Rotated clinching is a novel cold plastic deformation joining process, which is suitable for the multi-point simultaneous joining of sheet metals. However, the effect of various parameters on the mechanical properties of joints using rotated clinching remains unclear. The purpose of this study is to analyse the important parameters that affect the joint’s shearing strength and relationship between them. The relational expression between the four process parameters (die depth, rotation angle, small fillet radius and large fillet radius) and joint shearing strength was established using the response surface method. Additionally, the quantitative relationship between them was expressed by this relational expression, and the significance of process parameters were evaluated using the analysis of variance. The results revealed that the most significant parameter regarding the shearing strength was die depth h, with the contribution of 47.1%, followed by rotation angle α and small fillet radius r₁, with the contributions of 26.8% and 8.2%, respectively, whereas the large fillet radius R₁ is the least significant, there is a significant interaction effect between R₁ and α, with the contribution of 5.4%. The shearing strength had a negative relationship with the die depth h and small fillet r₁, whereas it had a positive relationship with rotation angle α. The predicted maximum value of the shearing strength was 1231.92 N at h = 2.29 mm, r₁ = 0.46 mm, R₁ = 1.27 mm and α = 18.45° in the range of given design parameter values. The experimental values of the shearing strength comprised approximately 74% of the predicted values. Full article

The clinching process is widely used in joining lightweight sheet metal. We proposed a novel rotated clinching process (RCP), which is characterized by a flat bottom die structure and twin rotating punches. The aim of this study was to evaluate the strength of RCP joints. Al1060 sheets with thicknesses of 1.5 mm and 2 mm were used as the experimental materials. Overlap and T-lap RCP joints with three die depths and five bottom thicknesses were fabricated, and shear and peel tests were performed on the joints. The joint strengths were evaluated based on the mechanical load, cross-sectional profile dimensions, and failure mode. The results showed that the mechanical load is a direct, reliable, and quantitative evaluation criterion, while the cross-sectional profile and failure mode are indirect and qualitative. These criteria confirmed that the strength of thick sheet joints is higher than that of thin sheet joints, the shear strength is superior to the peel strength, and the strengths of the joints are high with failure mainly occurring due to tearing or shear failure. Finally, the key parameters for determining the strength of a joint include the bottom thickness/sheet thickness ratio (R_t), and the die depth (h). Full article
