to smartphone cameras in visible light communication (VLC) applied to indoor positioning applications. The LEDs—modified to enable rapid on-off keying—transmit identification codes or optically encoded location data imperceptible to human perception. Equipped with a camera, the smartphone employs a single framed image to detect the presence of the luminaires in the image, decode their transmitted identifiers or locations, and determine the smartphone’s position and orientation relative to the luminaires. The camera captures and processes images continuously. The following fundamental issues are addressed in this research: (i) analyzing the camera parameters on smartphones that affect data decoding results; (ii) exploiting the rolling shutter effect of the CMOS image sensor to receive multiple bits of data encoded in the optical communication line with a single frame shot; (iii) advancing research in developing algorithms to process data from multiple LEDs simultaneously. We conduct experiments to evaluate and analyze feasibility, as well as the challenges of the design, through scenarios varying in distance, transmission frequency, and data length. Full article

Visible light positioning or VLP has been identified as a promising technique for accurate indoor localization utilizing pre-existing lighting infrastructure. Robot navigation is one of the many potential applications of VLP. Recent literature shows a small number of works on robots being controlled by fusing location information acquired via VLP that uses a rolling shutter effect camera as a receiver with other sensor data. This paper, in contrast, reports on the experimental performance of a cartesian robot that was controlled solely by a VLP system using a cheap photodiode-based receiver rigidly attached to the robot’s end-effector. The receiver’s position was computed using an inverse-Lambertian function for ranging followed by multi-lateration. We developed two novel methods to leverage the VLP as an online navigation system to control the robot. The position acquired from the VLP was used by the algorithms to determine the direction the robot needed to move. The developed algorithms guided the end-effector to move from a starting point to target/destination point(s) in a discrete manner, determined by a pre-determined step size. Our experiments consisted of the robot autonomously repeating straight line-, square- and butterfly-shaped paths multiple times. The results show median errors of 27.16 mm and 26.05 mm and 90 percentile errors of 37.04 mm and 47.48 mm, respectively, for the two methods. Full article

Optical wireless communication is a promising emerging technology that addresses the limitations of radio-frequency-based wireless technologies. This study presents a new hybrid modulation method for optical camera communication (OCC), which integrates two waveforms transmitted from a single transmitter light-emitting diode (LED) and receives data through two rolling shutter camera devices on the receiver side. Then, a smart camera with a high-resolution image sensor captures the high-frequency signal, and a low-resolution image sensor from a smartphone camera captures the low-frequency signal. Based on this hybrid scheme, two data streams are transmitted from a single LED, which reduces the cost of the indoor OCC device compared with transmitting two signals from two different LEDs. In the proposed scheme, rolling-shutter orthogonal frequency-division multiplexing is used for the high-frequency signals, and M-ary frequency-shift keying is used for the low-frequency signals in the time domain. This proposed scheme is compatible with smartphone and USB cameras. By controlling the OCC parameters, the hybrid scheme can be implemented with high performance for a communication distance of 10 m. Full article

To mitigate the influence of satellite platform vibrations on space camera imaging quality, a novel approach is proposed to detect vibration parameters based on correlation imaging of rolling-shutter CMOS. In the meantime, a restoration method to address the image degradation of rolling-shutter CMOS caused by such vibrations is proposed. The vibration parameter detection method utilizes the time-sharing and row-by-row imaging principle of rolling-shutter CMOS to obtain relative offset by comparing two frames of correlation images from continuous imaging. Then, the space camera’s vibration parameters are derived from the fitting curve parameters of the relative offset. According to the detected vibration parameters, the discrete point spread function is obtained, and the rolling-shutter CMOS image degradation caused by vibration is restored row by row. The verification experiments demonstrate that the proposed detection method for two-dimensional vibration achieves a relative accuracy of less than 1% in period detection and less than 2% in amplitude detection. Additionally, the proposed restoration method can enhance the MTF index by over 20%. The experimental results demonstrate that the detection method is capable of detecting high-frequency vibrations through low-frame-frequency image sequences, and it exhibits excellent applicability in both push-scan cameras and staring cameras. The restoration method effectively enhances the evaluation parameters of image quality and yields a remarkable restorative effect on degraded images. Full article

Image sensor communication (ISC), also known as optical camera communication, is a form of visible light communication that utilizes image sensors rather than a single photodiode, for data reception. ISC offers spatial separation properties and robustness to ambient noise, making it suitable for outdoor applications such as intelligent transportation systems (ITSs). This review analyzes the research trends in ISC, specifically concerning its application in ITSs. Our focus is on various ISC receivers, including rolling shutter cameras, global shutter high-speed cameras, optical communication image sensors, and event cameras. We analyze how each of these receivers is being utilized in ISC vehicular applications. In addition, we highlight the use of ISC in range estimation techniques and the ability to achieve simultaneous communication and range estimation. By examining these topics, we aim to provide a comprehensive overview of the role of ISC technology in ITSs and its potential for future development. Full article

Many unmanned aerial vehicles (UAV) host rolling shutter (RS) cameras, i.e., cameras where image rows are exposed at slightly different times. As the camera moves in the meantime, this causes inconsistencies in homologous ray intersections in the bundle adjustment, so correction models have been proposed to deal with the problem. This paper presents a series of test flights and simulations performed with different UAV platforms at varying speeds over terrain of various morphologies with the objective of investigating and possibly optimising how RS correction models perform under different conditions, in particular as far as block control is concerned. To this aim, three RS correction models have been applied in various combinations, decreasing the number of fixed ground control points (GCP) or exploiting GNSS-determined camera stations. From the experimental tests as well as from the simulations, four conclusions can be drawn: (a) RS affects primarily horizontal coordinates and varies notably from platform to platform; (b) if the ground control is dense enough, all correction models lead practically to the same mean error on checkpoints; however, some models may cause large errors in elevation if too few GCP are used; (c) in most cases, a specific correction model is not necessary since the affine deformation caused by RS can be adequately modelled by just applying the extended Fraser camera calibration model; (d) using GNSS-assisted block orientation, the number of necessary GCP is strongly reduced. Full article

The electric network frequency (ENF) is a signal that varies over time and represents the frequency of the energy supplied by a mains power system. It continually varies around a nominal value of 50/60 Hz as a result of fluctuations over time in the supply and demand of power and has been employed for various forensic applications. Based on these ENF fluctuations, the intensity of illumination of a light source powered by the electrical grid similarly fluctuates. Videos recorded under such light sources may capture the ENF and hence can be analyzed to extract the ENF. Cameras using the rolling shutter sampling mechanism acquire each row of a video frame sequentially at a time, referred to as the read-out time ($T_{ro}$) which is a camera-specific parameter. This parameter can be exploited for camera forensic applications. In this paper, we present an approach that exploits the ENF and the $T_{ro}$ to identify the source camera of an ENF-containing video of unknown source. The suggested approach considers a practical scenario where a video obtained from the public, including social media, is investigated by law enforcement to ascertain if it originated from a suspect’s camera. Our experimental results demonstrate the effectiveness of our approach. Full article

This paper presents a rolling shutter orthogonal frequency-division multiplexing (RS-OFDM) optical camera communication higher rate longer range proposed in IEEE 802.15.7a Task Group (TG7a) using an image sensor as a receiver. OFDM is a digital multi-carrier modulation scheme deployed for broadband wireless communication to resolve the inter-symbol interference (ISI) effect caused by the multipath channel. In optical wireless communication systems, OFDM was applied widely for indoor applications: internet of things, e-health, vehicular, and localization systems. The mobility scenario is a big problem for OWC systems, which reduces the system performance due to the optical channel variation in the processing time. In addition to that, signal detection should be considered in the mobility environment to improve the signal-to-noise ratio of OWC systems. In this paper, we proposed the convolution neural network (CNN) for LED detection in the RS-OFDM system, considering the mobility effect. In addition to that, the deep neural network was applied to detect the start of OFDM frame instead of conventional technology (Van De Beek algorithm). By applying our approach, the RS-OFDM system can achieve long communication (18 m distance) with a low error rate in the 2 m/s velocity environment. Full article

Light emitting diodes (LED) are becoming the dominant lighting elements due to their efficiency. Optical camera communications (OCC), the branch of visible light communications (VLC) that uses video cameras as receivers, is a suitable candidate in facilitating the development of new communication solutions for the broader public because video cameras are available on almost any smartphone nowadays. Unfortunately, most OCC systems that have been proposed until now require either expensive and specialized high-frame-rate cameras as receivers, which are unavailable on smartphones, or they rely on the rolling shutter effect, being sensitive to camera movement and pointing direction, they produce light flicker when low-frame-rate cameras are used, or they must discern between more than two light intensity values, affecting the robustness of the decoding process. This paper presents in detail the design of an OCC system that overcomes these limitations, being designed for receivers capturing 120 frames per second and being easily adaptable for any other frame rate. The system does not rely on the rolling shutter effect, thus making it insensitive to camera movement during frame acquisition and less demanding about camera resolution. It can work with reflected light, requiring neither a direct line of sight to the light source nor high resolution image sensors. The proposed communication is invariant to the moment when the transmitter and the receiver are started as the communication is self-synchronized, without any other exchange of information between the transmitter and the receiver, without producing light flicker, and requires only two levels of brightness to be detected (light on and light off). The proposed system overcomes the challenge of not producing light flicker even when it is adapted to work with very low-frame-rate receivers. This paper presents the statistical analysis of the communication performance and discusses its implementation in an indoor localization system. Full article
